Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V

SKU: TECNICA TIG 160 DC-HF - 815957
€7.84
VAT included

Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Telwin inverter TIG, TECNICA TIG 160 DC-HF/LIFT 230V - 815957.

TECNICA TIG 160 DC-HF/LIFT 815957
Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V
  • Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V
  • Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V - Drawing
  • Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V - Torch Drawing
  • Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V - Wire Diagram
Telwin s.p.a.

Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V

SKU: TECNICA TIG 160 DC-HF - 815957 Condition: New
€7.84
VAT included

Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Telwin inverter TIG, TECNICA TIG 160 DC-HF/LIFT 230V - 815957.

TECNICA TIG 160 DC-HF/LIFT 815957
settings 63 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:: TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
63 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 Potentiometer for Inverter Telwin Force 125-145-165 112017 Potentiometer for Inverter Telwin Force 125-145-165 €4.03
2
 Wire Resistance for Inverter Telwin Force 145 - 165 - 195 112048 Wire Resistance for Inverter Telwin Force 145 - 165 - 195 €2.91
3
 Capacitor for Inverter Telwin Force 145 - Technology 186 HD 112514 Capacitor for Inverter Telwin Force 145 - Technology 186 HD €9.02
4
 Diode 112948 for Inverter Tecnica 151-171-211/S 112948 Diode 112948 for Inverter Tecnica 151-171-211/S €4.34
5
 Single-Phase Rectifier for Inverter Telwin 144-164 116346 Single-Phase Rectifier for Inverter Telwin 144-164 €6.82
6
 photo_cameraImage coming soon 111925 RELAIS €2.07
7
 PWM CONTROLLER 111199 PWM CONTROLLER €7.84
8
 photo_cameraImage coming soon 980678 CONTROL PCB KIT €81.27
9
 Generator HF TIG Board Kit for Welding Technology Tig 182-185-230 980021 Generator HF TIG Board Kit for Welding Technology Tig 182-185-230 €95.48
10
 photo_cameraImage coming soon 120605 CONTROL CABLE €12.66
11
 photo_cameraImage coming soon 120612 SOCKET CABLE €18.22
12
 photo_cameraImage coming soon 121029 ELECTROVALVE €14.02
13
 Small knob for Inverter Telwin 121395 Small knob for Inverter Telwin €0.61
14
 photo_cameraImage coming soon 121192 SWITCH €6.98
15
 Green Switch for Inverter Telwin Force 125-145-165-195 122381 Green Switch for Inverter Telwin Force 125-145-165-195 €5.42
16
 Potentiometer Knob for Inverter Telwin Mastermig 232 Duplex 121394 Potentiometer Knob for Inverter Telwin Mastermig 232 Duplex €0.40
17
 photo_cameraImage coming soon 121193 SWITCH €5.53
18
 photo_cameraImage coming soon 132155 MAINS CABLE 3G1.5 2 M SCHUKO PLUG €12.34
19
 Fan for Inverter TIG Force-Superior 152006 Fan for Inverter TIG Force-Superior €13.79
20
 Inductance Filter for Inverter Telwin 164741 Inductance Filter for Inverter Telwin €6.99
21
 photo_cameraImage coming soon 164932 AUXILIARY TRANSFORMER €4.72
22
 photo_cameraImage coming soon 980167 POWER TRANSFORMER KIT €29.58
23
 photo_cameraImage coming soon 169506 INDUCTANCE €17.58
24
 photo_cameraImage coming soon 980170 TRANSFORMER KIT €15.79
25
 photo_cameraImage coming soon 980282 TRANSFORMER KIT €55.63
26
 Cable Busching for Inverter Welding and Battery Charger Telwin 322112 Cable Busching for Inverter Welding and Battery Charger Telwin €2.44
27
 photo_cameraImage coming soon 322065 BELT BUCKLE €2.31
