Lavor Pressure Cleaner XTR-R 1007 Parts

SKU: Lavor XTR-R 1007 - 8.052.0846
€65.35
VAT included

Lavor Original Parts for Pressure Cleaner XTR-R 1007

Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner 8.052.0846 - IDRO XTR-R 1007 230/50 TS -G- LAVOR

Fix Your Pressure Cleaner IDRO XTR 1007 R. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
Lavor Pressure Cleaner XTR 1007 R Parts
  • Lavor Pressure Cleaner XTR 1007 R Parts
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 1
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 2
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 3
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 4
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 5
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 6
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 7
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 8
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 9
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 10
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 11
  • Lavor Pressure Cleaner XTR-R 1007 Parts Drawing - 12
Lavorwash S.p.A.

Lavor Pressure Cleaner XTR-R 1007 Parts

SKU: Lavor XTR-R 1007 - 8.052.0846 Condition: New
€65.35
VAT included

Lavor Original Parts for Pressure Cleaner XTR-R 1007

Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner 8.052.0846 - IDRO XTR-R 1007 230/50 TS -G- LAVOR

Fix Your Pressure Cleaner IDRO XTR 1007 R. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
settings 92 spare parts
description 13 exploded views
picture_as_pdf Download Exploded PDF
CODICE ARTICOLO
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
92 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.013.0965 UPPER CAREN. RIO-G-PANT.108C €63.45
2
 photo_cameraImage coming soon 4.008.2567 LOWER CAREN. RH RIO-R BLACK €21.39
3
 photo_cameraImage coming soon 4.008.2566 LOWER CAREN. LEFT RIO-R BLACK €21.39
4
 photo_cameraImage coming soon 5.011.0536 HANDLE €121.84
5
 photo_cameraImage coming soon 4.608.0027 BLACK PLUG D.30 FOR TANK €10.03
6
 photo_cameraImage coming soon 7.100.2488 MANUAL RIO-R XTR-R LAVOR 19L A5 164F €5.16
7
 Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor 3.700.0036 Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor €30.90
8
 photo_cameraImage coming soon 4.618.0049 HOSE 1/4 R1 210BAR L=8000 3/8"F €55.11
9
 photo_cameraImage coming soon 3.712.0019 HI/LO LANCE 025 M22 (MAX 220BAR 3200PSI) -RED- RAL.3020 €30.85
10
 Inlet Quick Coupling for High Pressure Washers Lavor 3.100.0062 Inlet Quick Coupling for High Pressure Washers Lavor €4.25
11
 photo_cameraImage coming soon 3.100.0510 TRANSP.QUICK COUPLING W/INSPECT.FILTER (CAO) €7.93
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.611.0313 CONTROL PANEL 230V €117.88
2
 photo_cameraImage coming soon 4.008.1026 MOTOR CONVEYER RIGHT+LEFT 2100W €7.98
3
 photo_cameraImage coming soon 4.007.0355 L-SHAPED BRACKET FOR MOTOR SUPPORT €16.27
4
 photo_cameraImage coming soon 6.005.0640 INPUT EXTENSION KIT 3/4 M-F €14.96
5
 Lavor Pressure Washer XTR 1007 Motor Pump Ass'y 5.001.I763C Lavor Pressure Washer XTR 1007 Motor Pump Ass'y €114.73
6
 photo_cameraImage coming soon 4.612.0074 PVC GROUND WIRE D.2,5 L=500 €3.32
7
 photo_cameraImage coming soon 5.609.0260 MAX PRESSURE VALVE 250BAR 1/8 €24.79
8
 photo_cameraImage coming soon 5.611.0282 GROUP DIESEL PUMP (ULKA) PATRIOT 24220056 €94.81
10
 photo_cameraImage coming soon 6.005.0645 PATRIOT DIESEL TANK CAP KIT WITH GASKET €10.00
11
 Lavor Diesel Tank for RIO-R 1108 4.008.2565 Lavor Diesel Tank for RIO-R 1108 €71.89
12
 photo_cameraImage coming soon 5.011.0558 DIESEL FILTER GROUP RIO-R/XTR-R (NYLON FILTER) €9.55
13
 photo_cameraImage coming soon 5.009.1187 POWER WIRING 3X1,5 PVC MT 6,4 SP.SCHUKO W/ANTID. FILTER €87.21
14
 photo_cameraImage coming soon 6.605.0075 KIT WHEEL+STUD+STOP WHEEL (ONTARIO/TUCSON) €29.61
