Makita Spare Parts for Lawn Mower ELM3711
MAKITA service center and
original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for
Lawn Mower ELM3711.
In the following table, look for the model of Lawn Mower and the respective parts of the code.

| Lawn Mower ELM3711 |
| 1 |
671001008 |
SCREW M10 FOR ELM3310-3710 |
| 2 |
671002549 |
BLADE EM370 |
| 3 |
671492001 |
FAN ELM3310-3710 |
| 4 |
671051300 |
BUSCH |
| 5 |
671005133 |
BLUE FRAME |
| 6 |
671003028 |
HUB COVER |
| 7 |
671919001 |
WHEEL D.140MM |
| 8 |
671002281 |
PLATE |
| 9 |
671107301 |
SCREW 4X16 |
| 10 |
671980001 |
FRONT |
| 11 |
671920001 |
WHEEL D.177MM |
| 12 |
671003029 |
REAR WHEEL COVER |
| 13 |
671002014 |
1300W ELM3710 ENGINE |
| 14 |
671001053 |
SCREW 6X30 ELM3310-3710 |
| 15 |
671983001 |
DEFLECTOR |
| 16 |
671982001 |
ENGINE COVER |
| 17 |
671984001 |
HANDLE |
| 18 |
671090005 |
PIN |
| 19 |
671010790 |
PIN 6X186.5 |
| 20 |
671011214 |
SPRING |
| 21 |
671987001 |
REAR COVER |
| 22 |
671001023 |
ELM3310 CABLE CLAMP |
| 23 |
671003060 |
CAPACITOR |
| 24 |
671001046 |
SCREW M8X19 PM5120-5120S |
| 25 |
671001712 |
LOWER HANDLE |
| 26 |
671277001 |
CABLE SUPPORT |
| 27 |
671284001 |
BUSH 2 ELM3310-3710 |
| 28 |
671005016 |
NUT M6 PLM4110-4610-4611 |
| 29 |
671007007 |
WASHER 8 ELM3310-3710 |
| 30 |
671001198 |
PLUG ELM3310-3710 |
| 31 |
671005136 |
REGULATOR |
| 32 |
671005136 |
REGULATOR |
| 33 |
671005136 |
REGULATOR |
| 34 |
671005136 |
REGULATOR |
| 35 |
671001083 |
CLAMP ELM3310-3710 |
| 36 |
671001003 |
SCREW 4X12 ELM3310-3710 |
| 37 |
671001052 |
SUPPORT FOR CABLE ELM 3310-3710 |
| 38 |
671425003 |
SECURITY KEY |
| 39 |
671011079 |
SPRING ELM3310-3710 |
| 40 |
DA00000819 |
RIGHT SWITCH BOX |
| 41 |
671001043 |
SCREEN ELM3310-3710 |
| 42 |
671010040 |
ELM3310-3710 SWITCH |
| 43 |
671069001 |
LH SWITCH BOX |
| 44 |
671077001 |
LH SWITCH BOX |
| 45 |
671283001 |
BUSH 1 ELM3310-3710 |
| 46 |
671001010 |
CABLE 1250MM ELM3310-3710 |
| 47 |
DA00001053 |
CABLE CLAMP |
| 48 |
DA00001131 |
POWER CABLE |
| 49 |
671428001 |
PLATE ELM3310-3710 |
| 50 |
671001036 |
SCREW 3X10 ELM3310-3710 |
| 51 |
671011124 |
SPRING EM3310-3710 |
| 52 |
671072001 |
DX CONNECTOR |
| 53 |
671001021 |
SCREW 4X10 |
| 54 |
671001714 |
ENGINE BRAKE LEVER |
| 55 |
671071001 |
LH CONNECTOR |
| 56 |
671016150 |
SUPERIOR HANDLE |
| 57 |
671073001 |
SUPPORT LH |
| 58 |
671074001 |
RH SUPPORT |
| 59 |
671002387 |
BAG FRAME |
| 61 |
671985001 |
COVER BAG |
| 62 |
671010720 |
LEVEL INDICATOR |
| 63 |
671988001 |
BAG HANDLE |
