Maruyama Brushcutter MX24E Parts
Fix Your Brushcutter Maruyama MX24E. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Maruyama Brushcutter MX24E Parts |
| Main Body Pag.1 |
| # |
Part Num. |
Description |
| 1-1 |
366117 |
MX24E |
| 1-2 |
227923 |
Driveshaft Ass'y |
| 1-3 |
560386 |
Driveshaft Tube |
| 1-4 |
012382 |
Snap Ring |
| 1-5 |
560427 |
Throttle Trigger |
| 1-6 |
215533 |
Hanging Bracket Ass'y Incl.7 |
| 1-7 |
261762 |
Cap Screw |
| 1-8 |
560409 |
Bracket Ass'y Incl.9-11 |
| 1-9 |
560410 |
Bracket |
| 1-10 |
271437 |
Screw |
| 1-11 |
231704 |
Washer |
| 1-12 |
560240 |
Label |
| 1-13 |
560411 |
Label |
| 1-14 |
560246 |
Label |
| 1-15 |
215501 |
Label |
| 1-16 |
560229 |
Hanging Strap Ass'y |
| 1-17 |
560282 |
Hook |
| 1-18 |
560316 |
Loop Handle Ass'y Incl.19-22 |
| 1-19 |
222520 |
Loop Handle |
| 1-20 |
213171 |
Packing |
| 1-21 |
215608 |
Cap Screw |
| 1-22 |
081027 |
Nut |
| 1-23 |
560420 |
Safety Cover |
| 1-24 |
234999 |
Cover Extension |
| 1-25 |
230747 |
String Cutter |
| 1-26 |
232689 |
Screw |
| Gearcase Pag.2 |
| 2-1 |
241689 |
Gearcase Ass'y Incl.2-15 |
| 2-2 |
226284 |
Gearcase |
| 2-3 |
225897 |
Bolt |
| 2-4 |
226285 |
Bearing |
| 2-5 |
227108 |
Gear Set |
| 2-6 |
112184 |
Bearing |
| 2-7 |
054676 |
Snap Ring |
| 2-8 |
225898 |
Collar |
| 2-9 |
226286 |
Bearing |
| 2-10 |
228477 |
Snap Ring |
| 2-11 |
140270 |
Snap Ring |
| 2-12 |
261246 |
Cap Screw |
| 2-13 |
225891 |
Boss Adapter |
| 2-14 |
225892 |
Blade Boss B |
| 2-15 |
225893 |
Nut |
| 2-16 |
261233 |
Cap Screw |
| Engine Pag.3 |
| 3-1 |
875276 |
Engine |
| 3-2 |
289639 |
Cylinder |
| 3-3 |
289643 |
Gasket |
| 3-4 |
267290 |
Cap Screw |
| 3-5 |
272744 |
Insulator New gasket required |
| 3-6 |
267049 |
Gasket |
| 3-7 |
269826 |
Screw |
| 3-8 |
278096 |
Muffler Comp |
| 3-9 |
266402 |
Cap Screw |
| 3-10 |
273262 |
Gasket |
| 3-11 |
276868 |
Under Cover |
| 3-12 |
269827 |
Screw |
| 3-13 |
563533 |
Top Cover Comp |
| 3-14 |
563608 |
Label |
| 3-15 |
246082 |
Screw |
| 3-16 |
273674 |
Crankcase |
| 3-17 |
280488 |
Bearing |
| 3-18 |
261492 |
Oil Seal |
| 3-19 |
261386 |
Oil Seal |
| 3-20 |
055185 |
Snap Ring |
| 3-21 |
261612 |
Cap Screw |
| 3-22 |
272204 |
Piston |
| 3-23 |
264891 |
Piston Ring |
| 3-24 |
261036 |
Piston Pin |
| 3-25 |
288520 |
Bearing, Needle |
| 3-26 |
261576 |
Clip,Piston |
| 3-27 |
274146 |
Crankshaft/Conn.Rod Ass'y |
| 3-28 |
280375 |
Clutch Ass'y Incl.29,30 |
| 3-29 |
280407 |
Clutch Shoe |
| 3-30 |
264889 |
Spring,Clutch |
| 3-31 |
264505 |
Bolt |
| 3-32 |
261777 |
Wave Washer |
| 3-33 |
261189 |
Washer |
| 3-34 |
563556 |
Fan Cover Ass'y Incl.35-37 |
| 3-35 |
563557 |
Fan Cover Comp Incl.36,37 |
| 3-36 |
269124 |
Bearing |
| 3-37 |
013825 |
Snap Ring |
| 3-38 |
289727 |
Clutch Drum |
| 3-39 |
563065 |
Snap Ring |
| 3-40 |
269831 |
Screw |
| 3-41 |
246081 |
Screw |
| 3-42 |
563535 |
Magneto Ass'y |
| 3-43 |
277797 |
Rotor/Fan Incl.43-49 |
| 3-44 |
277798 |
Ignition Coil Ass'y Incl.45-49 |
