Stayer Spare Parts for Rotary Hammer MH6BK
We supply
original STAYER spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for
Rotary Hammer MH6BK.
In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
| Rotary Hammer MH6BK |
| # |
Part Num. |
Description |
| 1 |
5014.409 |
FRONT COVER |
| 2 |
5014.410 |
STEEL RETAINING RING |
| 3 |
5014.411 |
RETAINING RING |
| 4 |
5014.412 |
STEEL BALL FRAME |
| 5 |
5014.413 |
STEEL BALL SPRING |
| 6 |
5014.414 |
TOOL HOLDER |
| 7 |
5014.415 |
STEEL BALL |
| 8 |
5014.416 |
O-RING |
| 9 |
5014.417 |
O-RING |
| 10 |
5014.418 |
IMPACT POLE |
| 11 |
5014.419 |
CIRCLIP FOR HOLE |
| 12 |
5014.420 |
OIL SEAL |
| 13 |
5014.421 |
STEEL CABLE RETAINING RING |
| 14 |
5014.422 |
BALL BEARING |
| 15 |
5014.423 |
AIR CYLINDER |
| 16 |
5014.424 |
STEEL BALL |
| 17 |
5014.425 |
FLAT KEY |
| 18 |
5014.426 |
AIR CYLINDER BOX |
| 19 |
5014.427 |
SCREW |
| 20 |
5014.428 |
SPRING WASHER |
| 21 |
5014.429 |
RESET SPRING |
| 22 |
5014.430 |
SPRING |
| 23 |
5014.431 |
SPRING HOLDER |
| 24 |
5014.432 |
BIG BEVEL GEAR |
| 25 |
5014.433 |
BIG SPRING |
| 26 |
5014.434 |
CLUTCH |
| 27 |
5014.435 |
RETAINING RING |
| 28 |
5014.436 |
AIR HAMMER |
| 29 |
5014.437 |
O-RING |
| 30 |
5014.438 |
PISTON |
| 31 |
5014.439 |
PISTON PIN |
| 32 |
5014.440 |
CONNECTING ROD |
| 33 |
5014.441 |
STEEL SLEEVE |
| 34 |
5014.442 |
OIL BEARING |
| 35 |
5014.443 |
OIL BAFFLE PLATE |
| 36-48 |
5014.444 |
CLUTCH SET |
| 49 |
5014.445 |
BALL BEARING |
| 50 |
5014.446 |
CIRCLIP FOR HOLE |
| 51 |
5014.447 |
CIRCLIP FOR SHAFT |
| 52 |
5014.448 |
PLUNGER SPRING |
| 53 |
5014.449 |
FLAT KEY |
| 54 |
5014.450 |
GEAR |
| 55 |
5014.451 |
SUPPORT COVER |
| 56 |
5014.452 |
MANDRIL |
| 57 |
5014.453 |
NEEDLE BEARING |
| 58 |
5014.454 |
GEARBOX |
| 59 |
5014.455 |
ECCENTRIC SHAFT |
| 60 |
5014.456 |
OIL COVER |
| 61 |
5014.457 |
TWO FUNCTION KNOB SHAFT |
| 62 |
5014.458 |
CIRCLIP FOR HOLE |
| 63-87 |
5014.459 |
LEFT+RIGTH GEAR COVER |
| 64 |
5014.460 |
BUTTON |
| 65 |
5014.461 |
BUTTON SPRING |
| 66 |
5014.462 |
KNOB |
| 67 |
5014.463 |
WASHER RING |
| 68 |
5014.464 |
SCREW |
| 69 |
5014.465 |
GASKET |
| 70 |
5014.466 |
MIDDLE COVER |
| 71 |
5014.467 |
THREE FUNCTION KNOB SHAFT |
| 72 |
5014.468 |
SCREW |
| 73 |
5014.469 |
BEARING |
| 74 |
5014.470 |
ROTOR |
| 75 |
5014.471 |
BEARING |
| 76 |
5014.472 |
BEARING SLEEVE |
| 77 |
5014.473 |
WIND GIUDE COVER |
| 78 |
5014.474 |
SCREW |
| 79 |
5014.475 |
STATOR |
| 80 |
5014.476 |
BRUSH HOLDER COVER |
| 81 |
5014.477 |
CARBON BRUSH SET |
| 82 |
5014.478 |
BRUSH HOLDER |
| 83 |
5014.479 |
SCREW |
| 84 |
5014.480 |
HOUSING |
| 85 |
5014.481 |
INDUCTANCE |
| 86-89 |
5014.482 |
LEFT + RIGHT HANDLE |
| 88 |
5014.483 |
SCREW |
| 90 |
5014.484 |
SCREW |
| 91 |
5014.485 |
SOFT COVER FOR ANTI-VIBRATION |
| 92 |
5014.486 |
SPRING FOR ANTI-VIBRATION |
| 93 |
5014.487 |
WASHER FOR ANTI-VIBRATION |
| 94 |
5014.488 |
SCREW FOR ANTI-VIBRATION |
| 95 |
5014.489 |
SWITCH |
| 96 |
5014.490 |
CAPACITOR |
| 97 |
5014.491 |
CABLE CLAMP |
| 98 |
5014.492 |
CABLE SLEEVE |
| 99 |
- |
CABLE |
| 100 |
5014.493 |
REAR COVER |
| 101 |
5014.494 |
AUX HANDLE SET |
