Stayer Spare Parts for Rotary Hammer HD6K

SKU: Stayer HD6K
€2.77
VAT included

Stayer Spare Parts for Rotary Hammer HD6K

We have the original Spares STAYER for Rotary Demolition Hammer HD6K the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Demolition Hammer HD6K. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Stayer Spare Parts for Rotary Hammer HD6K
  • Stayer Spare Parts for Rotary Hammer HD6K
  • Stayer Spare Parts for Rotary Hammer HD6K

Stayer Spare Parts for Rotary Hammer HD6K

SKU: Stayer HD6K Condition: New
€2.77
VAT included

Stayer Spare Parts for Rotary Hammer HD6K

We have the original Spares STAYER for Rotary Demolition Hammer HD6K the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Demolition Hammer HD6K. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 72 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

72 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 42051238 SEAL RING €1.59
5
photo_cameraImage coming soon 42051242 PROTECTING COVER €3.09
6
photo_cameraImage coming soon 42051243 SPRING €1.49
7
photo_cameraImage coming soon 42051244 ROTATION SLEEVE €29.59
9
photo_cameraImage coming soon 42051246 ORING €2.59
11
photo_cameraImage coming soon 42051248 IMPACT HAMMER €1.59
12
photo_cameraImage coming soon 42051249 FRONT COVER    €10.59
13
photo_cameraImage coming soon 42051250 SCREW €10.59
14
photo_cameraImage coming soon 42051251 SPRING WASHER €1.59
15
photo_cameraImage coming soon 42051252 OIL SEAL WASHER €2.59
16
photo_cameraImage coming soon 42051253 BEARING 61907-2LS €3.59
17
photo_cameraImage coming soon 42051254 WASHER €1.49
18
photo_cameraImage coming soon 42051255 INNER SLEEVE €2.59
19
photo_cameraImage coming soon 42051256 SPRING €1.49
20
photo_cameraImage coming soon 42051257 WASHER €1.59
21
photo_cameraImage coming soon 42051258 SCREW €1.59
22
photo_cameraImage coming soon 42051259 PLATE €6.59
23
photo_cameraImage coming soon 42051260 SPRING WASHER €1.59
24
photo_cameraImage coming soon 42051261 SCREW €1.59
28
photo_cameraImage coming soon 42051265 CYLINDER €12.59
29
photo_cameraImage coming soon 42051266 SHIFT SPRING €1.49
30
photo_cameraImage coming soon 42051267 IMPACT PISTON €7.59
31
photo_cameraImage coming soon 42051268 ORING €2.59
32
photo_cameraImage coming soon 42051269 SHIFT WHEEL €10.49
33
photo_cameraImage coming soon 42051270 TAPER GEAR €20.49
36
photo_cameraImage coming soon 42051273 BEARING 61906-2Z €3.59
38
photo_cameraImage coming soon 42051275 PISTON €5.59
39
photo_cameraImage coming soon 42051276 CONECTING ROD €4.59
40
photo_cameraImage coming soon 42051277 NEEDLE BEARING HK0810 €3.59
41
photo_cameraImage coming soon 42051278 RUBBER WASHER €1.49
43
photo_cameraImage coming soon 42051280 RUBBER WASHER €1.49
45
photo_cameraImage coming soon 42051282 LEFT COVER €4.09
48
photo_cameraImage coming soon 42051285 SHIFT LOCALIZER PIN €1.49
49
photo_cameraImage coming soon 42051286 SHIFT PIECE €2.09
50
photo_cameraImage coming soon 42051287 ROTATION BUTTON €2.09
54
photo_cameraImage coming soon 42051291 UP COVER €4.59
58
photo_cameraImage coming soon 42051295 ECCENTRIC SPINDLE €10.49
60
photo_cameraImage coming soon 42051297 HANDLE CONECT RUBBER €2.09
62
photo_cameraImage coming soon 42051299 HANDLE CONECT HOLDER €1.49
65
photo_cameraImage coming soon 42051302 GEAR HOUSING €10.49
66
photo_cameraImage coming soon 42051303 GEAR SPINDLE €10.49
67
photo_cameraImage coming soon 42051304 BEARING 6002-2Z €3.59
68
photo_cameraImage coming soon 42051305 CLUTCH INNER SLEEVE €5.09
69
photo_cameraImage coming soon 42051306 CLUTCH SPRING €1.49
71
photo_cameraImage coming soon 42051308 CLUTCH GEAR €9.49
72
photo_cameraImage coming soon 42051309 BIG PLATE €3.09
73
photo_cameraImage coming soon 42051310 SMALL PLATE €2.59
75
photo_cameraImage coming soon 42051312 BEARING 627-2Z €3.59
76
photo_cameraImage coming soon 42051313 BEARING 6202-2Z €3.59
82
photo_cameraImage coming soon 42051319 DRIVEN GEAR €5.59
84
photo_cameraImage coming soon 42051321 NEEDLE BEARING HK081410 €3.49
85
photo_cameraImage coming soon 42051322 INTERMEDIATE COVER SEAL RING €2.49
86
photo_cameraImage coming soon 42051323 INTERMEDIATE COVER €3.59
87
photo_cameraImage coming soon 42051324 STATOR €25.49
88
photo_cameraImage coming soon 42051325 HOUSING €9.49
89
photo_cameraImage coming soon 42051326 LEFT HANDLE €3.59
90
photo_cameraImage coming soon 42051327 BACK COVER €4.09
92
photo_cameraImage coming soon 42051329 CARBON BRUSH €10.59
93
photo_cameraImage coming soon 42051330 BRUSH HOLDER €3.59
97
photo_cameraImage coming soon 42051334 RIGHT COVER €3.59
99
photo_cameraImage coming soon 42051336 BEARING 6001-2RZ €3.49
100
photo_cameraImage coming soon 42051337 ARMATURE €49.59
101
photo_cameraImage coming soon 42051338 BEARING 627-2RZ €3.59
102
photo_cameraImage coming soon 42051339 BEARING SLEEVE €2.09
104
photo_cameraImage coming soon 42051341 FAN GUIDE €2.09
105
photo_cameraImage coming soon 42051342 CAPACITOR €2.09
106
photo_cameraImage coming soon 42051343 SWITCH €17.59
108
photo_cameraImage coming soon 42051345 SWITCH BUTTON €2.09
110
photo_cameraImage coming soon 42051347 RIGHT HANDLE €3.59
115
photo_cameraImage coming soon 42051352 CABLE ARMOR €2.09
116
photo_cameraImage coming soon 42051353 SPEED CONTROLER MODULE €24.09
128
photo_cameraImage coming soon 42051488 CLUTCH SET €28.59

