Lavorwash S.p.A.

Lavor Pressure Cleaner NPX 1511XP Parts

SKU: Lavor NPX 1511XP - 8.620.0602
€5.70
VAT included

Lavor Original Parts for Pressure Cleaner NPX 1511XP

Lavor original spare parts for to replace broken parts for to fix HOT Water High Pressure Cleaner NPX 1511XP T 400/50-GR-8.620.0602
Lavor Pressure Cleaner NPX 1511XP Parts
  • Lavor Pressure Cleaner NPX 1511XP Parts
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 1
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 2
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 3
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 4
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 5
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 6
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 7
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 8
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 9
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 10
  • Lavor Pressure Cleaner NPX 1511XP Parts Page 11
Lavorwash S.p.A.

Lavor Pressure Cleaner NPX 1511XP Parts

SKU: Lavor NPX 1511XP - 8.620.0602 Condition: New
€5.70
VAT included

Lavor Original Parts for Pressure Cleaner NPX 1511XP

Lavor original spare parts for to replace broken parts for to fix HOT Water High Pressure Cleaner NPX 1511XP T 400/50-GR-8.620.0602
settings 124 spare parts
description 12 exploded views
picture_as_pdf Download Exploded PDF
CODICE ARTICOLO
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
124 spare parts
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
4
 photo_cameraImage coming soon 3.002.0060 SELF TAPPING CROSS HEAD SCREW3.9X16 RAPID FIX €3.35
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.608.0184 WINDING SEAT CLOSURE CAP. NPX'04 BLACK €5.71
2
 photo_cameraImage coming soon 6.605.0087 KIT N.3 HOOKS WITH SCREWS €11.10
3
 photo_cameraImage coming soon 5.611.0285 LEFT SIDE SIDE NPX-LKX -BLACK- W/HOOKS W/PAD.-DEEP WORK- €53.69
4
 photo_cameraImage coming soon 4.613.0289 UPPER FAIRING NPX-LKX04 -GR- RAL.7046 €78.56
5
 photo_cameraImage coming soon 4.608.0082 GAS OIL-CHEM TANK CAP €15.27
6
 photo_cameraImage coming soon 3.200.0038 O-RING GASKET 53,65X2,62 REF.3212 €1.70
7
 photo_cameraImage coming soon 5.611.0286 RIGHT SIDE PANEL NPX-LKX -BLACK- W/HOOK W/PAD-DEEP WORK- €53.69
8
 photo_cameraImage coming soon 4.613.0182 REAR FAIRING NPX-LKX'04 -BLACK- €48.58
9
 photo_cameraImage coming soon 3.700.0030 GUN AL55 350bar 45l / min 160Â ° C + sw8 3 / 8M + S7 + M22 (30129100) €64.28
10
 photo_cameraImage coming soon 4.618.0143 HIGH PRESSURE HOSE 5/16 315BAR R2 L=10000 1/2 TWIST.-3/8 €142.39
11
 700 mm Lance 1/8 "F High/Low Pressure for Pressure Washers Lavor 3.701.0015 700 mm Lance 1/8 "F High/Low Pressure for Pressure Washers Lavor €37.13
12
 photo_cameraImage coming soon 5.612.0013 NOZZLE KIT 15040 HOSE HOLDER €36.91
14
 photo_cameraImage coming soon 7.700.0551 MANUAL NPX+CE LAVOR A5 196F 19L €7.20
15
 photo_cameraImage coming soon 4.607.0726 PROTECTIVE STAINLESS STEEL SHEET NPX/LKX CHIMNEY €15.98
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon 5.601.0169 MTP LWT 400/50 2P 135 H1 30 9.30' €1,074.76
photo_cameraImage coming soon 5.609.0128 THERMOSTAT BULB BODY ASSEMBLY LKX/NPX'04 EXIT.INN.RAP. ZNT BRASS €113.80
photo_cameraImage coming soon 5.611.0105 NPX/LKX4 TRI F.16A DASHBOARD ASSEMBLY €218.37
photo_cameraImage coming soon 5.611.0169 EXT. BOILER COVER FOR PERFORATED CONE BAND €84.59
photo_cameraImage coming soon 5.611.0193 COMPLETE BURNER FLANGE 1.25-45B (RILSAN) W/FLAME CONTROL PRE-PREDICATION €123.34
1
 photo_cameraImage coming soon 4.612.0046 POWER CABLE H05VV-F 3X1.5 L = 6000 WITHOUT / FASTON €29.75
2
 photo_cameraImage coming soon 6.605.0168 WHEEL D.260X85 FULL BLACK €26.58
3
