Lavorwash S.p.A.

Lavor Floor Scrubber Drier L1 36B CBT Parts

SKU: L1 36B CBT - 8.518.0069
€223.81
VAT included

Lavor Pro Original Parts for Floor Scrubber Drier L1 36B CBT

Lavor original spare parts for to replace broken parts for to fix Floor Scrubber Drier L1 36B CBT+1X GEL GIALLO/GR.SC. - 8.518.0069.

Fix Your Floor Scrubber Drier L1 36B CBT+1X GEL GIALLO/GR.SC. - 8.518.0069. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts.
Lavor Floor Scrubber Drier L1 36B CBT Parts
  • Lavor Floor Scrubber Drier L1 36B CBT Parts
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 1
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 2
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 3
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 4
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 5
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 6
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 7
  • Lavor Floor Scrubber Drier L1 36B CBT Parts Drawing - 8
Lavorwash S.p.A.

Lavor Floor Scrubber Drier L1 36B CBT Parts

SKU: L1 36B CBT - 8.518.0069 Condition: New
€223.81
VAT included

Lavor Pro Original Parts for Floor Scrubber Drier L1 36B CBT

Lavor original spare parts for to replace broken parts for to fix Floor Scrubber Drier L1 36B CBT+1X GEL GIALLO/GR.SC. - 8.518.0069.

