Mountfield Spare Parts for Lawn Mower EL 4800 HP
€0.12
VAT included
Mountfield Spare Parts for Lawn Mower EL 4800 HP
We are Distributors of Original MOUNTFIELD Spare Parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on purchasing the most suitable spare part to quickly resolve any maintenance and repair issue for the Lawn Mower EL 4800 HP/299480663/MTF.
Mountfield Spare Parts for Lawn Mower EL 4800 HP
€0.12
VAT included
Mountfield Spare Parts for Lawn Mower EL 4800 HP
We are Distributors of Original MOUNTFIELD Spare Parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on purchasing the most suitable spare part to quickly resolve any maintenance and repair issue for the Lawn Mower EL 4800 HP/299480663/MTF.
settings
95 Spare parts
description
8 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
95 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 2
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 3
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 4
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 5
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 6
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 7
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 8
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Shipping and delivery information will be available shortly.
Mountfield Spare Parts for Lawn Mower EL 4800 HP
We are Distributors of original MOUNTFIELD spare parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on purchasing the most suitable spare part to quickly resolve any maintenance and repair problem of the Lawn Mower EL 4800 HP/299480663/MTF.
| Lawn Mower EL 4800 HP/299480663/MTF | ||
|---|---|---|
| Chassis And Height Adjustment Pag.1 | ||
| # | Part Num. | Description |
| 1 | 381004536/0 | Red Deck |
| 2 | 122534131/0 | Pin |
| 3 | 381003398/0 | Height Adjustment Lever |
| 3 | 381003399/0 | Height Adjustment Lever |
| 4 | 112154510/0 | Self-locking Nut M6 |
| 5 | 112788512/0 | Screw |
| 6 | 322394503/0 | Knob |
| 7 | 112521310/0 | Washer |
| 8 | 112150000/0 | Nut |
| 9 | 112728450/0 | Screw |
| 10 | 322034002/0 | Washing Connection |
| 11 | 322735593/0 | Height Adjustment Sector |
| 12 | 122171002/0 | Spacer |
| 13 | 112789000/0 | Screw |
| 14 | 381003351/0 | Wheels Adjustment Lever |
| 14 | 381003452/0 | Wheels Adjustment Lever |
| 15 | 112154330/0 | Nut |
| 16 | 112727803/0 | Screw |
| 17 | 381302803/1 | Front Wheels Axle |
| 18 | 112154510/0 | Self-locking Nut M6 |
| 19 | 119035000/0 | O-Ring |
| 20 | 322394522/0 | Knob |
| 21 | 322600145/0 | Wheel Protection |
| 22 | 322820077/1 | Cap |
| 24 | 112521350/0 | Washer |
| 25 | 112155000/0 | Self-locking Nut M8 |
| 27 | 322600194/0 | Wheel Protection |
| 31 | 381302833/0 | Rear Wheels Axle |
| 32 | 122450460/0 | Spring |
| 33 | 112728697/0 | Screw - Self-tapping Torx PT K50x16 |
| 34 | 322545152/0 | Plate |
| 35 | 112728697/0 | Screw - Self-tapping Torx PT K50x16 |
| 36 | 322785304/1 | Support |
| 40 | 122446192/0 | Spring |
| Belt Protection Pag.2 | ||
| # | Part Num. | Description |
| 1 | 322291150/0 | Rubber Insert |
| 2 | 122060192/0 | Belt Protection |
| 3 | 112728530/0 | Screw |
| 3 | 112728531/0 | Screw |
| 4 | 322500102/0 | Front Comb |
| 5 | 112523000/1 | Washer |
| 6 | 112728124/0 | Screw - TCB Torx Self-tapping 4.2x16 |
| Handle, Lower Part Pag.3 | ||
| # | Part Num. | Description |
| 1 | 381006735/0 | Handle, Lower Part Black |
