Lavor Pressure Cleaner RIO-R 1108 Parts

SKU: Lavor RIO-R 1108 - 8.052.0845
€13.97
VAT included

Lavor Original Parts for Pressure Cleaner RIO-R 1108 - 8.052.0845

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner Lavor RIO-R 1108 - 8.052.0845.

Fix Your Pressure Cleaner Rio-R 1108. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Lavor Pressure Cleaner RIO-R 1108 Parts
  • Lavor Pressure Cleaner RIO-R 1108 Parts
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 1
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 2
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 3
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 4
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 5
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 7
  • Lavor Pressure Cleaner RIO-R 1108 Parts
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 8
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 9
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 10
  • Lavor Pressure Cleaner RIO-R 1108 Parts Diagram 11
Lavorwash S.p.A.

Lavor Pressure Cleaner RIO-R 1108 Parts

SKU: Lavor RIO-R 1108 - 8.052.0845 Condition: New
€13.97
VAT included

Lavor Original Parts for Pressure Cleaner RIO-R 1108 - 8.052.0845

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner Lavor RIO-R 1108 - 8.052.0845.

Fix Your Pressure Cleaner Rio-R 1108. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 88 Spare parts
description 12 exploded views
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN: Usually Ships in 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR: LAVOR S/N START WITH (8. ) and have 8 DIGITS
Machine Type: Pressure Washer
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
88 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4.013.0965 UPPER CAREN. RIO-G-PANT.108C €63.45
2
 Image coming soon 4.008.2567 LOWER CAREN. RH RIO-R BLACK €21.39
3
 Image coming soon 4.008.2566 LOWER CAREN. LEFT RIO-R BLACK €21.39
4
 Image coming soon 4.008.0867 HANDLE €37.15
6
 Image coming soon 4.008.0869 LANCE HOLDER €6.01
7
 Image coming soon 4.008.0789 HOSE REEL TIGER €6.94
8
 DETERGENT TANK 4.008.0868 DETERGENT TANK €31.21
9
 Image coming soon 7.100.2488 MANUAL RIO-R XTR-R LAVOR 19L A5 164F €5.16
10
 Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor 3.700.0036 Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor €33.90
11
 Image coming soon 4.618.0049 HOSE 1/4 R1 210BAR L.8000 3/8"F €55.11
12
 Image coming soon 3.712.0018 EXT LANCIA S/COVER A/B 1.15 -G- M22 HOT (MAX 220BAR 3200PSI) €26.97
13
 Inlet Quick Coupling for High Pressure Washers Lavor 3.100.0062 Inlet Quick Coupling for High Pressure Washers Lavor €4.25
Page 2 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 5.611.0284 ELECTRIC PANEL ASSEMBLY 230V PATRIOT/RIO-R €92.54
2
 Image coming soon 3.404.0094 CAPACITOR 32mF 450V €17.69
3
 Image coming soon 3.555.1158 LOWER FIXED COLLAR MTP KT €2.17
4
 Image coming soon 6.005.0640 INPUT EXTENSION KIT 3/4 M-F €14.96
5
 Image coming soon 5.001.I1000C PT'03 MOTOR 110H110ALL 230-240/50 D12 9GR45 TS IN.1,7 D.TEN. €291.99
6
 Image coming soon 5.609.0260 MAX PRESSURE VALVE 250BAR 1/8 €24.79
7
 Image coming soon 5.611.0282 GROUP DIESEL PUMP (ULKA) PATRIOT 24220056 €94.81
8
 Image coming soon 4.007.0570 PATRIOT CHIMNEY EXTENSION €0.11 Not available for order
