settings 152 spare parts
description 9 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on Demand Only Call Us Before

SHIPPING IN:: ON DEMAND ONLY
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:: STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
152 spare parts
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
10
 photo_cameraImage coming soon 1812-2803-01 Chute  €169.19
20
 photo_cameraImage coming soon 1812-2805-01 Wing knob €5.74
30
 photo_cameraImage coming soon 1812-9032-01 Shear bolt kit  €5.51
40
 photo_cameraImage coming soon 1812-0812-01 Nut €4.69
40
 photo_cameraImage coming soon 1812-2795-01 Chute rotation assy €47.88
50
 photo_cameraImage coming soon 1812-1609-01 Key  €4.77
60
 photo_cameraImage coming soon 1812-2793-01 Auger pulley €76.78
70
 photo_cameraImage coming soon 1812-2804-01 Gear case assy  €400.68
80
 photo_cameraImage coming soon 1812-2780-01 Impeller  €95.59
90
 photo_cameraImage coming soon 1812-2553-01 Hub-impeller  €10.42
Page 1 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
10
 photo_cameraImage coming soon 9988-3751-12 Screw €3.74
80
 photo_cameraImage coming soon 1812-2605-01 Clutch lever-LH  €10.87
100
 photo_cameraImage coming soon 1812-2511-01 Speed lever €23.79
120
 photo_cameraImage coming soon 9988-3545-12 Screw €1.95
130
 photo_cameraImage coming soon 1812-2417-01 Controls brkt  €18.22
140
 photo_cameraImage coming soon 1812-2751-01 Rod, speed control  €16.51
175
 photo_cameraImage coming soon 9683-0030-02 Spring washer €2.28
180
 photo_cameraImage coming soon 1812-2738-01 Bracket, mounting €6.00
190
 photo_cameraImage coming soon 1812-2562-01 Ball joint €18.05
340
 photo_cameraImage coming soon 1812-2257-01 Screw €9.08
360
 photo_cameraImage coming soon 1812-2623-01 Shoulder bolt €6.17
370
 photo_cameraImage coming soon 1812-2381-01 Chute guard €35.66
370
 photo_cameraImage coming soon 9899-3625-16 Screw €2.33
390
 photo_cameraImage coming soon 1812-2426-01 Grommet  €8.14
390
 photo_cameraImage coming soon 1812-2575-01 Dash support  €55.07
400
 photo_cameraImage coming soon 1812-2478-01 Push nut €7.02
400
 photo_cameraImage coming soon 1812-2542-01 Drive cable-auger €29.50
410
 photo_cameraImage coming soon 1812-2606-01 Clutch lever-RH  €10.45
420
 photo_cameraImage coming soon 1812-2256-01 Nut €5.61
430
 photo_cameraImage coming soon 1812-2351-01 Hand grip  €8.90
440
 photo_cameraImage coming soon 1812-2412-01 Stepped spacer €5.57
450
 photo_cameraImage coming soon 1812-2148-01 Spacer €9.33
490
 photo_cameraImage coming soon 1812-2479-01 Carriage bolt €7.28
495
 photo_cameraImage coming soon 1812-2476-01 Carriage bolt €4.46
500
 photo_cameraImage coming soon 1812-2519-01 Handle-lower €154.83
530
 photo_cameraImage coming soon 1812-2641-01 Screw €6.44
540
 photo_cameraImage coming soon 1133-0977-01 Cable adjust bracket €4.83
550
 photo_cameraImage coming soon 1133-0968-01 Clutch spring boot €7.26
560
 photo_cameraImage coming soon 1812-2029-01 Cable Clutch SNOW €15.56
670
 photo_cameraImage coming soon 1812-2371-01 Self lock tie  €6.59
680
 photo_cameraImage coming soon 1812-2379-01 Knob €8.90