| 2 | 381005133/0 | Right Bracket |
| 3 | 381005135/0 | Left Bracket |
| 4 | 112819110/0 | Screw |
| 5 | 122680006/1 | Washer |
| 6 | 322399804/1 | Black Knob |
| 7 | 112293200/0 | Nut |
| 8 | 112819110/0 | Screw |
| 10 | 112760605/0 | Screw |
| 10 | 112793701/0 | Screw - TE M8x30 |
| 11 | 122192000/1 | Cable Clamp |
| 14 | 112521350/0 | Washer |
| 15 | 112154510/0 | Self-locking Nut M6 |
| 16 | 322551582/0 | Insulating Plate |
| 17 | 381008689/0 | Screws Outfit |
| Handle, Upper Part Pag.4 | ||
| # | Part Num. | Description |
| CE | 381600547/2 | Motor Switch CE |
| 1 | 381007017/2 | Handle, Upper Part Black |
| 2 | 122192000/1 | Cable Clamp |
| 3 | 381600547/2 | Motor Switch CE |
| 4 | 112728701/0 | Screw |
| 7 | 322230350/2 | Fulcrum |
| 8 | 122450115/0 | Spring |
| 9 | 322785144/1 | Support |
| 10 | 322322881/2 | Black Motor Brake Lever |
| Electric Motor/Blade Pag.5 | ||
| # | Part Num. | Description |
| 1 | 122055045/1 | Black Cover |
| 2 | 322785210/1 | Cover Support |
| 3 | 112728710/0 | Screw |
| 4 | 118563720/0 | Electric Motor 1800W |
| 6 | 118222045/0 | Capacitor 16 µf |
| 7 | 112735410/0 | Screw |
| 8 | 112583500/0 | Grower - M8 |
| 9 | 112293200/0 | Nut |
| 10 | 322207211/4 | Motor Flange |
| 11 | 322720360/2 | Screen |
| 12 | 112793701/0 | Screw - TE M8x30 |
| 13 | 112139440/0 | Key |
| 14 | 112728680/0 | Screw |
| 15 | 322463186/3 | Blade Hub |
| 16 | 181004397/0 | Winged Blade |
| 16 | 181004460/0 | Mulching Blade |
| 17 | 112540060/0 | Washer |
| 18 | 112793102/0 | Screw - TE M8x20 |
| 19 | 381004352/1 | Screw |
| Wheels and Hub Caps Pag.6 | ||
| # | Part Num. | Description |
| 1 | 119216035/0 | Bearing |
| 2 | 381007416/0 | Wheel Ø 200 |
| 2 | 381007416/1 | Wheel Ø 200 |
| 2 | 381007416/2 | Wheel Ø 200 |
| 3 | 322110382/0 | Grey Hub Cap |
| 4 | 322120114/0 | Driving Ring |
| 5 | 112728706/0 | Screw - Self-tapping Torx PT K40x16 |
| 6 | 112521350/0 | Washer |
| 7 | 112155000/0 | Self-locking Nut M8 |
| 7 | 112293203/0 | Flanged Nut |
| Grass-Catcher Pag.7 | ||
| # | Part Num. | Description |
| 1 | 381008081/2 | Stone Guard Black |
| 2 | 122450466/0 | Left Spring |
| 3 | 122517882/0 | Pin |
| 4 | 122450465/0 | Right Spring |
| 5 | 112604899/0 | Crown Fastener |
| 6 | 381486013/0 | Grass-Box, Upper Part |
| 7 | 122608525/2 | Lower Reinforcement |
| 8 | 181002211/0 | Grass-Catcher, Cloth |
| 8 | 181102332/0 | Grass-Catcher, Cloth |
| 9 | 112728680/0 | Screw |
| 10 | 112523050/0 | Washer |
| Adapter Cable UK Pag.8 | ||
| # | Part Num. | Description |
| 1 | 118804849/0 | Adapter Cable UK |
| 1 | 1911-9291-01 | Power Cable 15m, CE-UK Adapter |
All technical product information in this catalog is based on information taken from official sources, including the manufacturer websites Mountfield, which we consider reliable. Unfortunately, even official documents may contain errors or misprints - we are unable to confirm that all of this data is accurate and truly represents the facts. Most manufacturers reserve the right to modify product specifications or supplement descriptions without prior notice. We strongly recommend using the published information as basic information subject to review by the Mountfield brand. Please clarify important parameters with a sales assistant at the time of purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or reproduction (total or partial) without a reference to the source page is prohibited.
299480663/MTF-2021
