August Summer Clousure
Metabo

Metabo Spare Parts for Orbital Sander FSR 200 Intec

SKU: FSR 200 Intec - 00066000
€1.64
VAT included

Metabo Spare Parts for Orbital Sander FSR 200 Intec

We have the original Spares for Orbital Sander FSR 200 Intec - 00066000, the diagram, parts list and tool repair that help you need to get your tools running like new again.

FSR 200 Intec - 00066000

Metabo Spare Parts for Orbital Sander FSR 200 Intec
  • Metabo Spare Parts for Orbital Sander FSR 200 Intec
  • Metabo Spare Parts for Orbital Sander FSR 200 Intec
Metabo

Metabo Spare Parts for Orbital Sander FSR 200 Intec

SKU: FSR 200 Intec - 00066000 Condition: New
€1.64
VAT included

Metabo Spare Parts for Orbital Sander FSR 200 Intec

We have the original Spares for Orbital Sander FSR 200 Intec - 00066000, the diagram, parts list and tool repair that help you need to get your tools running like new again.

FSR 200 Intec - 00066000

settings 37 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
Machine Type: Sander
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
37 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Power Cord for Angle Grinder Metabo W 7-115 34448588 Power Cord for Angle Grinder Metabo W 7-115 €19.80
2
 photo_cameraImage coming soon 34410114 Cable sleeve €2.55
3
 photo_cameraImage coming soon 14112345 Fillister head screw €1.56
4
 photo_cameraImage coming soon 34339297 Cable clip €1.56
5
 photo_cameraImage coming soon 34305014 Terminal rail €1.74
6
 photo_cameraImage coming soon 31101058 Field coil assembly w.field coil,230V €18.67
7
 photo_cameraImage coming soon 34449686 Strand set condensor €2.48
8
 photo_cameraImage coming soon 34340838 Switch €3.20
9
 photo_cameraImage coming soon 34339267 Housing Cover €24.54
12
 photo_cameraImage coming soon 34407088 Felt seal €1.56
13
 photo_cameraImage coming soon 34409769 Swivel pin €1.56
14
 photo_cameraImage coming soon 14112344 Fill. head screw €1.50
15
 photo_cameraImage coming soon 31604071 Clamp cpl. €1.70
16
 photo_cameraImage coming soon 14115630 Washer €1.56
17
 photo_cameraImage coming soon 14311144 Ball bearing, 12x28x8 €23.75
18
 photo_cameraImage coming soon 14118036 Retaining ring €1.74
19
 photo_cameraImage coming soon 33900695 Washer €1.56
20
 photo_cameraImage coming soon 14111218 Countersunk screw €1.56
21
 Base Plate for Orbital Sander Metabo FSR 200 Intec 33916073 Base Plate for Orbital Sander Metabo FSR 200 Intec €24.00
22
 photo_cameraImage coming soon 14115041 Serrated lock washer €1.77
23
 photo_cameraImage coming soon 14111322 Fillister head screw €1.75
24
 photo_cameraImage coming soon 34339282 Hole punch €1.70
25
 Base Plate Holder for Orbital Sander Metabo FSR 200 Intec 31541615 Base Plate Holder for Orbital Sander Metabo FSR 200 Intec €13.43
26
 photo_cameraImage coming soon 14112343 Fillister head screw €1.57
28
 photo_cameraImage coming soon 34409768 Rubber plug €3.20
29
 photo_cameraImage coming soon 31604070 Brush holder complete €1.56
30
 Carbon brush set 31604069 Carbon brush set €9.90
31
 Ball Bearing 6x19x6 mm for Angle Grinders Metabo W 7-8-9-115 14311517 Ball Bearing 6x19x6 mm for Angle Grinders Metabo W 7-8-9-115 €7.95
32
 photo_cameraImage coming soon 14115629 Washer €1.57
33
 Metabo FSR 200 Intec Armature 230V 31000899 Metabo FSR 200 Intec Armature 230V €26.46
34
 photo_cameraImage coming soon 34409764 Switch guard €1.56
35
 photo_cameraImage coming soon 14115107 Washer €1.74
36
 photo_cameraImage coming soon 14311499 Ball bearing, 9x26x8 €14.39
37
 photo_cameraImage coming soon 33000175 Fan €8.79
38
 photo_cameraImage coming soon 34339270 Baffle €2.29
39
 photo_cameraImage coming soon 14111990 Self-tapp. fill. h. screw €1.65
40
 photo_cameraImage coming soon 34409788 Rubber packing €1.56

Shipping and delivery information will be available shortly.

Metabo Spare Parts for Orbital Sander FSR 200 Intec

Fix Your Orbital Sander FSR 200 Intec - 00066000. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Sander and the respective parts of the code.
FSR 200 Intec - 00066000

Orbital Sander FSR 200 Intec/00066000
# Part Num. Description
1 34448588 Cable with plug
2 34410114 Cable sleeve
3 14112345 Fillister head screw
4 34339297 Cable clip
5 34305014 Terminal rail
6 31101058 Field coil assembly w.field coil,230V
7 34449686 Strand set condensor
8 34340838 Switch
9 34339267 Housing Cover
10 33812050 Metabo label,FSR 200 Intec
12 34407088 Felt seal
13 34409769 Swivel pin
14 14112344 Fill. head screw
15 31604071 Clamp cpl.
16 14115630 Washer
17 14311144 Ball bearing, 12x28x8
18 14118036 Retaining ring
19 33900695 Washer
20 14111218 Countersunk screw
21 33916073 Sanding base plate compl.
22 14115041 Serrated lock washer
23 14111322 Fillister head screw
24 34339282 Hole punch
25 31541615 Oscillating plate compl.
26 14112343 Fillister head screw
27 33804762 Rating plate
28 34409768 Rubber plug
29 31604070 Brush holder complete
30 31604069 Carbon brush set
31 14311517 Ball bearing,6x19x6
32 14115629 Washer
33 31000899 Armature cpl. 230 V
34 34409764 Switch guard
35 14115107 Washer
36 14311499 Ball bearing, 9x26x8
37 33000175 Fan
38 34339270 Baffle
39 14111990 Self-tapp. fill. h. screw
40 34409788 Rubber packing
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
FSR 200 Intec - 00066000
6 Items

Data sheet

Machine Type
Sander
SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:
METABO S/N START WITH ( 0 ) and have 8 DIGITS

Specific References

New

Download

Diagram Metabo FSR 200 Intec

Diagram Metabo FSR 200 Intec

Download (892.08KB)