700
 photo_cameraImage coming soon 9699-0026-02 Flat washer  €1.95
880
 photo_cameraImage coming soon 1812-2765-01 Screw €5.14
930
 photo_cameraImage coming soon 9743-3521-32 Nut €2.07
940
 photo_cameraImage coming soon 1812-2481-01 Screw €3.86
950
 photo_cameraImage coming soon 1812-2256-01 Nut €5.61
Page 2 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
10A
 photo_cameraImage coming soon 795027 Fuel Cap €9.80
50
 photo_cameraImage coming soon 9899-3638-12 Screw €1.81
60
 photo_cameraImage coming soon 1812-1681-01 Retainer  €5.70
90
 photo_cameraImage coming soon 1812-1719-01 Engine pulley  €86.33
100
 photo_cameraImage coming soon 1812-2248-01 Washer €9.08
110
 photo_cameraImage coming soon 1812-2640-01 Set screw  €7.39
110
 photo_cameraImage coming soon 9987-5132-12 Screw €1.49
120
 photo_cameraImage coming soon 1812-2220-01 Belt-traction drive  €45.12
130
 photo_cameraImage coming soon 1812-2784-01 Belt-auger €40.78
140
 photo_cameraImage coming soon 1812-2443-01 Belt guide  €8.14
150
 photo_cameraImage coming soon 9683-0030-02 Spring washer €2.28
170
 photo_cameraImage coming soon 1812-1722-01 Idler bracket  €15.32
180
 photo_cameraImage coming soon 1812-1705-01 Bushing  €3.37
190
 photo_cameraImage coming soon 1812-1830-01 Extidler spring €8.30
200
 photo_cameraImage coming soon 1812-2077-01 Tension roller  €60.01
200
 photo_cameraImage coming soon 1812-2771-01 Screw €4.88
220
 photo_cameraImage coming soon 9899-3732-16 Screw €2.59
230
 photo_cameraImage coming soon 1812-2796-01 Auger idler  €57.12
280
 photo_cameraImage coming soon 1812-2407-01 Clevis pin  €4.12
290
 photo_cameraImage coming soon 1812-2465-01 Bottom cover €54.22
300
 photo_cameraImage coming soon 1812-2250-01 Screw €5.94
300
 photo_cameraImage coming soon 1812-2278-01 Washer €6.58
310
 photo_cameraImage coming soon 1812-1676-01 Spring  €7.23
350
 photo_cameraImage coming soon 1812-2141-01 Screw €9.08
370
 photo_cameraImage coming soon 1812-2748-01 Screw €7.88
390A
 photo_cameraImage coming soon 1812-2505-01 Foam seal  €7.03
400
 photo_cameraImage coming soon 1812-2614-01 Seal strip €11.48
410
 photo_cameraImage coming soon 9987-5125-16 Screw €2.19
420
 photo_cameraImage coming soon 1812-2281-01 Cotter pin  €11.38
500
 photo_cameraImage coming soon 1812-2657-01 Flat washer  €4.88
510
 photo_cameraImage coming soon 9699-0038-02 Flat washer  €1.93
Page 3 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
200
 photo_cameraImage coming soon 1812-1686-01 Chain  €70.91
210
 photo_cameraImage coming soon 1812-1178-01 Bearing & retainer €21.54
220
 photo_cameraImage coming soon 1812-1204-01 Washer €5.08
230
 photo_cameraImage coming soon 1812-2249-01 Screw €6.25
240
 photo_cameraImage coming soon 1812-1688-01 Chain  €67.26
250
 photo_cameraImage coming soon 1812-1672-01 Retainer ring €8.01
260
 photo_cameraImage coming soon 1812-2076-01 Spring link €20.71
300
 photo_cameraImage coming soon 1812-2410-01 Extension spring €6.17
310
 photo_cameraImage coming soon 1812-1751-01 Sprocket set €104.48
320
 photo_cameraImage coming soon 9699-0038-02 Flat washer  €1.93
340
