Rurmec Mixer EV22UP Spare Parts

SKU: Rurmec EV22UP
€0.40
VAT included

Rurmec Mixer EV22UP Spare Parts

We are RURMEC original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer EV 22 UP.
Rurmec Mixer EV22UP Spare Parts
  • Rurmec Mixer EV22UP Spare Parts
  • Rurmec Mixer EV22UP Spare Parts - Drawing
Rurmec

Rurmec Mixer EV22UP Spare Parts

SKU: Rurmec EV22UP Condition: New
€0.40
VAT included

Rurmec Mixer EV22UP Spare Parts

We are RURMEC original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer EV 22 UP.
settings 45 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN: Usually Ships in 10 BUSYNESS DAYS
MORE INFO:: [email protected]
Machine Type: Mixer
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
45 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 364.001.01 SCREW ST 4.8x55 €0.00 Not available for order
2
 photo_cameraImage coming soon 364.001.02 GEARBOX ASSEMBLED €114.39
3
 photo_cameraImage coming soon 371.500.37 INSERT 4X6 €0.00 Not available for order
4
 photo_cameraImage coming soon 364.001.04 ASSEMBLED CENTER COVER €47.36
5
 photo_cameraImage coming soon 364.001.05 INNER WHEEL €0.00 Not available for order
6
 photo_cameraImage coming soon 371.950.05 BALL C4 €0.00 Not available for order
7
 photo_cameraImage coming soon 371.950.06 SPRING C4 €0.00 Not available for order
8-16
 photo_cameraImage coming soon 371.500.11 O-RING €0.00 Not available for order
9
 photo_cameraImage coming soon 364.001.09 GEAR KNOB €1.49
10
 photo_cameraImage coming soon 301.300.57 SCREW ST 3x10 €0.00 Not available for order
11
 photo_cameraImage coming soon 364.001.11 THIRD STAGE GEAR SHAFT €21.34
12
 photo_cameraImage coming soon 364.001.12 SECOND SPEED GEAR €33.67
13
 photo_cameraImage coming soon 364.001.13 ASSEMBLED GEAR FORK €4.36
14
 photo_cameraImage coming soon 364.001.14 GEAR SHAFT SET SECONDARY €40.52
15
 photo_cameraImage coming soon 364.001.15 PAPER WASHER €0.00 Not available for order
17
 photo_cameraImage coming soon 364.001.17 ROTOR SPRING €0.00 Not available for order
18
 photo_cameraImage coming soon 371.758 GASKET €0.00 Not available for order
19
 photo_cameraImage coming soon 364.001.19 ARMATURE ASSEMBLED EV22UP €79.88
20
 photo_cameraImage coming soon 373.203 BEARING SLEEVE €2.85
21
 photo_cameraImage coming soon 364.001.21 ANTI-WIND RING €3.55
22
 photo_cameraImage coming soon 364.001.22 FIELD EV22UP €53.30
23
 photo_cameraImage coming soon 364.001.23 HEX NUT M6 €0.00 Not available for order
24
 photo_cameraImage coming soon 364.001.24 MOTOR CASING €30.25
25
 Rurmec EV22UP Carbon Brush Set 364.001.25 Rurmec EV22UP Carbon Brush Set €15.80
26
 Rurmec Brush Holder for Mixer EV22UP 364.001.26 Rurmec Brush Holder for Mixer EV22UP €7.16
27
 Rurmec Brush Holder Spring for EV22UP 364.001.27 Rurmec Brush Holder Spring for EV22UP €1.53
28
 photo_cameraImage coming soon 364.001.28 WIND SCREEN €2.85
29
 photo_cameraImage coming soon 364.001.29 CABLE €22.03
30
 photo_cameraImage coming soon 371.002 CABLE PROTECTION €1.49
31
 photo_cameraImage coming soon 372.023 CABLE CLAMP €0.00 Not available for order
32
 photo_cameraImage coming soon 371.500.24 SCREW ST 4X16 €0.00 Not available for order
33-34
 photo_cameraImage coming soon 364.001.33 LOWER HANDLE €23.39
35
 Rurmec Mixer EV22UP Switch 364.001.35 Rurmec Mixer EV22UP Switch €17.92
36
 Rurmec Mixer EV22UP Potentiometer 364.001.36 Rurmec Mixer EV22UP Potentiometer €26.92
37
 photo_cameraImage coming soon 364.001.37 SPEED ADJUSTMENT WHEEL €1.49
38
 photo_cameraImage coming soon 364.001.38 RIGHT LINE COVER €0.00 Not available for order
39
 photo_cameraImage coming soon 364.001.39 LEFT LINE COVER €0.00 Not available for order
40
 photo_cameraImage coming soon 364.001.40 METAL SUPPORT €116.51
41
 photo_cameraImage coming soon 364.001.41 M 6x20 SCREW €0.00 Not available for order
42-43
 photo_cameraImage coming soon 364.001.42 UPPER HANDLE €14.85
44
 photo_cameraImage coming soon 364.001.44 ALARM CONTACT PLATE €0.00 Not available for order
45
 photo_cameraImage coming soon 364.001.45.A SOFT START €47.32
46
 photo_cameraImage coming soon 364.001.46 SCREW ST 3x25 €0.00 Not available for order
47
 photo_cameraImage coming soon 364.001.47 LAMP COVER €0.00 Not available for order
48
 photo_cameraImage coming soon 364.001.48 REAR COVER €15.17

