Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Name: Lavor Original Parts for Pressure Cleaner TUCSON 1013LP
Brand: Lavorwash S.p.A.
SKU: Lavor TUCSON 1013LP 8.671.0016
Availability: InStock

SKU: Lavor TUCSON 1013LP 8.671.0016

€69.65

VAT included

Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner TUCSON 1013LP 220/60 -G- TS SCHUKO PLUG CALIBRATE TO 105-110BAR - LAVOR PROFESSIONAL - 8.671.0016.

Fix Your Pressure Cleaner TUCSON 1013LP. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts.

Pressure Cleaner TUCSON 1013LP

58 spare parts

Page 1 View exploded Usually Ships in: 10 BUSYNESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
001	Image coming soon	4.613.0388 UPPER CASING TUCSON CL4 (R.A. ENGINE) -G- PANT.108C	€61.90
002	Image coming soon	4.608.0314 HANDLE REGOLATOR BLACK	€3.72
003	Image coming soon	3.700.0030 GUN AL55 350bar 45l / min 160Â ° C + sw8 3 / 8M + S7 + M22 (30129100)	€64.28
004	Image coming soon	4.618.0143 HIGH PRESSURE HOSE 5/16 315BAR R2 L=10000 1/2 TWIST.-3/8	€142.39
005	Image coming soon	3.701.0027 Replaced by 3.701.0015 LANCE ZNT L = 600 COVER + SW + ATT.RAP.M22	€25.21
006	Image coming soon	4.608.0540 TUCSON TANK HANDLE S / HOSE HOLE	€36.15
007		4.008.0095 Einhell Tank Cap for RT-HP 1855 TR	€7.41
008	Image coming soon	4.608.0416 BLACK HANDLE X LMX LP	€24.00
009	Image coming soon	4.608.0417 HANDLE PLATE X LMX LP -GRY- RAL.7046 (PANT.430C)	€11.48
010	Image coming soon	7.700.0548 MANUAL TUCSON / TASMAN + CE LAVOR 16L A5 128F (+ REIS inserts)	€4.68

Page 2 View exploded Usually Ships in: 10 BUSYNESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
001	Image coming soon	4.613.0157 LOWER COVER DANUBIO-ONTARIO-LTX-TUCSON	€68.60
002	Image coming soon	5.613.0393 COMPLETE FRAME X TUCSON R.A. ENGINE	€59.21
004	Image coming soon	4.618.0202 PIPE B.P. L = 340 MOT. R.A. FOR TUCSON	€22.20
006	Image coming soon	4.607.0246 AXLE-BAR FOR ONTARIO/DANUBIO	€5.38
007	Image coming soon	3.006.0164 WHEEL D.220x55 HOLE D.15 -GR- RAL.7046	€15.56
008	Image coming soon	3.099.0020 WHEEL LOCKING DIAMETER 150 D.15	€13.46
009	Image coming soon	3.099.1755 D.45 WHEEL COVER STUD X 30060155 -GR- RAL.7016	€1.44
010	Image coming soon	4.608.0454 ELECTRIC CASE X TUCSON	€9.58
011		3.401.0042 ETA 3120-N554-P7T1-W02D-20A MICRO CIRCUIT BREAKER WITH PROTECTION	€45.91
013	Image coming soon	4.608.0477 ELECTRIC BOX COVER X INTERR. SINGLE PHASE TUCSON	€7.61
014	Image coming soon	4.012.0150 CABLE H05VV-F 3X1,5 MT.5,4 F/FSCHUKO PLUG	€29.49

Page 3 View exploded Usually Ships in: 10 BUSYNESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
001	Image coming soon	5.606.0125 MOTOR LW R.A. 220/60 1ph 152x125 WORK LINE	€741.33
003	Image coming soon	4.605.0070 CABLEHOLDER M22	€5.83
004	Image coming soon	4.605.0071 FRONT FLANGE MOTOR D.152 FOR PUMP D.90 WORKED	€55.59
005	Image coming soon	5.702.0072 PUMP LW CL4 150/11 1450 SX W/ IN. W / TS W /GAUGE (X DANUBIO MOT.R.A.)	€354.67

Page 4 View exploded Usually Ships in: 10 BUSYNESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
002	Image coming soon	3.099.0805 RING 61x51x0,4 H.3,5	€1.72
003	Image coming soon	3.001.0066 RADIAL SPHERE BEARING 6305 2RSKBC (25x62x17)	€11.41
004	Image coming soon	5.605.0061 ROTARY SHAFT 90X125 R.A. MONOF. LAV. LINE	€183.63

Page 5 View exploded Usually Ships in: 10 BUSYNESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
001	Image coming soon	5.008.0281 HEAD OTT LWS 1507 C / USC.3 / 8-IN.2,0 ENCLOSED C / TS (DANUBIO MOT.R.A.)	€170.66
002	Image coming soon	5.609.0311 PUMP ASSY KIT LAVOR CL4 D.15 1450rpm 11lt (1508) S / OIL	€180.30
003		3.107.0006 Lavor Ontario 1211LP Pressure Gauge D.40	€26.50