15
 photo_cameraImage coming soon 4.008.2596 WASHER 30X17 THICKNESS 2.5 €3.07
16
 photo_cameraImage coming soon 4.007.0602 SHAPED FOOT PATRIOT RAL.7015 €28.82
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.013.0093 HANDLE FOR XTR-R €101.86
2
 photo_cameraImage coming soon 4.607.1028 HOOK FOR HANDLE €15.85
3
 photo_cameraImage coming soon 4.007.0607 INTERNAL DETERGENT TANK SUPPORT BRACKET €18.91
4
 photo_cameraImage coming soon 4.008.0868 DETERGENT TANK €31.21
5
 photo_cameraImage coming soon 4.007.0608 EXTERNAL DETERGENT TANK SUPPORT BRACKET €18.91
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Inlet Quick Coupling for High Pressure Washers Lavor 3.100.0062 Inlet Quick Coupling for High Pressure Washers Lavor €4.25
2
 photo_cameraImage coming soon 3.100.0510 TRANSP.QUICK COUPLING W/INSPECT.FILTER (CAO) €7.93
3
 photo_cameraImage coming soon 4.608.0027 BLACK PLUG D.30 FOR TANK €10.03
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Transformer 230-240V for Pressure Washer Lavor RIO 1108 5.009.1126 Transformer 230-240V for Pressure Washer Lavor RIO 1108 €100.43
2
 photo_cameraImage coming soon 4.008.0848 GASKET NEW TRANSFORMER FKX €1.72
3
 photo_cameraImage coming soon 3.100.0075 CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- €14.98
4
 Lavor MISSOURI Boiler Cover 4.005.0194 Lavor MISSOURI Boiler Cover €79.65
5
 photo_cameraImage coming soon 5.009.0637 BOILER CAP KIT €3.43
6
 photo_cameraImage coming soon 4.006.0187 NOZZLE HOLDER PIN €5.32
7
 photo_cameraImage coming soon 3.104.0031 0.50 60 H DIESEL NOZZLE (DANFOSS) €21.68
8
 photo_cameraImage coming soon 6.005.0307 FKX DEFLECTOR WITHOUT ELECTRODES €46.47
9
 photo_cameraImage coming soon 5.013.0027 DISK HEAD HOLDER €77.49
10
 photo_cameraImage coming soon 5.013.0092 PATRIOT/RIO-R/XTR BOILER BODY €71.37
11
 photo_cameraImage coming soon 3.099.0124 SEEGER RING X TREE D.42UNI 7435 €1.72
12
 photo_cameraImage coming soon 4.007.0303 TUBE D.40 L=325 FE 37 PREZINCED €11.85
13
 photo_cameraImage coming soon 4.007.0180 TIE ROD FOR BOILER FIRE '98M6X352 FIL.12-12 ZNT €6.99
14
 photo_cameraImage coming soon 4.604.0028 COIL D.202 SINGLE TURN X FKX ECO €217.66
14
 photo_cameraImage coming soon 6.605.0075 KIT WHEEL+STUD+STOP WHEEL (ONTARIO/TUCSON) €29.61
15
 photo_cameraImage coming soon 4.608.0038 RUBBER PROTECTION FOR THERMAL FIRE €1.72
16
 photo_cameraImage coming soon 3.403.0003 THERMAL PROTECTOR L01.080.05.1000 CABLES * UL * €19.69
17
 photo_cameraImage coming soon 4.606.0002 DELIVERY FITTING WITH HOLE FOR THERMAL ESP.03 €4.62
18
 photo_cameraImage coming soon 4.008.2475 SEAL COIL CONNECTOR (1201030500) 2 €6.94
19
 photo_cameraImage coming soon 4.007.0322 TUBE FKX L=42 €1.72
20
 photo_cameraImage coming soon 6.605.0141 HOBBY BOILER REFRACTORY KIT €51.70
21
 photo_cameraImage coming soon 4.007.0599 CONNECTOR FOR COIL WITH 3/8 CONICAL THREAD €18.52
22
 photo_cameraImage coming soon 4.006.0283 FERRULE M22x1,5 L=16. €3.32
23
 Burner Motor for Pressure Cleaner Lavor RIO 1108 3.304.0056 Burner Motor for Pressure Cleaner Lavor RIO 1108 €42.00
24
 photo_cameraImage coming soon 4.012.0102 CABLE L=600 SEC.0,75 IEC227-3/1979 €5.83
25
 photo_cameraImage coming soon 4.007.0158 BOILER PAD €65.73
26
 photo_cameraImage coming soon 4.005.0186 BOILER BASE FKX (DIE CAST) ESP.00 €128.72
Page 6 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Diesel Pump for Pressure Washer Lavor FKX 1018 3.551.0014 Diesel Pump for Pressure Washer Lavor FKX 1018 €58.71
2
 Pressure Adjustment Valve for Pressure Washer Lavor Missouri 5.009.0304 Pressure Adjustment Valve for Pressure Washer Lavor Missouri €28.99
Page 7 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.008.0447 ELECTRIC BOX COVER X JET FIRE '98 €8.76
2
 Switch 0/1 Black Button for Pressure Washers Lavor 3.401.0178 Switch 0/1 Black Button for Pressure Washers Lavor €6.91