 photo_cameraImage coming soon 5.613.0402 NPX/LKX FRONT AXLE €34.20
4
 photo_cameraImage coming soon 5.613.0403 REAR AXLE NPX/LKX €30.52
5
 photo_cameraImage coming soon 4.608.0073 SHORT SPACER FOR TANK JOLLY 4/93 €1.74
6
 photo_cameraImage coming soon 4.608.0203 DIESEL / DETERGENT TANK J OLLY 5 / LKX €264.90
7
 photo_cameraImage coming soon 3.403.0078 INDICATED. DIESEL LEVEL L=185 W/CABLE L=1320 W/FASTON €54.88
8
 photo_cameraImage coming soon 4.608.0448 LONG SPACER FOR TANK. JOLLY 4/93 mm57.5 €3.28
9
 photo_cameraImage coming soon 4.608.0169 RIGHT HANDLE NPX'04-GR-RAL.7021 €38.26
10
 photo_cameraImage coming soon 4.608.0170 LEFT HANDLE NPX'04-GR-RAL.7021 €47.26
11
 photo_cameraImage coming soon 4.608.0191 NPX'04 BLACK DASHBOARD FRAME €8.45
12
 photo_cameraImage coming soon 4.608.0168 NPX4/LKX4/T4 ELECTRICAL BOX €26.96
13
 photo_cameraImage coming soon 3.402.0026 TLR4FC CONTACTOR €253.26
15
 photo_cameraImage coming soon 5.611.0193 COMPLETE BURNER FLANGE 1.25-45B (RILSAN) W/FLAME CONTROL PRE-PREDICATION €123.34
16
 photo_cameraImage coming soon 4.608.0145 RILSAN GASOIL HOSE X PARANA' L=500 €1.73
17
 Lavor LKX 2015 Ignition Transformer 5.609.0344 Lavor LKX 2015 Ignition Transformer €63.65
18
 photo_cameraImage coming soon 4.607.0072 Substituted by 6.605.0102 MOTOR CLAMP €8.32
19
 photo_cameraImage coming soon 5.613.0192 DASHBOARD SUPPORT/HANDLES NPX/LKX'04 €141.62
20
 photo_cameraImage coming soon 3.004.0015 PLAIN WASHER D.22X39X2 UNI6592 €1.63
21
 photo_cameraImage coming soon 4.606.0013 COIL FIXING NUT 1/2 BRASS SPEC. €3.25
22
 photo_cameraImage coming soon 5.611.0308 GR. DIESEL FILTER (PAPER) NPX SUNTEC PUMP €8.52
23
 photo_cameraImage coming soon 4.618.0035 TUBE R1 PUMP/COIL TG480 €28.57
24
 Lavor NPX 1400 Hose 4.618.0043 Lavor NPX 1400 Hose €27.71
25
 photo_cameraImage coming soon 3.102.0005 DIESEL FILTER FB15/P (AK3012) W/BRASS PLATE €7.55
26
 photo_cameraImage coming soon 5.611.0169 EXT. BOILER COVER FOR PERFORATED CONE BAND €84.59
27
 photo_cameraImage coming soon 5.613.0028 INT. COVER CAM.COMB. CHIMNEY L=120 €146.74
29
 photo_cameraImage coming soon 5.613.0274 NPX'04 BOILER BODY PAINTED FOR BAND €140.92
30
 photo_cameraImage coming soon 4.608.0536 VERMICULITE PANEL THICKNESS 20MM DIAM. 290MM 2 HOLES €27.23
31
 photo_cameraImage coming soon 4.607.0006 COIL FIXING STRIP PLATE 20/10 €46.76
32
 Lavor NPX1400 Insulating Rope 4.608.0162 Lavor NPX1400 Insulating Rope €35.27
33
 photo_cameraImage coming soon 5.613.0116 BOILER BASE JOLLY 5 / LKX -VERN ICIATA- €106.07
34
 photo_cameraImage coming soon 4.618.0030 TUBE B.P. D.20X10 3/8M-3/8M. L.450 €26.69
35
 photo_cameraImage coming soon 5.609.0128 THERMOSTAT BULB BODY ASSEMBLY LKX/NPX'04 EXIT.INN.RAP. ZNT BRASS €113.80
36
 photo_cameraImage coming soon 4.606.0019 SUCTION CONNECTOR M22 IDRO COMPACT €5.16
37
 photo_cameraImage coming soon 4.006.0088 INTAKE FITTING ADAPTER L=26 M22-3/4G €6.72
38
 Inlet Water Filter Conical for Pressurte Washer Lavor BEST 24 4.008.0031 Inlet Water Filter Conical for Pressurte Washer Lavor BEST 24 €2.07
39
 photo_cameraImage coming soon 4.608.0023 RUBBER SLEEVE JOLLY 4 SNAIL €14.85
42
 photo_cameraImage coming soon 4.608.0448 LONG SPACER FOR TANK. JOLLY 4/93 mm57.5 €3.28
43
 photo_cameraImage coming soon 5.611.0105 NPX/LKX4 TRI F.16A DASHBOARD ASSEMBLY €218.37
45
 photo_cameraImage coming soon 3.414.0010 COIL 230/50HZ FOR DANFOSS GAS PUMP (071N1006) €59.71
49
 photo_cameraImage coming soon 3.704.0009 PRESSURE SWITCH PS2 1/4M 25BAR RED P/N 4090000006 €37.87
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
Ceramic Piston Body Guide for Pressure Cleaner Lavor NPX 1400 5.007.0063 Ceramic Piston Body Guide for Pressure Cleaner Lavor NPX 1400 €153.20
Brass Head Injectors 1.9 for Pressure Cleaner Lavor NPX 1400 5.008.0145 Brass Head Injectors 1.9 for Pressure Cleaner Lavor NPX 1400 €243.77
