Rurmec Spare Parts for Mixer S-MIX50
Fix Your Mixer S-MIX50. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Mixer and the respective parts of the code.
| Mixer S-MIX 50 |
| # |
Part Num. |
Description |
| 0 |
369.500.90 |
COMPLETE SAFETY SWITCH |
| 4 |
201.035 |
SCREW M4X8 |
| 5 |
369.500.5 |
AERATION COVER |
| 6 |
369.500.6 |
FAN |
| 7 |
369.500.7 |
M5X160 SCREW |
| 8 |
369.500.8 |
COVER HOUSING MOTOR |
| 9 |
369.500.9 |
BALL BEARING 6201 ZZ |
| 10 |
369.500.10 |
ARMATURE |
| 11 |
369.500.11 |
STATOR |
| 12 |
369.500.12 |
HOUSING MOTOR |
| 13 |
369.500.13 |
BALL BEARING 6202 ZZ |
| 14 |
369.500.14 |
BOX SWITCH |
| 15 |
369.500.15 |
M5X15 SCREW |
| 16 |
369.500.16 |
CAPACITOR |
| 17 |
369.500.17 |
PLATE SWITCH |
| 18 |
369.500.18 |
SWITCH |
| 19 |
369.500.19 |
FLAT HD SCREW M4x16 |
| 20 |
300.300.05 |
M4X12 SCREW |
| 21A |
369.500.21 |
CABLE CLAMP |
| 21B |
369.500.21.B |
CABLE CLAMP |
| 22 |
367.040 |
SCREW M4x14 |
| 23 |
304.056 |
GLAND |
| 24 |
369.500.24 |
POWER CORD |
| 25 |
369.500.25 |
ARM |
| 26 |
369.500.26 |
BOLT M8X30 |
| 27 |
369.500.27 |
WASHER 8X16X1,5 |
| 28 |
369.500.28 |
GEAR BOX |
| 29 |
369.500.29 |
WASHER SPRING M8 |
| 30 |
369.500.30 |
NUT M8 |
| 31 |
369.500.31 |
TOP GEAR |
| 32 |
369.500.32 |
SEEGER R-42 |
| 33 |
369.500.33 |
SHAFT S-MIX50 |
| 34 |
369.500.34 |
BALL BEARING 6004 ZZ |
| 35 |
369.500.35 |
SEEGER S-20 |
| 36 |
369.500.36 |
BEARING TLA 2012 |
| 37 |
369.500.37 |
SEAL OIL |
| 38 |
369.500.38 |
SPACER |
| 39 |
369.500.39 |
HANDLE FRONT |
| 40 |
300.500.54 |
HEXAGON SOCKET SCREW M8x16 |
| 41 |
355.036 |
KEY 5X5X10 |
| 42 |
369.500.42 |
BEARING TLA 1015 |
| 43 |
369.500.43 |
LOWER GEAR |
| 44 |
369.500.44 |
PINION |
| 45 |
369.500.45 |
COVER GEAR BOX |
| 46 |
369.500.46 |
SCREW WITH WASHER M5x25 |
| 47 |
369.500.47 |
PROTECTIVE COVER |
| 48 |
369.500.48 |
WASHER 14X32X2,5 |
| 49 |
369.500.49 |
NUT M14XP2.0 |
| 50 |
369.500.50 |
MIXER |
| 52 |
369.500.52 |
GRIP T 5/8 " |
| 53 |
369.500.53 |
PLUG 7/8 inch |
| 54 |
369.500.54 |
COTTER PIN SSP-10 |
| 55 |
369.500.55 |
PIN LOCK |
| 58 |
369.500.58 |
PLUG DIAMETER 12X100 |
| 59 |
369.500.59 |
HEIGHT ADJUST BOLT M10x25 |
| 60 |
369.500.60 |
FRAME |
| 61 |
369.500.61 |
CAP FRAME |
| 63 |
369.500.63 |
WASHER 16X38X2,5 |
| 64 |
369.500.64 |
WHEEL |
| 65 |
369.500.65 |
NUT M4X8 |
| 67 |
369.500.67 |
STAR WASHER M5 |
| 69 |
369.500.69 |
SCREW M4x30 |
| 70 |
369.500.70 |
SCREW M4x16 |
| 71 |
369.500.71 |
COVER SAFETY SWITCH |
| 72 |
304.063 |
SAFETY SWITCH |
| 73 |
369.500.73 |
BALL |
| 74 |
369.000.74 |
BASIC SAFETY SWITCH |
| 75 |
369.500.75 |
SAFETY SWITCH |
| 76 |
369.500.76 |
PLUG INT-EST |
| 77 |
369.500.77 |
CABLE SAFETY SWITCH |
| 79 |
369.500.79 |
FIXED CABLE |
| 80 |
369.500.80 |
BUSH |
| 82 |
369.500.82 |
CONNECTOR 3 WAY |
| 83 |
369.500.83 |
PROTECT WIRE M8X5CM |
| 84 |
369.500.84 |
CABLE CONNECTION |
| 85 |
369.500.85 |
TERMINAL FEMALE |
| 86 |
369.500.86 |
PART INSULATION |
| 87 |
369.500.87 |
TERMINAL MALE |
| 88 |
367.039 |
GLAND |
| 89 |
369.500.89 |
SCREW M4X6 |
| 51 |
369.503 |
MIXER BIN |