9
 Image coming soon 6.005.0645 PATRIOT DIESEL TANK CAP KIT WITH GASKET €10.00
10
 Lavor Diesel Tank for RIO-R 1108 4.008.2565 Lavor Diesel Tank for RIO-R 1108 €50.00
11
 Image coming soon 5.011.0558 DIESEL FILTER GROUP RIO-R/XTR-R (NYLON FILTER) €9.55
12
 Image coming soon 5.009.1187 POWER WIRING 3X1,5 PVC MT 6,4 SP.SCHUKO W/ANTID. FILTER €87.21
13
 Image coming soon 6.605.0075 KIT WHEEL+STUD+STOP WHEEL (ONTARIO/TUCSON) €29.61
14
 Image coming soon 4.008.2596 WASHER 30X17 THICKNESS 2.5 €3.07
15
 Image coming soon 4.007.0602 SHAPED FOOT PATRIOT RAL.7015 €28.82
16
 Image coming soon 4.007.0621 MOTOR SUPPORT BRACKET RIO PRO PAINTED €0.11 Not available for order
17
 Image coming soon 4.608.0228 BUSHING D.20XH9 PP €0.11 Not available for order
Page 3 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Inlet Quick Coupling for High Pressure Washers Lavor 3.100.0062 Inlet Quick Coupling for High Pressure Washers Lavor €4.25
2
 Image coming soon 3.100.0510 TRANSP.QUICK COUPLING W/INSPECT.FILTER (CAO) €7.93
3
 BLACK PLUG D.30 FOR TANK 4.608.0027 BLACK PLUG D.30 FOR TANK €10.03
Page 4 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 6.605.0274 TRANSFORMER KIT 34000047 + CABLE 46120144 €104.68
2
 Image coming soon 4.008.0848 GASKET NEW TRANSFORMER FKX €1.72
3
 Image coming soon 3.100.0075 CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- €14.98
4
 Lavor MISSOURI Boiler Cover 4.005.0194 Lavor MISSOURI Boiler Cover €79.65
5
 Image coming soon 5.009.0637 BOILER CAP KIT €3.43
6
 Image coming soon 4.006.0187 NOZZLE HOLDER PIN €5.32
7
 Image coming soon 3.104.0031 0.50 60 H DIESEL NOZZLE (DANFOSS) €21.68
8
 Image coming soon 6.005.0307 FKX DEFLECTOR WITHOUT ELECTRODES €46.47
9
 Image coming soon 5.013.0027 DISK HEAD HOLDER €77.49
10
 Image coming soon 5.013.0092 PATRIOT/RIO-R/XTR BOILER BODY €71.37
11
 Image coming soon 3.099.0124 SEEGER RING X TREE D.42UNI 7435 €1.72
12
 Image coming soon 4.007.0303 TUBE D.40 L=325 FE 37 PREZINCED €11.85
13
 Image coming soon 4.007.0180 TIE ROD FOR BOILER FIRE '98M6X352 FIL.12-12 ZNT €6.99
14
 Image coming soon 4.604.0037 COIL D.200 L=15MT D.16X1.85 RIO-R €243.79
15
 Image coming soon 4.608.0038 RUBBER PROTECTION FOR THERMAL FIRE €1.72
16
 THERMAL PROTECTOR L01.080.05.1000 CABLES * UL * 3.403.0003 THERMAL PROTECTOR L01.080.05.1000 CABLES * UL * €19.69
17
 Image coming soon 4.606.0323 FLOW CONNECTOR D.15 M22X1.5 - G3/8"M L=95 €9.44
18
 Image coming soon 4.008.2475 SEAL COIL CONNECTOR (1201030500) 2 €6.94
20
 Image coming soon 6.605.0284 REFRACTORY KIT FOR RIO-R/PATRIOT BOILER €42.97
21
 Image coming soon 4.007.0599 CONNECTOR FOR COIL WITH 3/8 CONICAL THREAD €18.52
22
 Image coming soon 4.006.0283 FERRULE M22x1,5 L=16. €3.32
23
 Burner Motor for Pressure Cleaner Lavor RIO 1108 3.304.0056 Burner Motor for Pressure Cleaner Lavor RIO 1108 €42.00
24
 Image coming soon 4.012.0102 CABLE L=600 SEC.0,75 IEC227-3/1979 €5.83
25
 Image coming soon 4.007.0158 BOILER PAD €65.73
26
 Image coming soon 4.005.0186 BOILER BASE FKX (DIE CAST) ESP.00 €128.72
Page 5 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Diesel Pump for Pressure Washer Lavor FKX 1018 3.551.0014 Diesel Pump for Pressure Washer Lavor FKX 1018 €58.71
2
 Pressure Adjustment Valve for Pressure Washer Lavor Missouri 5.009.0304 Pressure Adjustment Valve for Pressure Washer Lavor Missouri €28.99
