FIAC spa

FIAC Spare Parts for Pump Unit VX 422

SKU: Fiac VX422
€562.05
VAT included

FIAC Spare Parts for Pump Unit VX 422

FIAC Air Compressors service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for direct driven lubricared pump unit VX 422 validity date - from 15/10/2008.

FIAC Spare Parts for Pump Unit VX 422
  • FIAC Spare Parts for Pump Unit VX 422
  • FIAC Spare Parts for Pump Unit VX 422
FIAC spa

FIAC Spare Parts for Pump Unit VX 422

SKU: Fiac VX422 Condition: New
€562.05
VAT included

FIAC Spare Parts for Pump Unit VX 422

FIAC Air Compressors service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for direct driven lubricared pump unit VX 422 validity date - from 15/10/2008.

settings 57 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
57 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Esploso pagina 2
Esploso pagina 3
1 / 3
Pos. Item Price Buy
1
 photo_cameraImage coming soon 7570090000 Head €29.39
2
 photo_cameraImage coming soon 7011220000 Screw M6X40 UNI-5737 €1.44
3
 Filter Plate for Pumping Uniti and Air Compressor Fiac 7458340000 Filter Plate for Pumping Uniti and Air Compressor Fiac €1.52
4
 Air Filter Element for Pumping Units Fiac VX - VS - GM 7210010000 Air Filter Element for Pumping Units Fiac VX - VS - GM €4.37
5
 photo_cameraImage coming soon 7012010000 Screw Ø3,9X19 UNI-6954 €1.48
6
 Air Cleaner Cover for Pump Units Fiac VX 254-304 7210180000 Air Cleaner Cover for Pump Units Fiac VX 254-304 €7.69
7
 Start Valve 2.2 BAR-G 1/4 for Pump Units Fiac VX - VS 7196000000 Start Valve 2.2 BAR-G 1/4 for Pump Units Fiac VX - VS €14.40
8
 Valves Plate Kit for Pump Unit Fiac VX 422 7459500000 Valves Plate Kit for Pump Unit Fiac VX 422 €30.01
9
 photo_cameraImage coming soon 7010120000 Screw M6X25 UNI-5931 €1.40
10
 photo_cameraImage coming soon 7575370000 Cylinder €61.52
11
 Fiac Stud M.8X35X14X16 7015020000 Fiac Stud M.8X35X14X16 €1.52
12
 Conrod for Pump Units FIAC GM-VX 5050150008 Conrod for Pump Units FIAC GM-VX €27.33
13
 photo_cameraImage coming soon 7220260000 Piston €24.91
14
 Piston Rings for Pumping Units FIAC VX 214-422-AB 525 4080230000 Piston Rings for Pumping Units FIAC VX 214-422-AB 525 €26.39
15
 Circlip for Pumping Units Fiac VX 194-VX 214 7041010000 Circlip for Pumping Units Fiac VX 194-VX 214 €1.52
16
 photo_cameraImage coming soon 7050210000 8X38 pin Ø12 €4.12
17
 Dipstick Level Oil for Pump Unit and Compressors Fiac GM-Vx-Colibrì 7181060000 Dipstick Level Oil for Pump Unit and Compressors Fiac GM-Vx-Colibrì €10.47
19
 photo_cameraImage coming soon 7011460000 Screw M6X16 TAP-TITE €1.48
20
 photo_cameraImage coming soon 7650010000 Crankcase cover €28.94
21
 Motor Carter Gasket for Pumping Units FIAC VX 7078440000 Motor Carter Gasket for Pumping Units FIAC VX €7.53
22
 photo_cameraImage coming soon 7237020000 Copper pipe €25.42
23
 photo_cameraImage coming soon 5041400008 Removable Crank €49.91
24
 photo_cameraImage coming soon 5070180008 Crankshaft housing €125.56
25
 photo_cameraImage coming soon 7090080000 Stopper M3 / 8 " €1.50
026A
 photo_cameraImage coming soon 4280820000 Rotor Kit €208.79
26
 photo_cameraImage coming soon 4280870000 Rotor Kit €171.31
27
 Capacitor 50 mf for Pump Units Fiac VX 304-402-422 7310410000 Capacitor 50 mf for Pump Units Fiac VX 304-402-422 €56.93
028A
 photo_cameraImage coming soon 7329870000 PR WIRE / MOTGMV25-30 3X1,5 + T PVC90CM €22.13
28
 photo_cameraImage coming soon 7329900000 Cable Pressure / Motor €15.66
29
 photo_cameraImage coming soon 7501050000 Cable locks €4.48
30
 photo_cameraImage coming soon 7501060000 Cable locks €1.52
31
 photo_cameraImage coming soon 7382340000 Terminal cover €4.34
031A
 photo_cameraImage coming soon 7382350000 COVER Morset MEC90 GMV-E TRIFAS €4.34
32
 photo_cameraImage coming soon 7012020000 Screw Ø3,9X12,7 DIN-7981 €1.52
33
 photo_cameraImage coming soon 7089950000 Collector €25.04
034A
 photo_cameraImage coming soon 7410460000 Prot. Thermal ETA-3120-F521-P7T1-W09D-6A €125.92
34
 photo_cameraImage coming soon 7410800000 Prot. Thermal 15 A €15.46
36
 Motor Fan for Pumping Unit Fiac VX-GM 7200020000 Motor Fan for Pumping Unit Fiac VX-GM €59.99
37
 photo_cameraImage coming soon 7038020000 Washer Ø8X30X3 UNI-6593 €1.52
38
 photo_cameraImage coming soon 7011090000 Screw M8x20 UNI-5739 €1.52
39
 FIAC Motor Cover for Series VS-VX 7150370000 FIAC Motor Cover for Series VS-VX €36.88
40
 photo_cameraImage coming soon 7031010000 Washer 8 UNI-3703 €1.52
41
 photo_cameraImage coming soon 7015100000 Guy M6X185 €1.44
42
 photo_cameraImage coming soon 7060030000 Bearing 6204 20-47-14 2RS1- €17.12
043B
 photo_cameraImage coming soon 4011030000 CARCASS GMVHP3 MOT V380 / 50 RPM2800 €624.74
43
 photo_cameraImage coming soon 4011390000 Stator €681.86
043A
 photo_cameraImage coming soon 4011420000 HOUSING MOT V240 GMV 30 / 50HZ S / TERMBLK €519.41
44
 Fiac VX214 Oil Seal 4062-10 SMIM 7071160000 Fiac VX214 Oil Seal 4062-10 SMIM €7.45
45
 photo_cameraImage coming soon 7060070000 Bearing 6007 €24.51
46
 photo_cameraImage coming soon 7078570000 Gasket €2.77
47
 photo_cameraImage coming soon 7020070000 Nut M8 UNI-5587 €1.48
50
 Fiac Pump Unit GM 143 Head Plate Gasket 7078580000 Fiac Pump Unit GM 143 Head Plate Gasket €4.34
51
 photo_cameraImage coming soon 7081100000 3/8 " €8.35
52
 FIAC Copper Pipe Right for Series VX 7237010000 FIAC Copper Pipe Right for Series VX €26.95
53
 photo_cameraImage coming soon 7310520000 BREAKER + 30MF.X2,5 SEC. + Lingueta €190.94
100
 Gasket kit for Pumping Units FIAC GM 110-191-201-243 4082010000 Gasket kit for Pumping Units FIAC GM 110-191-201-243 €18.27
101
 FIAC VX360 Conrod-Piston Kit 4191130000 FIAC VX360 Conrod-Piston Kit €62.35