3
 Electronic Board for Pressure Washer Lavor FKX 1018 3.403.0012 Electronic Board for Pressure Washer Lavor FKX 1018 €36.22
4
 photo_cameraImage coming soon 3.405.0011 TERMINAL BOARD PA 32/6 €12.60
6
 photo_cameraImage coming soon 4.008.0446 ELECTRIC BOX BASE FKX ESP.03 €7.73
Page 8 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 8
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3.499.0539 FERRITE ANTIDISTANCE FILTER 7427155 1 €15.85
2
 photo_cameraImage coming soon 4.012.0292 CABLE H05VV-F 3X1.5 MT.6.4 SP.SCHUKO ANTI-SPLASH F/F €32.38
Page 9 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 9
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Motor Ass'y for Pressure Washer Lavor WASHER 19 5.009.0924 Motor Ass'y for Pressure Washer Lavor WASHER 19 €97.14
2
 Kit 166 Footstep Bearing for Pressure Washer Lavor Predator 160 WPS 6.005.0180 Kit 166 Footstep Bearing for Pressure Washer Lavor Predator 160 WPS €13.79
3
 Pin 10x70 for Pressure Washer Lavor Predator 160 WPS 4.007.0205 Pin 10x70 for Pressure Washer Lavor Predator 160 WPS €7.68
4
 Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS 5.009.1020 Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS €17.59
5
 photo_cameraImage coming soon 4.007.0328 THRUST BEARING 35X55X12 PT'03 €15.13
6
 photo_cameraImage coming soon 5.009.0997C BODY GUIDE+HEAD(TPAV) W/TS 14.5KG-SUCT.-THREAD CAPS-PL.CHECK VALVE SEAT €52.04
Page 10 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 10
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.006.0259 SCREW HOSE HOLDER FOR ADJUSTMENT. DIESEL FKX €4.05
2
 photo_cameraImage coming soon 4.006.0260 NUT 10x1 EX.13 FOR ADJUSTMENT. DIESEL FKX €1.72
3
 photo_cameraImage coming soon 4.007.0306 SPRING FOR PRESS.REG.VALVE FKXD.5,4-7,8 L=20 WIRE 1,8 €1.72
4
 photo_cameraImage coming soon 3.200.0050 O-RING 5.28X1.78 €1.65
5
 photo_cameraImage coming soon 4.008.0856 BALL VALVE FOR BY-PASS REGULATION FKX-PARANA' €1.72
6
 photo_cameraImage coming soon 4.006.0254 BY-PASS DIESEL VALVE €6.01
7
 photo_cameraImage coming soon 3.200.0021 OR GASKET 6,75x1,78 RIF.106 €1.67
8
 photo_cameraImage coming soon 3.100.0057 CONNECTION D.4X1/8"M VITON O-RING €7.15
Page 11 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 11
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.007.0281C PISTON BODY GUIDE PT'03 W/TS 14.5KG-SUCTION €30.28
2
 Kit 257 LW Rings Support + Spacers for Washer Lavor ENDURO 145 6.005.0282 Kit 257 LW Rings Support + Spacers for Washer Lavor ENDURO 145 €14.54
3
 photo_cameraImage coming soon 5.008.0298C PT'03 HEAD D.12 W/THREAD CAPS(TPAV - ALUM.CAPS) €18.38
Page 12 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 12
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Lavor GALAXY 160 TSS Valve Assy 5.009.1022 Lavor GALAXY 160 TSS Valve Assy €18.00
2
 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 6.005.0277 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 €4.50
3
 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 6.005.0079 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 €14.50
4
 Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 6.005.0226 Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 €11.43
5
 photo_cameraImage coming soon 4.005.0263C 4.005.0263 PISTON BODY GUIDE PT'03 WITH SUCTION VALVE €25.85
6
 Kit 167 LW 3 Pistons + Springs for Pressurte Washer Lavor BEST 24 6.005.0181 Kit 167 LW 3 Pistons + Springs for Pressurte Washer Lavor BEST 24 €25.98
Page 13 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 13
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 6.005.0595 KIT HEAD VALVE KIT +CAPS PT'03 €14.17
2
 photo_cameraImage coming soon 4.005.0302 PT'03 HEAD WITH THREAD FOR VALVE CAPS (TPAV) €5.99
3
 Kit 124 Water Seal Partner for Pressurte Washer Lavor BEST 24 6.005.0133 Kit 124 Water Seal Partner for Pressurte Washer Lavor BEST 24 €14.54

