Lavorwash S.p.A.

Lavor Original Parts for Pressure Cleaner Prime 165G

SKU: Lavor Prime 165G - 80970010C
€3.32
VAT included

Lavor Original Parts for Pressure Cleaner Prime 165G

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner PRIME 165G 220-240~50/60 -N/G- TS EU 2L +SP.ROT.+L28+SPURG. - 80970010C.

Fix Your Pressure Cleaner. All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

Cold Water High Pressure Cleaner PRIME 165G
Lavor Original Parts for Pressure Cleaner Prime 165G
  • Lavor Original Parts for Pressure Cleaner Prime 165G
  • Lavor Original Parts for Pressure Cleaner Prime 165G - Diagram
  • Lavor Original Parts for Pressure Cleaner Prime 165G - Diagram - 1
  • Lavor Original Parts for Pressure Cleaner Prime 165G - Diagram - 2
  • Lavor Original Parts for Pressure Cleaner Prime 165G - Diagram - 4
  • Lavor Original Parts for Pressure Cleaner Prime 165G - Diagram - 4
Lavorwash S.p.A.

Lavor Original Parts for Pressure Cleaner Prime 165G

SKU: Lavor Prime 165G - 80970010C Condition: New
€3.32
VAT included

Lavor Original Parts for Pressure Cleaner Prime 165G

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner PRIME 165G 220-240~50/60 -N/G- TS EU 2L +SP.ROT.+L28+SPURG. - 80970010C.

Fix Your Pressure Cleaner. All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

