Stayer Spare Parts for Angle Grinder SAB21-230

SKU: Stayer SAB21-230
€35.35
VAT included

Stayer Spare Parts for Angle Grinder SAB21-230

STAYER Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues forr Angle Grinder SAB21-230.
Stayer Spare Parts for Angle Grinder SAB21-230
  • Stayer Spare Parts for Angle Grinder SAB21-230
  • Stayer Spare Parts for Angle Grinder SAB21-230

Stayer Spare Parts for Angle Grinder SAB21-230

SKU: Stayer SAB21-230 Condition: New
€35.35
VAT included

Stayer Spare Parts for Angle Grinder SAB21-230

STAYER Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues forr Angle Grinder SAB21-230.
settings 38 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

38 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 50001 STATOR €34.33
2
photo_cameraImage coming soon 50002 AIR FAN €3.88
3
photo_cameraImage coming soon 50003 RUBBER BEARING €3.09
4
photo_cameraImage coming soon 50004 BEARING 609 €10.91
5
photo_cameraImage coming soon 50005 BEARING COVER €2.94
6
photo_cameraImage coming soon 50006 ARMATURE €89.01
7
photo_cameraImage coming soon 50007 AIR FAN €5.44
8
photo_cameraImage coming soon 50008 CIRCLIP €1.53
9
photo_cameraImage coming soon 50009 BEARING 6202 €10.91
10
photo_cameraImage coming soon 500010 PINION €15.58
11
photo_cameraImage coming soon 500011 SPACER €1.53
14
photo_cameraImage coming soon 500014 HEAD BUTTON €2.31
15
photo_cameraImage coming soon 500015 SPRING HEAD €1.53
16
photo_cameraImage coming soon 500016 RUBBER RING €1.53
17
photo_cameraImage coming soon 500017 HEAD €31.20
18
photo_cameraImage coming soon 500018 HANDLE €12.30
19
photo_cameraImage coming soon 500019 BEARING 6003 €8.56
20
photo_cameraImage coming soon 500020 WASHER €13.88
21
photo_cameraImage coming soon 500021 CROWN €31.05
23
photo_cameraImage coming soon 500023 BEARING 6001 €1.53
25
photo_cameraImage coming soon 500025 COVER €17.14
26
photo_cameraImage coming soon 500026 SPINDLE €20.27
27
photo_cameraImage coming soon 500027 COVER €12.30
31
photo_cameraImage coming soon 500031 BEARING FLANGE ASS'Y €17.14
32
photo_cameraImage coming soon 500032 INNER FLANGE €10.91
34
photo_cameraImage coming soon 500033 OUTER FLANGE €10.91
40
photo_cameraImage coming soon 500038 CARBON BRUSH CAP €6.22
43
Stayer Carbon Brushes for SAB21-180 500041 Stayer Carbon Brushes for SAB21-180 €15.88
44
photo_cameraImage coming soon 500042 CARBON BRUSH HOLDER €21.83
45
photo_cameraImage coming soon 500044 LEFT HANDLE €12.30
47
photo_cameraImage coming soon 500045 CABLE ARMOR €3.09
52
Recoil Starter Hook Expansion Spring for Motor Pump CM 25 500050 Recoil Starter Hook Expansion Spring for Motor Pump CM 25 €2.33
53
photo_cameraImage coming soon 500051 RIGHT HANDLE €8.56
54
Switch With Lock for Angle Grinder Stayer SAB 21/180 500052 Switch With Lock for Angle Grinder Stayer SAB 21/180 €25.13
57
photo_cameraImage coming soon 500055 CAPACITOR €5.74
60
photo_cameraImage coming soon 500058 HOUSING €35.89
61
photo_cameraImage coming soon 500059 SERVICE KEY €12.30
62
photo_cameraImage coming soon 500060 ALLEN KEY €12.30

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Stayer Spare Parts for Angle Grinder AB21-230

STAYER Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues forr Angle Grinder SAB21-230.

In the following table, find position number and spare part code.
Stayer SAB21-230 Spare parts

STAYER DISC GRINDER SAB21-230 PARTS LIST
# Part Num. Description
1 50001 STATOR
2 50002 AIR FAN
3 50003 RUBBER BEARING
4 50004 BEARING 609
5 50005 BEARING COVER
6 50006 ARMATURE
7 50007 AIR FAN
8 50008 CIRCLIP
9 50009 BEARING 6202
10 500010 PINION
11 500011 SPACER
12 500012 WASHER
13 500013 SCREW
14 500014 HEAD BUTTON
15 500015 SPRING HEAD
16 500016 RUBBER RING
17 500017 HEAD
18 500018 HANDLE
19 500019 BEARING 6003
20 500020 WASHER
21 500021 CROWN
22 500022 CIRCLIP
23 500023 BEARING 6001
24 500024 RUBBER RING
25 500025 COVER
26 500026 SPINDLE
27 500027 COVER
28 500028 CARTER SCREW
29 500029 WASHER
30 500030 WASHER
31 500031 CARTER
32 500032 INNER FLANGE
34 500033 OUTER FLANGE
36 500034 COVER SCREW
37 500035 WASHER
38 500036 WASHER
40 500038 CARBON BRUSH CAP (2PCS)
41 500039 SCREW
42 500040 COVER CARBON BRUSH
43 500041 CARBON BRUSH
44 500042 CARBON BRUSH HOLDER
45 500044 LEFT HANDLE
47 500045 CABLE ARMOR
49 500047 PLETINE
50 500048 SCREW
51 500049 SCREW
52 500050 SCREW
53 500051 RIGHT HANDLE
54 500052 SWITCH
55 500053 SCREW
56 500054 COVER
57 500055 CAPACITOR
58 500056 FIX
59 500057 SCREW
60 500058 HOUSING
61 500059 SERVICE KEY
62 500060 ALLEN KEY