Page 6 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 5.009.1117C ASS.MOT.09 D110H100ALL 230-240/50 2P C/TER.PT03+PIATT.9GR45 €167.24
2
 THRUST BEARING 35X55X12 PT'03 4.007.0328 THRUST BEARING 35X55X12 PT'03 €14.74
3
 Image coming soon 5.009.1181C GR. C.GUIDE C/TS 13KG-ASP.+TEST.FIL.OTT.DOP.TEN.PRED.MAN. €111.22
Page 7 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4.008.2675 ELECTRIC BOX LID RIO-R -BLACK- €6.93
2
 Switch 0/1 Black Button for Pressure Washers Lavor 3.401.0178 Switch 0/1 Black Button for Pressure Washers Lavor €6.80
3
 Electronic Board for Pressure Washer Lavor FKX 1018 3.403.0012 Electronic Board for Pressure Washer Lavor FKX 1018 €36.22
4
 Image coming soon 3.405.0011 TERMINAL BOARD PA 32/6 €12.60
5
 Image coming soon 4.008.2664 ELECTRICAL BOX BASE RIO-R €6.37
Page 8 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 8
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 3.499.0539 FERRITE ANTIDISTANCE FILTER 7427155 1 €15.85
2
 Image coming soon 4.012.0292 CABLE H05VV-F 3X1.5 MT.6.4 SP.SCHUKO ANTI-SPLASH F/F €32.38
Page 9 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 9
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4.006.0259 SCREW HOSE HOLDER FOR ADJUSTMENT. DIESEL FKX €4.05
2
 Image coming soon 4.006.0260 NUT 10x1 EX.13 FOR ADJUSTMENT. DIESEL FKX €1.72
3
 Image coming soon 4.007.0306 SPRING FOR PRESS.REG.VALVE FKXD.5,4-7,8 L=20 WIRE 1,8 €1.72
4
 Image coming soon 3.200.0050 O-RING 5.28X1.78 €1.65
5
 Image coming soon 4.008.0856 BALL VALVE FOR BY-PASS REGULATION FKX-PARANA' €1.72
6
 Image coming soon 4.006.0254 BY-PASS DIESEL VALVE €6.01
7
 Image coming soon 3.200.0021 OR GASKET 6,75x1,78 RIF.106 €1.67
8
 Image coming soon 3.100.0057 CONNECTION D.4X1/8"M VITON O-RING €7.15
Page 10 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 10
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 5.007.0315 PT'03EVO GUIDE BODY D.D.12 DOUBLE SEAL W/TS-13KG-ASP.-V.COMP. €101.88
2
 Image coming soon 6.005.0649 PT' 03 DOUBLE SEAL SPACER KIT €14.12
3
 Image coming soon 6.005.0585 PT03 WATER SEAL RING KIT €5.71
4
 Image coming soon 5.008.0395 PT'03 HEAD D.12 BRASS W/FILLED CAPS DOUBLE SEAL W/MANOMETER €271.15
Page 11 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 11
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 6.005.0648 KIT VALVE INLET/OUTLET W/ BRASS SEAT-PLUGS BRASS FILTER PT'03 €9.44
2
 Image coming soon 4.006.0409 HEAD PT'03 BRASS MACHINED DOUBLE SEAL FOR PRESSURE GAUGE €0.11 Not available for order
3
 Image coming soon 6.005.0585 PT03 WATER SEAL RING KIT €5.71
Page 12 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 12
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4.005.0300 PISTON BODY GUIDE PT'03EVO WITH SUCTION €27.54
2
 Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110 5.009.0716 Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110 €16.00
3
 Image coming soon 6.005.0651 KIT 3 PISTONS + SPRINGS PT'03 DOUBLE SEAL €18.79
4
 Image coming soon 6.005.0647 KIT 'O-RING FOR PT'03 DOUBLE SEAL' €7.58
5
 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 6.005.0277 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 €4.79
6
 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 6.005.0079 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 €14.50

