Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean

SKU: Lavor Crystal Clean - 8.501.0508
€14.15
VAT included

Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean

Fix Your Floor Scrubber Drier Crystal Clean Lavor Pro - 8.501.0508. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Lavor Crystal Clean - 8.501.0508
Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean
  • Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean
  • Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean - Drawing
Lavorwash S.p.A.

Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean

SKU: Lavor Crystal Clean - 8.501.0508 Condition: New
€14.15
VAT included

Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean

Fix Your Floor Scrubber Drier Crystal Clean Lavor Pro - 8.501.0508. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Lavor Crystal Clean - 8.501.0508
settings 69 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
69 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
Pos. Item Price Buy
001
 photo_cameraImage coming soon 5.009.0482 SWITCH + PROTECTION COVER ASSEMBLY €13.74
002
 photo_cameraImage coming soon 4.508.0012 UPPER COVER HANDLE GREY RAL 7043B €30.06
003
 photo_cameraImage coming soon 4.508.1474 SWITCH ON/OFF COVER (RED) €4.67
004
 photo_cameraImage coming soon 4.508.1473 TANK CAP (RED) €6.17
005
 Filter Ass'y for Floor Scrubber Drier Lavor Crystal Clean 5.509.1838 Filter Ass'y for Floor Scrubber Drier Lavor Crystal Clean €54.85
006
 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter 6.505.0041 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter €6.40
007
 Filter Gasket for Floor Scrubber Drier Lavor Pro Sprinter 4.508.0029 Filter Gasket for Floor Scrubber Drier Lavor Pro Sprinter €3.92
008
 Lavor Pro Sprinter Solution Tank Grey 5.509.0415 Lavor Pro Sprinter Solution Tank Grey €38.08
009
 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter 6.505.0041 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter €6.40
010
 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter 6.505.0041 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter €6.40
011
 photo_cameraImage coming soon 4.508.0459 BLACK WATER TANK (GREY) €51.84
012
 Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter 5.509.0008 Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter €29.49
013
 photo_cameraImage coming soon 3.401.0181 SWITCH FOR CHEMICAL/WATER €4.89
014
 Lavor Solution Actuator for Sprint 4.508.0021 Lavor Solution Actuator for Sprint €3.50
015
 photo_cameraImage coming soon 4.508.1476 REAR HANDLE COVER (GREY) €69.90
016
 photo_cameraImage coming soon 4.508.0023 CABLE HOLDER MW GREY RAL 7043 B €3.54
017
 Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter 3.099.0278 Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter €29.49
018
 photo_cameraImage coming soon 4.507.0001 PULLEY Z20 MW €6.66
019
 photo_cameraImage coming soon 4.506.0001 WASHER €3.23
020
 photo_cameraImage coming soon 4.508.0042 PULLEY FOR BRUSH €10.99
021
 Diesel Filter TP3 for Floor Scrubber Drier Lavor Pro Sprinter 3.102.0003 Diesel Filter TP3 for Floor Scrubber Drier Lavor Pro Sprinter €6.55
022
 Detergent Pump for Floor Scrubber Drier Lavor Pro Sprinter 3.551.0032 Detergent Pump for Floor Scrubber Drier Lavor Pro Sprinter €45.78
023
 photo_cameraImage coming soon 4.508.0034 DISPENSER CONNECTION €5.11
024
 photo_cameraImage coming soon 4.508.0033 SOLUTION DISPENSER €5.11
025
 Lavor Sprinter Diffuser Assy 5.509.1226 Lavor Sprinter Diffuser Assy €41.38
026
 photo_cameraImage coming soon 5.509.0012 JOINT ASSY Y+FLEX HOSES MW. €27.51
027
 photo_cameraImage coming soon 4.505.0003 HANDLE SUPPORT €28.64
028
 photo_cameraImage coming soon 3.404.0053 CAPACITOR 8mF D.35X57 F/M €7.66
029