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC Spare Parts for Pump Unit VX 422

FIAC Air Compressors service center and original spare parts Worldwide Distributor

. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for direct driven lubricared pump unit VX 422 validity date - from 15/10/2008.

In the following table , look for the model of the Pumping Unit and the respective parts of the code .
Fiac VX 422

VX 422 validity date - from 15/10/2008
# Part Num. Description
1 7570090000 Head
2 7011220000 Screw M6X40 UNI-5737
3 7458340000 Plate filter
4 7210010000 Filter element
5 7012010000 Screw Ø3,9X19 UNI-6954
6 7210180000 Air Cleaner Cover
7 7196000000 Start valve M1/​​4" 2.2 bar
8 7459500000 Kit valve plate
9 7010120000 Screw M6X25 UNI-5931
10 7575370000 Cylinder
11 7015020000 Stud M.8X35X14X16
12 5050150008 Connecting Rod
13 7220260000 Piston
14 4080230000 Piston Ring Kit
15 7041010000 Seeger Ø12
16 7050210000 8X38 pin Ø12
17 7181060000 Dipstick
18 7012180000 Screw M6X20 UNI-8112
19 7011460000 Screw M6X16 TAP-TITE
20 7650010000 Crankcase cover
21 7078440000 Gasket
22 7237020000 Copper pipe
23 5041400008 Removable Crank
24 5070180008 Sump
25 7090080000 Cap M3/8"
26 4280870000 Rotor Kit
27 7310410000 Capacitor MF.50 V450
28 7329900000 Cable Pressure / Motor
29 7501050000 Block Cable
30 7501060000 Block Cable
31 7382340000 Terminal cover
32 7012020000 Screw Ø3,9X12,7 DIN-7981
33 7089950000 Collector
34 7410800000 Prot. Thermal 15 A
35 7640010000 Cover
36 7200020000 Fan raff.
37 7038020000 Washer Ø8X30X3 UNI-6593
38 7011090000 Screw M8X20 UNI-5739
39 7150370000 Carena plastic
40 7031010000 Washer Ø8 UNI-3703
41 7015100000 tie rod M6X185
42 7060030000 Bearing 6204 20-47-14 2RS1-
43 4011390000 Stator
44 7071160000 Oil seal 4062/10 SMIM
45 7060070000 Bearing 6007
46 7078570000 Gasket
47 7020070000 Nut M8 UNI-5587
48 7078030000 Gasket
50 7078580000 Gasket
51 7081100000 Fitting 3/8 "
52 7237010000 Copper pipe
53 7310520000 BREAKER + 30MF.X2,5 SEC. + Lingueta
100 4082010000 Gakets Kit
101 4191130000 Kit Conrod/piston
026A  4280820000 Rotor Kit
028A  7329870000 PR WIRE/MOTGMV25-30 3X1,5 + T PVC90CM
031A  7382350000 CLAMP COVER MEC90 GMV-E TRIFAS
034A  7410460000 Thermal PROT. ETA-3120-F521-P7T1-W09D-6A
043A  4011420000 MOTOR CASE V240 GMV 30 / 50HZ S/TERMBLK
043B  4011030000 MOTOR CASE GMVHP3 MOT V380 / 50 RPM2800
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac VX422
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Fiac VX422

Diagram Fiac VX422

Download (393.63KB)
