STIGA Spare Parts for Lawnmower DINO 47 (2019)

Name: STIGA Spare Parts for Lawnmower DINO 47 (2019)
Brand: GGP Italy
SKU: DINO 47 (2019) [292470148/S16
Availability: InStock

SKU: DINO 47 (2019) [292470148/S16

€206.08

VAT included

STIGA Spare Parts for Lawnmower DINO 47 (2019) 292470148/S16

STIGA authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Lawnmower DINO 47 (2019) [292470148/S16.

COMBI 55 SVEQ H 294557538/ST1

137 spare parts

Page 1 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	381004733/0 Grey Deck	€183.11
6	Image coming soon	322600159/0 Stone Guard, Black	€10.63
7	Image coming soon	381008502/0 Outfit, Screws	€4.43
8	Image coming soon	322041958/0 Bushing	€1.48
9	Image coming soon	112793701/0 Screw	€1.64
10	Image coming soon	122671651/0 Washer	€2.11
11	Image coming soon	322551577/0 Isolation Plate	€3.03
12	Image coming soon	112155000/0 Nut	€1.66
13	Image coming soon	381007548/0 Handle, Lower Part Yellow	€25.79
14	Image coming soon	112361005/0 Nut	€4.26
15	Image coming soon	322399810/0 Knob	€8.29
16	Image coming soon	112521350/0 Washer	€1.74
17	Image coming soon	122430311/0 Guide Spring	€6.91
18	Image coming soon	112820655/0 Screw	€1.61
19	Image coming soon	322545137/0 Plate For Handle Fastening	€1.64
38	Image coming soon	322192001/0 Anchor Clamp	€1.64
39	Image coming soon	112728691/0 Screw	€1.64
40	Image coming soon	114367494/2 Label STIGA logo	€9.39

Page 2 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	381006632/1 Handle, Upper Part Yellow	€29.23
2	Image coming soon	381003298/1 Lever, Engine Brake From 01-September-2004 To 31-August-2010	€32.00
3	Image coming soon	181000685/0 Cable, Thread Engine Brake From 01-September-2014	€12.33
4	Image coming soon	322551640/0 Plate	€7.99
4		322551685/0 Cable Plate for Lawn Mower DINO 47	€7.97
5	Image coming soon	112727783/0 Screw	€1.83
6	Image coming soon	112154510/0 Nut	€1.66

Page 3 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	322033395/0 Axle	€9.52
2	Image coming soon	122450442/0 Spring, Right	€1.55
3	Image coming soon	122450441/0 Left Spring	€1.55
4	Image coming soon	122671654/0 Washer	€2.33
5	Image coming soon	112521370/0 Washer	€1.64
5	Image coming soon	122671659/0 Washer	€1.59
6	Image coming soon	322600095/0 Inner Wheel Cover	€1.55
7	Image coming soon	122122200/0 Bearing	€2.21
7	Image coming soon	122122202/0 Bearing To S/N 20BA2WBH028059	€2.07
7		122122206/0 Bearing Axial Int.Diam-12 for Lawn Mower DINO 47	€2.01
8	Image coming soon	322686091/1 Wheel From 01-september-2006	€6.38
8	Image coming soon	381007346/0 Wheel To 31-august-2006	€6.45
10	Image coming soon	122020050/0 Ring	€1.59
11		322110491/0 Wheel Hub Cap Grey for Lawnmower Castelgarden 142 G	€3.14
12	Image coming soon	122430215/0 Spring	€3.11

Page 4 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	1111-9066-01 Hub Stiga Packed into 122465617/0	€18.54
1	Image coming soon	122465617/0 Hub	€7.85
2	Image coming soon	1111-9502-02 Blade Standard Stiga Packed into 181004124/1	€16.32
2	Image coming soon	181004124/1 Standard blade 45 cm	€13.75
3	Image coming soon	112530140/0 Washer	€2.00
4	Image coming soon	112735694/0 Screw	€2.05
5		112139100/0 Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ	€2.09
6		112735108/1 Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ	€2.19
7	Image coming soon	112521355/0 Washer	€1.48