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Stayer Spare Parts for Rotary Hammer HD6K

Fix Your Rotary Demolition Hammer HD6K. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the hammerr and the respective parts of the code.
Stayer HD6K

Rotary HAMMER HD6K
# Part Num. Description
1 42051238 SEAL RING
2 42051239 STEEL WIRE WASHER
3 42051240 WASHER
4 42051241 RUBBER SLEEVE
5 42051242 PROTECTING COVER
6 42051243 SPRING
7 42051244 ROTATION SLEEVE
8 42051245 STEEL BALL
9 42051246 ORING
10 42051247 ORING
11 42051248 IMPACT HAMMER
12 42051249 FRONT COVER
13 42051250 SCREW
14 42051251 SPRING WASHER
15 42051252 OIL SEAL WASHER
16 42051253 BEARING 61907-2LS
17 42051254 WASHER
18 42051255 INNER SLEEVE
19 42051256 SPRING
20 42051257 WASHER
21 42051258 SCREW
22 42051259 PLATE
23 42051260 SPRING WASHER
24 42051261 SCREW
25 42051262 RETAINING RING
26 42051263 STEEL BALL
27 42051264 NEEDLE PIN
28 42051265 CYLINDER
29 42051266 SHIFT SPRING
30 42051267 IMPACT PISTON
31 42051268 ORING
32 42051269 SHIFT WHEEL
33 42051270 TAPER GEAR
34 42051271 WASHER
35 42051272 STEEL WIRE WASHER
36 42051273 BEARING 61906-2Z
37 42051274 CYLINDRICAL PIN
38 42051275 PISTON
39 42051276 CONECTING ROD
40 42051277 NEEDLE BEARING HK0810
41 42051278 RUBBER WASHER
42 42051279 SCREW
43 42051280 RUBBER WASHER
44 42051281 SCREW
45 42051282 LEFT COVER
46 42051283 SCREW
47 42051284 SHIFT LOCALIZER SPRING
48 42051285 SHIFT LOCALIZER PIN
49 42051286 SHIFT PIECE
50 42051287 ROTATION BUTTON
51 42051288 ORING
52 42051289 ROTATION BUTTON SPRING
53 42051290 STEEL BALL
54 42051291 UP COVER
55 42051292 ROTATION WASHER
56 42051293 SCREW
57 42051294 RETAINING RING
58 42051295 ECCENTRIC SPINDLE
59 42051296 GEAR HOUSING CONECT HOLDER
60 42051297 HANDLE CONECT RUBBER
61 42051298 HANDLE SPRING
62 42051299 HANDLE CONECT HOLDER
63 42051300 WASHER
64 42051301 SCREW
65 42051302 GEAR HOUSING
66 42051303 GEAR SPINDLE
67 42051304 BEARING 6002-2Z
68 42051305 CLUTCH INNER SLEEVE
69 42051306 CLUTCH SPRING
70 42051307 CYLINDRICAL PIN
71 42051308 CLUTCH GEAR
72 42051309 BIG PLATE
73 42051310 SMALL PLATE
74 42051311 RETAINING RING
75 42051312 BEARING 627-2Z
76 42051313 BEARING 6202-2Z
77 42051314 PLATE
78 42051315 SPRING WASHER
79 42051316 SCREW
80 42051317 WASHER
81 42051318 KEY
82 42051319 DRIVEN GEAR
83 42051320 REAINING RING
84 42051321 NEEDLE BEARING HK081410
85 42051322 INTERMEDIATE COVER SEAL RING
86 42051323 INTERMEDIATE COVER
87 42051324 STATOR
88 42051325 HOUSING
89 42051326 LEFT HANDLE
90 42051327 BACK COVER
91 42051328 SCREW
92 42051329 CARBON BRUSH
93 42051330 BRUSH HOLDER
94 42051331 ROLL SPRING
95 42051332 SCREW
96 42051333 SCREW
97 42051334 RIGHT COVER
98 42051335 ORING
99 42051336 BEARING 6001-2RZ
100 42051337 ARMATURE
101 42051338 BEARING 627-2RZ
102 42051339 BEARING SLEEVE
103 42051340 SCREW
104 42051341 FAN GUIDE
105 42051342 CAPACITOR
106 42051343 SWITCH
107 42051344 SPRING
108 42051345 SWITCH BUTTON
109 42051346 SCREW
110 42051347 RIGHT HANDLE
111 42051348 SCREW
112 42051349 HANDLE WASHER
113 42051350 SCREW
114 42051351 CABLE CLAMP
115 42051352 CABLE ARMOR
116 42051353 SPEED CONTROLER MODULE
125 42051355 WASHER
126 42051356 ROLLER PIN
127 42051357 RUBBER WASHER
128 42051488 CLUTCH SET
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