 photo_cameraImage coming soon 1812-1862-01 Axle shaft - DISCONTINUED €73.61
350
 photo_cameraImage coming soon 1812-1755-01 Screw €7.14
430
 photo_cameraImage coming soon 1812-1724-01 Axle bearing €13.64
440
 photo_cameraImage coming soon 1812-1750-01 Hex shaft  €61.14
450
 photo_cameraImage coming soon 1812-2734-01 Hub, friction wheel  €55.83
460
 photo_cameraImage coming soon 1812-9028-01 Friction disc wheel €65.53
510
 photo_cameraImage coming soon 9795-3531-02 Nut €2.18
520
 photo_cameraImage coming soon 1812-2380-01 Retext ring €5.14
550
 photo_cameraImage coming soon 1812-1739-01 Spacer €9.51
560
 photo_cameraImage coming soon 1812-1725-01 Friction pulley €166.31
610
 photo_cameraImage coming soon 1812-1219-01 Plastic bushing  €12.75
620
 photo_cameraImage coming soon 9743-3521-32 Nut €2.07
630
 photo_cameraImage coming soon 9988-3538-12 Screw €1.81
640
 photo_cameraImage coming soon 1812-1205-01 Spool  €7.44
650
 photo_cameraImage coming soon 1812-1702-01 Bracket  €3.95
660
 photo_cameraImage coming soon 1812-1727-01 Drive cable-lower €15.58
Page 4 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
30
 photo_cameraImage coming soon 1812-2139-01 Retaining ring €7.58
60
 photo_cameraImage coming soon 1812-1114-01 Bolt €6.51
80
 photo_cameraImage coming soon 1812-0408-01 Clik pin €17.83
Page 5 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
10
 photo_cameraImage coming soon 1812-2774-01 Auger housing €425.64
20
 photo_cameraImage coming soon 1812-2778-01 Impeller housing  €170.47
30
 photo_cameraImage coming soon 1812-2789-01 Chimney €42.15
40
 photo_cameraImage coming soon 1812-2779-01 Bracket, rear mount €34.97
50
 photo_cameraImage coming soon 1812-2475-01 Screw €4.72
55
 photo_cameraImage coming soon 1812-2619-01 Screw €4.88
60
 photo_cameraImage coming soon 1812-2783-01 Skid shoe-LH  €11.56
70
 photo_cameraImage coming soon 1812-2782-01 Skid shoe-RH  €11.56
80
 photo_cameraImage coming soon 1812-2785-01 Scraper bar  €45.07
100
 photo_cameraImage coming soon 9743-3521-32 Nut €2.07
110
 photo_cameraImage coming soon 1812-2400-01 Cleanout brush  €64.30
150
 photo_cameraImage coming soon 1812-2413-01 Spring clamp  €8.74
160
 photo_cameraImage coming soon 1812-2480-01 Screw €5.14
170
 photo_cameraImage coming soon 1812-1912-01 Nut €5.83
180
 photo_cameraImage coming soon 1812-0878-01 Bearing €7.44
190
 photo_cameraImage coming soon 9988-3619-16 Screw €2.33
210
 photo_cameraImage coming soon 1812-2142-01 Bearing retainer €16.23
220
 photo_cameraImage coming soon 1812-2346-01 Greased bearing  €22.92
240
 photo_cameraImage coming soon 9899-3516-16 Screw €2.55
250
 photo_cameraImage coming soon 9899-3622-16 Screw €2.99
300
 photo_cameraImage coming soon 1812-2254-01 Carriage bolt €2.73
310
 photo_cameraImage coming soon 1812-1317-01 Universal pivot block €9.59
Page 6 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 6
Pos. Item Price Buy
30
 photo_cameraImage coming soon 1812-9032-01 Shear bolt kit  €5.51
40
 photo_cameraImage coming soon 1812-0812-01 Nut €4.69
50
 photo_cameraImage coming soon 1812-1609-01 Key  €4.77
60
 photo_cameraImage coming soon 1812-2793-01 Auger pulley €76.78
