Ryobi RAC121 Full Trimmer Head 1.5 mm

Product Details

- Model: RAC121
- Type: String trimmer head
- Product Code: 5132002593
- EAN Code: 4892210817693

Technical Specifications

- Line Diameter: 1.5 mm
- Compatibility: Specifically designed for Ryobi RBC1020 and RBC1226i models.

Note: Always ensure the line diameter is compatible with the head before reloading to prevent jamming during use.

1. Preparation and Safety
- Disconnect Power: Remove the battery or unplug the cable from the power outlet.
- Cleaning: Ensure the drive shaft is free of grass clippings or dirt.

2. Removing the Old Head
- Lock the Shaft: Insert an Allen key or the locking pin into the hole on the upper flange (above the head) to prevent the shaft from spinning.
- Unscrew: Rotate the old head clockwise (Note: the thread is reversed, so it unscrews "backwards").

3. Installing the RAC121
- Positioning: Place the new RAC121 head onto the threaded shaft.
- Tightening: Keep the shaft locked with the pin and rotate the head counter-clockwise until it is secure.

Note: Do not overtighten; the motor's natural rotation during use will keep it firmly in place.

4. Loading the Line (if empty)
- If you need to insert 1.5 mm line:
- Align the Arrows: Rotate the top knob until the arrows point toward the side eyelets (line exits).
- Insert and Wind: Feed the line through one eyelet and out the other until you have equal lengths on both sides, then rotate the knob to wind it inside.

Reminder: Always use 1.5 mm line only. A thicker line could strain the motor or fail to feed correctly through the head.