Page 5 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	118550941/1 Engine Assembly	€226.19
2	Image coming soon	112292102/0 Nut	€1.86
3	Image coming soon	118551467/0 Starter Assy	€71.57
4	Image coming soon	118551619/0 Starter handle	€8.98
5	Image coming soon	118550779/0 Starting Rope	€7.18
6	Image coming soon	118551621/0 Starter Spring	€10.10
7	Image coming soon	118551620/0 Starter Pulley	€15.36
8	Image coming soon	118551626/0 Spring	€2.46
9	Image coming soon	118551622/0 Starter ratchet	€3.02
10	Image coming soon	118551625/0 Spring	€3.15
11	Image coming soon	118551623/0 Cover	€7.88
13	Image coming soon	118551624/0 Pulley pin	€4.26
14	Image coming soon	118550908/0 Air conveyor	€37.58
15	Image coming soon	118550907/0 Pin	€5.22
16	Image coming soon	118550906/0 Pin	€4.82
17	Image coming soon	112791500/0 Screw	€1.64
18	Image coming soon	118551475/0 Electronic Coil	€51.95
20		9400-0244-00 Spark Plug Champion RC12YC	€6.06
21	Image coming soon	112789000/0 Screw	€1.77
22	Image coming soon	118551456/0 Starter control	€23.41
23	Image coming soon	118551459/0 Rod	€8.36
24	Image coming soon	118551352/0 Stopper	€3.72
25	Image coming soon	118551451/1 Carburetor	€72.35
26	Image coming soon	118550930/0 Stud Bolt	€5.79
27	Image coming soon	118550929/0 Gasket	€1.64
28	Image coming soon	118550928/0 Insulator, Carburettor	€3.02
29	Image coming soon	118550927/0 Gasket	€4.82
30	Image coming soon	118550924/0 Gasket	€1.78
31	Image coming soon	118551461/0 Air Filter Assy	€30.64
32	Image coming soon	118550946/0 Filter	€3.30
33	Image coming soon	118550945/0 Filter	€3.16
34	Image coming soon	118550944/0 Air Filter Cover	€8.91
35	Image coming soon	112292102/0 Nut	€1.86
36		118551481/0 Fuel Pipe for Lawnmower Alpina BL 460	€7.32
37	Image coming soon	118550918/0 Clamp	€1.64
38	Image coming soon	118550314/0 Fuel Filter	€4.41
39	Image coming soon	118551454/0 Tank	€40.34
40		118550943/0 Tank Cap for Engine Lawnmower Alpina AL5 51 G	€16.78
41	Image coming soon	112792099/0 Screw	€1.63
42	Image coming soon	118550920/0 Breather Fuel Pipe	€4.26
43	Image coming soon	118550933/0 Throttle Lever	€6.21
44	Image coming soon	118550931/0 Plate	€4.18
45	Image coming soon	112789000/0 Screw	€1.77
46	Image coming soon	118550932/0 Spring	€1.64
47	Image coming soon	118550805/0 Screw	€1.63
48	Image coming soon	118550806/0 Nut	€1.63
49	Image coming soon	118550925/0 Throttle rod	€1.64
50	Image coming soon	118550898/0 Muffler gasket	€2.47
51	Image coming soon	118551464/0 Muffler	€33.42
52	Image coming soon	112792425/0 Screw	€1.83
53	Image coming soon	118550900/0 Muffler protection	€20.91
54	Image coming soon	118551277/0 Bolt	€1.42