70
 photo_cameraImage coming soon 1812-2804-01 Gear case assy  €400.68
80
 photo_cameraImage coming soon 1812-2780-01 Impeller  €95.59
90
 photo_cameraImage coming soon 1812-2553-01 Hub-impeller  €10.42
100
 photo_cameraImage coming soon 1812-2249-01 Screw €6.25
110
 photo_cameraImage coming soon 1812-2640-01 Set screw  €7.39
Page 7 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
10
 photo_cameraImage coming soon 1812-2781-01 Impeller shaft  €63.87
30
 photo_cameraImage coming soon 1812-2786-01 Auger shaft €45.91
40
 photo_cameraImage coming soon 1812-1321-01 Thrust collar  €26.26
50
 photo_cameraImage coming soon 1133-0395-01 Roll pin €8.17
60
 photo_cameraImage coming soon 1812-0857-01 Thrust washer €13.35
70
 photo_cameraImage coming soon 1812-0285-01 Needle bearing  €17.83
80
 photo_cameraImage coming soon 1812-1360-01 Flange bearing €9.60
90
 photo_cameraImage coming soon 1812-0881-01 Oil seal  €31.67
100
 photo_cameraImage coming soon 1812-1359-01 Bushing  €9.25
110
 photo_cameraImage coming soon 1812-0908-01 Gear case-LH  €51.48
120
 photo_cameraImage coming soon 1812-0909-01 Gear case-RH  €51.48
150
 photo_cameraImage coming soon 1812-1371-01 Woodruff key  €6.51
160
 photo_cameraImage coming soon 1812-2798-01 Worm gear €36.86
170
 photo_cameraImage coming soon 1812-1758-01 Nut €6.33
180
 photo_cameraImage coming soon 1812-1361-01 Gasket  €6.93
Page 8 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 8
Pos. Item Price Buy
10
 photo_cameraImage coming soon 1812-2803-01 Chute  €169.19
20
 photo_cameraImage coming soon 1812-2805-01 Wing knob €5.74
40
 photo_cameraImage coming soon 1812-2795-01 Chute rotation assy €47.88
100
 photo_cameraImage coming soon 9743-3521-32 Nut €2.07
110E
 photo_cameraImage coming soon 1812-0203-01 Grommet  €7.05
110B
 photo_cameraImage coming soon 1812-1171-01 Washer €10.09
110C
 photo_cameraImage coming soon 1812-1483-01 Retainer  €6.56
110G
 photo_cameraImage coming soon 1812-1707-01 Chute crank  €34.43
110D
 photo_cameraImage coming soon 1812-1821-01 Eye bolt  €7.58
140H
 photo_cameraImage coming soon 1812-1316-01 Universal pin €14.83
140J
 photo_cameraImage coming soon 1812-1317-01 Universal pivot block €9.59
140I
 photo_cameraImage coming soon 1812-1318-01 Clevis pin  €7.93
140D
 photo_cameraImage coming soon 1812-1706-01 Gear €11.23
140G
 photo_cameraImage coming soon 1812-1708-01 Yoke adapter €20.35
140B
 photo_cameraImage coming soon 1812-1761-01 Spring  €12.29
140E
 photo_cameraImage coming soon 1812-1791-01 Hair pin  €7.26
140A
 photo_cameraImage coming soon 1812-1826-01 Yoke and rod  €14.03
140K
 photo_cameraImage coming soon 1812-2794-01 Mounting bracket  €47.04
140F
 photo_cameraImage coming soon 9599-0033-00 Split pin  €1.81
150
 photo_cameraImage coming soon 9743-3521-32 Nut €2.07
200
 photo_cameraImage coming soon 1812-2771-01 Screw €4.88
300
 photo_cameraImage coming soon 1812-2278-01 Washer €6.58
370
 photo_cameraImage coming soon 1812-2381-01 Chute guard €35.66
390
 photo_cameraImage coming soon 1812-2426-01 Grommet  €8.14
400
 photo_cameraImage coming soon 1812-2478-01 Push nut €7.02