Shipping and delivery information will be available shortly.

Lavor Original Parts for Pressure Cleaner RIO-R 1108 - 8.052.0845

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner Lavor RIO-R 1108 - 8.052.0845.

In the following tables, look for the spare part and its respective code.
Pressure Cleaner RIO-R 1108

Pressure Cleaner Lavor RIO-R 1108 - 8.052.0845 Parts
RIO-R 1108 220-230V 50HZ TS BASE Pag.1
# Part Num Description
1 4.013.0965 UPPER CAREN. RIO-G-PANT.108C
2 4.008.2567 LOWER CAREN. RH RIO-R BLACK
3 4.008.2566 LOWER CAREN. LEFT RIO-R BLACK
4 4.008.0867 HANDLE FOR HYDRO RIO
5 4.608.0027 D.30 CAP FOR FIRE 100 TANK -N-
6 4.008.0869 LANCE HOLDER FOR HYDRO RIO
7 4.008.0789 TIGER-MACH HOSE SUPPORT
8 4.008.0868 DETERGENT TANK
9 7.100.2488 MANUAL RIO-R XTR-R LAVOR 19L A5 164F
10 3.700.0036 AL15 GUN 26MPA-100GR-30LT/MIN G3/8M-M22
11 4.618.0049 HOSE R1 1/4 21MPA 8M 3/8F SWIVEL-M22X1.5 W/SLEEVE
12 3.712.0018 HI/LO LANCE 030 M22 (MAX 220BAR 3200PSI) -YELLOW- RAL.1016
13 3.100.0062 ATT. RAP. WITH ACQUASTOP W/HOLDER (3029)
14 3.100.0510 INN.RAP.3/4 TRANSP.+GARN.+FIL
Base Pag.2
1 5.611.0284 PATRIOT/RIO-R 230V ELECTRIC PANEL ASSEMBLY
2 3.404.0094 32MF 450V F/M CAPACITOR
3 3.555.1158 LOWER FIXED COLLAR MTP KT
4 6.005.0640 INPUT EXTENSION KIT 3/4 M-F
5 5.001.I1000C PT'03 MOTOR 110H110ALL 230-240/50 D12 9GR45 TS IN.1,7 D.TEN.
6 5.609.0260 MAX 250BAR SAFETY VALVE 1/8 W/PORTAG.
7 5.611.0282 PATRIOT DIESEL PUMP GR.(ULKA) 24220056
8 4.007.0570 PATRIOT CHIMNEY EXTENSION
9 6.005.0645 PATRIOT DIESEL TANK CAP KIT WITH GASKET
10 4.008.2565 LOWER TANK DIESEL RIO-R BLACK
11 5.011.0558 DIESEL FILTER GROUP RIO-R/XTR-R (NYLON FILTER)
12 5.009.1187 POWER CABLE 3X1.5 PVC MT 6.4 THICKNESS SCHUKO W/ANTI-DAMAGE FILTER
13 6.605.0075 WHEEL KIT + STUDS + LOCKS (ONTARIO/TUCSON)
14 4.008.2596 WASHER 30X17 THICKNESS 2.5
15 4.007.0602 SHAPED FOOT PATRIOT RAL.7015
16 4.007.0621 MOTOR SUPPORT BRACKET RIO PRO PAINTED
17 4.608.0228 BUSHING D.20XH9 PP
CORR.PER RIO-R Pag.3
1 3.100.0062 QUICK CONNECTOR WITH WATER STOP WITH HOLDER (3029)
2 3.100.0510 QUICK CONNECTOR 3/4 TRANSPARENT + GASKET + FILTER
3 4.608.0027 PLUG D.30 FOR FIRE 100 TANK -N-
ASSIEME TELAIO+CALDAIA RIO-R Pag.4
1 6.605.0274 TRANSFORMER KIT 34000047 + CABLE 46120144
2 4.008.0848 GASKET NEW FKX TRANSFORMER
3 3.100.0075 M 1/8 CONICAL F D.4 CURVED CONNECTOR
4 4.005.0194 COVER FOR FKX BOILER (DIESEL)
5 5.009.0637 COVER ASSEMBLY + FKX REGULATOR BUTTERFLY
6 4.006.0187 NOZZLE HOLDER PIN FOR FKX BOILER
7 3.104.0031 0.50 60 H DIESEL NOZZLE (DANFOSS)
8 6.005.0307 KIT 279 LW FKX DEFLECTOR + ELECTRODES
9 5.013.0027 MOUTHPIECE HOLDER DISC FOR FKX
10 5.013.0092 PATRIOT/RIO-R/XTR BOILER BODY
11 3.099.0124 SEEGER RING FOR SHAFT D.42 UNI 7435
12 4.007.0303 D.40 TUBE L=325 FE 37 PRE-ZINC TO
13 4.007.0180 TIE ROD FOR FIRE '98 BOILER M6X352 ZNT
14 4.604.0037 COIL D.200 L=15MT D.16X1.85 RIO-R
15 4.608.0038 RUBBER PROTECTION FOR THERMAL FIRE
