Stayer Spare Parts for Pressure Washer HL110
Stayer genuine spare parts or replacements parts for to fix Pressure Washer HL110
In the following table, look for the model of the Pressure Washer and the respective parts of the code.

| Pressure Washer Stayer HL110 |
| # |
Part Num. |
Description |
| 1 |
813710 |
WATER OUTLET JOINT |
| 2 |
813711 |
SPRING |
| 3 |
813712 |
O-RING |
| 4 |
813713 |
COVER VALVE SET |
| 10 |
813719 |
PRESOSTATE VALVE SET |
| 17 |
813726 |
PUMP HEAD |
| 18 |
813727 |
SCREW INTERNAL HEXAGONAL |
| 19 |
813728 |
SPRING GASKET |
| 20 |
813729 |
SCREW INTERNAL HEXAGONAL |
| 21 |
813730 |
O-RING |
| 22 |
813731 |
WATER INLET JOINT |
| 23 |
813732 |
FILTER |
| 24 |
813733 |
HANDSPIKE OF SWITCH |
| 25 |
813734 |
HANDSPIKE SPRING |
| 26 |
813735 |
CONNECTION NUT |
| 27 |
813736 |
V-RING |
| 28 |
813737 |
O-RING |
| 29 |
813738 |
CONNECTION NUT |
| 30 |
813739 |
SWITCH RIGHT AND LEFT COVER |
| 31 |
813740 |
MICRO SWITCH |
| 34 |
813743 |
PUMP SET |
| 36 |
813745 |
O-RING |
| 37 |
8137242 |
VALVE ASSEMBLY |
| 41 |
813750 |
O-RING |
| 42 |
813751 |
INLET & OUTLET VALVE CAP |
| 52 |
813761 |
BALL BEARING 51107B |
| 53 |
813762 |
SCREW INTERNAL HEXAGONAL |
| 54 |
813763 |
BEARING SEAT |
| 55 |
813764 |
BEARING 6302 |
| 56 |
813765 |
SEAL |
| 57 |
813766 |
INDUCTION MOTOR |
| 58 |
813779 |
MOTOR FAN |
| 59 |
8137253 |
PRESOSTATE SET |
| 60 |
8137252 |
SET COVER |
| 2 |
813768 |
SWITCH COVER |
| 3 |
813769 |
SWITCH |
| 4 |
813770 |
CONNECTING BOX |
| 5 |
813771 |
CAPACITOR |
| 6 |
813772 |
HANDLE |
| 7 |
813773 |
FRONT COVER |
| 8 |
813774 |
BACK FRONT |
| 9 |
813775 |
WHEEL |
| 10 |
813776 |
SPRAY LANCE |
| 11 |
81373 |
TURBO LANCE |
| 12 |
813777 |
HIGH PRESSURE HOSE 36 MP |
| 13 |
813778 |
DETERGENT BOTTLE |
| 14 |
8137246 |
MIDDLE LANCE |
| 15 |
8137247 |
HANDLE LANCE |
| 16 |
81371 |
CIRCULAR BRUSH |
| 17 |
81372 |
BRUSH |
| 18 |
81377 |
BRUSH 200 MM |
| 19 |
81375 |
RACOR |
| 20 |
81374 |
RACOR |
| - |
813780 |
COMPLETE MOTOR (ASSY) |
