Skil Spare Parts for Angle Grinder 9145

SKU: Skil 9145 - F015914501
€7.93
VAT included

Skil Spare Parts for Angle Grinder 9145

Skil genuine spare parts or replacement parts for to fix Angle Grinder 9145 - F015914501.

Angle Grinder 9145 - F015914501

Skil Spare Parts for Angle Grinder 9145
  • Skil Spare Parts for Angle Grinder 9145
  • Skil Spare Parts for Angle Grinder 9145
SKIL B.V

Skil Spare Parts for Angle Grinder 9145

SKU: Skil 9145 - F015914501 Condition: New
€7.93
VAT included

Skil Spare Parts for Angle Grinder 9145

Skil genuine spare parts or replacement parts for to fix Angle Grinder 9145 - F015914501.

Angle Grinder 9145 - F015914501

settings 36 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10/15 Business Days Approx

SHIPPING IN: ON DEMAND ONLY
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
Machine Type: Grinder
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
36 spare parts
Page 1 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 2609000006 Housing Section €0.12 Not available for order
2
 photo_cameraImage coming soon 2609000764 Field 220-230V €21.90
3/9
 photo_cameraImage coming soon 2609000021 Fan €0.12 Not available for order
4
 photo_cameraImage coming soon 2609000051 Switch €0.12 Not available for order
5
 photo_cameraImage coming soon 2609000117 Power supply cord 1,75m 2 x 0,75mm H05VV-F €0.12 Not available for order
6
 Power Cord Grommet Ø6,5-Ø6,9x95 MM for Power Tools Bosch 2600703012 Power Cord Grommet Ø6,5-Ø6,9x95 MM for Power Tools Bosch €2.38
16
 photo_cameraImage coming soon 2609000144 Brush Holder €0.12 Not available for order
19
 Torx Oval-Head Screw T20-8x19 mm for Circular Saw Skil 5750 2610374919 Torx Oval-Head Screw T20-8x19 mm for Circular Saw Skil 5750 €1.05
21
 photo_cameraImage coming soon 2609000036 Switch-Pawl €0.12 Not available for order
22
 photo_cameraImage coming soon 2609001153 Switch Button €0.12 Not available for order
25
 photo_cameraImage coming soon 2609000034 Switch Spring €0.12 Not available for order
30
 photo_cameraImage coming soon 2609000116 Pinion €3.60
31
 Crown Gear for Angle Grinder Bosch PWS 700-115 1606333624 Crown Gear for Angle Grinder Bosch PWS 700-115 €13.36
32
 Spindle Shaft M 14 for Angle Grinders Bosch GWS 6-115 1603523110 Spindle Shaft M 14 for Angle Grinders Bosch GWS 6-115 €12.14
33
 photo_cameraImage coming soon 2609001705 Shim €0.12 Not available for order
34
 photo_cameraImage coming soon 2609001706 Shim €0.12 Not available for order
35
 Pin Push Button for Angle Grinder Skil 9145 - 9240 2609000040 Pin Push Button for Angle Grinder Skil 9145 - 9240 €1.04
36
 photo_cameraImage coming soon 2609000043 Spring €0.12 Not available for order
37
 photo_cameraImage coming soon 2609000044 Bolt €0.12 Not available for order
40
 photo_cameraImage coming soon 2600917003 Needle bearing Ø8x8 MM €2.38
41
 Ball Bearing 608-2Z/C3 for Percussion Drill Bosch PSB 500 RE 3130900020 Ball Bearing 608-2Z/C3 for Percussion Drill Bosch PSB 500 RE €6.04
42
 photo_cameraImage coming soon 2609000041 Bearing Block €0.12 Not available for order
43
 photo_cameraImage coming soon 2609001630 Deep-Groove Ball Bearing €5.60
45
 photo_cameraImage coming soon 2609000047 Protective Cover €0.12 Not available for order
46
 Lock Spring for Angle Grinders Skil 9145 - 9240 2609000049 Lock Spring for Angle Grinders Skil 9145 - 9240 €1.04
47
 photo_cameraImage coming soon 2609000050 Washer €0.12 Not available for order
680/001
 photo_cameraImage coming soon 2609000079 Auxiliary Handle €0.12 Not available for order
680/003
 photo_cameraImage coming soon 2609000289 Hex Screw €0.12 Not available for order
681
 Upper Flange M14 for Angle Grinder Bosch GWS 6-115-GWS 660 1603345043 Upper Flange M14 for Angle Grinder Bosch GWS 6-115-GWS 660 €9.70
682
 photo_cameraImage coming soon 2610392429 Driving Flange €0.12 Not available for order
683
 photo_cameraImage coming soon 1607950060 Pin-Type Face-Wrench €7.26
684
 photo_cameraImage coming soon 2607950511 Single-Head Eng. Wrench SW17 €3.60
803
 photo_cameraImage coming soon 2609000245 Armature 230V €0.12 Not available for order
810
 Carbon Brush Se for Angle Grinders Skil 9145 - 9240 2609000246 Carbon Brush Se for Angle Grinders Skil 9145 - 9240 €8.56
832
 photo_cameraImage coming soon 2609000248 Grinding Spindle €0.12 Not available for order
846
 photo_cameraImage coming soon 2609000249 Locking Unit €0.12 Not available for order

Shipping and delivery information will be available shortly.

Skil Spare Parts for Angle Grinder 9145

Skil genuine spare parts or replacement parts for to fix Angle Grinder 9145 - F015914501.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Angle Grinder 9145 - F015914501

Angle Grinder 9145/F 015 914 501
# Part Num. Description
1 2609000006 Housing Section
2 2609000764 Field 220-230V
3/9 2609000021 Fan
4 2609000051 Switch
5 2609000117 Power supply cord 1,75m 2 x 0,75mm H05VV-F
6 2600703012 Grommet Ø6,5-Ø6,9x95 MM
16 2609000144 Brush Holder
19 2610374919 Torx Oval-Head Screw T20-8x19 MM
21 2609000036 Switch-Pawl
22 2609001153 Switch Button
25 2609000034 Switch Spring
30 2609000116 Pinion
31 1606333624 Crown Gear
32 1603523110 Grinding Spindle M14, SW17
33 2609001705 Shim
34 2609001706 Shim
35 2609000040 Push-Button
36 2609000043 Spring
37 2609000044 Bolt
40 2600917003 Needle bearing Ø8x8 MM
41 3130900020 Deep-Groove Ball Bearing 8x22x7 608-2Z/C3
42 2609000041 Bearing Block
43 2609001630 Deep-Groove Ball Bearing
45 2609000047 Protective Cover
46 2609000049 Lock Spring
47 2609000050 Washer
680/001 2609000079 Auxiliary Handle
680/003 2609000289 Hex Screw
681 1603345043 Round Nut M14
682 2610392429 Driving Flange
683 1607950060 Pin-Type Face-Wrench
684 2607950511 Single-Head Eng. Wrench SW17
803 2609000245 Armature 230V
810 2609000246 Carbon-Brush Set
832 2609000248 Grinding Spindle
846 2609000249 Locking Unit
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Skil 9145 - F015914501
12 Items

Data sheet

SHIPPING IN
ON DEMAND ONLY
CHECK ITEM CODE OR S/N
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
Machine Type
Grinder

Specific References

New

Download

Diagram Skil 9145

Diagram Skil 9145

Download (70.63KB)