photo_cameraImage coming soon 5.606.0144 MOTOR LW.T 400/50 D. 135 2P H130 X NPX 1500 (MALE CENTRE) €450.14
photo_cameraImage coming soon 5.609.0252 FRONT FLANGE 135 (FEMALE EDGE) €28.29
1
 photo_cameraImage coming soon 4.608.0017 Substituted by 6.605.0086 PUMP SIDE HALF FEMALE SCREW GMV D.150 €79.81
2
 PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500 4.608.0083 PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500 €30.42
3
 photo_cameraImage coming soon 4.608.0129 Substituted by 6.605.0086 HALF COVER MOTORSIDE €79.81
4
 photo_cameraImage coming soon 3.002.0060 SELF TAPPING CROSS HEAD SCREW3.9X16 RAPID FIX €3.35
5
 photo_cameraImage coming soon 4.608.0022 SETTING THROTTLE LEVER GMV 150 €1.74
6
 photo_cameraImage coming soon 4.608.0021 SETTING THROTTLE GMV 150 €3.36
7
 photo_cameraImage coming soon 4.607.0257 FAN CONNECTION €12.02
8
 photo_cameraImage coming soon 4.607.0233 MOTOR AIR CONVOY €39.67
9
 photo_cameraImage coming soon 5.606.0144 MOTOR LW.T 400/50 D. 135 2P H130 X NPX 1500 (MALE CENTRE) €450.14
10
 photo_cameraImage coming soon 5.609.0252 FRONT FLANGE 135 (FEMALE EDGE) €28.29
11
 photo_cameraImage coming soon 3.200.0002 O-RING GASKET 90X2,5 €1.70
12
 photo_cameraImage coming soon 3.001.0029 BEARING €29.76
13
 photo_cameraImage coming soon 4.605.0041 PLATE 9.30' €12.39
14
 photo_cameraImage coming soon 4.607.0208 AXIAL BEARING €25.19
15
 O-Ring 12.4x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500 3.200.0004 O-Ring 12.4x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500 €1.70
16
 Oil Seal Spacer D.19 for Pressure Washers Lavor NPX 1400 - NPX 1500 4.008.0391 Oil Seal Spacer D.19 for Pressure Washers Lavor NPX 1400 - NPX 1500 €1.70
17
 Ceramic Piston Body Guide for Pressure Cleaner Lavor NPX 1400 5.007.0063 Ceramic Piston Body Guide for Pressure Cleaner Lavor NPX 1400 €153.20
18
 photo_cameraImage coming soon 5.009.0207 CAP ASSY €14.27
19
 Brass Head Injectors 1.9 for Pressure Cleaner Lavor NPX 1400 5.008.0145 Brass Head Injectors 1.9 for Pressure Cleaner Lavor NPX 1400 €243.77
20
 photo_cameraImage coming soon 4.606.0041 SECOND SEALING HOLDER RING 130/8 ESP.1 €10.35
21
 photo_cameraImage coming soon 4.007.0080 FAN FIXING RING D.25,5 €28.68
22
 photo_cameraImage coming soon 3.099.0054 FEATHER KEY 5X5X20 UNI 6604 €1.74
23
 photo_cameraImage coming soon 3.100.0075 CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- €14.98
23
 photo_cameraImage coming soon 4.606.0114 CONVEYOR THICKNESS FOR MOTOR D.135 €3.36
24
 Double Pipe Diesel Pump for Pressure Washer Lavor NPX 1500 3.551.0062 Double Pipe Diesel Pump for Pressure Washer Lavor NPX 1500 €144.48
25
 photo_cameraImage coming soon 3.414.0010 COIL 230/50HZ FOR DANFOSS GAS PUMP (071N1006) €59.71
26
 Plastic Coupling Set for Pressure Cleaner Lavor NPX 1400 6.605.0173 Plastic Coupling Set for Pressure Cleaner Lavor NPX 1400 €29.06
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.606.0087 BULB ASSY €49.01
2
 photo_cameraImage coming soon 3.004.0004 ALUMINIUM WASHER 21X30XSP 1,5 €1.74
3
 photo_cameraImage coming soon 3.100.0020 REDUCTION M.GAS/M.GAS 1/2-3/8 €8.03
4
 photo_cameraImage coming soon 5.613.0191 THERMOSTAT/ALARM BULB SUPPORT. NPX/LKX'04 €28.78
5
 photo_cameraImage coming soon 3.100.0018 RAPID COUPLING 3/8 M. 08 (465) €14.98
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Lavor LKX 2015LP External Cover 5.613.0200 Lavor LKX 2015LP External Cover €40.44
2
 photo_cameraImage coming soon 5.610.0105 DEFLECTOR D.82 €29.76
Page 6 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3.499.0129 LIGHT TYPE 81F 220V BLACK BODY RED GEM €4.79
2
 photo_cameraImage coming soon 3.401.0063 MICRODISCONNECTOR ETA 3140-F230-P7TI-SGRX-3AC415V-16A €102.75