28
 photo_cameraImage coming soon 322906 FRAME €1.46
29
 photo_cameraImage coming soon 322408 BELT €3.12
31
 photo_cameraImage coming soon 642128 FRONT PANEL €14.05
32
 Socket DX 25 for Telwin Welding Machine 712035 Socket DX 25 for Telwin Welding Machine €3.47
33
 Kit IGBT + Diode for Inverter Telwin Tecnica TIG 160 - PLASMA 31 990734 Kit IGBT + Diode for Inverter Telwin Tecnica TIG 160 - PLASMA 31 €30.53
34
 photo_cameraImage coming soon 980930 COVER KIT €12.95
35
 photo_cameraImage coming soon 990818 COMPLETE PCB KIT €425.86
36
 photo_cameraImage coming soon 990120 GAS PIPE CONNECTOR KIT €5.82
37
 photo_cameraImage coming soon 123437 CABLE 16 MMQ 3 M - 25 €23.01
38
 Throwaway Argon + CO₂ ITA-USA Gas Bottle Adaptor Telwin 432036 432036 Throwaway Argon + CO₂ ITA-USA Gas Bottle Adaptor Telwin 432036 €10.50
39
 Plug DX 25 for Telwin Welding Machine 712039 Plug DX 25 for Telwin Welding Machine €3.47
40
 Toledo 300 Amp. Work Clamp for Inverter and Plasma Telwin 712231 Toledo 300 Amp. Work Clamp for Inverter and Plasma Telwin €5.89
41
 Telwin Gas Regulators for Refilable Bottles 722119 Telwin Gas Regulators for Refilable Bottles €58.24
42
 TIG Torch for Welding Machine Telwin Tecnica 160-Technology 182/185 742423 TIG Torch for Welding Machine Telwin Tecnica 160-Technology 182/185 €126.62
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
Pos. Item Price Buy
1
 photo_cameraImage coming soon 802244 KIT 10 CERAMIC NOZZLES NR.4 €9.89
1
 photo_cameraImage coming soon 802245 KIT 10 CERAMIC NOZZLES NR.6 €9.89
1
 photo_cameraImage coming soon 802246 KIT 10 CERAMIC NOZZLES NR.7 €9.89
2
 Insulator SR 17 for Telwin TIG Torch 722248 Insulator SR 17 for Telwin TIG Torch €8.21
4
 photo_cameraImage coming soon 802220 KIT 10 CERIUM-TUNGSTEN ELECTR. D.1 MM €17.75
4
 photo_cameraImage coming soon 802222 KIT 10 CERIUM-TUNGSTEN ELECTR. D.1,6 MM €17.75
4
 photo_cameraImage coming soon 802232 KIT 10 CERIUM-TUNGSTEN ELECTR. D.2,4 MM €53.95
5
 photo_cameraImage coming soon 802239 KIT 3 ELECTRODE HOLDER CLAMPS D.1,0 MM €3.36
5
 photo_cameraImage coming soon 802240 KIT 3 ELECTRODE HOLDER CLAMPS D.1,6 MM €3.61
5
 photo_cameraImage coming soon 802241 KIT 3 ELECTRODE HOLDER CLAMPS D.2,4 MM €3.61
6
 Short Hood SR 17 for Telwin TIG Torch 722192 Short Hood SR 17 for Telwin TIG Torch €4.03
7
 Long Hood SR 17 for Telwin TIG Torch 722193 Long Hood SR 17 for Telwin TIG Torch €17.14
8
 photo_cameraImage coming soon 981442 25 CONNECTION KIT €32.57
12
 Telwin Inverter TIG Welding Machines Plug 3P 722999 Telwin Inverter TIG Welding Machines Plug 3P €13.68
14
 PCB + Button for Torches Telwin TIG 452089 PCB + Button for Torches Telwin TIG €19.37
16
 Long Hood O-Ring 2037 for Telwin TIG Torch 722061 Long Hood O-Ring 2037 for Telwin TIG Torch €0.97
17
 Button for Torches Telwin TIG 742042 Button for Torches Telwin TIG €2.63
18
 Torch Body SR 17 for Telwin TIG Torch 722204 Torch Body SR 17 for Telwin TIG Torch €52.85
19
 photo_cameraImage coming soon 802249 KIT 3 ELECTRODE DIFFUSERS D.1 MM €7.78
19
 photo_cameraImage coming soon 802250 KIT 3 ELECTRODE DIFFUSERS D.1,6 MM €7.78
19
 photo_cameraImage coming soon 802251 KIT 3 ELECTRODE DIFFUSERS D.2,4 MM €7.78
21
 photo_cameraImage coming soon 990263 3/8" CONNECTION KIT TIG TORCH €5.10
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 3
info_outline

No spare parts mapped to this page.
Check the other pages for available parts.