Page 6 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	118550336/0 Nut	€6.07
2	Image coming soon	118550905/0 Flywheel Assy	€82.72
3	Image coming soon	118551277/0 Bolt	€1.42
4	Image coming soon	112791500/0 Screw	€1.64
5	Image coming soon	118551483/0 Flywheel Brake Assy	€38.97
6	Image coming soon	118550911/0 Spring	€38.97
7	Image coming soon	118550300/0 Oil Seal	€7.25
9	Image coming soon	112789000/0 Screw	€1.77
10	Image coming soon	118550904/0 Cover	€4.30
11	Image coming soon	118550903/0 Gasket	€3.30
12	Image coming soon	118550902/0 Valve	€2.05
13	Image coming soon	118551447/0 Crankshaft	€104.19
14	Image coming soon	118550288/0 Woodruff Key	€6.20
15	Image coming soon	118550283/0 Washer	€3.44
16	Image coming soon	118550890/0 Shaft Camm	€30.64
18	Image coming soon	112789000/0 Screw	€1.77
19	Image coming soon	118550888/0 Control	€16.49
20	Image coming soon	118550936/0 Shaft, Governor Arm	€6.49
22	Image coming soon	118550935/0 Oil Seal	€4.57
23	Image coming soon	118550856/0 Cotter Pin	€1.55
24	Image coming soon	118550379/0 Oil Seal	€6.76
25	Image coming soon	118551209/0 Engine crankcase	€77.83
26	Image coming soon	118550887/0 Oil cap Assy	€10.93
27	Image coming soon	112791500/0 Screw	€1.64
28	Image coming soon	118551276/0 Bolt	€3.44
29	Image coming soon	118550891/0 Valve Cover	€13.35
30	Image coming soon	118550892/0 Screw	€3.30
31	Image coming soon	118550893/0 Rocker Valve Arm	€13.08
32	Image coming soon	118550894/0 Plate	€4.13
33	Image coming soon	118550895/0 Retainer	€4.57
34	Image coming soon	118550896/0 Spring	€2.87
35	Image coming soon	118550910/0 Valve Assy, Intake + Exhaust	€21.34
36	Image coming soon	118550291/0 Valve Lifter Assy	€9.73
37	Image coming soon	118550912/0 Push Rod	€7.61
38	Image coming soon	118551482/0 Piston	€64.47
39	Image coming soon	118551445/0 Piston Ring Assy	€26.75
40	Image coming soon	118550915/0 Piston Pin	€5.38
41	Image coming soon	118550914/0 Washer, Piston Pin	€1.63
42	Image coming soon	118550916/0 Connecting rod assy	€24.94
45	Image coming soon	118550940/0 Engine Gasket Assy	€25.09

Page 7 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	322055629/0 Gray Cover	€5.08
2	Image coming soon	322055630/0 Yellow Cover	€6.48
3	Image coming soon	322055627/0 Gray Cover	€5.09

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

STIGA Spare Parts for Lawnmower DINO 47 (2019) 292470148/S16

STIGA authorized service center

and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Lawnmower DINO 47 (2019) 292470148/S16.

In the following table, look for the model of the Lawn Mower and the respective parts of the code.