3
 Lavor Adjustment Knob for MEK 1108 4.608.0164 Lavor Adjustment Knob for MEK 1108 €5.83
4
 Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500 3.107.0004 Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500 €33.35
5
 photo_cameraImage coming soon 4.608.0205 DASHBOARD NPX4/LKX4 THREE-PHASE-GR-W/PAMPOGR. €30.33
6
 Thermostat for Pressure Washers Lavor NPX 1400 - NPX 1500 3.403.0091 Thermostat for Pressure Washers Lavor NPX 1400 - NPX 1500 €40.24
7
 photo_cameraImage coming soon 3.105.0003 DETERGENT REGULATING COCK WITHRUBBER HOLDER D.7 €37.19
Page 7 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.614.0004 STANDARDIZED ELECTRODES COUPLE WITH ROD €36.46
2
 photo_cameraImage coming soon 3.100.0075 CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- €14.98
3
 photo_cameraImage coming soon 3.555.1098 EXTERNAL SEEGER ZJ D.22 (3019003500) €1.63
4
 photo_cameraImage coming soon 3.555.1099 CAP D21,75X2 (3200007400) €4.50
6
 Diesel Nozzle for Pressure Washers Lavor NPX 1400 3.104.0028 Diesel Nozzle for Pressure Washers Lavor NPX 1400 €28.36
Page 8 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 8
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.605.0117 MOTOR FLANGE 135 €31.45
2
 OIL SEAL RING D.25X40X7 DOUBLELIP 3.201.0019 OIL SEAL RING D.25X40X7 DOUBLELIP €14.52
Page 9 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 9
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Lavor MCHPV 1515LP Kit 111 LW 6.005.0120 Lavor MCHPV 1515LP Kit 111 LW €28.38
2
 photo_cameraImage coming soon 6.005.0129 COMPLETE BY-PASS KIT TEST.OCT.'99 TS €75.88
3
 Lavor NPX1400 Outlet Coupling 5.609.0079 Lavor NPX1400 Outlet Coupling €12.26
4
 photo_cameraImage coming soon 6.005.0071 KIT 71 LW NON-RETURN VALVE REPAIR €17.54
5
 photo_cameraImage coming soon 4.606.0001 1/4G CAP €3.36
6
 LAVOR Brass Pump Head for NPX 1400 Pressure Washers 4.606.0085 LAVOR Brass Pump Head for NPX 1400 Pressure Washers €147.90
7
 photo_cameraImage coming soon 5.609.0158 ASSEMBLY CONNECTOR 1/8 G + CAPM7 TS €14.85
8
 photo_cameraImage coming soon 6.005.0293 BOX+MICRO+CABLE 3X1 FOR TS BRASS HEAD '99 €29.18
9
 photo_cameraImage coming soon 6.005.0119 KIT 110 LW HEAD PISTONS BUSHINGS OCT.'99 €34.83
10
 photo_cameraImage coming soon 6.005.0118 LW KIT OF WATER SEAL RINGS BRASS HEAD '99 €48.71
11
 photo_cameraImage coming soon 6.005.0578 KIT 6 VALVES *AUTO SUCTION* (COMP.OR) TEST.OCT.'99 €23.29
12
 photo_cameraImage coming soon 5.609.Y154 HOSE ASSEMBLY D.1 C / OR-SPRING L = 7 wire D.0.4-BALL D.5.5 €6.53
13
 photo_cameraImage coming soon 5.609.0064 VALVE CAP ASSY + OR €13.32
14
 photo_cameraImage coming soon 6.005.0020 KIT 23 LAVOR €29.18
Page 10 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 10
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Lavor Oil Lever Indicator for NPX 1400 3.099.0003 Lavor Oil Lever Indicator for NPX 1400 €4.14
2
 photo_cameraImage coming soon 5.009.0094 BEST FINNED GUIDE BODY ASSEMBLY WITH SEALS €87.38
4
 photo_cameraImage coming soon 6.005.0006 KIT 5 LW OIL SEAL RINGS TEST.OCT'97-'99-BEST-OMNIA €87.37
5
 STEI Screw 3/8" for Pressure Washers Lavor NPX 1400 - NPX 1500 3.002.0004 STEI Screw 3/8" for Pressure Washers Lavor NPX 1400 - NPX 1500 €1.70
6
 photo_cameraImage coming soon 6.005.0032 KIT OF 3 PISTONS D.15 OCT. TEST. '99 €118.99
Page 11 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 11
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.602.0065 LW.T 400/50 2P HOUSING D.135 H.130 (MALE CENTRE) €118.98
2
 photo_cameraImage coming soon 3.099.0002 UNLOADING RING 40X47 €77.91
3
 photo_cameraImage coming soon 3.001.0001 BALL RADIAL BEARING 6204-2Z €14.95
4
 photo_cameraImage coming soon 5.605.0032 ROTOR SHAFT D.70 H130 FOR MOTOR D.135 THREE-PHASE WITH FAN €14.94