16 3.403.0003 THERMAL PROTECTOR L01.080.05.UL CABLES L=1200
17 4.606.0323 FLOW CONNECTOR D.15 M22X1.5 - G3/8"M L=95
18 4.008.2475 SEAL FOR COIL CONNECTOR (1201030500)
20 6.605.0284 REFRACTORY KIT FOR RIO-R/PATRIOT BOILER
21 4.007.0599 CONNECTOR FOR COIL WITH 3/8 CONICAL THREAD
22 4.006.0283 RING NUT M22X1.5 L=16
23 3.304.0056 MOTOR FOR BURNER 230/50 + VENT/FLANG/CABLES/COVER/FILTER
24 4.012.0102 MOTOR CABLE.BRUSH L=850 SEC.0.75 IEC227-3/1979 S/FAST.
25 4.007.0158 BOILER BOTTOM FOR NUOVA FIRE
26 4.005.0186 BOILER BASE FKX (DIESEL CAST)
GR.POMPA GASOLIO(ULKA)PATRIOT 24220056 Pag.5
1 3.551.0014 ULKA DIESEL PUMP EP 5 48W 230/50 W/OR R4 VITON
2 5.009.0304 ASS. PRESSURE REGULATION VALVE FOR ULKA PUMP (SPRING L=20)
MOTOP.PT'03 110H110ALL 230-240/50 D12 9GR45 TS IN.1,7 D.TEN. Pag.6
1 5.009.1117C ASS.MOT.09 D110H100ALL 230-240/50 2P C/TER.PT03+PIATT.9GR45
2 4.007.0328 BALL THRUST BEARING 35X55X12 FOR PT03
3 5.009.1181C GR. C.GUIDE C/TS 13KG-ASP.+TEST.FIL.OTT.DOP.TEN.PRED.MAN.
ASSIEME QUADRO ELETTRICO 230V PATRIOT/RIO-R Pag.7
1 4.008.2675 ELECTRIC BOX LID RIO-R -BLACK-
2 3.401.0178 0/1 SWITCH BLACK PUSH/BUTTON IP55 12/10
3 3.403.0012 ELECTRIC BOARD 230/50 FKX
4 3.405.0011 TERMINAL BLOCK PA 32/6
5 4.008.2664 ELECTRICAL BOX BASE RIO-R
CABLAG.ALIMENTAZ.3X1,5 PVC MT 6,4 SP.SCHUKO C/FILTRO ANTID. Pag.8
1 3.499.0539 ANTIDIST. FILTER IN FERRITE 7427155
2 4.012.0292 CABLE H05VV-F 3X1.5 MT.6.4 SP.SCHUKO ANTISP.F/F
ASS.VALVOLA REGOLAZIONE PRESSIONE X POMPA ULKA(MOLLA L=20) pag.9
1 4.006.0259 SCREW HOLDER FOR FKX DIESEL REGULATION
2 4.006.0260 NUT 10X1 ES.13 FOR FKX DIESEL REGULATION
3 4.007.0306 SPRING FOR PRESSURE REGULATION FKX NEW MUSHROOM D.5.4-7.8 L=20 THREAD 1.8
4 3.200.0050 OR SEAL 5.28X1.78 REF.2021
5 4.008.0856 SPHERICAL VALVE FOR BY-PASS REGULATION FKX-PARANA'
6 4.006.0254 FKX DIESEL BY-PASS VALVE BODY
7 3.200.0021 OR SEAL 6.75X1.78 NBR SH.70 REF.106
8 3.100.0057 CONNECTOR D.4X1/8M
GR. C.GUIDA C/TS 13KG-ASP.+TEST.T.FIL.OTT.DOP.TEN.PRED.MAN. Pag.10
1 5.007.0315 PT'03EVO GUIDE BODY D.D.12 DOUBLE SEAL W/TS-13KG-ASP.-V.COMP.
2 6.005.0649 PT' 03 DOUBLE SEAL SPACER KIT
3 6.005.0585 PT03 WATER SEAL RING KIT
4 5.008.0395 PT'03 HEAD D.12 BRASS W/FILLED CAPS DOUBLE SEAL W/MANOMETER
Pag.11
1 6.005.0648 KIT VALVE INLET/OUTLET W/ BRASS SEAT-PLUGS BRASS FILTER PT'03
2 4.006.0409 HEAD PT'03 BRASS MACHINED DOUBLE SEAL FOR PRESSURE GAUGE
3 6.005.0585 KIT WATER SEAL RINGS PT03
CORPO GUIDA PT'03EVO P.D.12 DOP.TEN. C/TS-13KG-ASP.-V.COMP. Pag.12
1 4.005.0300 PISTON GUIDE BODY PT03EVO W/HOLE ASP. DET. THREAD.
2 5.009.0716 ASS.V.COMP.W/TS PT03 CABLE L=530 SPRING 13KG (WHITE COVER)
3 6.005.0651 KIT 3 PISTONS + SPRINGS PT'03 DOUBLE SEAL
4 6.005.0647 KIT 'O-RING FOR PT'03 DOUBLE SEAL'
5 6.005.0277 KIT INJECTOR 1.7 THREAD HOLDER + CHECK VALVE PT'03
6 6.005.0079 KIT 79 LW OIL SEAL RINGS FOR PARTNER D.12/FIBER
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor RIO-R 1108 - 8.052.0845
6 Items