Cold Water High Pressure Cleaner PRIME 165G
settings 42 spare parts
description 5 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
42 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
006
 photo_cameraImage coming soon 4.008.1432 BLACK SWITCH KNOB €3.23
007
 photo_cameraImage coming soon 3.401.0202 ROTARY SWITCH TWO GEARS BIPOLAR 16A (0-1) W/PIN 11.5 €5.55
009
 photo_cameraImage coming soon 4.008.1437 BLACK CAP FOR ELECTRICAL BOX VERTIGO €3.15
011
 photo_cameraImage coming soon 4.008.1425 BLACK HANDLE FOR VERTIGO €25.47
012
 photo_cameraImage coming soon 4.008.1430 YELLOW CABLE REEL VERTIGO -PANT.108C- €24.93
013
 Einhell Tank Cap for RT-HP 1855 TR 4.008.0095 Einhell Tank Cap for RT-HP 1855 TR €7.41
014
 Lavor Tank for Vertigo 28 Plus 4.008.1431 Lavor Tank for Vertigo 28 Plus €13.68
015
 photo_cameraImage coming soon 4.013.0639 BLACK BACK SIDE CABINET VERTIGO €26.75
016
 photo_cameraImage coming soon 4.008.1433 BLACK WHEEL VERTIGO €12.82
017
 photo_cameraImage coming soon 4.012.0235 CABLE H05VV-F 2X1,5 5,4MT SCHUKO PLUG €28.64
018
 Trigger Gun S'09 6.001.0076 for Pressure Washers Cold Water Lavor 6.001.0076 Trigger Gun S'09 6.001.0076 for Pressure Washers Cold Water Lavor €24.00
019
 H.P. Hose 4.018.0096 8 m for Quick Coupling Trigger Gun Lavor S’09 4.018.0096 H.P. Hose 4.018.0096 8 m for Quick Coupling Trigger Gun Lavor S’09 €29.90
022
 Lance 6.002.0340 Nozzle Head Holder for Trigger Guns Lavor 6.002.0340 Lance 6.002.0340 Nozzle Head Holder for Trigger Guns Lavor €10.11
023
 Head Soap Nozzle 6.002.0634 6.002.0634 Head Soap Nozzle 6.002.0634 €6.20
024
 Head Turbo Nozzle Ø 1,025 for Lance Lavor 6.002.0346 Head Turbo Nozzle Ø 1,025 for Lance Lavor €7.50
026
 photo_cameraImage coming soon 3.601.0066 Substituted by 3.601.0074 1 ROTATING BRUSH WITH FIXED HAND €24.33
027
 Head Nozzle Jet Adjustable Needle-Fan Ø 1.00 6.002.0637 6.002.0637 Head Nozzle Jet Adjustable Needle-Fan Ø 1.00 6.002.0637 €9.65
030
 photo_cameraImage coming soon 7.100.2136 MANUAL PRIME/PATROL LAVOR €11.82
032
 photo_cameraImage coming soon 6.005.0450 HOSE REEL KIT PRIME €37.39
033
 photo_cameraImage coming soon 3.601.0102 YELLOW/BLACK FLOOR BRUSH L28 W/EXTENSION (D.1,2) €48.89
034
 6 m Pipe Cleaning Hose 6.003.0037 for Pressure Washer Lavor 6.003.0037 6 m Pipe Cleaning Hose 6.003.0037 for Pressure Washer Lavor €57.27
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
001
 Motor Ass'y for Pressure Washer Lavor WASHER 19 5.009.0924 Motor Ass'y for Pressure Washer Lavor WASHER 19 €97.14
002
 Kit 166 Footstep Bearing for Pressure Washer Lavor Predator 160 WPS 6.005.0180 Kit 166 Footstep Bearing for Pressure Washer Lavor Predator 160 WPS €13.79