Fix Your Floor Scrubber Drier L1 36B CBT+1X GEL GIALLO/GR.SC. - 8.518.0069. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts.
settings 109 spare parts
description 10 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
109 spare parts
Esploso pagina 1
Pos. Item Price Buy
2
 photo_cameraImage coming soon 5.511.1407 BUMPER WHEEL SUPPORT COMPLETE €45.99
3
 photo_cameraImage coming soon 5.511.1397 WHEEL AXLE ASSEMBLY €155.67
4
 photo_cameraImage coming soon 4.508.0123 SUCTION MOTOR GASKET €10.54
5
 photo_cameraImage coming soon 4.513.0375 BRUSH CARTER €121.70
6
 photo_cameraImage coming soon 4.513.0380 RELE PROTECTION CARTER €51.18
7
 photo_cameraImage coming soon 4.508.0518 PROTECTION €3.34
8
 photo_cameraImage coming soon 4.507.1251 SQUEEGEE LIFT CABLE SUPPORT €29.49
9
 photo_cameraImage coming soon 4.508.1064 DETERGENT TANK FILTER €1.68
10
 photo_cameraImage coming soon 4.508.0739 SPONGE FILTER €1.63
11
 photo_cameraImage coming soon 4.508.0689 FIXING WHEEL AXLE €1.73
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.508.1983 UPPER RECOVERY TANK FLICK/QUICK PANT. 108C €217.29
2
 photo_cameraImage coming soon 4.508.1042 SOLUTION WATER TANK €314.31
3
 photo_cameraImage coming soon 5.511.2213 ORDER BRUSH ASSEMBLY Y21B MOD PP0.6 D360 €57.45
4
 photo_cameraImage coming soon 0.108.0061 EXTERNAL BATTERY CHARGER ON-BOARD 12V 8A IUUO-GEL WITH PLASTIC COVERS - SCHUKO PLUG €207.35
5
 photo_cameraImage coming soon 0.107.0061 GEL BATTERY 12V MFP 50 -65 Ah C-20/50 Ah C-5 €371.95
6
 photo_cameraImage coming soon 7.504.0283 QUICK/A1/FLICK MANUAL + CE LAVOR 19L A5 432F €18.28
7
 photo_cameraImage coming soon 3.499.0393 MAIN WIRING €77.07
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.507.1123 WATER VALVE SUPPORT €35.14
2
 photo_cameraImage coming soon 5.511.1407 BUMPER WHEEL SUPPORT COMPLETE €45.99
3
 photo_cameraImage coming soon 5.511.1397 WHEEL AXLE ASSEMBLY €155.67
4
 photo_cameraImage coming soon 4.508.0123 SUCTION MOTOR GASKET €10.54
5
 photo_cameraImage coming soon 4.513.0375 BRUSH CARTER €121.70
6
 photo_cameraImage coming soon 4.513.0380 RELE PROTECTION CARTER €51.18
7
 photo_cameraImage coming soon 4.508.0518 PROTECTION €3.34
8
 photo_cameraImage coming soon 4.507.1251 SQUEEGEE LIFT CABLE SUPPORT €29.49
9
 photo_cameraImage coming soon 4.508.1064 DETERGENT TANK FILTER €1.68
10
 photo_cameraImage coming soon 4.508.0739 SPONGE FILTER €1.63
11
 photo_cameraImage coming soon 4.508.0689 FIXING WHEEL AXLE €1.73
21
 Vac Hose for Floor Scrubber Drier SCL QUICK 36B CBT 3.752.0190 Vac Hose for Floor Scrubber Drier SCL QUICK 36B CBT €22.41
23
 photo_cameraImage coming soon 3.412.0028 SOLENOID VALVE €73.44
24
 photo_cameraImage coming soon 3.105.0012 VALVE €29.49
25
 photo_cameraImage coming soon 3.100.0340 HOSE FITTING UNION G1/4 D10 €3.73
27
 photo_cameraImage coming soon 3.099.1409 CLIPS €1.72
28
 Lavor SCL QUICK 36B CBT Squeegee Lift Cable 3.099.1459 Lavor SCL QUICK 36B CBT Squeegee Lift Cable €36.86
29
 photo_cameraImage coming soon 3.100.0357 ELBOW 1/2'M 1/2'M €12.43
30
 photo_cameraImage coming soon 5.513.0230 HANDLE LOCK PEDAL €113.90
32