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Original Parts for Pressure Cleaner NPX 1511XP

Lavor original spare parts for to replace broken parts for to fix HOT Water High Pressure Cleaner NPX 1511XP T 400/50-GR-8.620.0602

In the following tables, look for the spare part and its respective code.
Lavor NPX 1511XP - 8.620.0602

NPX 1511XP T 400/50-GR-8.620.0602
Pag.1
# Part Num Description
0 8.620.X016 NPX4 1511 400/50 TS BASE TO BE FINISHED
1 4.608.0184 COVER CAP FOR REEL SEAT NPX'04 BLACK
2 6.605.0087 KIT OF 3 HOOKS WITH SCREWS
3 5.611.0285 LEFT SIDE PANEL NPX-LKX-BLACK-W/HOOKS WITH PAD
4 4.613.0289 UPPER FAIRING NPX-LKX04-GR-RAL.7046
5 4.608.0082 FUEL TANK CAP-CHEM-N-
6 3.200.0038 OR SEAL 53.65X2.62 REF. 3212
7 5.611.0286 RIGHT SIDE PANEL NPX-LKX-BLACK-W/HOOKS WITH PAD
8 4.613.0182 FAIRING POSTER.NPX-LKX'04-BLACK-
9 3.700.0030 AL55 GUN 350BAR 45L/MIN 160GR+SW8
10 4.618.0143 HOSE 5/16 R1 - 315 bar 10M W/ATT.RAP.
11 3.701.0015 STAINLESS STEEL LANCE L.700 COATED+ROS.+RAP.ATT.
12 5.612.0013 NOZZLE KIT 15040 HOSE HOLDER
14 7.700.0551 NPX+CE WORK MANUAL A5 196F 19L
15 4.607.0726 STAINLESS STEEL CHIMNEY PROTECTION NPX/LKX
NPX4 1511 400/50 TS BASE DA FINIRE Pag.2
0 5.601.0169 MTP LWT 400/50 2P 135 H1 30 9.30'
0 5.609.0128 THERMOSTAT BULB BODY ASSEMBLY LKX/NPX'04 OUTPUT RAP.
0 5.611.0169 BOILER EXTERNAL COVER FOR PERFORATED CONE BAND
0 5.611.0105 NPX/LKX4 TRI F.16A DASHBOARD ASSEMBLY
0 5.611.0193 COMPLETE BURNER FLANGE 1.25-45B RH (RILSAN)
1 4.612.0046 POWER CABLE H05VV-F 4X1.5 6M WITH FASTON W/O PLUG
2 6.605.0168 WHEEL KIT 30060155 + STUD + STOP
3 5.613.0402 FRONT AXLE NPX/LKX
4 5.613.0403 NPX/LKX REAR AXLE
5 4.608.0073 SHORT SPACER FOR JOLLY 4/93 TANK
6 4.608.0203 NPX4/LKX4 DIESEL/DETERGENT TANK
7 3.403.0078 FUEL LEVEL GAUGE L=185 W/CABLE
8 4.608.0448 LONG SPACER FOR JOLLY 4/93 TANK 57.5 MM
9 4.608.0169 RH HANDLE NPX'04-GR-RAL.7021
10 4.608.0170 LEF HANDLE NPX'04-GR-RAL.7021
11 4.608.0191 DASHBOARD FRAME NPX'04 BLACK
12 4.608.0168 ELECTRIC BOX NPX4/LKX4/TEKNA4
13 3.402.0026 REMOTE CONTROL SWITCH TLR4FC
15 5.611.0193 COMPLETE BURNER FLANGE 1.25-45B RH (RILSAN)
16 4.608.0145 DIESEL DELIVERY PIPE RILSAN PARANA' L=540
17 5.609.0344 220-240V AC TRANSFORMER WITH PIPET.NPX-LKX + CABLE
18 4.607.0072 MOTOR MOUNTING BRACKET
19 5.613.0192 DASHBOARD/HANDLE SUPPORT NPX/LKX '04
20 3.004.0015 FLAT WASHER D.22X39 TH.3 ZNT UNI6592
21 4.606.0013 COOLER FIXING NUT 1/2" OT SPECIAL
22 5.611.0308 FUEL FILTER (PAPER) NPX SUNTEC PUMP
23 4.618.0035 R1 PIPE 250 BAR L=600 W/CONNECTOR 1/2-3/8F 90°
24 4.618.0043 R1 PIPE 3/8 L=375 W/1/2F 90° ROTARY / C. 3/8F
25 3.102.0005 FUEL FILTER FB15/P W/BRASS PLATE
26 5.611.0169 BOILER EXTERNAL COVER FOR DRILLED CONE BAND
27 5.613.0028 CHROME COMBINATION INTERNAL COVER L=120
29 5.613.0274 NPX'04 BOILER BODY, PAINTED
30 4.608.0536 VERMICULITE PANEL, D. 290MM, 2 HOLES
31 4.607.0006 COOLER FASTENING BAND 15/10 STAINLESS STEEL
32 4.608.0162 INSULATING CORD FOR BOILER BASE L=975
33 5.613.0116 JOLLY 5/LKX BOILER BASE - PAINTED
34 4.618.0030 B.P.R1 PIPE L=450 CONNECTOR 3/8M-3/8M
35 5.609.0128 THERMAL BULB BODY ASSEMBLY, QUICK INLET OUTPUT
36 4.606.0019 INTAKE CONNECTOR L=60 M22-3/8G
37 4.006.0088 INTAKE CONNECTOR ADAPTER L=26 M22-3/4G
38 4.008.0031 WATER INTAKE FILTER D.16 CONICAL
39 4.608.0023 RUBBER SLEEVE FOR JOLLY 4 SPIRAL
42 4.608.0448 LONG SPACER FOR TANK MM 57.5
43 5.611.0105 NPX/LKX4 TRI F.16A DASHBOARD ASSEMBLY
45 3.414.0010 230/50HZ COIL FOR GAS PUMP DANFOSS
49 3.704.0009 PS2 PRESSURE SWITCH 1/4M 25 BAR RED
MTP LWT 400/50 2P 135 H1 30 9.30' X NPX 1500 TS Pag.3
0 5.609.0252 MOTOR FRONT FLANGE 135 X WING GUIDE
0 5.008.0145 CYLINDER HEAD OCT. '99 INJECTION D. 1.9 TS
0 5.007.0063 WITH PISTON GUIDE D. 15 CER. BEST WITH FANS WITH WARNING LIGHT
0 5.606.0144 ENGINE LW.T 400/50 D. 135 2P H130
1 4.608.0017 HALF-NUCLEAR GEAR PUMP SIDE GMV D. 150
2 4.608.0083 PVC FAN D. 180 LOWERED HUB