Data sheet

Machine Type
Pressure Washer
CHECK S/N LAVOR
LAVOR S/N START WITH (8. ) and have 8 DIGITS
SHIPPING IN
Usually Ships in 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

You might also like

Inlet Quick Coupling for High Pressure Washers Lavor
Lavorwash S.p.A. SKU: 3.100.0062
Inlet Quick Coupling for High Pressure Washers Lavor
Inlet Quick Coupling for High Pressure Washers Lavor Genuine Replacement part Lavor, Inlet Quick Coupling 3.100.0062 for Cold Water High Pressure Washers Fury 110 - Ride 110 - Race 125 - Cross 140 - Army 120. Part suitable for the...
AVAILABLE €4.25
Details
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0079
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 Original replacement part Lavor, Kit 79 LW Oil Seal for Partner D.12/Fibra per Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 - ENDURO 145 COMP. Part for the following...
Usually Shipped on: 7/10 Business Days Approx. €14.50
Details
Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110
Lavorwash S.p.A. SKU: 5.009.0716
Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110
Kit Valve Total-Stop Automatic Stop System for Washers Lavor ARMY 110 Original replacement part Lavor, Kit Valvola Total-Stop Automatic Stop System PT'03 Cable L=530 Spring 13KG for ARMY 110 - MARINE 125 - NAVY 140. Part for the...
Usually Ships in: 7/10 Business Days Approx. €16.00
Details
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.107.0004
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Pressure Gauge D.50 0/315 BAR - 1/4 Rear thread + Bracket (ref 129 939 81) for Pressure Washers NPX 1400 - NPX...
on 7/10 Business Days Approx. €33.35
Details
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 4.608.0083
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, PVC Fan D.180 Lowered Hub for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: -  Pressure Washer Lavor NPX 1400 -...
Usually Ships in: 10/15 Business Days Approx. €30.42
Details
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 5.009.0340
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Quick Coupling Assy + O-Ring + Ring Nut for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor...
on 10 Business Days Approx €15.06
Details
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 4.608.0019
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Black Thermostate Knob 3079/1t for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor NPX 1400...
on 10 Business Days Approx €10.03
Details
Water Sealing Ring for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.201.0003
Water Sealing Ring for Pressure Washers Lavor NPX 1400 - NPX 1500
Water Sealing Ring for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Water Sealing Ring N.15x22x4 for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor NPX...
Usually Ships in: 7/10 Business Days Approx. €5.27
Details
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.100.0043
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, 3/8 M Rotating Quick Coupling for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor NPX 1400 -...
AVAILABLE €17.59
Details
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500
Lavorwash S.p.A. SKU: 5.009.0136
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500 Genuine replacement part  Lavor , Hose Coupling Omnia Complete with O-Rings for  Pressure Washer NPX 1500  - 8.605.0049. Part for the following products: -  Pressure Washer Lavor...
on 10 Business Days Approx €3.27
Details
Gasket O-Ring 85x2.5 for Pressure Washer Lavor NPX 1500
Lavorwash S.p.A. SKU: 3.200.0014
Gasket O-Ring 85x2.5 for Pressure Washer Lavor NPX 1500
Gasket O-Ring 85x2.5 for Pressure Washer Lavor NPX 1500 Genuine replacement part  Lavor , Gasket O-Ring 85x2.5 Nitrile for  Pressure Washer NPX 1500  - 8.605.0049 -  8.605.0049 - FKX 1018 - KARJET PROFI130. Part for the following...
AVAILABLE €3.27
Details
Oil Seal Spacer D.19 for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 4.008.0391
Oil Seal Spacer D.19 for Pressure Washers Lavor NPX 1400 - NPX 1500
Oil Seal Spacer D.19 for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Oil Seal Ring Spacer D.19 for Pressure Washers  NPX 1400  8.605.0048 - NPX 1500 8.605.0049. Part for the following products: -...
on 10 Business Days Approx €1.70
Details