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Original Parts for Pressure Cleaner XTR-R 1007

Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner 8.052.0846 - IDRO XTR-R 1007 230/50 TS -G- LAVOR

In the following tables, look for the spare part and its respective code.
Lavor XTR 1007 R - 80520846

8.052.0846 - IDRO XTR-R 1007 230/50 TS -G- LAVOR
Chassis Pag.1
Pos. Codice Descrizione
1 4.013.0965 UPPER COVER
2 4.008.2567 RIGHT CABINET RIO-R
3 4.008.2566 LEFT CABINET RIO-R
4 5.011.0536 HANDLE
5 4.608.0027 BLACK PLUG D.30 FOR TANK
6 7.100.2488 INSTRUCTION MANUAL RIO-R XTR-R LAVOR
7 3.700.0036 GUN 26Mpa-100°C-30lt/min G3/8M - M22
8 4.618.0049 HOSE R1 1/4 8MT 3/8F-M22 (MAX 21MPa)
9 3.712.0019 HI/LO LANCE 025 M22 (MAX 220BAR 3200PSI) -RED- RAL.3020
10 3.100.0062 QUICK COUPLING WITH VALVE (3029)
11 3.100.0510 TRANSP.QUICK COUPLING W/INSPECT.FILTER
Base Pag.2
1 5.611.0313 CONTROL PANEL 230V
2 4.008.1026 MOTOR CONVEYER RIGHT+LEFT 2100W
3 4.007.0355 L-SHAPED BRACKET FOR MOTOR SUPPORT
4 6.005.0640 INLET EXTENSION KIT
5 5.001.I763C MOTORPUMP PT'03 230/50 TS W/THERM.-SUCT. 7'10AL THREAD CAPS HE
6 4.612.0074 PVC GROUND WIRE D.2,5 L=500
7 5.609.0260 MAX PRESSURE VALVE 250BAR 1/8
8 5.611.0282 DIESEL PUMP + VALVE
9 4.007.0570 CHIMNEY EXTENSION PATRIOT
10 6.005.0645 KIT CAP FOR TANK WITH SEAL
11 4.008.2565 GASOIL TANK RIO-R
12 5.011.0558 GASOIL FILTER GROUP
13 5.009.1187 WIRING 3X1,5 PVC MT 6 SCHUKO PLUG W/FILTER
14 6.605.0075 KIT WHEEL+STUD+STOP WHEEL (ONTARIO/TUCSON)
15 4.008.2596 WASHER 30X17 th.2.5
16 4.007.0602 SUPPORT BRACKET
ASSIEME MANICO XTR-R Pag.3
1 5.013.0093 HANDLE FOR XTR-R
2 4.607.1028 HOOK FOR HANDLE
3 4.007.0607 INTERNAL DETERGENT TANK SUPPORT BRACKET
4 4.008.0868 DETERGENT TANK
5 4.007.0608 EXTERNAL DETERGENT TANK SUPPORT BRACKET
Corredo Pag.4
1 3.100.0062 QUICK COUPLING WITH VALVE (3029)
2 3.100.0510 TRANSP.QUICK COUPLING W/INSPECT.FILTER
3 4.608.0027 BLACK PLUG D.30 FOR TANK
ASSIEME TELAIO+CALDAIA XTR-R Pag.5
1 5.009.1126 TRANSFORMER WITH CABLES (FKX-RIO)
2 4.008.0848 GASKET NEW TRANSFORMER FKX
3 3.100.0075 CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O-RING
4 4.005.0194 CAP FOR BOILER FKX
5 5.009.0637 BOILER CAP KIT
6 4.006.0187 NOZZLE HOLDER PIN
7 3.104.0031 GAS OIL NOZZLE 0.50 60 H
8 6.005.0307 COMPLETE DEFLECTOR WITH ELECTRODE
9 5.013.0027 DISK HEAD HOLDER
10 5.013.0092 BODY BOILER PATRIOT/RIO-R
11 3.099.0124 RING LOCKER X SHAFT D.42 UNI 7435
12 4.007.0303 TUBE D.40 L=325 FE 37 PREZINCE D
13 4.007.0180 BOILER STAY M6X352
14 4.604.0028 COIL D.202 SINGLE FKX ECO
15 4.608.0038 RUBBER PROTECTION FOR THERMIC
16 3.403.0003 THERMAL PROTECTOR L01.090.05.7 00
