Telwin s.p.a.

Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC

SKU: ADVANCE 187 MV/PFC - 816009
€7.47
VAT included

Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Welding inverter Tig ADVANCE 187 MV/PFC 100-240V-816009.

ADVANCE 187 MV/PFC - 816009

Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC
  • Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC
  • Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC - Drawing
Telwin s.p.a.

Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC

SKU: ADVANCE 187 MV/PFC - 816009 Condition: New
€7.47
VAT included

Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Welding inverter Tig ADVANCE 187 MV/PFC 100-240V-816009.

ADVANCE 187 MV/PFC - 816009

settings 33 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:: TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
33 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 Controller UCC2818AD for Inverter Telwin Advance 187 MV/PFC 111037 Controller UCC2818AD for Inverter Telwin Advance 187 MV/PFC €7.48
2
 photo_cameraImage coming soon 111091 COND.ALL.RAD. 470U 450V €11.08
3
 Potentiometer for Inverter Telwin Force 125-145-165 112017 Potentiometer for Inverter Telwin Force 125-145-165 €4.03
4
 Wire Resistance for Inverter Telwin Force 145 - 165 - 195 112048 Wire Resistance for Inverter Telwin Force 145 - 165 - 195 €2.91
5
 Diode for Inverter Telwin Advance 187-TIG 227 113286 Diode for Inverter Telwin Advance 187-TIG 227 €2.62
6
 Relay 14VDC for Inverter Telwin 116320 Relay 14VDC for Inverter Telwin €5.42
7
 Single-Phase Rectifier for Inverter Telwin 144-164 116346 Single-Phase Rectifier for Inverter Telwin 144-164 €6.82
8
 Diode for Inverter Telwin Tecnica 151-S - 171-S - 211-S 116839 Diode for Inverter Telwin Tecnica 151-S - 171-S - 211-S €7.24
9
 Wire Resistance for Inverter Telwin Tecnica TIG 190 DC-Lift Vrd 230v 116962 Wire Resistance for Inverter Telwin Tecnica TIG 190 DC-Lift Vrd 230v €2.42
10
 PWM Controller for Inverter Force TIG 170 DC-LIFT 116966 PWM Controller for Inverter Force TIG 170 DC-LIFT €3.45
11
 Small knob for Inverter Telwin 121395 Small knob for Inverter Telwin €0.61
12
 photo_cameraImage coming soon 121555 THERMAL SWITCH €8.44
13
 Green Switch for Inverter Telwin Force 125-145-165-195 122381 Green Switch for Inverter Telwin Force 125-145-165-195 €5.42
14
 photo_cameraImage coming soon 132356 MAINS CABLE 3G1.5 2.30 M €9.11
15
 Fan for Inverter TIG Force-Superior 152006 Fan for Inverter TIG Force-Superior €13.79
16
 Power Adapter for Inverter Telwin 152230 Power Adapter for Inverter Telwin €7.34
17
 Pulse Transformer for Inverter Telwin 152247 Pulse Transformer for Inverter Telwin €10.43
18
 Fan for Inverter Technology-Technomig 152269 Fan for Inverter Technology-Technomig €17.98
19
 photo_cameraImage coming soon 152277 AMMETER SHUNT €2.03
20
 Inductance Filter for Inverter Telwin 164741 Inductance Filter for Inverter Telwin €6.99
21
 Inductance for Inverter Telwin Tecnica 151/S 169907 Inductance for Inverter Telwin Tecnica 151/S €11.54
22
 photo_cameraImage coming soon 169700 TRANSFORMER X FLYBACK €13.78
23
 photo_cameraImage coming soon 169736 POWER TRAFO €33.82
24
 photo_cameraImage coming soon 169738 INDUCTANCE €29.13
25
 photo_cameraImage coming soon 322692 FRONT PANEL €14.47
26
 Back-Cover for Inverter Telwin Technology Tig 182-230 322694 Back-Cover for Inverter Telwin Technology Tig 182-230 €16.58
27
 photo_cameraImage coming soon 322695 HANDLE €8.13
28
 Socket MMQ 25 DX for Telwin Welding Machine 712000 Socket MMQ 25 DX for Telwin Welding Machine €2.63
29
 Kit IGBT + Diode for Inverter Telwin Tecnica 151/171S 980614 Kit IGBT + Diode for Inverter Telwin Tecnica 151/171S €27.00
30
 photo_cameraImage coming soon 981174 COVER KIT €12.01
31
 photo_cameraImage coming soon 981175 COMPLETE PCB KIT €356.88
32
 Kit IGBT + Diode for Inverter Telwin Advance 187 MV/PFC 100-240V 981176 Kit IGBT + Diode for Inverter Telwin Advance 187 MV/PFC 100-240V €24.95
33
 photo_cameraImage coming soon 990913 KIT FUND €13.51

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Telwin Spare Parts for Welding Inverter Tig Advance 187 MV/PFC

We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Welding inverter Tig ADVANCE 187 MV/PFC 100-240V-816009.
In the following table, look for the model of the drill and the respective parts of the code.
ADVANCE 187 MV/PFC - 816009
ADVANCE 187 MV/PFC 100-240V-816009
# Description Part Num.
1 INT.PFC CONTROLLER UCC2818AD SO16 111037
2 COND.ALL.RAD. 470U 450V 111091
3 POTENTIOMETER 112017
4 RESISTANCE 112048
5 DIODE 113286
6 RELAIS 116320
7 RECTIFIER 116346
8 DIODE 116839
9 RESISTANCE 10R 2W 5% FUSE 116962
10 PWM CONTROLLER 116966
11 KNOB 121395
12 THERMAL SWITCH 121555
13 SWITCH 122381
14 MAINS CABLE 3G1.5 2.30 M 132356
15 FAN 152006
16 CURRENT TRANSFORMER 152230
17 PULSE TRANSFORMER 152247
18 FAN 152269
19 AMMETER SHUNT 152277
20 FILTER INDUCTANCE 164741
21 INDUCTANCE 169907
22 TRANSFORMER X FLYBACK 169700
23 POWER TRAFO 169736
24 INDUCTANCE 169738
25 FRONT PANEL 322692
26 BACK PANEL 322694
27 HANDLE 322695
28 SOCKET DX 25 712000
29 KIT IGBT + DIODE 980614
30 COVER KIT 981174
31 COMPLETE PCB KIT 981175
32 IGBT + DIODE KIT 981176
33 BOTTOM KIT 990913
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
ADVANCE 187 MV/PFC - 816009
9 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:
TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS

Specific References

New

Download

Diagram Telwin 187 MV/PFC

Diagram Telwin 187 MV/PFC

Download (342.46KB)