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.200.0019
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Gasket O-Ring 12.4X1.78 SHORE 90 for Pressure Washer Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 8052001. Part for the following...
AVAILABLE €1.70
Details
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.200.0003
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, O-Ring Gasket 25.12x1.78 REF.2100 for Pressure Washers  NPX 1400  8.605.0048 - NPX 1500 8.605.0049. Part for the following products: -...
AVAILABLE €1.70
Details
Diesel Pump for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.551.0014
Diesel Pump for Pressure Washer Lavor FKX 1018
Diesel Pump for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Diesel Pump ULKA EP 5 48W 230/50 with O-Ring R4 for Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 8052001. Part for the...
on 7/10 Business Days Approx €58.71
Details
Diesel Filter Unit for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.611.0043
Diesel Filter Unit for Pressure Washer Lavor Missouri
Diesel Filter Unit for Pressure Washer Lavor Missouri Genuine part Lavor, Diesel Filter Unit JOLLY 4 '93 / MISSOURI / MEK for Pressure Washers Missouri - NPX 1400 - NPX 1500. Part for the following products: -  86190601 - IDRO...
Usually Ships in: 10 Business Days Approx. €15.19
Details
Pressure Adjustment Valve for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.009.0304
Pressure Adjustment Valve for Pressure Washer Lavor Missouri
Pressure Adjustment Valve for Pressure Washer Lavor Missouri Genuine part Lavor, Pressure Adjustment Valve Ass'y for Pump ULKA (Spring L=20) for Pressure Washers MISSOURI FKX-PARANA' - MISSOURI - RIO (EMC) + Cable. Part for the...
on 7/10 Business Days Approx. €28.99
Details
Transformer 230-240V for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 5.009.1126
Transformer 230-240V for Pressure Washer Lavor RIO 1108
Transformer 230-240V for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Ignition Transformer 230-240V/50-60Hz With Pipette for FKX-RIO (EMC) + Cable With External Ground for  Pressure Cleaner RIO 1108 220-230/50 TS Part for the...
Usually Ships in: 10 Business Days Approx. €100.43
Details
Diesel Fuel Tank Cap for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 4.608.0180
Diesel Fuel Tank Cap for Pressure Washer Lavor RIO 1108
Diesel Fuel Tank Cap for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Diesel Fuel Tank Cap for Pressure Washers Tekna 4 - RIO 1108 - 8.052.0801 -GR- RAL.7021 Part for the following products: -  Cleaner RIO 1108 220-230/50 TS...
on 10 Business Days Approx €12.99
Details
Electronic Board for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.403.0012
Electronic Board for Pressure Washer Lavor FKX 1018
Electronic Board for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Electronic Board for Pressure Washer Pressure Washers FKX 1018 230/50 TS -R- (VAPORNOVA)- 80520001 - Idropulitrice RIO 1108 220-230/50 TS -G- -LAVOR -...
Usually Ships in: 10/15 Business Days Approx. €36.22
Details
Burner Motor for Pressure Cleaner Lavor RIO 1108
Lavorwash S.p.A. SKU: 3.304.0056
Burner Motor for Pressure Cleaner Lavor RIO 1108
Burner Motor for Pressure Cleaner Lavor RIO 1108 Genuine part Lavor, Burner Motor 230/50Hz Complete With Fan, Flange, Cables L=850 and Cover for Pressure Cleaners RIO 1108 - YUKON 1310 - MISSOURI. Part for the following products: -...
Usually Ships in: 10/15 Business Days Approx. €42.00
Details
Motorpump Ass'y for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 5.001.0824
Motorpump Ass'y for Pressure Washer Lavor RIO 1108
Motorpump Ass'y for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Motorpump Ass'y PT'03 110h 100AL 230-240/50Hz D.12 9GR35 TS W/SUCTION (FKX) - 40050260 - with Pressure Switch for Pressure Washers RIO 1108 - MEK 1108 Part for...
Usually Ships in: 10/15 Business Days Approx. €275.00
Details
Motor Housing for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 5.002.0151
Motor Housing for Pressure Washer Lavor RIO 1108
Motor Housing for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Motor Housing '02 D110 H100 ALL 230-240/50Hz 2P (FKX) for Pressure Washers RIO 1108 - MEK 1108 Part for the following products: -...
Out-of-Stock €273.18
Details
Switch 0/1 Black Button for Pressure Washers Lavor
