SELF-PRIMING PUMP 0.55 kW PEDROLLO JSWm-1AX
Recommended for pumping clean water even in the presence of air mixed with the pumped liquid. Thanks to their reliability, ease of use, and cost-effectiveness, they are particularly suitable for domestic use, especially for automatic water distribution when coupled with small to medium-sized pressure systems (autoclaves).
TECHNICAL DATA SHEET: PEDROLLO JSWm 1AX
- BRAND: PEDROLLO
- MODEL: JSWm 1AX ("m" indicates single-phase power supply)
- POWER: 0.75 HP / 0.55 kW
- IMPELLER: Stainless Steel AISI 304 ("X" version)
- PUMP BODY: Cast iron with cataphoretic coating
- FITTINGS: 1" x 1" (Inlet x Outlet)
- PERFORMANCE & OPERATING LIMITS
- MAX FLOW RATE: 50 L/min
- MAX HEAD: 47 meters
- SUCTION LIFT: Up to 9 meters (Self-priming system)
- LIQUID TEMPERATURE: From -10 °C to +40 °C
- Performance Examples:
- At 47 meters: 5 L/min
- At 31 meters: 30 L/min
- At 21 meters: 50 L/min
STRENGTHS OF THE 1AX MODEL
"X" Version: Compared to the standard technopolymer version, the stainless steel impeller ensures much higher resistance to wear and cavitation.
"JET" System: Thanks to the internal ejector, the pump can prime even with air-mixed liquids.
Compact Dimensions: Ideal for small domestic systems, garden irrigation, or pressurizing water in small apartments.
