Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI

SKU: 264D CE LOMBARDINI - 815980
€0.10
VAT included

Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for  gasoline or diesel Motoinverter 264D CE LOMBARDINI cod. 815980

264D CE LOMBARDINI - 815980

Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI
  • Out-of-Stock
  • Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI
  • Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI Drawing
Telwin s.p.a.

Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI

SKU: 264D CE LOMBARDINI - 815980 Condition: New
€0.10
VAT included

Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for  gasoline or diesel Motoinverter 264D CE LOMBARDINI cod. 815980

264D CE LOMBARDINI - 815980

settings 38 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

SHIPPING IN: Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN: TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
38 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 116369 RECTIFIER €11.20
2
 photo_cameraImage coming soon 116865 POTENTIOMETER €4.82
3
 photo_cameraImage coming soon 121220 POWER OUTLET €7.71
4
 photo_cameraImage coming soon 121268 SWITCH €4.82
5
 Small knob for Inverter Telwin 121395 Small knob for Inverter Telwin €0.32
6
 Potentiometer Big Knob for Inverter Telwin 121424 Potentiometer Big Knob for Inverter Telwin €1.16
7
 photo_cameraImage coming soon 122112 Fuse 8A €0.00 Not available for order
8
 photo_cameraImage coming soon 124054 POWER CORD €7.26
9
 photo_cameraImage coming soon 154006 DIESEL ENGINE €3,636.76
10
 photo_cameraImage coming soon 169574 POWER TRANSFORMER €17.02
11
 photo_cameraImage coming soon 242125 THREADED TIE ROD €6.45
12
 photo_cameraImage coming soon 322666 FRAME €2.38
13
 photo_cameraImage coming soon 322722 AIR FAN €3.57
14
 photo_cameraImage coming soon 322858 According Pinion Dv20vb2 €34.10
15
 photo_cameraImage coming soon 322875 ANTI €29.22
16
 photo_cameraImage coming soon 483818 DIAPHRAGM €13.36
17
 photo_cameraImage coming soon 522042 ALTERNATOR SHIELD €18.95
18
 photo_cameraImage coming soon 522045 BLADE FLANGE  €34.10
19
 photo_cameraImage coming soon 645142 FAN COVER €11.20
20
 photo_cameraImage coming soon 645333 COVER CLIP €28.00
21
 photo_cameraImage coming soon 645376 RIGHT REINFORCEMENT €4.82
22
 photo_cameraImage coming soon 645377 RINFORZO left €6.04
23
 photo_cameraImage coming soon 645378 BATTERY SUPPORT BRAKET €21.90
24
 photo_cameraImage coming soon 645379 BACK €26.78
25
 photo_cameraImage coming soon 645394 BASE ASSY €181.72
26
 photo_cameraImage coming soon 649987 DASHBOARD €13.36
27
 photo_cameraImage coming soon 651119 COAT €31.66
28
 photo_cameraImage coming soon 655953 LEFT COVER €20.68
29
 photo_cameraImage coming soon 655954 RIGHT COVER €20.68
30
 Socket DX 25 for Telwin Welding Machine 712035 Socket DX 25 for Telwin Welding Machine €3.60
31
 photo_cameraImage coming soon 980490 KIT ROTOR COMPLETE €318.36
32
 photo_cameraImage coming soon 980491 KIT PRIMARY CARD €364.72
33
 photo_cameraImage coming soon 980492 KITSECONDARY CARD €331.78
34
 photo_cameraImage coming soon 980493 FEET KIT €13.36
35
 photo_cameraImage coming soon 980693 KIT CONTROL CARD €141.46
36
 photo_cameraImage coming soon 980775 Battery €118.28
37
 Black Charging Clamp Kit for Inverter Telwin BIMAX 990073 Black Charging Clamp Kit for Inverter Telwin BIMAX €9.47
38
 photo_cameraImage coming soon 990976 KIT VENTILATORE €45.21

Shipping and delivery information will be available shortly.

Telwin Spare Parts for Motoinveter 264D CE LOMBARDINI

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for  gasoline or diesel Motoinverter 264D CE LOMBARDINI cod. 815980

Inverter technology, petrol engine-driven (HONDA engine) welding machine with high frequency permanent magnets alternator for electrode MMA and TIG-DC welding with scratch striking. Use with a wide range of electrodes: rutile, basic, cellulosic, stainless steel, cast iron, etc. It can also beused as direct current (DC) generator for powering electrical tools such as drills, sanders, etc. Characteristics: 4-stroke, air cooled petrol engine with recoil starter * shutdown for lack of oil *over-fast engine safeguard * continuous welding current adjustment * high current stability by variations in engine revs * arc-force, hot start, anti-stick devices * welding machine-generator selector switch * thermostatic protection.

In the following table, look for the model of the drill and the respective parts of the code.
264D CE LOMBARDINI - 815980

MOTOINVERTER 264D CE LOMBARDINI cod.815980
1 RECTIFIER 116369
2 POTENTIOMETER 116865
3 POWER OUTLET 121220
4 SWITCH 121268
5 KNOB 121395
6 KNOB 121424
7 FUSE 8A 122112
8 POWER CORD 124054
9 DIESEL ENGINE 154006
10 TRASFORMER 169574
11 THREADED TIE ROD 242125
12 FRAME 322666
13 FAN 322722
14 BELT 322858
15 DAMPER 322875
16 DIAPHRAGM 483818
17 ALTERNATOR SHIELD 522042
18 FLANGE 522045
19 FAN COVER 645142
20 FRONT 645333
21 RIGHT REINFORCEMENT 645376
22 LEFT REINFORCEMENT 645377
23 BATTERY SUPPORT BRAKET 645378
24 BACK 645379
25 BASE ASSY 645394
26 DASHBOARD 649987
27 MANTLE 651119
28 LEFT COVER 655953
29 RIGHT COVER 655954
30 PLUG DX 25 712035
31 KIT ROTOR COMPLETE 980490
32 KIT PRIMARY CARD 980491
33 KITSECONDARY CARD 980492
34 KIT FEET 980493
35 KIT CONTROL CARD 980693
36 BATTERY 980775
37 KIT BLACK CHARGE CLAMP 990073
38 KIT FAN 990976

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

264D CE LOMBARDINI - 815980

Data sheet

CHECK ITEM OR S/N CODE TELWIN
TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
SHIPPING IN
Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

Download

Diagram Motoinverter 264D CE L.

Diagram Motoinverter 264D CE L.

Download (276.87KB)

Manual Motoinverter 264D-CE

Manual Motoinverter 264D-CE

Download (594.27KB)
