Stayer Spare Parts for Orbital Sander LOM185
Stayer genuine spare parts for the replacement or repair of
Orbital Sander LOM185- Prepared for the 'aspiration
- Softgrips
- Electronic
In the following table, look for the model of the SANDERS and the respective parts of the code.
|
SANDER Stayer LOM185 |
| # |
Part Num. |
Description |
| 2 |
5019467 |
LEFT HOUSING |
| 3 |
5019468 |
INDUCTANCE |
| 4 |
5019469 |
BRUSH HOLDER COVER |
| 5 |
5019470 |
CARBON BRUSH |
| 6 |
5019471 |
BRUSH HOLDER |
| 7 |
5019472 |
SWITCH |
| 8 |
5019473 |
STATOR |
| 9 |
5019474 |
RIGHT HOUSING |
| 10 |
- |
SPEC. LABEL |
| 11 |
5019475 |
SCREW |
| 12 |
5019476 |
SCREW |
| 13 |
5019477 |
CABLE CLAMP |
| 14 |
5019478 |
CABLE ARMOR |
| 15 |
- |
CABLE AND PLUG |
| 16 |
5019479 |
CAPACITOR |
| 17 |
5019480 |
WOOLEN FELT RING |
| 18 |
5019481 |
BASE SEAT |
| 19 |
5019482 |
O RING |
| 20 |
5019483 |
MOVABLE PIN SLEEVE |
| 21 |
5019484 |
MOVABLE PIN |
| 22 |
5019485 |
TAPPER GROOVED PIN |
| 23 |
5019486 |
PAPER LOCKER |
| 24 |
5019487 |
TORSIONAL SPRING |
| 25 |
5019488 |
BEARING 6002-2RS |
| 26 |
5019489 |
BALANCE BLOCK |
| 27 |
5019490 |
WASHER |
| 28 |
5019491 |
SCREW |
| 29 |
5019492 |
WOOLING RING |
| 30 |
5019493 |
BASE PLATE |
| 31 |
5019494 |
SPONGE SHEET |
| 32 |
5019495 |
FLAT WASHER |
| 33 |
5019496 |
SPRING WASHER |
| 34 |
5019497 |
SCREW |
| 35 |
5019498 |
SCREW |
| 36 |
5019499 |
ANTI-DUST RING |
| 37 |
5019500 |
FLAT WASHER |
| 38 |
5019501 |
ARMATURE |
| 39 |
5019502 |
BEARING 627-2RZ |
| 40 |
5019503 |
BEARING SLEEVE |
| 41 |
5019504 |
CIRCLIP |
| 42 |
5019505 |
DUST BAG |
| 43 |
- |
SANDING PAPER |
| 44 |
5019506 |
FLAT WASHER |
| 45 |
5019507 |
FLEXIBLE RUBBER BLOCK |
| 46 |
5019508 |
CIRCLIP |