17 4.606.0002 DELIVERY CONNECTION
18 4.008.2475 SEAL FOR HEATING COIL
19 4.007.0322 TUBE FKX L=42
20 6.605.0141 HOBBY BOILER REFRACTORY KIT
21 4.007.0599 JUNCTION
22 4.006.0283 FERRULE M22x1,5 L=16.
23 3.304.0056 BURNER MOTOR 230/50 C/W FAN, FLANGE, CABLES AND COVER
24 4.012.0102 CABLE L=600 SEC.0,75 IEC227-3/1979
25 4.007.0158 BOILER PAD
26 4.005.0186 BOILER BASE PLATE X FKX (LIKE DIE CASTING )
GRUPPO POMPA GASOLIO (ULKA) PATRIOT 24220056 Pag.6
1 3.551.0014 DIESEL PUMP 48W 230/50
2 5.009.0304 ADJUSTING VALVE SET (SPRING L=20)
ASSIEME QUADRO ELETTRICO 230V XTR-R Pag.7
1 4.008.0447 ELECTRICAL BOX COVER
2 3.401.0178 SWITCH 0/1 BLACK BOTTON IP55 12/10
3 3.403.0012 ELECTRICAL BOARD
4 3.405.0011 TERMINAL BOARD PA 32/6
5 4.608.0561 GASKET
6 4.008.0446 ELECTRICAL BOX BASE
CABLAG.ALIMELINTAZIONE.3X1,5 PVC MT 6,4 SP.SCHUKO C/FILTRO ANTID. Pag.8
1 3.499.0539 WIRE HARNESS
2 4.012.0292 CABLE H05VV-F 3X1,5 MT.6,4 F/F SCHUKO PLUG
MTP.SP.PT'03 230/50 7'10 C/TERM.-TS-ASP. 14.5KG TEST.T.FIL.S.PL.(8850) Pag.9
1 5.009.0924 8850 MOTOR 230/50 W/CAPACITOR-THERMAL 17AM-D 140G
2 6.005.0180 KIT 166 FOOTSTEP BEARING 3047 PT' 03-SD
3 4.007.0205 PIN 10X70
4 5.009.1020 7'10 WOBBLE PLATE ASSEMBLY W/PLASTIC INSERT+RING GEAR Z 50
5 4.007.0328 THRUST BEARING 35X55X12 PT'03
6 5.009.0997C BODY GUIDE+HEAD(TPAV) W/TS 14.5KG-SUCT.-THREAD CAPS-PL.CHECK VA
ASSIEME VALVOLA REGOLAZIONE PRESSIONE X POMPA ULKA (MOLLA L=20) Pag.10
1 4.006.0259 HOSE HOLDER FOR DIESEL FLOW ADJUSTMENT
2 4.006.0260 NUT 10X1 FOR DIESEL FLOW ADJUSTMENT
3 4.007.0306 SPRING FOR PRESS.REG.VALVE FKX D.5,4-7,8 L=20 WIRE 1,8
4 3.200.0050 O-RING 5.28X1.78
5 4.008.0856 BALL VALVE
6 4.006.0254 BY-PASS DIESEL VALVE
7 3.200.0021 OR GASKET 6,75x1,78 RIF.106
8 3.100.0057 CONNECTION D.4X1/8"M VITON O-RING
GRUPPO C.GUIDA C/TS 14.5KG-ASP.+TEST.TAPPI FIL. PT'03-TPAV Pag.11
1 5.007.0281C PISTON BODY GUIDE PT'03 W/TS 14.5KG-SUCTION
2 6.005.0282 KIT 257 O-RING SEAL
3 5.008.0298C PT'03 HEAD (TPAV) D.12 W/ALUM.THREAD CAPS
CORPO GUIDA PT'03 C/TS 14.5KG-ASP. Pag.12
1 5.009.1022 COMPLETED VALVE TS PT'03 CABLE L=530 SPRING 14.5KG (WHITE FASTON
2 6.005.0277 KIT 252
3 6.005.0079 KIT 79 LW OIL SEALS
4 6.005.0226 KIT "O-RING FOR PT'03"
5 4.005.0263C PISTON BODY GUIDE PT'03 WITH SUCTION VALVE
6 6.005.0181 KIT 167 LW PISTON
TESTATA PT'03 (TPAV) D.12 C/TAPPI FIL.ALL. Pag.13
1 6.005.0595 KIT HEAD VALVE KIT +CAPS PT'03
2 4.005.0302 PT'03 HEAD WITH THREAD FOR VALVE CAPS (TPAV)
3 6.005.0133 KIT 124 O-RING WATER SEAL PARTNER D.12
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor XTR-R 1007 - 8.052.0846
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

