Stayer Spare Parts for Angle Grinder SAB22-230

We have the original Spares STAYER for Angle Grinder SAB22-230 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Angle Grinder SAB22-230. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.

In the following table, look for the model of the hammerr and the respective parts of the code.

ANGLE GRINDER SAB22-230
1	5000431	STATOR
2	5000432	AIR FAN
3	5000433	RUBBER BEARING
4	5000434	BEARING 609
5	5000435	COVER
6	5000436	ARMATURE
7	5000437	AIR FAN
8	5000438	CIRCLIP
9	5000439	BEARING 602
10	5000440	PINION
11	5000442	NUT
12	5000443	WASHER
13	5000444	SCREW
14	5000445	BUTTON
15	5000446	SPRING
16	5000447	WASHER
17	5000448	HEAD
18	5000449	HANDLE
19	5000450	BEARING 6003
20	5000451	WASHER
21	5000452	CROWN
22	5000453	CIRCLIP
23	5000454	BEARING 6001
24	5000455	RUBBER RING
25	5000456	HEAD COVER
26	5000457	SPINDLE
27	5000458	COVER
28	5000460	SCREW
29	5000461	WASHER
30	5000462	WASHER
31	5000463	CARTER
32	5000465	INNER FLANGE
34	5000466	OUTER FLANGE
36	5000467	SCREW
37	5000468	SPRING WASHER
38	5000469	WASHER
40	5000470	COVER
41	5000471	SCREW
42	5000472	CAP
43	5000473	CARBON BRUSH
44	5000474	CARBON BRUSH HOLDER
46	5000475	LEFT HANDLE
47	5000476	CABLE ARMOR
48	5000477	CABLE
49	5000478	PLETINE
50	5000479	SCREW
51	5000480	SCREW
52	5000481	SCREW
53	5000482	RIGHT HANDLE
54	5000483	SWITCH
55	5000484	SCREW
56	5000485	COVER
57	5000486	CAPACITOR
58	5000487	FIXING
59	5000488	SCREW
60	5000489	HOUSING
61	5000490	KEY
62	5000491	WRENCH
63	5000492	MODULE
64	5000.718	FAN