 Water Filter for Floor Scrubber Drier SCL QUICK 36B CBT 3.102.0020 Water Filter for Floor Scrubber Drier SCL QUICK 36B CBT €53.43
46
 photo_cameraImage coming soon 3.755.0116 VACUUM MOTOR 12V 180W €122.93
47
 Vac Motor Ass'y for Floor Scrubber Drier SCL QUICK 36B CBT 5.511.1399 Vac Motor Ass'y for Floor Scrubber Drier SCL QUICK 36B CBT €165.21
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3.006.0127 LOOSE WHEEL D=210 L=42 D10 €80.15
2
 photo_cameraImage coming soon 4.507.1118 WHEEL SHAFT €77.12
3
 photo_cameraImage coming soon 3.099.1066 CAP FOR WHEEL - GREY €14.80
4
 photo_cameraImage coming soon 4.508.0687 AXLE SUPPORT €1.73
21
 Vac Hose for Floor Scrubber Drier SCL QUICK 36B CBT 3.752.0190 Vac Hose for Floor Scrubber Drier SCL QUICK 36B CBT €22.41
23
 photo_cameraImage coming soon 3.412.0028 SOLENOID VALVE €73.44
24
 photo_cameraImage coming soon 3.105.0012 VALVE €29.49
25
 photo_cameraImage coming soon 3.100.0340 HOSE FITTING UNION G1/4 D10 €3.73
27
 photo_cameraImage coming soon 3.099.1409 CLIPS €1.72
28
 Lavor SCL QUICK 36B CBT Squeegee Lift Cable 3.099.1459 Lavor SCL QUICK 36B CBT Squeegee Lift Cable €36.86
29
 photo_cameraImage coming soon 3.100.0357 ELBOW 1/2'M 1/2'M €12.43
30
 photo_cameraImage coming soon 5.513.0230 HANDLE LOCK PEDAL €113.90
32
 Water Filter for Floor Scrubber Drier SCL QUICK 36B CBT 3.102.0020 Water Filter for Floor Scrubber Drier SCL QUICK 36B CBT €53.43
46
 photo_cameraImage coming soon 3.755.0116 VACUUM MOTOR 12V 180W €122.93
47
 Vac Motor Ass'y for Floor Scrubber Drier SCL QUICK 36B CBT 5.511.1399 Vac Motor Ass'y for Floor Scrubber Drier SCL QUICK 36B CBT €165.21
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 4
Pos. Item Price Buy
1
 photo_cameraImage coming soon 7.503.0376 STICKER FOR SUCTION MOTOR COMP ARTMENT €30.96
2
 photo_cameraImage coming soon 5.511.1400 VACCUM COVER ASSEMBLY €57.67
3
 photo_cameraImage coming soon 5.511.1401 FLOAT ASSEMBLY €49.98
4
 photo_cameraImage coming soon 5.511.1511 KIT FILTRE €49.51
5
 photo_cameraImage coming soon 5.511.0203 RECOVERY TANK CAP ASSEMBLY €28.80
6
 Lavor SCL QUICK 36B CBT Exhaust Pipe 3.752.0256 Lavor SCL QUICK 36B CBT Exhaust Pipe €26.22
7
 Drain Hose Cap for Floor Scrubber Drier SCL QUICK 36B CBT 4.208.0274 Drain Hose Cap for Floor Scrubber Drier SCL QUICK 36B CBT €5.35
8
 photo_cameraImage coming soon 3.200.0077 OR GASKET 64,39X1,78 NBR SH70 €1.67
9
 photo_cameraImage coming soon 4.507.0813 THREADED BAR M6X60 €10.52
10
 photo_cameraImage coming soon 4.507.1487 SPACER FOR COVER €10.25
11
 photo_cameraImage coming soon 4.508.0565 INSERT €10.63
12
 photo_cameraImage coming soon 4.508.1610 RING FOR COVER €3.34
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 5
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.513.0313 REAR SQUEEGEE BLADE HOLDER PLATE €32.38
2
 photo_cameraImage coming soon 4.507.1554 BLADE HOLDER - FRONT €29.30
3
 Rear Squeegee Blade for Floor Scrubber Drier SCL QUICK 36B CBT 4.508.1101 Rear Squeegee Blade for Floor Scrubber Drier SCL QUICK 36B CBT €8.75
4
 Front Squeegee Blade for Floor Scrubber Drier SCL QUICK 36B CBT 4.508.1100 Front Squeegee Blade for Floor Scrubber Drier SCL QUICK 36B CBT €8.75
5
 photo_cameraImage coming soon 4.508.1039 VACCUM RACCORD €11.58