 Squeegee + Support for Floor Scrubber Drier Lavor Pro Sprinter 5.509.0010 Squeegee + Support for Floor Scrubber Drier Lavor Pro Sprinter €14.85
030
 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter 5.509.0002 Brush + Bearing Ass'y for Floor Scrubber Drier Lavor Pro Sprinter €35.95
032
 photo_cameraImage coming soon 4.508.0001 U BUSH LOCKING €5.92
033
 photo_cameraImage coming soon 4.507.0004 SQUEEGEE SUPPORT SPRING €3.23
034
 Lavor Sprinter Wheel D.100 MW Grey 4.508.0007 Lavor Sprinter Wheel D.100 MW Grey €15.00
035
 photo_cameraImage coming soon 5.509.1822 ASSIEME CAREN.INF.MW TERMORES. NERO C/ISOL.ACUST./SEDE CALDAIA €78.47
036
 photo_cameraImage coming soon 4.508.0027 ACOUSTIC PANEL €5.92
037
 photo_cameraImage coming soon 4.508.0030 EXHAUST AIR FILTER €4.24
038
 photo_cameraImage coming soon 4.508.0009 AIR INTAKE PORTION €3.00
039
 Lavor Sprinter Air Intake Seal 4.508.0032 Lavor Sprinter Air Intake Seal €5.90
040
 Lavor Sprinter Offset Ring 4.508.0031 Lavor Sprinter Offset Ring €3.50
041
 Suction Motor for Floor Scrubber Drier Lavor Crystal Clean 6.505.0040 Suction Motor for Floor Scrubber Drier Lavor Crystal Clean €76.38
042
 photo_cameraImage coming soon 3.200.0092 OR 139,37x2,62 NBR SH 70 €1.62
043
 photo_cameraImage coming soon 4.507.0002 SUCTION MOTOR SUPPORT €9.18
044
 photo_cameraImage coming soon 4.508.0028 UPPER ACOUSTIC PANEL €6.27
045
 Lavor Sprinter Pedal Grey RAL 7043B 4.508.0004 Lavor Sprinter Pedal Grey RAL 7043B €15.00
047
 photo_cameraImage coming soon 4.508.0036 ADHESIVE GASKET €4.60
048
 photo_cameraImage coming soon 4.508.0003 TRACTION MOTOR AIR CONVEYOR €6.61
049
 photo_cameraImage coming soon 3.099.0277 FAN FOR TRACTION MOTOR €1.68
050
 photo_cameraImage coming soon 4.505.0002 FLANGE FOR MOTOR €12.20
051
 photo_cameraImage coming soon 3.001.0032 BEARING 6002 2RS1 €5.03
052
 photo_cameraImage coming soon 6.505.0003 KIT STATOR + ROTOR + SHAFT LWS €128.18
054
 photo_cameraImage coming soon 4.505.0001 MOTOR SUPPORT €28.64
055
 photo_cameraImage coming soon 4.506.0004 SUPPORT FOR PULLEY €5.99
056
 photo_cameraImage coming soon 4.508.0041 BRUSH TRACTOR €1.69
057
 photo_cameraImage coming soon 3.004.0007 FLAT WASHER D.6X18 Sp.2 UNI6593 ZNT €1.72
058
 photo_cameraImage coming soon 3.004.0035 SPRING WASHER GROWER D.6 DI N 127 TYPE B ZNT WHITE €1.68
059
 photo_cameraImage coming soon 3.002.0150 SCREW M6X35 UNI 5931 €1.68
060
 photo_cameraImage coming soon 4.012.0268 MAIN POWER CABLE 3X1,5 MT.10 SCHUKO PLUG €68.68
063
 photo_cameraImage coming soon 3.002.0106 SELF-TAPPING SCREW TC-TC 3.9X16 UNI 6954 ZNT €1.72
064
 photo_cameraImage coming soon 3.002.0068 SCREW TCEI M6X12 UNI 5931 ZNT €1.68
065
 photo_cameraImage coming soon 4.506.0003 SCREW M3 €7.28
066
 photo_cameraImage coming soon 4.506.0002 SCREW M6 €3.77
067
 photo_cameraImage coming soon 3.004.0026 FLAT WASHER D.4,3X12 UNI 6593 ZNT €1.72
068
 photo_cameraImage coming soon 3.002.0028 SCREW TC-TC M4X12 UNI 7687 ZNT €3.23
069
 photo_cameraImage coming soon 3.004.0003 PINK WASHER EX.D.4X8 Sp0,5 DIN6798A ZNT €1.72
070
 photo_cameraImage coming soon 3.002.0182 TCEI SCREW M4X55 UNI ZNT €1.68
071
 photo_cameraImage coming soon 3.002.0127 SCREW TC CROSS CUT M5X35 SWAGE FORM ZNT €1.68
072
 photo_cameraImage coming soon 5.509.1836 ASSEMBLY UPPER COVER (RED) €99.74
075
 photo_cameraImage coming soon 5.509.0394 CARPET BRUSH + BEARING ASSEMBLY €63.17
076
 Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean 6.505.0087 Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean €87.31

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Pro Original Parts for Floor Scrubber Drier Crystal Clean

Fix Your Floor Scrubber Drier Crystal Clean Lavor Pro - 8.501.0508. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Crystal Clean Lavor Pro - 8.501.0508