New

Download

Lavor XTR-R 1007 Parts Drawing

Lavor XTR-R 1007 Parts Drawing

Download (574.49KB)

You might also like

Inlet Quick Coupling for High Pressure Washers Lavor
Lavorwash S.p.A. SKU: 3.100.0062
Inlet Quick Coupling for High Pressure Washers Lavor
Inlet Quick Coupling for High Pressure Washers Lavor Genuine Replacement part Lavor, Inlet Quick Coupling 3.100.0062 for Cold Water High Pressure Washers Fury 110 - Ride 110 - Race 125 - Cross 140 - Army 120. Part suitable for the...
AVAILABLE €4.25
Details
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0079
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 Original replacement part Lavor, Kit 79 LW Oil Seal for Partner D.12/Fibra per Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 - ENDURO 145 COMP. Part for the following...
Usually Shipped on: 7/10 Business Days Approx. €14.50
Details
Kit 170 LW Intake-Delivery Valve for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0184
Kit 170 LW Intake-Delivery Valve for Pressurte Washer Lavor BEST 24
Kit 170 LW Intake-Delivery Valve for Pressurte Washer Lavor BEST 24 Original replacement part Lavor, Kit 170 LW Intake-Delivery Valve PT' 03 per Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 - ENDURO 145 COMP. Part for the...
Usually Shipped on: 10/15 Business Days Approx. €15.19
Details
Kit 125 LW Rings Holding Brass Seal for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0134
Kit 125 LW Rings Holding Brass Seal for Pressurte Washer Lavor BEST 24
Kit 125 LW Rings Holding Brass Seal for Pressurte Washer Lavor BEST 24 Original spare part Lavor, Kit 125 LW Rings Holding Brass Seal + Spacers PT D.12 per Pressure Washers GIANT 24 - TEMPESTA 24 - BEST 24. Part for the following...
Usually Ships in: 7/10 Business Days Approx. €15.18
Details
Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0226
Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24
Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 Original replacement part Lavor, Kit 209 O-Ring for PT'03 per Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 - ENDURO 145 - BEST 24. Part for the following products: -...
Usually Ships in: 7/10 Business Days Approx. €11.43
Details
Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110
Lavorwash S.p.A. SKU: 5.009.0716
Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110
Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110 Original replacement part Lavor, Kit Valvola Total-Stop Automatic Stop System PT'03 Cable L=530 Spring 13KG for ARMY 110 - MARINE 125 - NAVY 140. Part for the...
Usually Ships in: 7/10 Business Days Approx. €16.00
Details
Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS
Lavorwash S.p.A. SKU: 5.009.1020
Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS
Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS Genuine replacement part Lavor, 7'10 Wobble Plate Assembly W/Crown Z 50 (PT'03) for Prssure Washer Predator 160 WPS 220-240~50/60 -V/N- TS EU C/AVV. LWS 8.101.0012....
Usually Ships in: 10/15 Business Days Approx. €17.59
Details
Pin 10x70 for Pressure Washer Lavor Predator 160 WPS
Lavorwash S.p.A. SKU: 4.007.0205
Pin 10x70 for Pressure Washer Lavor Predator 160 WPS
Pin 10x70 for Pressure Washer Lavor Predator 160 WPS Genuine replacement part Lavor, Pin 10x70 for Drive Wooble Plate Assembly with Crown for Pressure Washer Predator 160 WPS 220-240~50/60 -V/N- TS EU C/AVV. LWS 8.101.0012. Part for...