6
 photo_cameraImage coming soon 6.505.0082 WHEEL SET €9.17
7
 photo_cameraImage coming soon 3.099.1226 SPHERE CONNECTION €48.67
8
 photo_cameraImage coming soon 5.513.0245 SWINGING SQUEEGEE SUPPORT €145.72
09
 photo_cameraImage coming soon 3.200.0212 O-RING €3.23
10
 photo_cameraImage coming soon 3.099.0477 KNOB M6 (THREADED PASS-THROUGH HOLE) €4.39
11
 photo_cameraImage coming soon 4.507.1273 LIFT SQUEEGEE CABLE FORK €11.65
12
 photo_cameraImage coming soon 4.507.1245 SQUEEGEE SUPPORT €39.42
13
 photo_cameraImage coming soon 3.002.0822 SCREW M6 X 45 €1.72
14
 photo_cameraImage coming soon 3.002.0820 SCREW M6 X 35 €1.72
15
 photo_cameraImage coming soon 4.507.1130 SQUEGEE BALLAST €184.39
16
 photo_cameraImage coming soon 4.508.1557 SQUEGEE €27.44
Page 6 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 6
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.501.0082 MOTOR 12V 250W 1200g €321.03
2
 photo_cameraImage coming soon 5.513.0244 BRUSH PLATE SUPPORT €123.23
3
 photo_cameraImage coming soon 4.507.1125 SWINGING SUPPORT €113.35
4
 Belt PJ762 for Floor Scrubber Drier SCL QUICK 36B CBT 3.099.1394 Belt PJ762 for Floor Scrubber Drier SCL QUICK 36B CBT €17.50
5
 photo_cameraImage coming soon 4.507.1272 SPRING €6.60
6
 photo_cameraImage coming soon 4.507.1124 BELD LEVER €62.83
7
 photo_cameraImage coming soon 3.001.0032 BEARING 6002 2RS1 €5.03
8
 Lavor SCL QUICK 36B CBT Pulley Assy 5.511.1385 Lavor SCL QUICK 36B CBT Pulley Assy €106.77
9
 photo_cameraImage coming soon 4.507.1613 BRUSH CONNECTOR FOR FIXING WITH PRESSURES 1 €26.34
10
 photo_cameraImage coming soon 4.508.1758 CONICAL CENTERING INN.BRUSH WITH CENTRAL SCREW €5.36
Page 7 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 7
Pos. Item Price Buy
1
 photo_cameraImage coming soon 6.505.0137 CONTROL ROD KIT WITH SCREW FOR QUICK €47.62
2
 photo_cameraImage coming soon 4.508.1035 HANDLE €164.35
3
 photo_cameraImage coming soon 4.507.1248 MICROSWITCH INSIDE SUPPORT €37.60
4
 photo_cameraImage coming soon 4.507.1269 STOP BUSH €44.04
5
 photo_cameraImage coming soon 4.508.1026 HANDLE FIXING WASHER €13.92
6
 photo_cameraImage coming soon 3.004.0105 PLAIN WASHER D.10X40X2.5 INOX UNI6593 €1.72
7
 photo_cameraImage coming soon 3.002.0819 SCREW 10 X 150 €13.92
8
 photo_cameraImage coming soon 4.507.0522 SPRING €3.49
9
 photo_cameraImage coming soon 3.401.0157 MICROSWITCH WITH LEVER 20A 250 V €14.87
10
 photo_cameraImage coming soon 3.099.1338 TIE ROD €5.26
11
 photo_cameraImage coming soon 4.507.1119 COMAND LEVER €34.81
12
 photo_cameraImage coming soon 4.507.1247 SQUEEGEE LEVER SUPPORT €35.82
Page 8 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 8
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.505.0879 DASH BOARD €18.20
2
 photo_cameraImage coming soon 3.401.0116 CAP €3.94
3
 photo_cameraImage coming soon 3.401.0109 DOUBLE BLACK SWITCH WITH PROTECTION €8.37
4
 photo_cameraImage coming soon 5.009.0879 SWITCH ASSEMBLY €13.19
Page 9 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 9
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.511.2201 BIDIRECTIONAL BRUSH CONNECTOR ASSEMBLY WITH PRESSURES €17.92