003
 Pin 10x70 for Pressure Washer Lavor Predator 160 WPS 4.007.0205 Pin 10x70 for Pressure Washer Lavor Predator 160 WPS €7.68
004
 photo_cameraImage coming soon 5.009.0742 7'10 WOBBLE PLATE ASSEMBLY W/CROWNZ 50 (PT'03) €17.08
005
 photo_cameraImage coming soon 4.007.0328 THRUST BEARING 35X55X12 PT'03 €15.13
006
 photo_cameraImage coming soon 5.009.0997C BODY GUIDE+HEAD(TPAV) W/TS 14.5KG-SUCT.-THREAD CAPS-PL.CHECK VALVE SEAT €52.04
007
 photo_cameraImage coming soon 4.008.1026 MOTOR CONVEYER RIGHT+LEFT 2100W €7.98
008
 photo_cameraImage coming soon 4.008.1077 LOW COVER FOR CONVEYOR IN 2 PARTS (8850) €4.95
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
.
 photo_cameraImage coming soon 50070281C PISTON BODY GUIDE PT'03 W/TS 14.5KG-SUCTION €30.27
001
 photo_cameraImage coming soon 5.007.0281C PISTON BODY GUIDE PT'03 W/TS 14.5KG-SUCTION €30.28
002
 Kit 257 LW Rings Support + Spacers for Washer Lavor ENDURO 145 6.005.0282 Kit 257 LW Rings Support + Spacers for Washer Lavor ENDURO 145 €14.54
003
 photo_cameraImage coming soon 5.008.0298C PT'03 HEAD D.12 W/THREAD CAPS(TPAV - ALUM.CAPS) €18.38
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
001
 Lavor GALAXY 160 TSS Valve Assy 5.009.1022 Lavor GALAXY 160 TSS Valve Assy €18.00
002
 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 6.005.0277 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 €4.50
003
 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 6.005.0079 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 €14.50
004
 Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 6.005.0226 Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 €11.43
005
 Piston Body Guide for Pressure Washer Lavor BEST 24 4.005.0263 Piston Body Guide for Pressure Washer Lavor BEST 24 €25.65
006
 Kit 167 LW 3 Pistons + Springs for Pressurte Washer Lavor BEST 24 6.005.0181 Kit 167 LW 3 Pistons + Springs for Pressurte Washer Lavor BEST 24 €25.98
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
001
 photo_cameraImage coming soon 6.005.0595 KIT HEAD VALVE KIT +CAPS PT'03 €14.17
002
 photo_cameraImage coming soon 4.005.0302 PT'03 HEAD WITH THREAD FOR VALVE CAPS (TPAV) €5.99
003
 Kit 124 Water Seal Partner for Pressurte Washer Lavor BEST 24 6.005.0133 Kit 124 Water Seal Partner for Pressurte Washer Lavor BEST 24 €14.54

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Original Parts for Pressure Cleaner Prime 165G

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner PRIME 165G 220-240~50/60 -N/G- TS EU 2L +SP.ROT.+L28+SPURG. - 80970010C.