3 4.608.0129 HALF-NUCLEAR GEAR ENGINE SIDE 150-135 NPX
4 3.002.0060 SELF-TAP SCREW TC-TC 3.9X16 RAPID FIX ZNT
5 4.608.0022 LEVER FOR ADJUSTMENT THROTTLE GMV 150
6 4.608.0021 ADJUSTMENT THROTTLE FOR GM V 150
7 4.607.0257 CONNECTOR FOR NPX FAN FOR COUPLING
8 4.607.0233 ENGINE AIR CONVEYOR D. 135
9 5.606.0144 ENGINE LW.T 400/50 D. 135 2P H130
10 5.609.0252 FRONT ENGINE FLANGE 135 X WING GUIDE
11 3.200.0002 O-RING 90X2.5
12 3.001.0029 ANGLE BALL BEARING 7305-BE
13 4.605.0041 PLATE 9.30" FOR BALL BEARING
14 4.607.0208 THrust BALL BEARING 30X73X18
15 3.200.0004 O-RING 12.4X1.78 SH.70 REF. 2050
16 4.008.0391 OIL SEAL SPACER
17 5.007.0063 WITH PISTON GUIDE D15 BEST WING WITH WINGS AND LIGHT
18 5.009.0207 ASSEMBLY OF VERTICAL OIL PLUG + O-RING SH.90
19 5.008.0145 BRASS CYLINDER HEAD '99 INJECTION D.1.9 TS
20 4.606.0041 SECONDARY SUPPORT RING SEAL 130/8
21 4.007.0080 STOP RING D. 25.5 FAN
22 3.099.0054 TAB 5X5X20 UNI 6604A
23 3.100.0075 M 1/8 TAPERED FEMALE D. 4 CURVED CONNECTOR
23 4.606.0114 ENGINE HALF-SPIRAL SPACER
24 3.551.0062 DUAL-PIPE DIESEL PUMP RH 230/50-60
25 3.414.0010 230/50HZ COIL FOR DANFOSS GAS PUMP
26 6.605.0173 PLASTIC JOINT KIT FOR DIESEL PUMP (3 PCS)
ASS.CORPO BULBO TERMOST.LKX/NPX'04 USC.INN.RAP.OTTONE ZNT Pag.4
1 4.606.0087 PROFESSIONAL THERMOSTAT BULB BODY
2 3.004.0004 ALUMINIUM WASHER 21X30XTH.1.5
3 3.100.0020 NIPPLE 1/2G-3/8G
4 5.613.0191 THERMOSTAT BULB SUPPORT/START NPX/LKX '04
5 3.100.0018 QUICK-RELEASE CONNECTOR 3/8"-1/2" ZNT
COP.EST.CALDAIA X FASCIA CONO FORATO Pag.5
1 5.613.0200 EXTERNAL COVER FOR '04 BOILER
2 5.610.0105 DEFLECTOR WITH CONE D.82" WITH HOLES
ASSIEME CRUSCOTTO NPX/LKX4 TRI F.16A Pag.6
1 3.499.0129 LAMP LIGHT TYPE 81F 220V BLACK BODY RED LENS
2 3.401.0063 ETA 16A MICRO-DISCONNECTOR (SWITCH)
3 4.608.0164 THERMOSTAT ADJUSTMENT KNOB -N-
4 3.107.0004 PRESSURE GAUGE D.50 0/315 BAR 1/4 REAR + BRACKET
5 4.608.0205 NPX4/LKX4 THREE-PHASE DASHBOARD -GR-W/BUFFER
6 3.403.0091 THERMOSTAT 30/150 BULB D.6.5" (3 FASTONS)
7 3.105.0003 DET. ADJUSTMENT TAP WITH HOLDER D.7"
FLANGIA BRUC.COMPL.1,25-45B DX (RILSAN) C/PRED.CONTR.FIAMMA Pag.7
1 4.614.0004 PAIR OF PROFESSIONAL ELECTRODES W/BRACKET
2 3.100.0075 M 1/8 TAPERED F CONNECTOR D.4 CURVED
3 3.555.1098 ZJ TYPE SEEGER D22
4 3.555.1099 FLAME CONTROL CAP D.21.75X2 (GLASS)
5 4.605.0223 STANDARD BURNER FLANGE
6 3.104.0028 1.25 OIL NOZZLE 45/B
FLANGIA ANT.MOTORE 135 X C.GUIDA ALETT.(BORDO FEMM.) Pag.8
1 4.605.0117 MOTOR FLANGE 135 X WITH FINNED GUIDE (FEMALE)
2 3.201.0019 OIL SEAL RING D.25X40X7 DOUBLE LIP
TESTATA OTT.'99 INIET.D.1,9 TS X IDRO A CALDO Pag.9
1 6.005.0120 PRESSURE REGULATOR KIT, OPT. TESTED '99
2 6.005.0129 COMPLETE BYPASS KIT FOR HOT HYDRO
3 5.609.0079 OUTLET CONNECTOR ASSEMBLY D.1.9 + O-RING
4 6.005.0071 71 LW NON-RETURN VALVE KIT
5 4.606.0001 TEE CAP 1/4 GAS
6 4.606.0085 BRASS HEAD '99
7 5.609.0158 1/8 CONNECTOR ASSEMBLY WITH M7 TE CAP
8 6.005.0293 3-WIRE MICROSWITCH BOX KIT
9 6.005.0119 110 LW PISTON BUSHINGS KIT
10 6.005.0118 LW WATER SEAL RING KIT
11 6.005.0578 6-PIECE "AUTO SUCTION" VALVE KIT (W/O-RING)
12 5.609.Y154 1" HOSE CONNECTOR ASSEMBLY WITH O-RING AND BALL
13 5.609.0064 INTAKE/DELIVERY VALVE CAP ASSEMBLY WITH CAPILLARY + O-RING
14 6.005.0020 23 LW INTAKE VALVE CAP KIT
C.GUIDA PIST.D15 CER.BEST C/ALETT.C/SPIA Pag.10
1 3.099.0003 SLNS-3/8 HOBBY OIL LEVEL LIGHT
2 5.009.0094 ASSEMBLY BEST FINNED GUIDE COVER WITH SEALS
4 6.005.0006 KIT OF 5 LW OIL SEAL RINGS
5 3.002.0004 3/8 G STEI SCREW (OIL DRAIN PLUG)
6 6.005.0032 KIT OF 3 PISTONS D.15, OPTICAL TEST, '99
MOTORE LW.T 400/50 D.135 2P H130 X NPX 1500(CENTR.MASCHIO) Pag.11
1 5.602.0065 LWT 400/50 2P HOUSING D.135 H.130
2 3.099.0002 4-WAVE COMPENSATION RING (217N)
3 3.001.0001 RADIAL BEARING 6204-2Z (150°C)
4 5.605.0032 ROTOR SHAFT D.70 H.130, THREE-PHASE WITH FAN
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor NPX 1511XP - 8.620.0602
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

