Bosch

Skil Spare Parts for Mixer 1016

SKU: Skil 1016 - F015101601
€31.07
VAT included

Skil Spare Parts for Mixer 1016

Skil original spare parts for to replace broken parts for to fix Mixer 1016 - F015101601.

Mixer 1016 - F015101601

Skil Spare Parts for Mixers 1016
  • Online only
  • Skil Spare Parts for Mixers 1016
  • Skil Spare Parts for Mixers 1016
Bosch

Skil Spare Parts for Mixer 1016

SKU: Skil 1016 - F015101601 Condition: New
€31.07
VAT included

Skil Spare Parts for Mixer 1016

Skil original spare parts for to replace broken parts for to fix Mixer 1016 - F015101601.

Mixer 1016 - F015101601

settings 21 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 15/20 Business Days Approx.

SHIPPING IN:: Usually Ships in:: 15/20 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
21 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in:: 15/20 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
4
 Switch for Mixer Skil 1016 2610Z03066 Switch for Mixer Skil 1016 €11.82
5
 photo_cameraImage coming soon 1607000386 Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F €30.17
5
 photo_cameraImage coming soon 2604460222 Power supply cord GB 230V 4,15m 2 x 1,0mm H05 RN-F €18.56
6
 photo_cameraImage coming soon 2610Z00596 Grommet €29.41
10
 Carbon Brushe Set for Mixer Skil 1016 2610Z03067 Carbon Brushe Set for Mixer Skil 1016 €9.73
26
 photo_cameraImage coming soon 2610Z00602 Deep-Groove Ball Bearing €7.49
28
 photo_cameraImage coming soon 2610Z00605 Spindle €40.99
29
 photo_cameraImage coming soon 2610Z00601 Gear €24.18
31
 Gasket for Mixer Skil 1016 2610Z03075 Gasket for Mixer Skil 1016 €1.88
801
 photo_cameraImage coming soon 2610Z03070 Housing Set €52.27
802
 photo_cameraImage coming soon 2610Z03069 Field €40.99
803
 photo_cameraImage coming soon 2610Z03065 Armature €80.48
812
 photo_cameraImage coming soon 2610Z00595 Suppression Capacitor €3.34
816
 Carbon Brushe Holder for Mixer Skil 1016 2610Z03068 Carbon Brushe Holder for Mixer Skil 1016 €9.72
824
 photo_cameraImage coming soon 2610Z00600 Parts Set €2.77
827
 photo_cameraImage coming soon 2610Z03073 Bearing Plate €21.53
830
 photo_cameraImage coming soon 2610Z00607 Set Of Gears €46.40
832
 photo_cameraImage coming soon 2610Z03076 Cover Plate €6.57
833
 photo_cameraImage coming soon 2610Z03077 Integrated circuit €24.18
834
 photo_cameraImage coming soon 2610Z03074 Gear Box €31.89
835
 Skil 1016 Potentiometer Ass'y 2610Z03078 Skil 1016 Potentiometer Ass'y €12.62

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Skil Spare Parts for Mixer 1016

Skil original spare parts for to replace broken parts for to fix Mixer 1016 - F015101601.

In the following table, look for the model of the Mixers and the respective parts of the code.
Mixer 1016

Mixer 1016/F 015 101 601
# Part Num. Description
4 2610Z03066 Switch
5 1607000386 Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F
5 2604460222 Power supply cord GB 230V 4,15m 2 x 1,0mm H05 RN-F
6 2610Z00596 Grommet
10 2610Z03067 Carbon-Brush Set
26 2610Z00602 Deep-Groove Ball Bearing
28 2610Z00605 Spindle
29 2610Z00601 Gear
31 2610Z03075 Gasket
36 2610Z03072 Tapping Screw
37 2610Z03071 Tapping Screw
801 2610Z03070 Housing Set
802 2610Z03069 Field
803 2610Z03065 Armature
807 2610Z00598 Cable Clip
812 2610Z00595 Suppression Capacitor
816 2610Z03068 Brush Holder
824 2610Z00600 Parts Set
827 2610Z03073 Bearing Plate
830 2610Z00607 Set Of Gears
832 2610Z03076 Cover Plate
833 2610Z03077 Integrated circuit
834 2610Z03074 Gear Box
835 2610Z03078 Potentiometer Assembly