Floor Scrubber Drier 90°C Hot water Power 1500 Watt - 8.501.0508 Crystal Clean
# Part Num. Description
001 5.009.0482 SWITCH + PROTECTION COVER ASSEMBLY
002 4.508.0012 UPPER COVER HANDLE GREY RAL 7043B
003 4.508.1474 SWITCH ON/OFF COVER (RED)
004 4.508.1473 TANK CAP (RED)
005 5.509.1838 ASSEMBLY FOR FILTER (RED) BY-PASS D.10
006 6.505.0041 VALVE RUBBER GASKET NR-EPDM 55 SH MW
007 4.508.0029 FILTER GASKET 10X12 L=690
008 5.509.0415 GREY SOLUTION TANK WITH WASHER AND GASKET
009 6.505.0041 SOLUTION TANK GASKET DIAM. 46X18 SP.2 MW
010 6.505.0041 VALVE FOR TANK MW
011 4.508.0459 BLACK WATER TANK (GREY)
012 5.509.0008 ASSY FLEXIBLE HOSE L.800 MW
013 3.401.0181 SWITCH FOR CHEMICAL/WATER
014 4.508.0021 SOLUTION ACTUATOR GREY RAL 7043B
015 4.508.1476 REAR HANDLE COVER (GREY)
016 4.508.0023 CABLE HOLDER MW GREY RAL 7043 B
017 3.099.0278 BELT 336 RPP3-12
018 4.507.0001 PULLEY Z20 MW
019 4.506.0001 WASHER
020 4.508.0042 PULLEY FOR BRUSH
021 3.102.0003 DIESEL FUEL FILTER TP3
022 3.551.0032 DETERGENT PUMP 230-240V - 50Hz
023 4.508.0034 DISPENSER CONNECTION
024 4.508.0033 SOLUTION DISPENSER
025 5.509.1226 DIFFUSER ASSY+230V PUMP+ FILTER+SOLUTION HOSE
026 5.509.0012 JOINT ASSY Y+FLEX HOSES MW.
027 4.505.0003 HANDLE SUPPORT
028 3.404.0053 CAPACITOR 8mF D.35X57 F/M
029 5.509.0010 SQUEEGEE + SUPPORT ASSEMBLY
030 5.509.0002 BRUSH + BEARING ASSEMBLY
032 4.508.0001 U BUSH LOCKING
033 4.507.0004 SQUEEGEE SUPPORT SPRING
034 4.508.0007 GREY WHEEL D.100 MW
035 5.509.1822 ASSIEME CAREN.INF.MW TERMORES. NERO C/ISOL.ACUST./SEDE CALDAIA
036 4.508.0027 ACOUSTIC PANEL
037 4.508.0030 EXHAUST AIR FILTER
038 4.508.0009 AIR INTAKE PORTION
039 4.508.0032 AIR INTAKE SEAL
040 4.508.0031 NON SIMMETRIC RING
041 6.505.0040 SUCTION MOTOR 230V/50-60Hz 800 W
042 3.200.0092 OR 139,37x2,62 NBR SH 70
043 4.507.0002 SUCTION MOTOR SUPPORT
044 4.508.0028 UPPER ACOUSTIC PANEL
045 4.508.0004 PEDAL GREY RAL 7043B
047 4.508.0036 ADHESIVE GASKET
048 4.508.0003 TRACTION MOTOR AIR CONVEYOR
049 3.099.0277 FAN FOR TRACTION MOTOR
050 4.505.0002 FLANGE FOR MOTOR
051 3.001.0032 BEARING 6002 2RS1
052 6.505.0003 KIT STATOR + ROTOR + SHAFT LWS
054 4.505.0001 MOTOR SUPPORT
055 4.506.0004 SUPPORT FOR PULLEY
056 4.508.0041 BRUSH TRACTOR
057 3.004.0007 PLAIN WASHER D.6X18X2 UNI6593
058 3.004.0035 WASHER GROWER D.6 UNI1751 ZNT
059 3.002.0150 SCREW M6X35 UNI 5931
060 4.012.0268 MAIN POWER CABLE 3X1,5 MT.10 SCHUKO PLUG
063 3.002.0106 SELF TAPPING CROSS HEAD SCREW 3.9X16
064 3.002.0068 SCREW TCEI M6X12 UNI 5931 ZNT
065 4.506.0003 SCREW M3
066 4.506.0002 SCREW M6
067 3.004.0026 PLAIN WASHER D.4.3X12 UNI6593
068 3.002.0028 SCREW TC-TC M4X12 UNI 7687 ZNT
069 3.004.0003 WASHER D.4X8 DIN6798 ZNT
070 3.002.0182 TCEI SCREW M4X55 UNI ZNT
071 3.002.0127 SCREW TC CROSS CUT M5X35 SWAGE FORM ZNT
072 5.509.1836 ASSEMBLY UPPER COVER (RED)
075 5.509.0394 CARPET BRUSH + BEARING ASSEMBLY
076 6.505.0087 KIT CALDAIA CRYSTAL CLEAN
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor Crystal Clean - 8.501.0508
5 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