New

Download

Lavor NPX 1511XP Drawing

Lavor NPX 1511XP Drawing

Download (269.64KB)

You might also like

Inlet Water Filter Conical for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 4.008.0031
Inlet Water Filter Conical for Pressurte Washer Lavor BEST 24
Inlet Water Filter Conical for Pressurte Washer Lavor BEST 24 Original replacement part Lavor, Inlet Water Filter H20 D.16 Conical for Pressurte Washers STORM II 17 - STORM II PLUS 21 - BEST 24.  Part for the following products: -...
AVAILABLE €2.07
Details
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.107.0004
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Pressure Gauge D.50 0/315 BAR - 1/4 Rear thread + Bracket (ref 129 939 81) for Pressure Washers NPX 1400 - NPX...
on 7/10 Business Days Approx. €33.35
Details
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 4.608.0083
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, PVC Fan D.180 Lowered Hub for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - ...
Last items in stock €30.42
Details
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 5.009.0340
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Quick Coupling Assy + O-Ring + Ring Nut for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor...
Last items in stock €15.06
Details
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 4.608.0019
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Black Thermostate Knob 3079/1t for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor NPX 1400...
on 10 Business Days Approx €10.03
Details
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.100.0043
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, 3/8 M Rotating Quick Coupling for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor NPX 1400 -...
AVAILABLE €17.59
Details
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500
Lavorwash S.p.A. SKU: 5.009.0136
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500 Genuine replacement part  Lavor , Hose Coupling Omnia Complete with O-Rings for  Pressure Washer NPX 1500  - 8.605.0049. Part for the following products: -  Pressure Washer Lavor...
on 10 Business Days Approx €3.27
Details
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.200.0019
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Gasket O-Ring 12.4X1.78 SHORE 90 for Pressure Washer Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 8052001. Part for the following...
AVAILABLE €1.70
Details
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.200.0003
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, O-Ring Gasket 25.12x1.78 REF.2100 for Pressure Washers  NPX 1400  8.605.0048 - NPX 1500 8.605.0049. Part for the following products: -...
AVAILABLE €1.70
Details
Diesel Filter Unit for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.611.0043
Diesel Filter Unit for Pressure Washer Lavor Missouri
Diesel Filter Unit for Pressure Washer Lavor Missouri Genuine part Lavor, Diesel Filter Unit JOLLY 4 '93 / MISSOURI / MEK for Pressure Washers Missouri - NPX 1400 - NPX 1500. Part for the following...
Last items in stock €15.19
Details
Electrodes for Pressure Cleaner Lavor NPX 1400
Lavorwash S.p.A. SKU: 4.614.0001
Electrodes for Pressure Cleaner Lavor NPX 1400
Electrodes for Pressure Cleaner Lavor NPX 1400 Genuine replacement part Lavor, Unified Electrodes with Bracket for Boilerfor Pressure Cleaners NPX 1400 - NPX 1500 - LKX 40 - NPX 1511 XP T...
on 10 Business Days Approx €36.16
Details
High Pressure Nozzle for Pressure Washer Lavor NPX 1500
Lavorwash S.p.A. SKU: 3.103.0047
High Pressure Nozzle for Pressure Washer Lavor NPX 1500
High Pressure Nozzle for Pressure Washer Lavor NPX 1500 Genuine replacement part  Lavor , High Pressure Nozzle 1/8 Male cod.1503 for  Pressure Washer NPX 1500  - 8.605.0049. Part for the...
on 10 Business Days Approx €16.18
Details
Diesel Pump Coil for Pressure Cleaner Lavor NPX 1400
Lavorwash S.p.A. SKU: 3.414.0002
Diesel Pump Coil for Pressure Cleaner Lavor NPX 1400
Diesel Pump Coil for Pressure Cleaner Lavor NPX 1400 Genuine replacement part Lavor, Diesel Pump Coil 230V 50/60Hz 9W 100%  ED 25 Bar IP65 Delta Pump for Pressure Cleaners NPX 1400 - NPX 1500 Part for the following products: -...
on 10 Business Days Approx €40.38
Details
Plastic Coupling Set for Pressure Cleaner Lavor NPX 1400
Lavorwash S.p.A. SKU: 6.605.0173
Plastic Coupling Set for Pressure Cleaner Lavor NPX 1400
Plastic Coupling Set for Pressure Cleaner Lavor NPX 1400 Genuine replacement part Lavor, Diesel Pump Red Plastic Coupling Set for Engine EME/UNIELECTRICp for Pressure Cleaners NPX 1400 - NPX 1500 Part for the following products: -...
Last items in stock €29.06
Details
Washer SNHORt for Pressure Cleaner Lavor NPX 1400
Lavorwash S.p.A. SKU: 3.004.0022
Washer SNHOR for Pressure Cleaner Lavor NPX 1400
Washer SNHOR for Pressure Cleaner Lavor NPX 1400 Genuine replacement part Lavor, Washer SNHOR D.8x13 sp.0.8 for Pressure Cleaners NPX 1400 - NPX 1500 Part for the following products: -  Pressure Cleaner Lavor NPX 1400 - 8.605.0048 -...
on 10 Business Days Approx €1.71
Details
Thermostat for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.403.0091
Thermostat for Pressure Washers Lavor NPX 1400 - NPX 1500
Thermostat for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Thermostat 30/150 Bulb d.6.5 (3 Faston) for Pressure Washers NPX 1400 - NPX 1500. Part for the following...
on 10 Business Days Approx €40.24
Details
Dashboard Gasket for Pressure Cleaner Lavor NPX 1400
Lavorwash S.p.A. SKU: 4.608.0078
Dashboard Gasket for Pressure Cleaner Lavor NPX 1400
Dashboard Gasket for Pressure Cleaner Lavor NPX 1400 Genuine replacement part Lavor, Dashboard Gasket '93 (3x900) for Pressure Cleaners NPX 1400 - NPX 1500 - LKX 40. Part for the following products: -  Pressure Cleaner NPX 1400 230/50...
Last items in stock €3.32
Details
Pressure Switch for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 3.704.0006
Pressure Switch for Pressure Washer Lavor Missouri
