ABAC

ABAC PAT24A SPARE GRAY Parts

SKU: ABAC PAT24A SPARE GRAY
€93.56
VAT included

ABAC PAT24A SPARE GRAY Spare Parts

Distribution and sale of original ABAC spare parts, low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and fix Issues for PAT24A SPARE GRAY Pump Unit.
ABAC PAT24A SPARE GRAY Parts
  • ABAC PAT24A SPARE GRAY Parts
  • ABAC PAT24A SPARE GRAY Parts Diagram
  • ABAC PAT24A SPARE GRAY Parts Diagram - 1
  • ABAC PAT24A SPARE GRAY Oil
ABAC

ABAC PAT24A SPARE GRAY Parts

SKU: ABAC PAT24A SPARE GRAY Condition: New
€93.56
VAT included

ABAC PAT24A SPARE GRAY Spare Parts

Distribution and sale of original ABAC spare parts, low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and fix Issues for PAT24A SPARE GRAY Pump Unit.
settings 17 spare parts
description 3 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Shipped on: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
17 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
004
 photo_cameraImage coming soon 2236111600 Crankshaft €36.15
030
 photo_cameraImage coming soon 0502210500 Bearing 6205 €8.74
034
 photo_cameraImage coming soon 6231630100 Oil Seal €2.87
305
 Air Filter Kit for Pump Units ABAC PAT24-PAT38 2236112835 Air Filter Kit for Pump Units ABAC PAT24-PAT38 €15.18
310
 Cylinder Head Kit for Pump Unit ABAC A29B 2901325044 Cylinder Head Kit for Pump Unit ABAC A29B €35.92
325
 Valve Plate Kit for Pump Unit ABAC A29B 2236112518 Valve Plate Kit for Pump Unit ABAC A29B €34.95
340
 ABAC PAT24A-PAT38A Aftercooler Kit 2236112794 ABAC PAT24A-PAT38A Aftercooler Kit €15.68
345
 photo_cameraImage coming soon 2236112434 CYLINDER KIT PAT24 €60.68
355
 ABAC Conrod Piston Kit Ass'y for Pump Unit PAT24 - A29 - NS12 2236111619 ABAC Conrod Piston Kit Ass'y for Pump Unit PAT24 - A29 - NS12 €26.83
360
 photo_cameraImage coming soon 2901325049 OIL LEVEL KIT €3.29
365
 photo_cameraImage coming soon 2236112437 BOTTOM CRANKCASE COVER KIT PAT 24 €27.80
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
PK1
 Performance Kit for Pump Units ABAC PAT24-PAT38 8973037657 Performance Kit for Pump Units ABAC PAT24-PAT38 €56.71
KM1
 ABAC Maintenance Kit for Pump Unit A29B - A39B 8973037864 ABAC Maintenance Kit for Pump Unit A29B - A39B €18.91
305
 Air Filter Kit for Pump Units ABAC PAT24-PAT38 2236112835 Air Filter Kit for Pump Units ABAC PAT24-PAT38 €15.18
325
 Valve Plate Kit for Pump Unit ABAC A29B 2236112518 Valve Plate Kit for Pump Unit ABAC A29B €34.95
330
 ABAC Upgrade Kit for Pump Unit A29B - A39B 2901325046 ABAC Upgrade Kit for Pump Unit A29B - A39B €48.30
335
 ABAC Gasket Kit for Pump Unit A29 2901325045 ABAC Gasket Kit for Pump Unit A29 €17.28
350
 Flywheel Kit for Pump Unit A29B 2901325048 Flywheel Kit for Pump Unit A29B €39.17
355
 ABAC Conrod Piston Kit Ass'y for Pump Unit PAT24 - A29 - NS12 2236111619 ABAC Conrod Piston Kit Ass'y for Pump Unit PAT24 - A29 - NS12 €26.83
375
 photo_cameraImage coming soon 1630020700 ALTAIR PRO 1L €12.76
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
375
 photo_cameraImage coming soon 1630020700 ALTAIR PRO 1L €12.76

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

ABAC PAT24A SPARE GRAY Spare Parts

Distribution and sale of original ABAC spare parts, low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and fix Issues for PAT24A SPARE GRAY Pump Unit.

In the following table, look for the spare parts of the ABAC Air Compressor and the corresponding code.
PAT24A SPARE GRAY

ABAC 4116090646_00 Pump Unit PAT24A SPARE GRAY Spare Parts Pag.1
(4116091292)
# Part No. Description
001 2236111607 Crankcase
004 2236111600 Crankshaft
030 0502210500 Bearing 6205
034 6231630100 Oil seal 35/25/7
305 2236112835 Air filter
310 2901325044 KIT HEAD CYLINDER PAT24/PAT38
325 2236112518 VALVE PLATE KIT
336 2236112436 Shaft seal kit
340 2236112794 Aftercooler kit
345 2236112434 Cylinder kit
355 2236111619 PISTON-CONN.ROD KIT PAT24 - LP
360 2901325049 Oil level kit
365 2236112437 Crankcase cover kit
1609403123_00 Service kits Pag.2
# Part No. Description
305 2236112835 Air filter
325 2236112518 VALVE PLATE KIT
330 2901325046 UPGRADE KIT PAT24/38
335 2901325045 GASKET KIT PAT24/PAT38
350 2901325048 KIT FLYWHEEL PAT24
355 2236111619 Conrod-piston kit
375 1630020700 Can altair pro 1l
KM1 8973037864 MAINTENANCE KIT LIGHT PAT24/38
PK1 8973037657 PERFORMANCE KIT PAT24/PAT38
HDK NA Heavy duty kit
1121453001_00 Lubricants Pag.3
# Part No. Description
375 1630020700 Can altair pro 1l
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s ABAC websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to ABAC brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
ABAC PAT24A SPARE GRAY
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

ABAC PAT24A SPARE GRAY Diagram

ABAC PAT24A SPARE GRAY Diagram

Download (738.49KB)
