Telwin Spare Parts for Welding Superior 630 CE VRD 400V - 816032

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Welding Inverter SUPERIOR 630 CE VRD 400V - 816032

MMA inverter, electrode welding machine in direct current (DC). Use with a wide range of electrodes:rutile, basic, stainless steel, cast iron, etc. Recommended for motorgenerators, this model grants high performance despite power supply instability, thanks to the MPGE multiprotections: control device of the wave form, filter against input peaks, stabilization of oscillations. Characteristics:compact and light * high welding current stability in spite of mains voltage fluctuations * arc force, hot start and anti-stick devices * thermostatic, overvoltage, undervoltage, overcurrent protections.

In the following table, look for the model of the drill and the respective parts of the code.

SUPERIOR 630 CE 230-400V VRD - 816032
1	SWITCH	121505
2	WIRING REMOTE CONTROL	124633
3	TOWING HARNESS CONNECTOR	124672
4	CABLE ALIM. 4G06.00 L = 03:00	132361
5	FAN	152000
6	ADAPTOR AUXILIARY	164991
7	ADAPTOR AUXILIARY	169122
8	COVER HANDLE	322848
9	FRONT	322872
10	BACK	322873
11	SWITCH KNOB	323101
12	HANDLE	641005
13	BACK PANEL	642296
14	FRONT	642300
15	FUND	645447
16	COAT	651149
17	RIGHT SIDE	656108
18	LEFT SIDE	656109
19	PLUG DX 70/95	712037
20	BLACK KNOB SET	980772
21	DATA ENTRY FILTER KIT	980947
22	KIT 10 DIODES	981005
23	PANEL + CARD KIT	981410
24	KIT INTERFACE CARD MIG	981412
25	BOARD KIT PRIMARY	981413
26	POWER TRANSFORMER KIT	981415
27	KIT FORM SECONDARY	981417
28	BOARD KIT INDUCTOR	981418
29	GLAND NUT + KIT	990046