Lavorwash S.p.A. SKU: 3.401.0178
Switch 0/1 Black Button for Pressure Washers Lavor
Switch 0/1 Black Button for Pressure Washers Lavor Genuine replacement part Lavor, Switch 0/1 Black Button IP55 12/10 for Pressure Washers Lavor Part for the following products: -  Pressure washer Ride 110...
Usually Ships in: 10 Business Days Approx. €6.80
Details
Body Guide PT'03 for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 5.007.0187C
Body Guide PT'03 for Pressure Washer Lavor RIO 1108
Body Guide PT'03 for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Body Guide PT'03 Pistons D.12 with ASS Detergent Suction for Pressure Washers RIO 1108 - MEK 1108 Part for the following products: -  Pressure Cleaner RIO 1108 -...
on 10 Business Days Approx €57.11
Details
Diesel Nozzle for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.104.0008
Diesel Nozzle for Pressure Washer Lavor FKX 1018
Diesel Nozzle for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Diesel Nozzle 0.60 60° HFD Kg/h 231 EN 6011 43281 for Pressure Washers FKX 1018 - RIO 1108 - MEK 1108 - XTR 1007 Part for the following products: -...
Usually Ships in: 10/15 Business Days Approx. €29.49
Details
Body Guide + Head Ass'y for Pressure Washer Lavor RIO 1108
Lavorwash S.p.A. SKU: 5.009.0703C
Body Guide + Head Ass'y for Pressure Washer Lavor RIO 1108
Body Guide + Head Assembled for Pressure Washer Lavor RIO 1108 Genuine part Lavor, Body Guide + Head Assembled TS With Suction (SPRING 13KG) -PT for Pressure Washers RIO 1108 - MEK 1108 Part for the following products: -  Pressure...
Usually Ships in: 10 Business Days Approx. €55.00
Details
Coil for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 4.604.0011
Coil for Pressure Washer Lavor FKX 1018
Coil for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Coil D.202 L.15Mt for Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 80520001. Part for the following products: -  Pressure...
on 10 Business Days Approx €342.49
Details
Lavor Electrode D.2 for YUKON 1310
Lavorwash S.p.A. SKU: 4.614.0003
Lavor Electrode D.2 for YUKON 1310
Lavor Electrode D.2 for Pressure Cleaner YUKON 1310 Original replacement part Lavorwash, Electrode D.2 for Pressure Cleaners YUKON 1310 - RIO 1108. Part for the following products: -  Pressure Cleaner Lavor YUKON 1310 - 86180001...
Usually Ships in: 10 Business Days Approx. €11.56
Details
Lavor MISSOURI Boiler Cover
Lavorwash S.p.A. SKU: 4.005.0194
Lavor MISSOURI Boiler Cover
Lavor MISSOURI Boiler Cover Original part Lavorwash, Boiler Cover for Pressure Cleaners MISSOURI - PARANA' -  YUKON 1310. Part for the following products: - Lavor MISSOURI - Lavor HOT130 - Lavor PARANA' G-LWS - Lavor...
Usually Ships in: 10 Business Days Approx. €79.65
Details
Lavor MISSOURI Heat Resistant Pad
Lavorwash S.p.A. SKU: 4.008.0450
Lavor MISSOURI Heat Resistant Pad
Lavor MISSOURI Heat Resistant Pad Original part Lavorwash, Heat Resistant Pad for Pressure Cleaners MISSOURI - PARANA' -  YUKON 1310. Part for the following products: - Lavor MISSOURI - Lavor HOT130 - Lavor PARANA'...
Usually Ships in: 10 Business Days Approx. €11.02
Details
Lavor MISSOURI Heat Resistant Felt Pad
Lavorwash S.p.A. SKU: 4.008.0658
Lavor MISSOURI Heat Resistant Felt Pad
Lavor MISSOURI Heat Resistant Felt Bottom Pad Original part Lavorwash, Heat Resistant Felt Bottom Pad (FKX/PARANA') for Pressure Cleaners MISSOURI - PARANA' -  YUKON 1310. Part for the following products: - Lavor...
Usually Ships in: 10 Business Days Approx. €6.22
Details
Lavor MISSOURI Ceramic Fiber Band
Lavorwash S.p.A. SKU: 4.008.0503
Lavor MISSOURI Ceramic Fiber Band
Lavor MISSOURI Ceramic Fiber Band Original part Lavorwash, Band in Ceramic Fiber 120X635 SP.4 for Pressure Cleaners MISSOURI - PARANA' -  YUKON 1310. Part for the following products: - Lavor MISSOURI - Lavor HOT130 -...
Usually Ships in: 10 Business Days Approx. €19.00
Details
Lavor Diesel Tank for RIO-R 1108
Lavorwash S.p.A. SKU: 4.008.2565
Lavor Diesel Tank for RIO-R 1108
Lavor Diesel Tank for Pressure Washer RIO-R 1108 Genuine replacement part Lavor, Black Diesel Tank for Pressure Washer RIO-R 1108 - RIO-R 1107. Part for the following products: -  Pressure Washer Lavor RIO-R 1108 - 8.052.0845 -...
Usually Ships in: 10/15 Business Days Approx. €50.00
Details
Comments (0)
No customer reviews for the moment.