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Telwin Parts for Inverter Welding TECNICA TIG 160 DC-HF/LIFT 230V

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Telwin inverter TIG, TECNICA TIG 160 DC-HF/LIFT 230V - 815957.

In the following table, look for the model of the drill and the respective parts of the code.
TECNICA TIG 160 DC-HF/LIFT 815957
TECNICA TIG 160 DC-HF/LIFT 230V-815957 Pag.1
# Description Part Num.
1 POTENTIOMETER 112017
2 RESISTANCE 112048
3 CAPACITOR 112514
4 DIODE 112948
5 RECTIFIER 116346
6 RELAIS 111925
7 PWM CONTROLLER 111199
8 CONTROL PCB KIT 980678
9 HF BOARD KIT 980021
10 CONTROL CABLE 120605
11 SOCKET CABLE 120612
12 ELECTROVALVE 121029
13 KNOB 121395
14 SWITCH 121192
15 SWITCH 122381
16 KNOB 121394
17 SWITCH 121193
18 MAINS CABLE 3G1.5 2 M SCHUKO PLUG 132155
19 FAN 152006
20 FILTER INDUCTANCE 164741
21 AUXILIARY TRANSFORMER 164932
22 POWER TRANSFORMER KIT 980167
23 INDUCTANCE 169506
24 TRANSFORMER KIT 980170
25 TRANSFORMER KIT 980282
26 CABLE BUSHING 322112
27 BELT BUCKLE 322065
28 FRAME 322906
29 BELT 322408
30 PIPE FITTING 602052
31 FRONT PANEL 642128
32 SOCKET DX 25 712035
33 KIT IGBT + DIODE 990734
34 COVER KIT 980930
35 COMPLETE PCB KIT 990818
36 GAS PIPE CONNECTOR KIT 990120
37 CABLE 16 MMQ 3 M - 25 123437
38 ARGON GAS BOTTLE IT ADAPTOR 432036
39 PLUG DX 25 712039
40 TOLEDO 300 WORK CLAMP 712231
41 GAS REGULATOR 2 MANOMETERS 722119
42 ST17 TIG TORCH 4 M 180 A 742423
TORCH TECNICA TIG 160 DC-HF/LIFT 230V-815957 Pag.2
1 KIT 10 CERAMIC NOZZLES NR.6 802245
1 KIT 10 CERAMIC NOZZLES NR.4 802244
1 KIT 10 CERAMIC NOZZLES NR.7 802246
2 INSULATOR 722248
4 KIT 10 CERIUM-TUNGSTEN ELECTR. D.2,4 MM 802232
4 KIT 10 CERIUM-TUNGSTEN ELECTR. D.1 MM 802220
4 KIT 10 CERIUM-TUNGSTEN ELECTR. D.1,6 MM 802222
5 KIT 3 ELECTRODE HOLDER CLAMPS D.2,4 MM 802241
5 KIT 3 ELECTRODE HOLDER CLAMPS D.1,0 MM 802239
5 KIT 3 ELECTRODE HOLDER CLAMPS D.1,6 MM 802240
6 SHORT CAP 722192
7 LONG CAP 722193
8 CONNECTION KIT 25 981442
12 3P PLUG 722999
14 PUSHBOTTON CONTACT 452089
16 OR RING 722061
17 PUSHBOTTON 742042
18 TORCH BODY 722204
19 KIT 3 ELECTRODE DIFFUSERS D.1,6 MM 802250
19 KIT 3 ELECTRODE DIFFUSERS D.1 MM 802249
19 KIT 3 ELECTRODE DIFFUSERS D.2,4 MM 802251
21 3/8" CONNECTION KIT TIG TORCH 990263
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
