Stayer BJ120B Spare Parts

SKU: Stayer BJ120B
€0.50
VAT included

Stayer BJ120B Spare Parts

Stayer original spare parts at best price, the perfect solution to keep your Biscuit Joiner Machine BJ120B always efficient. Order now and receive spare parts directly to your home.
Stayer BJ120B Spare Parts
  • Stayer BJ120B Spare Parts
  • Stayer BJ120B Spare Parts Drawing

Stayer BJ120B Spare Parts

SKU: Stayer BJ120B Condition: New
€0.50
VAT included

Stayer BJ120B Spare Parts

Stayer original spare parts at best price, the perfect solution to keep your Biscuit Joiner Machine BJ120B always efficient. Order now and receive spare parts directly to your home.
settings 31 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

31 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
2
photo_cameraImage coming soon 5008.327 BEARING €3.32
3
photo_cameraImage coming soon 5008.328 ARMATURE €29.90
6
photo_cameraImage coming soon 5008.331 BEARING €5.18
8
photo_cameraImage coming soon 5008.333 FRONT HANDLE €4.86
11
photo_cameraImage coming soon 5008.336 GEAR BOX €7.34
14
photo_cameraImage coming soon 5008.339 COLUMN BEARING €1.97
16
photo_cameraImage coming soon 5008.341 GEAR €12.50
18
photo_cameraImage coming soon 5008.343 FRONT CAP €5.79
22
photo_cameraImage coming soon 5008.347 SPINDLE €9.40
24
photo_cameraImage coming soon 5008.349 BACK CAP €3.13
26
photo_cameraImage coming soon 5008.350 BRUSH HOLDER ( 2 PCS ) €5.00
27
photo_cameraImage coming soon 5008.351 BRUSHES ( 2 PCS ) €9.90
31
photo_cameraImage coming soon 5008.353 SWITCH €7.00
32
photo_cameraImage coming soon 5008.354 CAPACITANCE €10.00
38
photo_cameraImage coming soon 5008.359 HOUSING €7.66
40
photo_cameraImage coming soon 5008.361 STATOR €20.70
48
photo_cameraImage coming soon 5008.369 PINION €8.50
51
photo_cameraImage coming soon 5008.372 FLANGE €3.32
52
photo_cameraImage coming soon 12.870 GRINDING WHEEL €13.00
53
photo_cameraImage coming soon 5008.373 FLANGE UNT €3.32
57
photo_cameraImage coming soon 5008.377 SETTING WHEEL €1.47
59
photo_cameraImage coming soon 5008.379 SPRING €1.34
60
photo_cameraImage coming soon 5008.380 SLIDE PLATE €9.81
61
photo_cameraImage coming soon 5008.381 BASE PLATE €7.09
64
photo_cameraImage coming soon 5008.384 DEPTH MARK €1.72
65
photo_cameraImage coming soon 5008.385 SUPPORT STAND BOARD €7.28
67
photo_cameraImage coming soon 5008.387 ANGLE FENCE €4.75
70
photo_cameraImage coming soon 5008.390 PIVOT BRACKET €3.26
72
photo_cameraImage coming soon 5008.392 ANGLE RULER €3.57
76
photo_cameraImage coming soon 5008.396 DUST BAG €9.80
77
photo_cameraImage coming soon 5008.397 OBLIQUE PIPE €2.33

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Stayer BJ120B Spare Parts

Stayer original spare parts at best price, the perfect solution to keep your Biscuit Joiner Machine BJ120B always efficient. Order now and receive spare parts directly to your home.

In the following table, look for the spare part and its respectvive code.
Stayer LOM 230 Spare Parts
Stayer Biscuit Joiner Machine BJ120B
Pos. Code Description
1 5008.326 BEARING SET
2 5008.327 BEARING
3 5008.328 ARMATURE
4 5008.329 CHECK RING
5 5008.330 SPECIAL SCREW
6 5008.331 BEARING
7 5008.332 SCREW
8 5008.333 FRONT HANDLE
9 5008.334 STOP PIN
10 5008.335 SPRING
11 5008.336 GEAR BOX
12 5008.337 TAPPING CREW
13 5008.338 CHECK RING
14 5008.339 COLUMN BEARING
15 5008.340 SPRING WASHER
16 5008.341 GEAR
17 5008.342 SPECIAL SCREW
18 5008.343 FRONT CAP
19 5008.344 SPRING WASHER
20 5008.345 SCREW
21 5008.346 WOOD RUFF-KEY
22 5008.347 SPINDLE
23 5008.348 TAPPING CREW
24 5008.349 BACK CAP
26 5008.350 BRUSH HOLDER ( 2 PCS )
27 5008.351 BRUSHES ( 2 PCS )
28 5008.352 TAPPING CREW
31 5008.353 SWITCH
32 5008.354 CAPACITANCE
33 5008.355 SWITCH DRAWBAR
34 5008.356 SWITCH BUTTON
35 5008.357 SPRING
37 5008.358 CORD ARMOR
38 5008.359 HOUSING
39 5008.360 ROLLER
40 5008.361 STATOR
41 5008.362 FAN GUIDE
42 5008.363 WASHER
43 5008.364 SCREW
44 5008.365 SCREW
45 5008.366 NUT
46 5008.367 SCREW
47 5008.368 DEPTH BASE BLOCK
48 5008.369 PINION
49 5008.370 SPRING WASHER
50 5008.371 NUT
51 5008.372 FLANGE
52 12.870 GRINDING WHEEL
53 5008.373 FLANGE UNT
54 5008.374 SCREW
55 5008.375 SPRING
56 5008.376 STEEL BALL
57 5008.377 SETTING WHEEL
58 5008.378 SCREW
59 5008.379 SPRING
60 5008.380 SLIDE PLATE
61 5008.381 BASE PLATE
62 5008.382 SCREW
63 5008.383 SCREW
64 5008.384 DEPTH MARK
65 5008.385 SUPPORT STAND BOARD
66 5008.386 KNOB
67 5008.387 ANGLE FENCE
68 5008.388 SCREW
69 5008.389 ANGLE POINTER
70 5008.390 PIVOT BRACKET
71 5008.391 DOWEL
72 5008.392 ANGLE RULER
73 5008.393 CAP
74 5008.394 SCREW
75 5008.395 ENTRANCE FOR DUST
76 5008.396 DUST BAG
77 5008.397 OBLIQUE PIPE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Stayer BJ120B
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Stayer BJ120B Parts Drawing

Stayer BJ120B Parts Drawing

Download (607.66KB)