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Pro Original Parts for Floor Scrubber Drier L1 36B CBT

Lavor original spare parts for to replace broken parts for to fix Floor Scrubber Drier L1 36B CBT+1X GEL GIALLO/GR.SC. - 8.518.0069.

In the following tables, look for the spare part and its respective code.
L1 36B CBT - 8.518.0069
L1 36B CBT+1X GEL GIALLO/GR.SC. - 8.518.0069
Pag.1
# Part Num Description
1 4.508.1983 UPPER RECOVERY TANK FLICK/QUICK PANT. 108C
2 4.508.1042 LOWER SOLUTION TANK FLICK/QUICK GR. SC. RAL. 7021
3 5.511.2213 ORDER BRUSH ASSEMBLY Y21B MOD PP0.6 D360
4 0.108.0061 EXTERNAL BATTERY CHARGER ON-BOARD 12V 8A IUUO-GEL WITH PLASTIC COVERS - SCHUKO PLUG
5 0.107.0061 EXT MONOBLOC GEL BATTERY 12 MFP 50-65 A C-20/50 A C-5
6 7.504.0283 QUICK/A1/FLICK MANUAL + CE LAVOR 19L A5 432F
7 3.499.0393 BATTERY POWER WIRING
GRUPPO SOLUZIONE FLICK/QUICK BATTERIA Pag.2
1 4.507.1123 TAP BRACKET
2 5.511.1407 BUFFER WHEEL ASSEMBLY
3 5.511.1397 WHEEL AXLE ASSEMBLY
4 4.508.0123 VACUUM MOTOR SEAL Thickness 8mm
5 4.513.0375 FLICK/QUICK BRUSH COVER
6 4.513.0380 RELAY GROUP COVER (FINISHED)
7 4.508.0518 IMPELLER PROTECTION FOR 44 mm HOLES
8 4.507.1251 SQG LIFTING BRACKET
9 4.508.1064 SWIFT/FLICK DETERGENT TANK FILTER
10 4.508.0739 FILTER SPONGE
11 4.508.0689 WHEEL FIXING AXLE
21 3.752.0190 EXT SQG SUCTION HOSE D.25 WITH SLEEVES
23 3.412.0028 EXT 2-WAY SOLENOID VALVE 1/4 12V
24 3.105.0012 BALL VALVE TAP 1/4 F 1/4 M
25 3.100.0340 HOSE CONNECTOR G1/4 D10
27 3.099.1409 HOSE CLIP D.25
28 3.099.1459 EXT SQG CONTROL CABLE WITH SHEATH
29 3.100.0357 90 CONNECTOR G1/2 M-G1/2 M
30 5.513.0230 EXT RELEASE PEDAL
32 3.102.0020 WATER FILTER G1/2 D.13 SHURFLO 255-223
46 3.755.0116 EXT 12V 180W DOUBLE-STAGE SUCTION MOTOR WITH TANG. EXHAUST
47 5.511.1399 EXT FLICK/QUICK INTAKE MOTOR ASSEMBLY
ASSIEME ASSE RUOTE Pag.3
1 3.006.0127 EXT FLICK/QUICK IDLER WHEEL 210x45
2 4.507.1118 REAR WHEEL AXLE
3 3.099.1066 GRAY G-48 HUB CAP FOR 16" WHEEL, POLYURETHANE
4 4.508.0687 AXLE SUPPORT
GRUPPO RECUPERO FLICK/QUICK Pag.4
1 7.503.0376 ENGINE COMPARTMENT STICKER SWIFT B
2 5.511.1400 INTAKE COVER ASSEMBLY
3 5.511.1401 QUICK FLOAT ASSEMBLY
4 5.511.1511 FILTER + SPONGE KIT
5 5.511.0203 RECOVERY TANK CAP KIT WITH SEAL
6 3.752.0256 EXTRA QUICK DRAIN PIPE
7 4.208.0274 EXTRA 32mm DIAM. CAP FOR DRAIN PIPE WITH RETAINING RING
8 3.200.0077 OR-SEAL 2262 64.39x1.78 NBR SH.70
9 4.507.0813 M6X60 STAINLESS STEEL THREADED ROD
10 4.507.1487 QUICK COVER FIXING SPACER
11 4.508.0565 QUICK INSERT