Pressure Switch for Pressure Washer Lavor Missouri Genuine part Lavor, Pressure Switch 25 Bar 1/8 Red L.700 Faston F. for Pressure Washers  MISSOURI - YUKON 1310 - NPX 1500 - LKX 40. Part...
Last items in stock €30.90
Details
HP Tube R2 400 BAR for Pressure Washer Lavor NPX 1400
Lavorwash S.p.A. SKU: 4.618.0033
HP Tube R2 400 BAR for Pressure Washer Lavor NPX 1400
HP Tube R2 400 BAR for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, HP Tube R2 400 BAR L=300 From Coil to Block JOLLY 4/93 for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: -...
Last items in stock €26.97
Details
Diesel Nozzle for Pressure Washers Lavor NPX 1400
Lavorwash S.p.A. SKU: 3.104.0028
Diesel Nozzle for Pressure Washers Lavor NPX 1400
Diesel Nozzle for Pressure Washers Lavor NPX 1400 Genuine replacement part Lavor, Diesel Nozzle 1,25 45-B for Pressure Washers NPX 1400 - NPX 1500 - LKX 31 - LKX 40. Part for the following...
Last items in stock €28.36
Details
Ceramic Piston Body Guide for Pressure Cleaner Lavor NPX 1400
Lavorwash S.p.A. SKU: 5.007.0063
Ceramic Piston Body Guide for Pressure Cleaner Lavor NPX 1400
Ceramic Piston Body Guide for Pressure Cleaner Lavor NPX 1400 Genuine replacement part Lavor, Ceramic Piston Body Guide for Pressure Cleaners NPX 1400. Part for the following products: -  Pressure Cleaner NPX 1400 230/50 TS -...
Last items in stock €153.20
Details
Pistons Guide Body for Pressure Washer Lavor NPX 1500
Lavorwash S.p.A. SKU: 4.005.0055
Pistons Guide Body for Pressure Washer Lavor NPX 1500
Pistons Guide Body for Pressure Washer Lavor NPX 1500 Genuine replacement part Lavor, Pistons Guide Body OMNIA 130/8 Aluminium for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: -  Pressure Washer LKX 40 -...
Last items in stock €94.47
Details
Pressure Gauge Pipe for Pressure Washers Lavor NPX 1500
Lavorwash S.p.A. SKU: 4.618.0014
Pressure Gauge Pipe for Pressure Washers Lavor NPX 1500
Pressure Gauge Pipe for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Pressure Gauge Pipe 2x380 Max 630 Bar 1/4 F. Gir. 1/4 F Gir. for Pressure Washers NPX 1400 - NPX...
Usually Ships in: 10/15 Business Days Approx. €26.46
Details
Burner Flange Cpl for Pressure Washer Lavor NPX 1400
Lavorwash S.p.A. SKU: 5.611.0027
Burner Flange Cpl for Pressure Washer Lavor NPX 1400
Burner Flange Complete for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Burner Flange Complete for Pressure Washers NPX 1400 - NPX 1500. Part for the following...
Last items in stock €84.30
Details
Double Pipe Diesel Pump for Pressure Washer Lavor NPX 1500
Lavorwash S.p.A. SKU: 3.551.0062
Double Pipe Diesel Pump for Pressure Washer Lavor NPX 1500
Double Pipe Diesel Pump R. for Pressure Washer Lavor NPX 1500 Genuine replacement part Lavor, Double Pipe Diesel Pump Right Suntec with Coil 220V 50/60Hz for Pressure Washers NPX 1500. Part for the following products:...
on 7/10 Business Days Approx. €144.48
Details
Lavor MCHPV 1515LP Kit 111 LW
Lavorwash S.p.A. SKU: 6.005.0120
Lavor MCHPV 1515LP Kit 111 LW
Lavor MCHPV 1515LP Kit 111 LW Genuine replacement part Lavor, Kit 111 LW Pressure Regulator For Brass Head Test.Oct.'99 for Pressure Cleaner MCHPV 1515LP 400-415/SC1 - 8.626.0002. Part for the following products:...
on 10 Business Days Approx. €28.38
Details
Lavor Ontario 1211LP Pressure Gauge D.40
Lavorwash S.p.A. SKU: 3.107.0006
Lavor Ontario 1211LP Pressure Gauge D.40
Lavor Ontario 1211LP Pressure Gauge D.40 Genuine replacement part Lavor, Pressure Gauge D.40 0/300 BAR 1/8" Glycerine for Pressure Cleaner Ontario 1211LP - 86590033. Part for the following products: -  ONTARIO 1211LP 220/60 -G- LWS...
on 10 Business Days Approx. €26.50
Details
Lavor LKX 2015 Ignition Transformer
Lavorwash S.p.A. SKU: 5.609.0344
Lavor LKX 2015 Ignition Transformer
Lavor LKX 2015 Ignition Transformer Genuine replacement part Lavor, Ignition Transformer 220-240V 50/60Hz C/PIPET.NPX-LKX + CAVO (POTENZ.) for LKX 2015. Part for the following products: - 8.621.2935 - Pressure Washer LKX...
Usually Ships in: 10/15 Business Days Approx. €63.65
Details
Lavor Oil Lever Indicator for NPX 1400
Lavorwash S.p.A. SKU: 3.099.0003
Lavor Oil Lever Indicator for NPX 1400
Lavor Oil Lever Indicator for Pressure Washer NPX 1500 Genuine replacement part Lavor, Oil Lever Indicator SLNS-3/8 HOBBY for Pressure Cleaner NPX 1400 - NPX 1500 - MCHPV 1515LP. Part for the following products: -  Pressure Cleaner...
Usually Ships in: 10/15 Business Days Approx. €4.14
Details
Lavor Adjustment Knob for MEK 1108
Lavorwash S.p.A. SKU: 4.608.0164
Lavor Adjustment Knob for MEK 1108
Lavor Adjustment Knob for Pressure Cleaner MEK 1108 Genuine replacement part Lavorwash, Black Thermostat Adjustment Knob for Pressure Cleaner DAKOTA-R 2007XP - MISSOURI - MEK 1108. Part for the following products: - ...
Last items in stock €5.83
Details
LAVOR Brass Pump Head for NPX 1400 Pressure Washers
Lavorwash S.p.A. SKU: 4.606.0085
LAVOR Brass Pump Head for NPX 1400 Pressure Washers
LAVOR Brass Pump Head for NPX 1400 Pressure Washers Original Lavor Spare Part: Brass Pump Head '99 for LAVOR NPX 1400 Pressure Washers. Compatible with the following products: -  Lavor NPX 1400 - 86050048 -  Lavor NPX 1400...
Usually Ships in: 10/15 Business Days Approx €147.90
Details
Lavor Recall Spring for Pressure Cleaner FKX 1018
Lavorwash S.p.A. SKU: 00030-00517 ex 4.007.0014
Lavor Recall Spring for Pressure Cleaner FKX 1018
Lavor Recall Spring for Pressure Cleaner FKX 1018 Original replacement part Lavorwash, Detergent Stop Valve Spring De4, 5/6 L=7 FILO D.0,3 INOX for Pressure Cleaners FKX 1018 - NPX1400. Part for the following products:...
Usually Ships in: 10 Business Days Approx. €2.57
Details
Lavor Pressure Washer NPX1400 Insulating Rope
Lavorwash S.p.A. SKU: 4.608.0162
Lavor NPX1400 Insulating Rope
Lavor Pressure Washer NPX1400 Insulating Rope Genuine replacement part Lavor, Insulating Rope For Boiler Base L=990 for Pressure Washer NPX1400 - LKX 31 - LKX 55. Part for the following products: - ...
Last items in stock €35.27
Details
Comments (0)