Fix Your Pressure Cleaner. All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Lavor Prime 165G - 80970010C

80970010C - PRESSURE CLEANER PRIME 165G 220-240~50/60 -N/G- TS EU 2L Pag.1
# part Num. Description
. 5001X763C MTP.SP.PT'03 230/50 7'10 C/TERM.-TS-ASP. 14.5KG (8850) C/CONV.
001 5.011.0241 ASSEMBLY COVER+FRONTAL COVER PRIME (YELLOW/BLACK)
006 4.008.1432 BLACK SWITCH KNOB
007 3.401.0202 ROTARY SWITCH TWO GEARS BIPOLAR 16A (0-1) W/PIN 11.5
009 4.008.1437 BLACK CAP FOR ELECTRICAL BOX VERTIGO
011 4.008.1425 BLACK HANDLE FOR VERTIGO
012 4.008.1430 YELLOW CABLE REEL VERTIGO PANT.108C
013 4.008.0095 BLACK DETERGENT TANK CAP WITH HOLE D.9
014 4.008.1431 TANK FOR VERTIGO
015 4.013.0639 BLACK BACK SIDE CABINET VERTIGO
016 4.008.1433 BLACK WHEEL VERTIGO
017 4.012.0235 CABLE H05VV-F 2X1,5 5,4MT SCHUKO PLUG
018 6.001.0076 GUN S'09 WITH INTEGRAL QUICK JOINT
019 4.018.0096 HOSE 1/4 180BAR L=8000 M22x1,5 D.15-RAPID FIX
022 6.002.0340 LANCE S'12 WITHOUT NOZZLE HEAD WITH QUICK COUPLING/COGETIL
023 6.002.0634 SOAP HEAD LANCE S'12 W/QUICK COUPLING
024 6.002.0346 ROTOX NOZZLE HEAD LANCE S'12 D.1,025 WITH QUICK COUPLING
026 3.601.0066 ROTATING HYDRO BRUSH W/HANDLE
027 6.002.0637 NOZZLE HEAD LANCE S'12 D.1,00 (L.BLUE) ADJUST.FAN JET W/QUICK COUPLING
030 7.100.2136 MANUAL PRIME/PATROL LAVOR
032 6.005.0450 HOSE REEL KIT PRIME
033 3.601.0102 YELLOW/BLACK FLOOR BRUSH L28 D.1,2 W/EXTENSION
034 6.003.0037 PIPE CLEANING HOSES MT6+COGETIL+ NOZZLE
5001X763C - MTP.SP.PT'03 230/50 7'10 C/TERM.-TS-ASP. 14.5KG (8850) Pag.2
. 50090997C GRUPPO C.GUIDA C/TS 14.5KG-ASP.+TEST.TAPPI FIL. PT'03-TPAV
001 5.009.0924 8850 MOTOR 230/50 W/CAPACITOR-THERMAL 17AM-D 140G
002 6.005.0180 KIT 166 FOOTSTEP BEARING 3047 PT' 03-SD
003 4.007.0205 PIN 10X70
004 5.009.0742 7'10 WOBBLE PLATE ASSEMBLY W/PLASTIC INSERT+RING GEAR Z 50
005 4.007.0328 THRUST BEARING 35X55X12 PT'03
006 5.009.0997C BODY GUIDE+HEAD(TPAV) W/TS 14.5KG-SUCT.-THREAD CAPS-PL.CHECK VALVE SEAT
007 4.008.1026 MOTOR CONVEYER RIGHT+LEFT 2100W
008 4.008.1077 LOW COVER FOR CONVEYOR IN 2 PARTS (8850)
50090997C - GRUPPO C.GUIDA C/TS 14.5KG-ASP.+TEST.TAPPI FIL. Pag.3
. 50070281C CORPO GUIDA PT'03 C/TS 14.5KG-ASP.
. 50080298C TESTATA PT'03 (TPAV) D.12 C/TAPPI FIL.ALL.
001 5.007.0281C PISTON BODY GUIDE PT'03 W/TS 14.5KG-SUCTION
002 6.005.0282 KIT 257 O-RING SEAL
003 5.008.0298C PT'03 HEAD (TPAV) D.12 W/ALUM.THREAD CAPS
50070281C - CORPO GUIDA PT'03 C/TS 14.5KG-ASP. Pag.4
001 5.009.1022 COMPLETED VALVE TS PT'03 CABLE L=530 SPRING 14.5KG (WHITE FASTON COVER)
002 6.005.0277 KIT 252
003 6.005.0079 KIT 79 LW OIL SEALS
004 6.005.0226 KIT 209 O-RING
005 4.005.0263 PISTON BODY GUIDE PT'03 WITH SUCTION VALVE
006 6.005.0181 KIT 167 LW PISTON
50080298C - TESTATA PT'03 (TPAV) D.12 C/TAPPI FIL.ALL. Pag.5
001 6.005.0595 KIT HEAD VALVE KIT +CAPS PT'03
002 4.005.0302 PT'03 HEAD WITH THREAD FOR VALVE CAPS (TPAV)
003 6.005.0133 KIT 124 O-RING WATER SEAL PARTNER D.12
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor Prime 165G - 80970010C
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

