Telwin s.p.a.

Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V

SKU: TECH PLASMA 54 KOMPR. 815088
€7.84
VAT included

Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V

TELWIN authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Plasma TECHNOLOGY PLASMA 54 KOMPRESSOR 230V – 815088.

TECH PLASMA 54 KOMPR. 815088
Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V
  • Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V
  • Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V
  • Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V
Telwin s.p.a.

Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V

SKU: TECH PLASMA 54 KOMPR. 815088 Condition: New
€7.84
VAT included

Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V

TELWIN authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Plasma TECHNOLOGY PLASMA 54 KOMPRESSOR 230V – 815088.

TECH PLASMA 54 KOMPR. 815088
settings 39 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:: TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
39 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 Potentiometer for Inverter Telwin Force 125-145-165 112017 Potentiometer for Inverter Telwin Force 125-145-165 €4.03
2
 Wire Resistance for Inverter Telwin Force 145 - 165 - 195 112048 Wire Resistance for Inverter Telwin Force 145 - 165 - 195 €2.91
3
 photo_cameraImage coming soon 112357 PHASE RECTIFIER €12.21
4
 Capacitor for Inverter Telwin Force 125 - 165 - Force Tig 170 113122 Capacitor for Inverter Telwin Force 125 - 165 - Force Tig 170 €10.50
5
 Telwin 113233 Relè for Inverter Welding 113233 Telwin 113233 Relè for Inverter Welding €4.14
6
 PWM CONTROLLER 111199 PWM CONTROLLER €7.84
7
 Control PCB Kit Telwin TECHNOLOGY PLASMA 41-54 980526 Control PCB Kit Telwin TECHNOLOGY PLASMA 41-54 €54.25
8
 Potentiometer Knob for Inverter Telwin Mastermig 232 Duplex 121394 Potentiometer Knob for Inverter Telwin Mastermig 232 Duplex €0.40
9
 Green Switch for Inverter Telwin Tecnica 211/S-Technology 236 HD 121248 Green Switch for Inverter Telwin Tecnica 211/S-Technology 236 HD €5.42
10
 photo_cameraImage coming soon 123422 6 3 M CABLE MMQ €10.71
11
 photo_cameraImage coming soon 132155 MAINS CABLE 3G1.5 2 M SCHUKO PLUG €12.34
12
 Fan for Inverter Pratica-Technomig 152101 Fan for Inverter Pratica-Technomig €27.74
13
 Power Adapter for Inverter Telwin 152230 Power Adapter for Inverter Telwin €7.34
14
 photo_cameraImage coming soon 169503 REACTOR €31.94
15
 photo_cameraImage coming soon 322065 BELT BUCKLE €2.31
16
 Cable Busching for Inverter Welding and Battery Charger Telwin 322112 Cable Busching for Inverter Welding and Battery Charger Telwin €2.44
18
 photo_cameraImage coming soon 322408 BELT €3.12
19
 Telwin Superior Plasma 60 HF Front Panel 322508 Telwin Superior Plasma 60 HF Front Panel €16.58
20
 photo_cameraImage coming soon 638044 FRONT €7.74
21
 photo_cameraImage coming soon 639527 BACK €3.70
22
 Toledo 300 Amp. Work Clamp for Inverter and Plasma Telwin 712231 Toledo 300 Amp. Work Clamp for Inverter and Plasma Telwin €5.89
23
 Plasma Torch for Inverter Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR 742381 Plasma Torch for Inverter Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR €294.84
24
 photo_cameraImage coming soon 980170 TRANSFORMER KIT €15.79
25
 Kit IGBT + Diode for Inverter Plasma Telwin Technology 41-54 980253 Kit IGBT + Diode for Inverter Plasma Telwin Technology 41-54 €30.53
26
 photo_cameraImage coming soon 980254 KIT COAT €16.42
27
 photo_cameraImage coming soon 980255 KIT FORM €414.73
28
 TECHNOLOGY PLASMA 54 KOMPRESSOR Compressor Kit 980256 TECHNOLOGY PLASMA 54 KOMPRESSOR Compressor Kit €251.32
29
 photo_cameraImage coming soon 980257 KIT BOTTOM BASE €7.84
30
 photo_cameraImage coming soon 980258 NEEDLE (C) €45.04
31
 Kit Diodes for Inverter Plasma Telwin Technology 41-54 981273 Kit Diodes for Inverter Plasma Telwin Technology 41-54 €27.74
32
 photo_cameraImage coming soon 980259 GLAND KIT €5.82
33
 Inductance Filter for Inverter Telwin 164741 Inductance Filter for Inverter Telwin €6.99
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
Pos. Item Price Buy
1
 Plasma Cutting Torch Button for Telwin TECNICA-TECHNOLOGY-SUPERIOR 722677 Plasma Cutting Torch Button for Telwin TECNICA-TECHNOLOGY-SUPERIOR €15.80
2
 photo_cameraImage coming soon 990983 SPINE SAFETY KIT €18.50
3
 Kit 5 Torch Electrodes for Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR 802420 Kit 5 Torch Electrodes for Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR €16.58
4
 Kit 5 Insulating Diffusers for Plasma Torch Telwin TECNICA-TECHNOLOGY 802422 Kit 5 Insulating Diffusers for Plasma Torch Telwin TECNICA-TECHNOLOGY €56.54
5
 Kit 5 Torch Nozzles for Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR 802423 Kit 5 Torch Nozzles for Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR €15.19
6
 Kit 2 Torch Safety Caps for Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR 802485 Kit 2 Torch Safety Caps for Telwin TECHNOLOGY PLASMA 54 KOMPRESSOR €30.53
7
 photo_cameraImage coming soon 742036 BODY TORCH €209.91

