Skil Masters Parts for Angle Grinder 9425/F 015 942 511
€31.07
VAT included
Skil Masters Parts for Angle Grinder 9425/F 015 942 511
Skil genuine spare parts for replacing or to fix Angle Grinder 9425 - F015942511.
Skil Masters Parts for Angle Grinder 9425/F 015 942 511
€31.07
VAT included
Skil Masters Parts for Angle Grinder 9425/F 015 942 511
Skil genuine spare parts for replacing or to fix Angle Grinder 9425 - F015942511.
settings
21 spare parts
description
1 exploded view
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
21 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in:: 15/20 BUSINESS DAYS
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Skil Masters Parts for Angle Grinder 9425/F 015 942 511
Skil genuine spare parts for replacing or to fix Angle Grinder 9425 - F015942511.In the following table, look for the model of the Angle Grinder the respective parts of the code.
| Angle Grinder 9425/F 015 942 511 | ||
| # | Part Num. | Description |
| 2 | 2610Z02362 | Field 230V |
| 4 | 2610Z02363 | On-Off Switch |
| 5 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 1604460403 | Power supply cord CH 230V 4,15m 2 x 1,0mm H05 RN-F | |
| 2604460222 | Power supply cord GB 230V 4,15m 2 x 1,0mm H05 RN-F | |
| 2610Z00075 | Power supply cord HO5RN-F 4M OHNE STECKER | |
| 6 | 2610Z02364 | Grommet |
| 10 | 2610Z02365 | Carbon-Brush Set |
| 12 | 2610Z02366 | Suppression Capacitor |
| 20 | 2610Z02368 | Crown Gear |
| 21 | 2610Z02369 | Deep-Groove Ball Bearing |
| 23 | 2610Z02370 | Rear Housing Section |
| 24 | 2610Z02372 | Tapping Screw |
| 25 | 2610Z02373 | Tapping Screw |
| 650 | 2610Z00781 | Auxiliary Handle |
| 651 | 2610Z00780 | Safety Guard |
| 652 | 2610Z00782 | Clamping Flange |
| 653 | 2610Z00783 | Pin Type Face Wrench |
| 801 | 2610Z02375 | Motor Housing |
| 803 | 2610Z02376 | Armature 230V |
| 807 | 2610Z02377 | Cable Clip |
| 816 | 2610Z02378 | Carbon Brush Holder |
| 822 | 2610Z02367 | Locking Unit |
| 826 | 2610Z02374 | Set of screws |
| 827 | 2610Z02379 | Gear Housing |
| 828 | 2610Z02380 | Pinion |
| 829 | 2610Z02381 | Spindle Assembly |
