Skil Spare Parts for Percussion Drill 6950
€10.25
VAT included
Skil Spare Parts for Percussion Drill 6950
SKIL Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues forr Percussion Drill 6950 - F015695001.
Skil Spare Parts for Percussion Drill 6950
€10.25
VAT included
Skil Spare Parts for Percussion Drill 6950
SKIL Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues forr Percussion Drill 6950 - F015695001.
settings
10 spare parts
description
1 exploded view
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
10 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in:: 15/20 BUSINESS DAYS
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
| photo_cameraImage coming soon | 1604460124 Power supply cord GB 230V 2,65m 2 x 1,0mm H05 VV-F | €15.59 | ||
|
4
|
photo_cameraImage coming soon | 2610Z03460 On-Off Switch | €16.06 | |
|
5
|
photo_cameraImage coming soon | 2610362954 Power supply cord EU 2,65m 2 x 1,0mm H05 VV-F | €7.49 | |
|
650
|
photo_cameraImage coming soon | 2610397394 Auxiliary Handle | €7.23 | |
|
651
|
photo_cameraImage coming soon | 2610397395 Depth-Gauge | €2.09 | |
|
801
|
photo_cameraImage coming soon | 2610Z03464 Motor Housing | €30.54 | |
|
803
|
photo_cameraImage coming soon | 2610Z03456 Armature 230V | €30.54 | |
|
820
|
photo_cameraImage coming soon | 2610Z03454 Keyless Chuck | €26.51 | |
|
821
|
photo_cameraImage coming soon | 2610Z03455 Spindle With Gear | €20.68 | |
|
825
|
photo_cameraImage coming soon | 2610Z03463 Knob | €7.23 |
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Skil Spare Parts for Percussion Drill 6950
SKIL Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues forr Percussion Drill 6950 - F015695001.In the following table, look for the model of the Percussion Drill and the respective parts of the code.
| Percussion Drill 6950/F 015 695 001 | ||
| # | Part Num. | Description |
| 2 | 2610Z03457 | Field 230V |
| 4 | 2610Z03460 | On-Off Switch |
| 5 | 2610362954 | Power supply cord EU 2,65m 2 x 1,0mm H05 VV-F |
| 1604460124 | Power supply cord GB 230V 2,65m 2 x 1,0mm H05 VV-F | |
| 2610386925 | Power supply cord CH 2,75m 2 x 1,0mm H05 VV-F | |
| 6 | 2610Z03465 | Grommet |
| 12 | 2610Z03461 | Suppression Capacitor |
| 16 | 2610Z03459 | Carbon-Brush Set |
| 24 | 2610Z03458 | Interference Suppr.Choke |
| 650 | 2610397394 | Auxiliary Handle |
| 651 | 2610397395 | Depth-Gauge |
| 801 | 2610Z03464 | Motor Housing |
| 803 | 2610Z03456 | Armature 230V |
| 807 | 2610Z03462 | Cable Clip |
| 820 | 2610Z03454 | Keyless Chuck |
| 821 | 2610Z03455 | Spindle With Gear |
| 825 | 2610Z03463 | Knob |
| 826 | 2610Z03466 | Bearing Plate |
