FIAC spa

FIAC Spare Parts for Pump Unit VX 304

SKU: Fiac VX304 2027022000
€757.16
VAT included

FIAC Spare Parts for Pump Unit VX 304

We are FIAC AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Direct Driven Lubricared Pump Unit VX 304 - from 05/12/2005.
FIAC Spare Parts for Pump Unit VX 304
  • FIAC Spare Parts for Pump Unit VX 304
  • FIAC Spare Parts for Pump Unit VX 304
FIAC spa

FIAC Spare Parts for Pump Unit VX 304

SKU: Fiac VX304 2027022000 Condition: New
€757.16
VAT included

FIAC Spare Parts for Pump Unit VX 304

We are FIAC AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Direct Driven Lubricared Pump Unit VX 304 - from 05/12/2005.
settings 59 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
57 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
Esploso pagina 2
Esploso pagina 3
1 / 3
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5030250008 Head €57.22
2
 photo_cameraImage coming soon 7011220000 Screw M6X40 UNI-5737 €1.44
3
 Filter Plate for Pumping Uniti and Air Compressor Fiac 7458340000 Filter Plate for Pumping Uniti and Air Compressor Fiac €1.52
4
 Air Filter Element for Pumping Units Fiac VX - VS - GM 7210010000 Air Filter Element for Pumping Units Fiac VX - VS - GM €4.37
5
 photo_cameraImage coming soon 7012010000 Screw Ø3,9X19 UNI-6954 €1.48
6
 Air Cleaner Cover for Pump Units Fiac VX 254-304 7210180000 Air Cleaner Cover for Pump Units Fiac VX 254-304 €7.69
7
 Start Valve 2.2 BAR-G 1/4 for Pump Units Fiac VX - VS 7196000000 Start Valve 2.2 BAR-G 1/4 for Pump Units Fiac VX - VS €14.40
8
 Valves Plate Kit for Puming Units Fiac VX 214-254-304 7459490000 Valves Plate Kit for Puming Units Fiac VX 214-254-304 €30.64
9
 photo_cameraImage coming soon 7010120000 Screw M6X25 UNI-5931 €1.40
10
 FIAC Pump Unit GM 300 Cylinder 5060160008 FIAC Pump Unit GM 300 Cylinder €128.06
11
 Fiac Stud M.8X35X14X16 7015020000 Fiac Stud M.8X35X14X16 €1.52
12
 Conrod for Pump Unit FIAC S15 5050160008 Conrod for Pump Unit FIAC S15 €27.40
13
 Piston for Pumping Unit FIAC AB 335 7220050000 Piston for Pumping Unit FIAC AB 335 €29.18
14
 Piston Rings for Pumping Units FIAC AB 248-338 - AB 268 4080030000 Piston Rings for Pumping Units FIAC AB 248-338 - AB 268 €30.64
15
 photo_cameraImage coming soon 7041030000 Seeger Ø13 €1.44
16
 photo_cameraImage coming soon 7050030000 Pin Ø 13 €5.58
17
 Dipstick Level Oil for Pump Unit and Compressors Fiac GM-Vx-Colibrì 7181060000 Dipstick Level Oil for Pump Unit and Compressors Fiac GM-Vx-Colibrì €10.47
19
 photo_cameraImage coming soon 7011460000 Screw M6X16 TAP-TITE €1.48
20
 photo_cameraImage coming soon 7650010000 Crankcase cover €28.94
21
 Motor Carter Gasket for Pumping Units FIAC VX 7078440000 Motor Carter Gasket for Pumping Units FIAC VX €7.53
22
 Seeger E 20 for Pumping Units FIAC S 15-GM 25-GM 50 7040040000 Seeger E 20 for Pumping Units FIAC S 15-GM 25-GM 50 €0.62
23
 photo_cameraImage coming soon 7081100000 3/8 " €8.35
24
 FIAC Copper Pipe Right for Series VX 7237010000 FIAC Copper Pipe Right for Series VX €26.95
25
 photo_cameraImage coming soon 7237020000 Copper pipe €25.42
26
 Crankshaft for Pump Unit FIAC VX 304 5041390008 Crankshaft for Pump Unit FIAC VX 304 €55.73
27
 photo_cameraImage coming soon 5070180008 Crankshaft housing €125.56
28
 photo_cameraImage coming soon 7090080000 Stopper M3 / 8 " €1.50
029A
 photo_cameraImage coming soon 4280790000 Rotor kit €245.74
29
 photo_cameraImage coming soon 4280860000 Rotor Kit €227.53
30
 Capacitor 50 mf for Pump Units Fiac VX 304-402-422 7310410000 Capacitor 50 mf for Pump Units Fiac VX 304-402-422 €56.93
031A
 photo_cameraImage coming soon 7329870000 PR WIRE / MOTGMV25-30 3X1,5 + T PVC90CM €22.13
31
 photo_cameraImage coming soon 7329900000 Cable Pressure / Motor €15.66
32
 photo_cameraImage coming soon 7501050000 Cable locks €4.48
33
 photo_cameraImage coming soon 7501060000 Cable locks €1.52
34
 photo_cameraImage coming soon 7382340000 Terminal cover €4.34
034A
 photo_cameraImage coming soon 7382350000 COVER Morset MEC90 GMV-E TRIFAS €4.34
35
 photo_cameraImage coming soon 7012020000 Screw Ø3,9X12,7 DIN-7981 €1.52
36
 photo_cameraImage coming soon 7410530000 TERM.WEBER UNIMAT WTT22-551-8AMP €131.03
37
 Thermal Protection AMF 15 A for Pump Units Fiac VX 254-304 7410390000 Thermal Protection AMF 15 A for Pump Units Fiac VX 254-304 €35.10
39
 FIAC Pump Units VS-VX-GMS Fan 7200340000 FIAC Pump Units VS-VX-GMS Fan €29.81
40
 photo_cameraImage coming soon 7038020000 Washer Ø8X30X3 UNI-6593 €1.52
41
 photo_cameraImage coming soon 7011090000 Screw M8x20 UNI-5739 €1.52
42
 FIAC Motor Cover for Series VS-VX 7150370000 FIAC Motor Cover for Series VS-VX €36.88
43
 photo_cameraImage coming soon 7031010000 Washer 8 UNI-3703 €1.52
44
 photo_cameraImage coming soon 7015100000 Guy M6X185 €1.44
45
 photo_cameraImage coming soon 7060030000 Bearing 6204 20-47-14 2RS1- €17.12
046A
 photo_cameraImage coming soon 4011340000 MOTOR HOUSING VX 304-V400 / 50HZ- S / MORSET €750.12
46
 photo_cameraImage coming soon 4011450000 CARC ENGINE VX 304 V.230 / 50Hz +/- 5% €713.70
47
 Fiac VX214 Oil Seal 4062-10 SMIM 7071160000 Fiac VX214 Oil Seal 4062-10 SMIM €7.45
48
 photo_cameraImage coming soon 7060070000 Bearing 6007 €24.51
49
 Cylinder Gasket for Pumping Units FIAC GM 142 7078150000 Cylinder Gasket for Pumping Units FIAC GM 142 €2.94
50
 photo_cameraImage coming soon 7020070000 Nut M8 UNI-5587 €1.48
51
 photo_cameraImage coming soon 7078160000 Gasket €4.11
52
 photo_cameraImage coming soon 7089950000 Collector €25.04
53
 Fiac Pump Unit GM 143 Head Plate Gasket 7078580000 Fiac Pump Unit GM 143 Head Plate Gasket €4.34
100
 Gasket Set for Pump Unit FIAC VX 304 4082080000 Gasket Set for Pump Unit FIAC VX 304 €21.06
101
 Conrod + Piston + Piston Ring Ass'y Set for Pump Unit Fiac S15 4191040000 Conrod + Piston + Piston Ring Ass'y Set for Pump Unit Fiac S15 €76.79