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Stiga Spare Parts for Snow Throrowers Snow Fox

Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Snow Throrowers Snow Fox/18-2869-32-2015.

In the following table, look for the model of the Snow Throrowers and the respective parts of the code.
Snow Throrowers Snow Fox/18-2869-32-2015
Snow Throrowers Snow Fox/18-2869-32-2015 Handle Pag.1
# Part Num. Description
10 9988-3751-12 Screw
80 1812-2605-01 Clutch lever-LH
100 1812-2511-01 Speed lever
120 9988-3545-12 Screw
130 1812-2417-01 Controls brkt
140 1812-2751-01 Rod, speed control
175 9683-0030-02 Spring washer
180 1812-2738-01 Bracket, mounting
190 1812-2562-01 Ball joint
340 1812-2257-01 Screw
360 1812-2623-01 Shoulder bolt
370 9899-3625-16 Screw
390 1812-2575-01 Dash support
400 1812-2542-01 Drive cable-auger
410 1812-2606-01 Clutch lever-RH
420 1812-2256-01 Nut
430 1812-2351-01 Hand grip
440 1812-2412-01 Stepped spacer
450 1812-2148-01 Spacer
490 1812-2479-01 Carriage bolt
495 1812-2476-01 Carriage bolt
500 1812-2519-01 Handle-lower
530 1812-2641-01 Screw
540 1133-0977-01 Cable adjust bracket
550 1133-0968-01 Clutch spring boot
560 1812-1729-01 Control cable
670 1812-2371-01 Self lock tie
680 1812-2379-01 Knob
700 9699-0026-02 Flat washer
880 1812-2765-01 Screw
930 9743-3521-32 Nut
940 1812-2481-01 Screw
950 1812-2256-01 Nut
Snow Throrowers Snow Fox/18-2869-32-2015 Engine Pag.2
10A 795027 Fuel Cap
50 9899-3638-12 Screw
60 1812-1681-01 Retainer
90 1812-1719-01 Engine pulley
100 1812-2248-01 Washer
110 9987-5132-12 Screw
120 1812-2220-01 Belt-traction drive
130 1812-2784-01 Belt-auger
140 1812-2443-01 Belt guide
150 9683-0030-02 Lock washer
170 1812-1722-01 Idler bracket
180 1812-1705-01 Bushing
190 1812-1830-01 Extidler spring
200 1812-2077-01 Tension roller
220 9899-3732-16 Screw
230 1812-2796-01 Auger idler
280 1812-2407-01 Clevis pin
290 1812-2465-01 Bottom cover
300 1812-2250-01 Screw
310 1812-1676-01 Spring
350 1812-2141-01 Screw
370 1812-2748-01 Screw
390A 1812-2505-01 Foam seal
400 1812-2614-01 Seal strip
410 9987-5125-16 Screw
420 1812-2281-01 Cotter pin
500 1812-2657-01 Flat washer
510 9699-0038-02 Flat washer
Snow Throrowers Snow Fox/18-2869-32-2015 Traction Drive Pag.3
200 1812-1686-01 Chain
210 1812-1178-01 Bearing & retainer
220 1812-1204-01 Washer
230 1812-2249-01 Screw
240 1812-1688-01 Chain
250 1812-1672-01 Retainer ring
260 1812-2076-01 Spring link
300 1812-2410-01 Extension spring
310 1812-1751-01 Sprocket set
320 9699-0038-02 Flat washer
340 1812-1862-01 Axle shaft - DISCONTINUED
350 1812-1755-01 Screw
420 1812-1712-01 Sprocket - DISCONTINUED
430 1812-1724-01 Axle bearing
440 1812-1750-01 Hex shaft
450 1812-2734-01 Hub, friction wheel
460 1812-9028-01 Friction disc wheel
510 9795-3531-02 Nut
520 1812-2380-01 Retext ring
550 1812-1739-01 Spacer
560 1812-1725-01 Friction pulley
610 1812-1219-01 Plastic bushing
620 9743-3521-32 Nut
630 9988-3538-12 Screw
640 1812-1205-01 Spool
650 1812-1702-01 Bracket
660 1812-1727-01 Drive cable-lower
Snow Throrowers Snow Fox/18-2869-32-2015 Whell Pag.4