New

Download

Drawing Lavor Crystal Clean

Drawing Lavor Crystal Clean

Download (458.8KB)

You might also like

Filter Gasket for Floor Scrubber Drier Lavor Pro Sprinter
Lavorwash S.p.A. SKU: 4.508.0029
Filter Gasket for Floor Scrubber Drier Lavor Pro Sprinter
Filter Gasket for Floor Scrubber Drier Lavor Pro Sprinter Genuine replacement part Lavor, Filter Gasket 10X12 L. 690 (MW) for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following...
on 7/10 Business Days Approx. €3.92
Details
Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter
Lavorwash S.p.A. SKU: 5.509.0008
Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter
Flexible Hose for Floor Scrubber Drier Lavor Pro Sprinter Genuine replacement part Lavor, Flexible Hose Ass'y L.800 MW for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following products:...
Last items in stock €29.49
Details
Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter
Lavorwash S.p.A. SKU: 3.099.0278
Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter
Belt 336 RPP3-12 for Floor Scrubber Drier Lavor Pro Sprinter Genuine replacement part Lavor, Belt 336 RPP3-12 for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following...
Usually Shipped on: 10 Business Days Approx. €29.49
Details
Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean
Lavorwash S.p.A. SKU: 6.505.0087
Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean
Boiler Kit for Floor Scrubber Drier Lavor Crystal Clean Genuine replacement part Lavor, Boiler Kit for Floor Scrubber Drier Crystal Clean. Part for the following products: -  Floor Scrubber Drier Lavor...
Last items in stock €87.31
Details
Lavor Pro Sprinter Solution Tank Grey
Lavorwash S.p.A. SKU: 5.509.0415
Lavor Pro Sprinter Solution Tank Grey
Lavor Pro Sprinter Solution Tank Grey Genuine replacement part Lavor, Solution Tank Grey with Washer & Gasket Ass'y for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following products: - ...
Last items in stock €38.08
Details
Lavor Solution Actuator for Sprint
Lavorwash S.p.A. SKU: 4.508.0021
Lavor Solution Actuator for Sprint
Lavor Solution Actuator for Sprint Original replacement part Lavorwash, Solution Actuator Grey Ral 7043b for Floor Scrubber Drier. Part for the following products: -  Floor Scrubber Drier Lavor Pro SPRINTER - 8.501.0501 - ...
Usually Ships in: 10 Business Days Approx. €3.50
Details
Lavor Sprinter Wheel D.100 MW Grey
Lavorwash S.p.A. SKU: 4.508.0007
Lavor Sprinter Wheel D.100 MW Grey
Lavor Sprinter Wheel D.100 MW Grey RAL.7016 Genuine replacement part Lavor, Wheel D.100 MW Grey RAL.7016 for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following products: -  Floor Scrubber...
Usually Ships in: 10/15 Business Days Approx. €15.00
Details
Lavor Sprinter Pedal Grey RAL 7043B
Lavorwash S.p.A. SKU: 4.508.0004
Lavor Sprinter Pedal Grey RAL 7043B
Lavor Sprinter Pedal Grey RAL 7043B Genuine replacement part Lavor, Pedal Grey RAL 7043B for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following products: -  Floor Scrubber Drier Sprinter Lavor Pro -...
Last items in stock €15.00
Details
Lavor Joint and Flex Hoses for Sprinter
Lavorwash S.p.A. SKU: 10002-06600 ex 5.509.0012
Lavor Joint and Flex Hoses for Sprinter
Lavor Joint and Flex Hoses for Floor Scrubber Drier Sprinter Genuine replacement part Lavor, Joint Assy Y+Flex Hoses Mw. for Floor Scrubber Drier Sprinter - Crystal. Part for the following products: -  Floor Scrubber Drier...
Last items in stock €28.33
Details
Lavor Sprinter Offset Ring
Lavorwash S.p.A. SKU: 4.508.0031
Lavor Sprinter Offset Ring
Lavor Floor Scrubber Drier Sprinter Offset Ring Genuine replacement part Lavor, Non Simmetric Ring for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following products: -  Floor...
Last items in stock €3.50
Details
Lavor Sprinter Air Intake Seal
Lavorwash S.p.A. SKU: 4.508.0032
Lavor Sprinter Air Intake Seal
Lavor Floor Scrubber Drier Sprinter Air Intake Seal Genuine replacement part Lavor, Air Intake Seal D.65X33X2Sp. Mw for Floor Scrubber Drier Sprinter Lavor Pro - 8.501.0501 Part for the following...
Last items in stock €5.90
Details
Comments (0)