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Telwin Parts for Inverter Plasma TECHNOLOGY PLASMA 54 KOMP. 230V

TELWIN authorized service center and original spare parts Worldwide Distributor

. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Plasma TECHNOLOGY PLASMA 54 KOMPRESSOR 230V – 815088.

In the following table, look for the model of the Plasma and the respective parts of the code.
TECH PLASMA 54 KOMPR. 815088

TECHNOLOGY PLASMA 54 KOMPRESSOR 230V – 815088 Pag.1
# Part Num. Description
1 112017 Potentiometer
2 112048 RESISTANCE
3 112357 PHASE RECTIFIER
4 113122 CAPACITOR
5 113233 RELAY '
6 111199 PWM CONTROLLER
7 980526 KIT CONTROL BOARD
8 121394 KNOB
9 121248 SWITCH, GREEN
10 123422 6 3 M CABLE MMQ
11 132155 CABLE ALIM. 3G1.5 2 M SCHUKO PLUG
12 152101 FAN
13 152230 CURRENT TRANSFORMER
14 169503 REACTOR
15 322065 BUCKLE FOR BELT
16 322112 GLAND
17 322138 GLAND
18 322408 BELT
19 322508 FRAME - FRONT PANEL
20 638044 FRONT
21 639527 RETRO
22 712231 TOLEDO 300 CLAMP MASS
23 742381 PLASMA TORCH 4 M 35A
24 980170 KIT TRANSFORMER
25 980253 KIT IGBT + DIODE
26 980254 KIT COAT
27 980255 KIT FORM
28 980256 KIT COMPRESSOR
29 980257 KIT BOTTOM BASE
30 980258 KIT TRANSFORMER
31 981273 KIT DIODES
32 980259 GLAND KIT
33 164741 CHOKE FILTER
TORCH FOR TECHNOLOGY PLASMA 54 KOMPRESSOR 230V – 815088 Pag.2
1 722677 BUTTON
2 990983 SPINE SAFETY KIT
3 802420 KIT 5 ELECTRODES
4 802422 KIT 5 INSULATION DIFFUSER
5 802423 KIT 5 NOZZLES
6 802485 KIT 2 SAFETY TORCH CAPS
7 742036 BODY TORCH
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
TECH PLASMA 54 KOMPR. 815088
11 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:
TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS

Specific References

New

Download

Diagram Technology PLASMA 54 K.

Diagram Technology PLASMA 54 K.

Download (457.14KB)