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC Spare Parts for Pump Unit VX 304

We are FIAC AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Direct Driven Lubricared Pump Unit VX 304 validity date - from 05/12/2005.

In the following table , look for the model of the Pumping Unit and the respective parts of the code.
Fiac VX 304 2027022000

VX 304 validity date - from 05/12/2005
# Part Num. Description
1 5030250008 Head
2 7011220000 Screw M6X40 UNI-5737
3 7458340000 Plate filter
4 7210010000 Filter element
5 7012010000 Screw Ø3,9X19 UNI-6954
6 7210180000 Air Cleaner Cover
7 7196000000 Start valve M1/4" 2.2 bar
8 7459490000 Kit valve plate
9 7010120000 Screw M6X25 UNI-5931
10 5060160008 Cylinder - NEW 1124080114
11 7015020000 Stud M.8X35X14X16
12 5050160008 Connecting Rod
13 7220050000 Piston
14 4080030000 Piston Ring Kit
15 7041030000 Seeger Ø13
16 7050030000 Pin Ø 13
17 7181060000 Dipstick
18 7012180000 Screw M6X20 UNI-8112
19 7011460000 Screw M6X16 TAP-TITE
20 7650010000 Crankcase cover
21 7078440000 Gasket
22 7040040000 Seeger E 20
23 7081100000 Fitting 3/8 "
24 7237010000 Copper pipe
25 7237020000 Copper pipe
26 5041390008 Tree in Elbow
27 5070180008 Sump
28 7090080000 Cap M3 / 8 "
29 4280860000 Rotor Kit
30 7310410000 Capacitor MF.50 V450
31 7329900000 Cable Pressure / Motor
32 7501050000 Block Cable
33 7501060000 Block Cable
34 7382340000 Terminal cover
35 7012020000 Screw Ø3,9X12,7 DIN-7981
36 7410530000 TERM.WEBER UNIMAT WTT22-551-8AMP
37 7410390000 Thermal protection AMF 15 AMP.MOD.ACS K 800
38 7640010000 Cover
39 7200340000 Fan
40 7038020000 Washer Ø8X30X3 UNI-6593
41 7011090000 Screw M8X20 UNI-5739
42 7150370000 Carena plastic
43 7031010000 Washer Ø8 UNI-3703
44 7015100000 tie rod M6X185
45 7060030000 Bearing 6204 20-47-14 2RS1-
46 4011450000 CARC ENGINE VX 304 V.230 / 50Hz +/- 5%
47 7071160000 Oil seal 4062/10 SMIM
48 7060070000 Bearing 6007
49 7078150000 Gasket
50 7020070000 Nut M8 UNI-5587
51 7078160000 Gasket
52 7089950000 Collector
53 7078580000 Gasket
100 4082080000 Gasket Kit
101 4191040000 CONROD-PISTON-RINGS KIT D.55 / VX 304
029A  4280790000 Rotor Kit
031A  7329870000 CABLE / ENGINE GMV25-30 3X1,5 + T PVC90CM
034A  7382350000 COVER MEC90 GMV-E TRIFAS
046A  4011340000 MOTOR HOUSING VX-304 V400 / 50HZ S / TERMINALS
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac VX304 2027022000
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Fiac VX304

Diagram Fiac VX304

Download (359.38KB)
