Telwin Spare Parts for Spotter PCP 28

SKU: Telwin PCP 28 - 824045
€71.07
VAT included

Telwin Spare Parts for Spotter PCP 28

We supply original TELWIN spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Spotter PCP 28 - 824045.

Telwin PCP 28 - 824045
Telwin Spare Parts for Spotter PCP 28
  • Telwin Spare Parts for Spotter PCP 28
  • Telwin Spare Parts for Spotter PCP 28 - Drawing

Telwin Spare Parts for Spotter PCP 28

SKU: Telwin PCP 28 - 824045 Condition: New
€71.07
VAT included

Telwin Spare Parts for Spotter PCP 28

We supply original TELWIN spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Spotter PCP 28 - 824045.

Telwin PCP 28 - 824045
settings 46 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:: TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

44 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 114619 RELAY BOARD ' €39.33
2
photo_cameraImage coming soon 980671 KIT CONTROL BOARD €144.91
3
photo_cameraImage coming soon 113121 SCR €66.99
4
Pedal for Spotter Telwin PCP 18 - PCP 28 120011 Pedal for Spotter Telwin PCP 18 - PCP 28 €136.00
6
photo_cameraImage coming soon 122124 SOLENOID €40.22
7
photo_cameraImage coming soon 122599 PRESSURE €15.98
8
photo_cameraImage coming soon 122019 SWITCH €59.91
9
photo_cameraImage coming soon 122840 KNOB FOR COMMUTATATORE €27.91
10
photo_cameraImage coming soon 990844 WIRING THERMOSTAT €21.51
11
photo_cameraImage coming soon 142117 PROTECTIVE MASK €3.10
12
Fan Motor for Welding Machines Telwin Eurarc-Artika-Quality 152073 Fan Motor for Welding Machines Telwin Eurarc-Artika-Quality €34.72
13
Fan for Welding Machines Telwin Eurarc-Artika-Quality 152111 Fan for Welding Machines Telwin Eurarc-Artika-Quality €8.21
14
Auxiliary Power Adapter for Welding Machines Telwin TELMIG 183-203-250/2 164270 Auxiliary Power Adapter for Welding Machines Telwin TELMIG 183-203-250/2 €37.26
15
photo_cameraImage coming soon 164112 TRANSFORMER €810.01
20
photo_cameraImage coming soon 322274 INSULATION €1.48
21
photo_cameraImage coming soon 422248 THREADED ROD €21.37
22
photo_cameraImage coming soon 422266 BOLT €1.52
23
Electrode Holder for Spotter Telwin PCP 18 - PCP 28 443020 Electrode Holder for Spotter Telwin PCP 18 - PCP 28 €60.04
24
photo_cameraImage coming soon 452021 SPRING €22.23
25
photo_cameraImage coming soon 512023 MERGER LOWER ARM €163.08
26
photo_cameraImage coming soon 512024 FIXING PLATE ARM €476.77
27
photo_cameraImage coming soon 512026 MOBILE MERGER €318.87
28
photo_cameraImage coming soon 513052 COIL SECONDARY €298.54
29
photo_cameraImage coming soon 602002 PISTON PNEUMATIC €272.15
30
photo_cameraImage coming soon 602092 TOGETHER Reducer filter €84.03
31
photo_cameraImage coming soon 644298 FRAME €277.98
32
photo_cameraImage coming soon 644542 MASK €1.79
33
photo_cameraImage coming soon 644543 LEVER ARM €53.80
35
photo_cameraImage coming soon 648672 FRONT €16.30
36
photo_cameraImage coming soon 650326 COVER €3.54
37
photo_cameraImage coming soon 650391 BACK €24.01
38
photo_cameraImage coming soon 650392 COAT €20.05
39
photo_cameraImage coming soon 655336 LEFT SIDE €60.18
40
photo_cameraImage coming soon 655335 RIGHT SIDE €62.58
41
Standard Straight Electrode for Spot Welding Telwin CP-18 PTE 18 690035 Standard Straight Electrode for Spot Welding Telwin CP-18 PTE 18 €13.79
42
Bended Electrode for Spotter Telwin PCP 18-28/PTE 18-28 690036 Bended Electrode for Spotter Telwin PCP 18-28/PTE 18-28 €27.74
43
photo_cameraImage coming soon 803100 XP1 KIT ARM 350 M €565.22
44
photo_cameraImage coming soon 803101 XP2 KIT ARM 500 MM €703.85
45
photo_cameraImage coming soon 803102 XP3 KIT ARM 700 MM €885.15
46
photo_cameraImage coming soon 990187 BUSHING KIT FOR ARMS €9.88
47
photo_cameraImage coming soon 990329 SWITCH KNOB KIT €10.91
48
photo_cameraImage coming soon 990368 CABLE BUSHING KIT €24.18
49
photo_cameraImage coming soon 114628 SHEET SNUBBER SCR €32.91
50
photo_cameraImage coming soon 482661 CARTER SETTING €5.27

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Telwin Spare Parts for Spotter PCP 28

We supply original TELWIN spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Spotter PCP 28 - 824045.

In the following table, look for the model of the Spotter and the respective parts of the code.
Telwin PCP 28 - 824045

Telwin Spotter PCP 28 400V – 824045
# Part Num. Descrizione
1 114619 RELAY BOARD '
2 980671 KIT CONTROL BOARD
3 113121 SCR
4 120011 PEDAL
6 122124 SOLENOID
7 122599 PRESSURE
8 122019 SWITCH
9 122840 KNOB FOR COMMUTATATORE
10 990844 WIRING THERMOSTAT
11 142117 PROTECTIVE MASK
12 152073 ENGINE
13 152111 FAN
14 164270 TRANSFORMER AUXILIARY
15 164112 TRANSFORMER
19 322272 INSULATION WASHER
20 322274 INSULATION
21 422248 THREADED ROD
22 422266 BOLT
23 443020 ELECTRODE HOLDER
24 452021 SPRING
25 512023 MERGER LOWER ARM
26 512024 FIXING PLATE ARM
27 512026 MOBILE MERGER
28 513052 COIL SECONDARY
29 602002 PISTON PNEUMATIC
30 602092 TOGETHER Reducer filter
31 644298 FRAME
32 644542 MASK
33 644543 LEVER ARM
34 648682 DASHBOARD
35 648672 FRONT
36 650326 COVER
37 650391 RETRO
38 650392 COAT
39 655336 LEFT SIDE
40 655335 RIGHT SIDE
41 690035 ELECTRODE STANDARD RIGHT
42 690036 BENDED ELECTRODE
43 803100 XP1 KIT ARM 350 M
44 803101 XP2 KIT ARM 500 MM
45 803102 XP3 KIT ARM 700 MM
46 990187 BUSHING KIT FOR ARMS
47 990329 KIT WHEEL
48 990368 GLAND KIT
49 114628 SHEET SNUBBER SCR
50 482661 CARTER SETTING
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Telwin PCP 28 - 824045
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:
TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS

Specific References

New

Download

Telwin PCP 28 Drawing

Telwin PCP 28 Drawing

Download (389.25KB)