12 4.508.1610 EXTRA QUICK COVER SEALING RING
GRUPPO SQUEGEE FLICK / QUICK '16 Pag.5
1 5.513.0313 SQG REAR BLADE STOP. QUICK
2 4.507.1554 QUICK FRONT BLADE STOP
3 4.508.1101 ORD REAR BLADE SQUEEGEE NATURAL RUBBER 590X50X3
4 4.508.1100 ORD FRONT BLADE SQUEEGEE NATURAL RUBBER 537X50X1.5
5 4.508.1039 INTAKE MANIFOLD
6 6.505.0082 KIT OF 1 WHEEL d. 35 SQG. QUICK VERSION '16 / DYNAMIC
7 3.099.1226 BALL JOINT, HOLE D=8, M8 FEMALE SHAFT (STEEL-STEEL)
8 5.513.0245 SQG SWING ARM
09 3.200.0212 OR SEAL 2150 37.82x1.78 NBR SH. 90
10 3.099.0477 M6 THROUGH-N-HANDWHEEL
11 4.507.1273 PINGO FOR LIFTING CABLE SQG
12 4.507.1245 SQG SUPPORT
13 3.002.0822 ROUND HEAD SCREW WITH SQUARE UNDERHEAD M6X45 UNI 5731 STAINLESS STEEL FULL THREAD
14 3.002.0820 ROUND HEAD SCREW WITH SQUARE UNDERHEAD M6X35 UNI 5732 STAINLESS STEEL
15 4.507.1130 BALLAST FOR FLICK SQUEGEE
16 4.508.1557 QUICK SQUEGEE
GRUPPO PIATTO FLICK / QUICK BATTERIA BIDIREZZIONALE Pag.6
1 5.501.0082 EXTERNAL MOTOR 12V 250W 1200g FLICK/QUICK
2 5.513.0244 FIXED BRUSH SUPPORT
3 4.507.1125 MOBILE BRUSH PLATE SUPPORT
4 3.099.1394 EXTERNAL POLY-V BELT PJ762/300J EL H = 7 TEETH
5 4.507.1272 BRUSH PLATE TRACTION SPRING
6 4.507.1124 BELT TENSIONER LEVER
7 3.001.0032 RADIAL BALL BEARING 6002 2RS1
8 5.511.1385 DRIVEN PULLEY ASSEMBLY
9 4.507.1613 BRUSH COUPLING FOR FIXING WITH PRESSURES
10 4.508.1758 BRUSH COUPLING CONICAL CENTERING WITH CENTRAL SCREW
ASSIEME MANICO COMANDO Pag.7
1 6.505.0137 CONTROL ROD KIT WITH SCREW FOR QUICK
2 4.508.1035 DARK GREY GUIDE HANDLE RAL.7021
3 4.507.1248 INTERNAL CONTROL SUPPORT SQG. EXP.B
4 4.507.1269 SAFETY LOCKING SELECTOR exp.D
5 4.508.1026 SIDE JOINT PIN
6 3.004.0105 FLAT WASHER D.10X40 Th.2.5 STAINLESS STEEL UNI6593
7 3.002.0819 TCEI SCREW M10X150 UNI 5931 STAINLESS STEEL
8 4.507.0522 SPRING FOR TRACTION LEVER
9 3.401.0157 EXT MICROSWITCH WITH LEVER XG02-86-P23
10 3.099.1338 BLACK TIE ROD L=60 FEMALE M8
11 4.507.1119 SQG CONTROL LEVER
12 4.507.1247 SQG LEVER SUPPORT
ASSIEME PIASTRA INTERRUTTORI (FLICK-QUICK) Pag.8
1 4.505.0879 CONTROL PANEL WITHOUT HOUR METER HOUSING
2 3.401.0116 PLUG 22x30 B71XX1X000015
3 3.401.0109 EXTERNAL BLACK DOUBLE SWITCH 0-1 WITH PROTECTION
4 5.009.0879 EXTERNAL SINGLE SWITCH ASSEMBLY + TRANSPORT PROTECTION 12V (QUICK)
ASSIEME SPAZZ. Y21B MOD PP0,6 D360 Pag.9
1 5.511.2201 BIDIRECTIONAL BRUSH CONNECTOR ASSEMBLY WITH PRESSURES
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
L1 36B CBT - 8.518.0069
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