Shipping and delivery information will be available shortly.

Rurmec Mixer EV22UP Spare Parts

We are RURMEC original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer EV 22 UP.
In the following table, look for the model of the Mixer and the respective parts of the code.
Rurmec EV 22 UP

RURMEC MIXER EV 22 UP - 364.001 Spare Parts
# Part Num. Description
1 364.001.01 SCREW ST 4.8x55
2 364.001.02 GEARBOX ASSEMBLED
3 371.500.37 INSERT 4x6
4 364.001.04 ASSEMBLED CENTER COVER
5 364.001.05 INNER WHEEL
6 371.950.05 BALL C4
7 371.950.06 SPRING C4
8-16 371.500.11 O-RING MX8
9 364.001.09 GEAR KNOB
10 301.300.57 SCREW ST 3x10
11 364.001.11 THIRD STAGE GEAR SHAFT
12 364.001.12 SECOND SPEED GEAR
13 364.001.13 ASSEMBLED GEAR FORK
14 364.001.14 GEAR SHAFT SET SECONDARY
15 364.001.15 PAPER WASHER
17 364.001.17 ROTOR SPRING
18 371.758 GASKET
19 364.001.19 ARMATURE ASSEMBLED EV22UP
20 373.203 BEARING SLEEVE
21 364.001.21 ANTI-WIND RING
22 364.001.22 FIELD EV22UP
23 364.001.23 HEX NUT M6
24 364.001.24 MOTOR CASING
25 364.001.25 CARBON BRUSH SET
26 364.001.26 BRUSH HOLDER
27 364.001.27 HELICAL SPRING
28 364.001.28 WIND SCREEN
29 364.001.29 CABLE
30 371.002 CABLE PROTECTION
31 372.023 CABLE GLAND
32 371.500.24 SCREW ST 4x16
33-34 364.001.33 LOWER HANDLE
35 364.001.35 SWITCH
36 364.001.36 POTENTIOMETER
37 364.001.37 SPEED ADJUSTMENT WHEEL
38 364.001.38 RIGHT LINE COVER
39 364.001.39 LEFT LINE COVER
40 364.001.40 METAL SUPPORT
41 364.001.41 M 6x20 SCREW
42-43 364.001.42 UPPER HANDLE
44 364.001.44 ALARM CONTACT PLATE
45 364.001.45.A SOFT START
46 364.001.46 SCREW ST 3x25
47 364.001.47 LAMP COVER
48 364.001.48 REAR COVER