Lawnmower DINO 47 (2019) 292470148/S16 pag.1
#	Part Num.	Description
1	381004733/0	Grey Deck
6	322600159/0	Stone Guard, Black
7	381008502/0	Outfit, Screws
8	322041958/0	Bushing
9	112793701/0	Screw
10	122671651/0	Washer
11	322551577/0	Isolation Plate
12	112155000/0	Nut
13	381007548/0	Handle, Lower Part Yellow
14	112361005/0	Nut
15	322399810/0	Knob
16	112521350/0	Washer
17	122430311/0	Starting Rope Guide Spring
18	112820655/0	Screw
19	322545137/0	Handle, Upper Part Plate
38	322192001/0	Clamp
39	112728691/0	Screw
40	114367494/2	Logo STIGA
DINO 47 (2019) 292470148/S16 pag.2
1	381006632/1	Handle, Upper Part Yellow
2	381003298/0	Lever, Engine Brake To 31-August-2004
2	381003298/1	Lever, Engine Brake From 01-September-2004
3	181000685/0	Cable, Thread Engine Brake From 01-September-2014
4	322551640/0	Plate To S/N 20AA2WBH066503
4	322551685/0	Plate Cable ø22 From S/N 20AA2WBH066504
5	112727783/0	Screw
6	112154510/0	Nut
DINO 47 (2019) 292470148/S16 pag.3
1	322033375/0	Axle To 31-August-2006
1	322033395/0	Axle
2	122450442/0	Spring, Right
3	122450441/0	Left Spring
4	122671654/0	Washer
5	112521370/0	Washer From 01-September-2015
5	122671659/0	Washer To 31-August-2015
6	322600095/0	Protection, Wheel
7	122122200/0	Bearing From 01-September-2006 To 31-August-2019
7	122122202/0	Bearing To S/N 20BA2WBH028059
7	122122206/0	Bearing From S/N 20BA2WBH028060
8	322686091/1	Wheel Ø 165 From 01-September-2006
8	381007346/0	Wheel To 31-August-2006
10	122020050/0	Ring
11	322110491/0	Hub Cap Grey
12	122430215/0	Spring
DINO 47 (2019) 292470148/S16 pag.4
1	1111-9066-01	Hub Stiga Packed into 122465617/0
1	122465617/0	Hub
2	1111-9502-02	Blade Standard Stiga Packed into 181004124/1
2	181004124/0	Blade Standard To 31-August-2007
2	181004124/1	Blade Standard From 01-September-2007
3	112530140/0	Washer
4	112735694/0	Screw
5	112139100/0	Key
6	112735108/0	Screw To 31-August-2007
6	112735108/1	Screw From 01-September-2007
7	112521355/0	Washer
DINO 47 (2019) 292470148/S16 pag.5
1	118550941/1	Engine Assembly
2	112292102/0	Nut
3	118551467/0	Starter Assy Cover
4	118551619/0	Starter handle
5	118550779/0	Starter rope
6	118551621/0	Starter spring
7	118551620/0	Starter Pulley
8	118551626/0	Spring
9	118551622/0	Starter Pawl
10	118551625/0	Spring
11	118551623/0	Cover
13	118551624/0	Recoil Pulley Bolt
14	118550908/0	Fan Cover
15	118550907/0	Pin
16	118550906/0	Pin
17	112791500/0	Screw
18	118551475/0	Electronic Ignition coil
20	9400-0244-00	Spark Plug
21	112789000/0	Screw
22	118551456/0	Auto-Choke Control
23	118551459/0	Choke Control Rod
24	118551352/0	Retaining Clip
25	118551451/1	Carburetor
26	118550930/0	Stud Bolt
27	118550929/0	Gasket
28	118550928/0	Carburettoe Insulator
29	118550927/0	Gasket
30	118550924/0	Gasket
31	118551461/0	Air Filter Assembly
32	118550946/0	Filter element
33	118550945/0	Filter element
34	118550944/0	Air Filter Cover
35	112292102/0	Nut
36	118551481/0	Fuel Pipe
37	118550918/0	Pipe Clip
38	118550314/0	Fuel Filter
39	118551454/0	Fuel Tank
40	118550943/0	Tank Tank cap
41	112792099/0	Screw
42	118550920/0	Breather fuel pipe
43	118550933/0	Governor Arm
44	118550931/0	Plate
45	112789000/0	Screw
46	118550932/0	Spring
47	118550805/0	Screw
48	118550806/0	Nut
49	118550925/0	Governor rod
50	118550898/0	Muffler gasket
51	118551464/0	Muffler
52	112792425/0	Screw
53	118550900/0	Muffler Guard
54	118551277/0	Bolt
DINO 47 (2019) 292470148/S16 pag.6
1	118550336/0	Nut
2	118550905/0	Flywheel Ass.Y
3	118551277/0	Bolt
4	112791500/0	Screw
5	118551483/0	Flywheel Brake/Stop Switch
6	118550911/0	Spring
7	118550300/0	Oil Seal
9	112789000/0	Screw
10	118550904/0	Cover
11	118550903/0	Oil Breath gasket
12	118550902/0	Valve
13	118551447/0	Crankshaft
14	118550288/0	Woodruff key
15	118550283/0	Washer
16	118550890/0	Camshaft
18	112789000/0	Screw
19	118550888/0	Speed Governor
20	118550936/0	Governor Arm shaft
21	118550666/0	Washer
22	118550935/0	Oil Seal
23	118550856/0	Cotter pin
24	118550379/0	Oil Seal
25	118551209/0	Engine crankcase
26	118550887/0	Oil Dipstick Assy
27	112791500/0	Screw
28	118551276/0	Bolt
29	118550891/0	Head Cover
30	118550892/0	Gasket
31	118550893/0	Rocker Valve Arm Set
32	118550894/0	Plate
33	118550895/0	Retainer Valve Spring
34	118550896/0	Spring
35	118550910/0	Intake + Exhaust Valve Kit
36	118550291/0	Valve lifter assy
37	118550912/0	Push Rod
38	118551482/0	Piston
39	118551445/0	Piston Ring Set
40	118550915/0	Piston pin
41	118550914/0	Circlip
42	118550916/0	Connecting rod
43	118551223/0	Dowl pin
45	118550940/0	Engine Gaskets Set
DINO 47 (2019) 292470148/S16 pag.7
1	322055629/0	Engine Cover Insert Grey]
2	322055630/0	Stiga Ext.Insert Cover St120-140 Yellow
3	322055627/0	Premium Insert Cover Grey]