New

Download

LAVOR L1 36B CBT Parts Drawing

LAVOR L1 36B CBT Parts Drawing

Download (503.68KB)

You might also like

Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter
Lavorwash S.p.A. SKU: 5.509.0008
Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter
Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter Genuine replacement part Lavor, Flexible Hose Ass'y L.800 MW for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following products:...
Last items in stock €29.49
Details
Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter
Lavorwash S.p.A. SKU: 3.099.0278
Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter
Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter Genuine replacement part Lavor, Belt 336 RPP3-12 for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following...
Usually Shipped on: 10 Business Days Approx. €29.49
Details
Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean
Lavorwash S.p.A. SKU: 6.505.0087
Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean
Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean Genuine replacement part Lavor, Boiler Kit for Floor Scrubber Drier Crystal Clean. Part for the following products: -  Floor Scrubber Drier Lavor...
Last items in stock €87.31
Details
Vac Motor Ass'y for Floor Scrubber Drier SCL QUICK 36B CBT
Lavorwash S.p.A. SKU: 5.511.1399
Vac Motor Ass'y for Floor Scrubber Drier SCL QUICK 36B CBT
Vac Motor FLICK/QUICK Ass'y for Floor Scrubber Drier SCL QUICK 36B CBT Genuine replacement part Lavor, Vac Motor FLICK/QUICK Assembly for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the following...
Last items in stock €165.21
Details
Water Filter for Floor Scrubber Drier SCL QUICK 36B CBT
Lavorwash S.p.A. SKU: 3.102.0020
Water Filter for Floor Scrubber Drier SCL QUICK 36B CBT
Water Filter for Floor Scrubber Drier SCL QUICK 36B CBT Genuine replacement part Lavor, Water Filter G 1/2" D.13 SHURFLO 255-223 for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the...
Last items in stock €53.43
Details
Vac Hose for Floor Scrubber Drier SCL QUICK 36B CBT
Lavorwash S.p.A. SKU: 3.752.0190
Vac Hose for Floor Scrubber Drier SCL QUICK 36B CBT
Vac Hose for Floor Scrubber Drier SCL QUICK 36B CBT Genuine replacement part Lavor, Vacuum Hose Squeegee D.25 with Sleeves for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the...
Last items in stock €22.41
Details
Drain Hose Cap for Floor Scrubber Drier SCL QUICK 36B CBT
Lavorwash S.p.A. SKU: 4.208.0274
Drain Hose Cap for Floor Scrubber Drier SCL QUICK 36B CBT
Drain Hose Cap for Floor Scrubber Drier SCL QUICK 36B CBT Genuine replacement part Lavor, Cap d.32MM for Drain Hose with Stop Ring for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the following...
Last items in stock €5.35
Details
Belt PJ762 for Floor Scrubber Drier SCL QUICK 36B CBT
Lavorwash S.p.A. SKU: 3.099.1394
Belt PJ762 for Floor Scrubber Drier SCL QUICK 36B CBT
POLY-V Belt PJ762 for Floor Scrubber Drier SCL QUICK 36B CBT Genuine replacement part Lavor, POLY-V Belt PJ762/300J EL H =7 Teeth for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the...
Last items in stock €17.50
Details
Lavor SCL QUICK 36B CBT Pulley Assy
Lavorwash S.p.A. SKU: 5.511.1385
Lavor SCL QUICK 36B CBT Pulley Assy
Floor Scrubber Drier SCL QUICK 36B CBT Free Pulley Assembly Genuine replacement part Lavor, Free Pulley Assembly for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the following products: -  Floor Scrubber...
Last items in stock €106.77
Details
Lavor SCL QUICK 36B CBT Squeegee Lift Cable
Lavorwash S.p.A. SKU: 3.099.1459
Lavor SCL QUICK 36B CBT Squeegee Lift Cable
Lavor SCL QUICK 36B CBT Squeegee Lift Cable Complete Genuine replacement part Lavor, Squeegee Lift Cable Complete for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the following products: -  Floor...
Last items in stock €36.86
Details
Lavor SCL QUICK 36B CBT Exhaust Pipe
Lavorwash S.p.A. SKU: 3.752.0256
Lavor SCL QUICK 36B CBT Exhaust Pipe
Lavor SCL QUICK 36B CBT Exhaust Pipe Genuine replacement part Lavor, Exhaust Pipe for Floor Scrubber Drier SCL QUICK 36B CBT - 85180003. Part for the following products: -  Floor Scrubber Drier SCL QUICK 36B CBT -...
AVAILABLE €26.22
Details
Lavor Traction Spring Lever for SCL QUICK 36B CBT
Lavorwash S.p.A. SKU: 00030-00682 ex 4.507.0522
Lavor Traction Spring Lever for SCL QUICK 36B CBT
Lavor Traction Spring Lever for Floor Scrubber Drier SCL QUICK 36B CBT Original replacement part Lavorwash, Traction Lever Spring for Floor Scrubber Drier SCL QUICK 36B CBT - L1 36B CBT. Part for the following products: -  Floor...
Usually Ships in: 10 Business Days Approx. €3.09
Details
Comments (0)