AVAILABLE €7.68
Details
Transformer 230-240V for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.009.0686
Transformer 230-240V for Pressure Washer Lavor Missouri
Transformer 230-240V for Pressure Washer Lavor Missouri Genuine part Lavor, Ignition Transformer 230-240V/50-60Hz with Pipette for Pressure Washers Burner FKX-PARANA ' - RIO (EMC) + Cable Part for the following products: -  86190601...
Usually Ships in: 10/15 Business Days Approx. €100.43
Details
Diesel Pump for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.551.0014
Diesel Pump for Pressure Washer Lavor FKX 1018
Diesel Pump for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Diesel Pump ULKA EP 5 48W 230/50 with O-Ring R4 for Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 8052001. Part for the...
Last items in stock €58.71
Details
Diesel Filter Unit for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.611.0043
Diesel Filter Unit for Pressure Washer Lavor Missouri
Diesel Filter Unit for Pressure Washer Lavor Missouri Genuine part Lavor, Diesel Filter Unit JOLLY 4 '93 / MISSOURI / MEK for Pressure Washers Missouri - NPX 1400 - NPX 1500. Part for the following...
Usually Ships in: 10 Business Days Approx. €15.19
Details
Pressure Adjustment Valve for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.009.0304
Pressure Adjustment Valve for Pressure Washer Lavor Missouri
Pressure Adjustment Valve for Pressure Washer Lavor Missouri Genuine part Lavor, Pressure Adjustment Valve Ass'y for Pump ULKA (Spring L=20) for Pressure Washers MISSOURI FKX-PARANA' - MISSOURI - RIO (EMC) + Cable. Part for the...
on 7/10 Business Days Approx. €28.99
Details
Transformer 230-240V for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 5.009.1126
Transformer 230-240V for Pressure Washer Lavor RIO 1108
Transformer 230-240V for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Ignition Transformer 230-240V/50-60Hz With Pipette for FKX-RIO (EMC) + Cable With External Ground for  Pressure Cleaner RIO 1108 220-230/50 TS Part for the...
Last items in stock €100.43
Details
Diesel Fuel Tank Cap for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 4.608.0180
Diesel Fuel Tank Cap for Pressure Washer Lavor RIO 1108
Diesel Fuel Tank Cap for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Diesel Fuel Tank Cap for Pressure Washers Tekna 4 - RIO 1108 - 8.052.0801 -GR- RAL.7021 Part for the following products: -  Cleaner RIO 1108 220-230/50 TS -G-...
Last items in stock €14.99
Details
Electronic Board for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.403.0012
Electronic Board for Pressure Washer Lavor FKX 1018
Electronic Board for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Electronic Board for Pressure Washer Pressure Washers FKX 1018 230/50 TS -R- (VAPORNOVA)- 80520001 - Idropulitrice...
Usually Ships in: 10/15 Business Days Approx. €36.22
Details
Burner Motor for Pressure Cleaner Lavor RIO 1108
Lavorwash S.p.A. SKU: 3.304.0056
Burner Motor for Pressure Cleaner Lavor RIO 1108
Burner Motor for Pressure Cleaner Lavor RIO 1108 Genuine part Lavor, Burner Motor 230/50Hz Complete With Fan, Flange, Cables L=850 and Cover for Pressure Cleaners RIO 1108 - YUKON 1310...
Usually Ships in: 10/15 Business Days Approx. €42.00
Details
Switch 0/1 Black Button for Pressure Washers Lavor