| 3-45 |
279577 |
Spark Plug Wire Ass'y Incl.46,47 |
| 3-46 |
278755 |
Plug Cap |
| 3-47 |
278756 |
Connector |
| 3-48 |
278754 |
Insulator |
| 3-49 |
278752 |
Cap |
| 3-50 |
261076 |
Woodruff Key |
| 3-51 |
261417 |
Nut,Rotor |
| 3-52 |
280381 |
Spacer |
| 3-53 |
261256 |
Cap Screw |
| 3-54 |
288264 |
Spark Plug |
| 3-55 |
263804 |
Lead |
| 3-56 |
284541 |
Wire,Lead |
| 3-57 |
246078 |
Grommet |
| 3-58 |
563192 |
Label |
| Recoil Starter Pag.4 |
| 4-1 |
563307 |
Recoil Starter Ass'y Incl.2-14 |
| 4-2 |
273093 |
Recoil Ass'y Incl.3-13 |
| 4-3 |
280492 |
Reel |
| 4-4 |
287421 |
Spiral Spring |
| 4-5 |
280494 |
Screw |
| 4-6 |
280495 |
Starter Rope Ass'y Incl.7-9 |
| 4-7 |
283616 |
Starter Rope |
| 4-8 |
280497 |
Starter Grip |
| 4-9 |
280550 |
Stopper |
| 4-10 |
280547 |
Washer |
| 4-11 |
280548 |
Collar |
| 4-12 |
269423 |
Nut |
| 4-13 |
288500 |
Plate |
| 4-14 |
287399 |
Stater Pulley Ass'y |
| 4-15 |
269833 |
Screw |
| 4-16 |
280489 |
Screw |
| 4-17 |
563532 |
Label |
| Carburetor - Fuel Tank Pag.5 |
| 5-1 |
276663 |
Carburetor Ass'y Incl.2-15 New gasket required |
| 5-2 |
274472 |
Pump Body |
| 5-3 |
262991 |
Purge Body |
| 5-4 |
262992 |
Cover Plate |
| 5-5 |
261874 |
Primer Bulb |
| 5-6 |
283905 |
Diaphragm, Meterring |
| 5-7 |
262993 |
Gasket |
| 5-8 |
262994 |
Diaphragm,Fuel Pump |
| 5-9 |
282576 |
Gasket |
| 5-10 |
289396 |
Main Jet |
| 5-11 |
261871 |
O-Ring |
| 5-12 |
261876 |
E-Ring |
| 5-13 |
261658 |
Swivel |
| 5-14 |
264682 |
Screw |
| 5-15 |
262996 |
Screw |
| 5-16 |
261864 |
Gasket |
| 5-17 |
264691 |
O-Ring |
| 5-18 |
563411 |
Cleaner Ass'y |
| 5-19 |
277927 |
Case Body Ass'y |
| 5-20 |
266433 |
Housing |
| 5-21 |
264695 |
Filter |
| 5-22 |
277553 |
Cleaner Cover |
| 5-23 |
269834 |
Screw |
| 5-24 |
280020 |
Swivel Ring |
| 5-25 |
563261 |
Fuel Tank Ass'y |
| 5-26 |
563466 |
Fuel Tank |
| 5-27 |
275306 |
Fuel Tank Cap Ass'y |
| 5-28 |
274875 |
Gasket |
| 5-29 |
563262 |
Breather Ass'y |
| 5-30 |
563232 |
Fuel Pipe Pick-up Ass'y |
| 5-31 |
563233 |
Fuel Pipe Ass'y |
| 5-32 |
288192 |
Grommet |
| 5-33 |
261690 |
Fuel Pipe |
| 5-34 |
288194 |
Return Pipe |
| 5-35 |
264653 |
Filter Ass'y |
| 5-36 |
563014 |
Clip |
| 5-37 |
269828 |
Screw |
| 5-38 |
281208 |
Screw |
| 5-39 |
563014 |
Clip |
| Accessories Pag.6 |
| 6-1 |
210418 |
Box Spanner |
| 6-2 |
022865 |
Double-ended Wrench |
| 6-3 |
219431 |
Wrench |
| 6-4 |
219432 |
Wrench |
| 6-5 |
219433 |
Wrench |
| 6-6 |
231202 |
Semi-Auto Head (L) |
| 6-7 |
560349 |
Instruction Manual |
| 6-8 |
560403 |
Instruction Manual |
| 6-9 |
560404 |
Instruction Manual |
| 6-10 |
560405 |
Instruction Manual |
| 6-11 |
524714 |
Parts List |
| 6-12 |
560251 |
Colgate Tube |
| 6-13 |
685048 |
Band |
| Head Pag.7 |
|
231202 |
TRIMMER LINE HEAD |
| 1 |
242848 |
HOUSING |
| 2 |
242849 |
SPRING |
| 3 |
242850 |
BOBBIN |
| 4 |
242851 |
EYELET |
| 5 |
242852 |
COVER |
| 6 |
242853 |
TRIMMER LINE |
| 7 |
242854 |
INSTRUCTION MANUAL |
| 8 |
242855 |
LABEL |