30 1812-2139-01 Retaining ring
60 1812-1114-01 Bolt
80 1812-0408-01 Clik pin
Snow Throrowers Snow Fox/18-2869-32-2015 Auger Housing Pag.5
10 1812-2774-01 Auger housing
20 1812-2778-01 Impeller housing
30 1812-2789-01 Chimney
40 1812-2779-01 Bracket, rear mount
50 1812-2475-01 Screw
55 1812-2619-01 Screw
60 1812-2783-01 Skid shoe-LH
70 1812-2782-01 Skid shoe-RH
80 1812-2785-01 Scraper bar
100 9743-3521-32 Nut
110 1812-2400-01 Cleanout brush
150 1812-2413-01 Spring clamp
160 1812-2480-01 Screw
170 1812-1912-01 Nut
180 1812-0878-01 Bearing
190 9988-3619-16 Screw
210 1812-2142-01 Bearing retainer
220 1812-2346-01 Greased bearing
240 9899-3516-16 Screw
250 9899-3622-16 Screw
300 1812-2254-01 Carriage bolt
310 1812-1317-01 Universal pivot block
Snow Throrowers Snow Fox/18-2869-32-2015 Auger Drive Pag.6
30 1812-9032-01 Shear bolt kit
40 1812-0812-01 Nut
50 1812-1609-01 Key
60 1812-2793-01 Auger pulley
70 1812-2804-01 Gear case assy
80 1812-2780-01 Impeller
90 1812-2553-01 Hub-impeller
100 1812-2249-01 Screw
110 1812-2640-01 Set screw
Snow Throrowers Snow Fox/18-2869-32-2015 Gear Case Pag.7
10 1812-2781-01 Impeller shaft
30 1812-2786-01 Auger shaft
40 1812-1321-01 Thrust collar
50 1133-0395-01 Roll pin
60 1812-0857-01 Thrust washer
70 1812-0285-01 Needle bearing
80 1812-1360-01 Flange bearing
90 1812-0881-01 Oil seal
100 1812-1359-01 Bushing
110 1812-0908-01 Gear case-LH
120 1812-0909-01 Gear case-RH
150 1812-1371-01 Woodruff key
160 1812-2798-01 Worm gear
170 1812-1758-01 Nut
180 1812-1361-01 Gasket
Snow Throrowers Snow Fox/18-2869-32-2015 Discharge Case Pag.8
10 1812-2803-01 Chute
20 1812-2805-01 Wing knob
40 1812-2795-01 Chute rotation assy
100 9743-3521-32 Nut
110B 1812-1171-01 Washer
110C 1812-1483-01 Retainer
110D 1812-1821-01 Eye bolt
110E 1812-0203-01 Grommet
110G 1812-1707-01 Chute crank
140A 1812-1826-01 Yoke and rod
140B 1812-1761-01 Spring
140D 1812-1706-01 Gear
140E 1812-1791-01 Hair pin
140F 9599-0033-00 Split pin
140G 1812-1708-01 Yoke adapter
140H 1812-1316-01 Universal pin
140I 1812-1318-01 Clevis pin
140J 1812-1317-01 Universal pivot block
140K 1812-2794-01 Mounting bracket
150 9743-3521-32 Nut
200 1812-2771-01 Screw
300 1812-2278-01 Washer
370 1812-2381-01 Chute guard
390 1812-2426-01 Grommet
400 1812-2478-01 Push nut
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stiga websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stiga brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Stiga Snow Fox 18-2869-32-2015
12 Items

Data sheet

SHIPPING IN:
ON DEMAND ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:
STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS

Specific References

New

Download

Diagram Stiga Snow Fox

Diagram Stiga Snow Fox

Download (1.1MB)

You might also like

Stiga Snow Fox Bolt
GGP Italy SKU: 1812-0809-01 ex 1812-9032-01
Stiga Snow Fox Bolt
Stiga Snow Throrowers Snow Fox Bolt Original replacement part Stiga, Shear Bolt for Snow Throrowers Snow Fox/18-2869-32-2015. Part for the following products: -  Snow Throrowers Snow Fox/18-2869-32-2015 -...
on Demand Only €5.66
Details
Comments (0)