Lavorwash S.p.A. SKU: 3.401.0178
Switch 0/1 Black Button for Pressure Washers Lavor
Switch 0/1 Black Button for Pressure Washers Lavor Genuine replacement part Lavor, Switch 0/1 Black Button IP55 12/10 for Pressure Washers Lavor Part for the following products: -  Pressure washer Ride 110...
Last items in stock €6.91
Details
Body Guide PT'03 for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 5.007.0187C
Body Guide PT'03 for Pressure Washer Lavor RIO 1108
Body Guide PT'03 for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Body Guide PT'03 Pistons D.12 with ASS Detergent Suction for Pressure Washers RIO 1108 - MEK 1108 Part for the following products: -  Pressure Cleaner RIO 1108 -...
on 10 Business Days Approx €57.11
Details
Diesel Nozzle for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.104.0008
Diesel Nozzle for Pressure Washer Lavor FKX 1018
Diesel Nozzle for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Diesel Nozzle 0.60 60° HFD Kg/h 231 EN 6011 43281 for Pressure Washers FKX 1018 - RIO 1108 - MEK 1108 - XTR...
Usually Ships in: 10/15 Business Days Approx. €29.49
Details
Motor Ass'y for Pressure Washer Lavor WASHER 19
Lavorwash S.p.A. SKU: 5.009.0924
Motor Ass'y for Pressure Washer Lavor WASHER 19
Motor Ass'y for Pressure Washer Lavor WASHER 19 Genuine part Lavor, Brush Motor Assembly '03 230/50 for Pressure Washers WASHER 19 - XTR 1007 - GALAXY 160 - PLANET 160 - STM 160 - PRIME...
Usually Ships in: 10 Business Days Approx. €97.14
Details
Lavor Pressure Washer XTR 1007 Motor Pump Ass'y
Lavorwash S.p.A. SKU: 5.001.I763C
Lavor Pressure Washer XTR 1007 Motor Pump Ass'y
Lavor Pressure Washer XTR 1007 Motor Pump Ass'y Genuine part Lavor, Motor Pump Brushes Ass'y PT'03 230/50 7'10 TS With Suction M.13KG (8850) for Pressure Washers XTR 1007 - FUEGO 1007. Part for the following products: -  Pressure...
Usually Ships in: 10/15 Business Days Approx. €114.73
Details
Lavor FKX 1018 Kit 291 LW
Lavorwash S.p.A. SKU: 6.005.0319
Lavor FKX 1018 Kit 291 LW
Lavor FKX 1018 Kit 291 LW Genuine replacement part Lavor, Kit 291 LW Boiler Pump Junction Fitting for Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 80520001. Part for the following products: - ...
on 10 Business Days Approx €28.92
Details
Lavor MISSOURI Boiler Cover
Lavorwash S.p.A. SKU: 4.005.0194
Lavor MISSOURI Boiler Cover
Lavor MISSOURI Boiler Cover Original part Lavorwash, Boiler Cover for Pressure Cleaners MISSOURI - PARANA' -  YUKON 1310. Part for the following products: - Lavor MISSOURI - Lavor HOT130 - Lavor PARANA' G-LWS - Lavor...
Usually Ships in: 10 Business Days Approx. €79.65
Details
Lavor GALAXY 160 TSS Valve Assy
Lavorwash S.p.A. SKU: 5.009.1022
Lavor GALAXY 160 TSS Valve Assy
Lavor GALAXY 160 TSS Valve Assy for Pressure Cleaner Genuine replacement part Lavor 1002-05463 EX 5.009.1022, TSS Valve Assembly Assieme V.COMP. C/TS PT'03 Cable L=530 Spring 14.5KG (WHITE COVER) for Pressure Cleaners GALAXY 160....
Usually Ships in: 10/15 Business Days Approx. €18.00
Details
Lavor Diesel Tank for RIO-R 1108
Lavorwash S.p.A. SKU: 4.008.2565
Lavor Diesel Tank for RIO-R 1108
Lavor Diesel Tank for Pressure Washer RIO-R 1108 Genuine replacement part Lavor, Black Diesel Tank for Pressure Washer RIO-R 1108 - RIO-R 1107. Part for the following products: -  Pressure Washer Lavor RIO-R 1108 - 8.052.0845...
Last items in stock €71.89
Details
Comments (0)