New

Download

Drawing Lavor Prime 165G

Drawing Lavor Prime 165G

Download (1019.77KB)

You might also like

Lance 6.002.0340 Nozzle Head Holder for Trigger Guns Lavor
Lavorwash S.p.A. SKU: 6.002.0340
Lance 6.002.0340 Nozzle Head Holder for Trigger Guns Lavor
Lance 6.002.0340 Nozzle Head Holder for Trigger Guns Lavor Genuine Replacement part Lavor, Lance 6.002.0340 Nozzle Head Holder for Cold Water Pressure Washers Trigger Guns Lavor Fury 110 - Ride 110 - Race 125...
Last items in stock €10.11
Details
Head Nozzle Jet Adjustable Needle-Fan Ø 1.00 6.002.0637
Lavorwash S.p.A. SKU: 6.002.0637
Head Nozzle Jet Adjustable Needle-Fan Ø 1.00 6.002.0637
Head Nozzle Jet Adjustable Needle-Fan Ø 1.00 6.002.0637 Genuine Replacement part Lavor, Head Nozzle Jet Adjustable Needle-Fan Ø 1.00 6.002.0637 for Lance Lavor 6.002.0343. Part suitable for the following high pressure washers: - Lavor...
AVAILABLE €9.65
Details
Head Soap Nozzle 6.002.0634
Lavorwash S.p.A. SKU: 6.002.0634
Head Soap Nozzle 6.002.0634
Head Soap Nozzle 6.002.0634 Genuine Replacement part Lavor, Head Soap Nozzle 6.002.0634 for Lance Lavor 6.002.0343. Part suitable for the following high pressure washers: - Lavor Fury 110 - Lavor Race 125 - Lavor Cross 140 - Lavor...
Last items in stock €6.20
Details
Head Turbo Nozzle Ø 1,025 for Lance Lavor
Lavorwash S.p.A. SKU: 6.002.0346
Head Turbo Nozzle Ø 1,025 for Lance Lavor
Head Turbo Nozzle Ø 1,025 for Lance Lavor Genuine Replacement part Lavor, Head cod. 6.002.0346 Turbo Nozzle Ø 1,025 for Lance Lavor 6.002.0340. Part suitable for the following high pressure...
Last items in stock €7.50
Details
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0079
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24
Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 Original replacement part Lavor, Kit 79 LW Oil Seal for Partner D.12/Fibra per Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 - ENDURO 145 COMP. Part for the following...
Usually Shipped on: 7/10 Business Days Approx. €14.50
Details
Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0226
Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24
Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 Original replacement part Lavor, Kit 209 O-Ring for PT'03 per Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 - ENDURO 145 - BEST 24. Part for the following products: -...
Usually Ships in: 7/10 Business Days Approx. €11.43
Details
Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS
Lavorwash S.p.A. SKU: 5.009.1020
Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS
Wobble Plate Assembly for Pressure Washer Lavor Predator 160 WPS Genuine replacement part Lavor, 7'10 Wobble Plate Assembly W/Crown Z 50 (PT'03) for Prssure Washer Predator 160 WPS 220-240~50/60 -V/N- TS EU C/AVV. LWS 8.101.0012....
Usually Ships in: 10/15 Business Days Approx. €17.59
Details
Pin 10x70 for Pressure Washer Lavor Predator 160 WPS
Lavorwash S.p.A. SKU: 4.007.0205
Pin 10x70 for Pressure Washer Lavor Predator 160 WPS
Pin 10x70 for Pressure Washer Lavor Predator 160 WPS Genuine replacement part Lavor, Pin 10x70 for Drive Wooble Plate Assembly with Crown for Pressure Washer Predator 160 WPS 220-240~50/60 -V/N- TS EU C/AVV. LWS 8.101.0012. Part for...
AVAILABLE €7.68
Details
Piston Body Guide for Pressure Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 4.005.0263
Piston Body Guide for Pressure Washer Lavor BEST 24
Piston Body Guide for Pressure Washer Lavor BEST 24 Original replacement part Lavor, Kit Piston Body Guide PT'03 for Pressure Washers Vertigo 28 - BEST 24. Part for the following products: -  Pressure Washer...
Last items in stock €25.65
Details
Motor Ass'y for Pressure Washer Lavor WASHER 19
Lavorwash S.p.A. SKU: 5.009.0924
Motor Ass'y for Pressure Washer Lavor WASHER 19
Motor Ass'y for Pressure Washer Lavor WASHER 19 Genuine part Lavor, Brush Motor Assembly '03 230/50 for Pressure Washers WASHER 19 - XTR 1007 - GALAXY 160 - PLANET 160 - STM 160 - PRIME...
Usually Ships in: 10 Business Days Approx. €97.14
Details
Einhell Tank Cap for RT-HP 1855 TR
Einhell Italia s.r.l. SKU: 4.008.0095
Einhell Tank Cap for RT-HP 1855 TR
Einhell Tank Cap for Pressure Cleaner RT-HP 1855 TR Original replacement part Lavorwash, Black Detergent Tank Cap With Hole D.9 for Pressure Cleaners EINHELL RT-HP 1855 TR - Lawor TUCSON 1013LP. Part for the following products:...
Last items in stock €7.41
Details
Lavor Tank for Vertigo 28 Plus
Lavorwash S.p.A. SKU: 4.008.1431
Lavor Tank for Vertigo 28 Plus
Lavor Tank for Pressure Cleaner Vertigo 28 Plus Original replacement part Lavorwash, Tank for Pressure Cleaners Vertigo 28 Plus - Vertigo 25. Part for the following products: -  Pressure Cleaner Lavor Vertigo 28 Plus 80470016 -...
Usually Ships in: 10 Business Days Approx. €13.68
Details
Lavor GALAXY 160 TSS Valve Assy
Lavorwash S.p.A. SKU: 5.009.1022
Lavor GALAXY 160 TSS Valve Assy
Lavor GALAXY 160 TSS Valve Assy for Pressure Cleaner Genuine replacement part Lavor 1002-05463 EX 5.009.1022, TSS Valve Assembly Assieme V.COMP. C/TS PT'03 Cable L=530 Spring 14.5KG (WHITE COVER) for Pressure Cleaners GALAXY 160....
Usually Ships in: 10/15 Business Days Approx. €18.00
Details
Comments (0)