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Reference DINO 47 (2019) [292470148/S16

Available 12 Items

Data sheet

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:: STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS

Specific References

Condition New

Download

Diagram STIGA DINO 47 (2019)

Download (1.29MB)

GGP Italy SKU: 122122206/0

Bearing Axial Int.Diam-12 for Lawn Mower DINO 47

Bearing Axial Int.Diam-12 for Lawn Mower DINO 47 Original spare part Alpina, Bearing Axial Int.Diam= 12 Omet 1000861 for Lawn Mower DINO 47 - BL 450. Parts for the following products: - BL 450 (2020) - BL 450 (2021) - DINO 47 (2011) -...

on 7/10 Business Days Approx €2.01

Details

GGP Italy SKU: 322551685/0

Cable Plate for Lawn Mower DINO 47

Cable Plate for Lawn Mower DINO 47 Original spare part Alpina, Cable Plate ø22 From S/N 20AA2WBH066504 for Lawn Mower DINO 47 - BL 450. Parts for the following products: - LAWNMOWER CASTELGARDEN XC 48 GSW4 - L AWNMOWER ALPINA BL 460...

on 7/10 Business Days Approx €7.97

Details

GGP Italy SKU: 118550943/0

Tank Cap for Engine Lawnmower Alpina AL5 51 G

Tank Cap for Engine Lawnmower Alpina AL5 51 G Original replacement part Alpina, Tank Cap for Engine Lawnmower Alpina AL5 51 G - BL 460 - HW531 PD - S481 PD ES. Part for the following products: - Lawnmower AL5 51 G - Lawnmower BL...

AVAILABLE €16.78

Details

GGP Italy SKU: 118551481/0

Fuel Pipe for Lawnmower Alpina BL 460

Fuel Pipe for Lawnmower Alpina BL 460 Original part Alpina, Fuel Pipe for Lawnmowers BL 460 - BL 460 S - BL 510 SQ - AL3 45. Part for the following products: - Lawnmower ALPINA BL...

on 7/10 Business Days Approx. €7.32

Details

Comments (0)

Cart (0)

Subcategories

Subcategories

Subcategories

Power Tools Spare Parts

Garden Spare Parts

Air Compressor Spare Parts

Protezione & Edilizia

Impianti & Utensili

Casa & Giardino

STIGA Spare Parts for Lawnmower DINO 47 (2019)

STIGA Spare Parts for Lawnmower DINO 47 (2019) 292470148/S16

STIGA Spare Parts for Lawnmower DINO 47 (2019)

STIGA Spare Parts for Lawnmower DINO 47 (2019) 292470148/S16

STIGA Spare Parts for Lawnmower DINO 47 (2019) 292470148/S16

Data sheet

Specific References

Download

Diagram STIGA DINO 47 (2019)

You might also like

Products

News

Notes

Our company