Page 6 View exploded Usually Ships in: 10 BUSYNESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
001	Image coming soon	4.606.0196 HEAD LAVOR LINE 1507	€167.78
003	Image coming soon	4.606.0161 G3/8 CAP	€9.98
004	Image coming soon	4.606.0001 1/4G CAP	€3.36
005	Image coming soon	6.005.0117 Replaced by 6.005.0578 KIT 108LW 6 VALVES * AUTO SUCTION * (COMP.OR) TEST.OTT.'99	€29.49
006	Image coming soon	5.009.0101 CAP VALVE SUCTION DELIVERY-ORMOUNTED	€6.91
007	Image coming soon	5.609.Y154 HOSE ASSEMBLY D.1 C / OR-SPRING L = 7 wire D.0.4-BALL D.5.5	€6.53
008		6.005.0120 Lavor MCHPV 1515LP Kit 111 LW	€28.38
009	Image coming soon	6.005.0290 KIT 265 LW REPAIR BY-PASS LW 18 TS	€50.06
010	Image coming soon	5.609.0106 ASSEMBLY BOX + MICRO + CABLE 2X1.5 PERFORATED CAP TEST.OTT.'99	€39.47
012	Image coming soon	5.609.0153 ASSEMBLY OUTLET 3 / 8G IN. D.2,0 C / OR WORK 18	€9.52
013	Image coming soon	6.605.0089 BUSH KIT D.15 FOR PUMP LP 1507	€36.26
014	Image coming soon	6.605.0088 SEALS KIT A.P. D.15 FOR LP 1507 PUMP	€50.76

Page 7 View exploded Usually Ships in: 10 BUSYNESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
001	Image coming soon	4.605.0096 PUMP BEARING COVER 1808	€7.56
002	Image coming soon	3.200.0219 GASKET OR 44,04X3,53 NBR SH.70	€1.70
003	Image coming soon	3.001.0084 RADIAL SPHERE BEARING 25X62X17	€28.65
004	Image coming soon	4.606.0161 G3/8 CAP	€9.98
005	Image coming soon	4.605.0154C CL4-15 IN-LINE PUMP CASE -N- MACHINED	€76.88
006	Image coming soon	6.605.0180 ALUMINUM CONNECTING RODS KIT FOR LP CL4-15 PUMP	€16.17
007	Image coming soon	3.200.0249 GASKET OR 98.02X3.53 NBR SH.70	€1.66
008	Image coming soon	4.605.0174C POSTER COVER. CRANKCASE CL4-15 BLACK X GUARN.OR	€18.92
009	Image coming soon	3.001.0085 RADIAL BALL BEARING 6304 (20X52X15) HIGH QUALITY	€28.64
010	Image coming soon	3.099.1480 OIL CAP (L=58 STICK)	€3.36
011	Image coming soon	6.605.0090 KIT 3 PISTONS + PIN FOR PUMP LP 1507	€100.32
012	Image coming soon	4.607.0533 PUMP SHAFT IN LINE C = 14.4 MACHINED X 1808	€97.20
013	Image coming soon	6.605.0211 KIT 5 SEEGER D.28	€10.11
014	Image coming soon	6.605.0114 SEEGER KIT D.62	€29.62
015	Image coming soon	3.201.0058 Replaced by 6.005.0306 RING SHAFT SEAL D.25X62X 10 DIN AS	€25.22
018	Image coming soon	6.605.0111 OIL GASKET KIT	€12.20

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner TUCSON 1013LP 220/60 -G- TS SCHUKO PLUG CALIBRATE TO 105-110BAR - LAVOR PROFESSIONAL - 8.671.0016.

Fix Your Pressure Cleaner TUCSON 1013LP. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.

TUCSON 1013LP 220/60 -G- TS SCHUKO - LAVOR PROFESSIONAL 8.671.0016 Pag.1
#	Part Num.	Description
0	R8671X009	TUCSON 1013LP 220/60 4P TS (SP.SCHUKO) B.D.F.
001	4.613.0388	UPPER CASING TUCSON CL4 (R.A. ENGINE) -G- PANT.108C
002	4.608.0314	DANUBE ADJUST KNOB X P80.0394
003	3.700.0030	GUN AL55 350bar 45l / min 160Â ° C + sw8 3 / 8M + S7 + M22 (30129100)
004	4.618.0143	HOSE 5/16 R2 315BAR L = 10000 C / ATT .RAP.1 / 2 TURN.-3/8
005	3.701.0027	Replaced by 3.701.0015 LANCE ZNT L = 600 COVER + SW + ATT.RAP.M22
006	4.608.0540	TUCSON TANK HANDLE S / HOSE HOLE
007	4.008.0095	DETERGENT TANK CAP C / HOLE D.9 -N-
008	4.608.0416	BLACK HANDLE X LMX LP
009	4.608.0417	HANDLE PLATE X LMX LP -GRY- RAL.7046 (PANT.430C)
010	7.700.0548	MANUAL TUCSON / TASMAN + CE LAVOR 16L A5 128F (+ REIS inserts)
017	5.612.0017	NOZZLE KIT 15065 HOSE HOLDER. BRASS X 3/4 NUT
8671X009 - TUCSON 1013LP 220/60 4P TS (SCHUKO PLUG) B.D.F. Pag.2
0	R56010684	MTP. R.A. 220/60 4P HP3,5 SX X COLD (CL4)
001	4.613.0157	LOWER CASING DANUBE-ONTARIO-LTX-TUCSON -N-
002	5.613.0393	COMPLETE FRAME X TUCSON R.A. ENGINE
003	5.601.0684	MTP. R.A. 220/60 4P HP3,5 SX X COLD (CL4)
004	4.618.0202	PIPE B.P. L = 340 MOT. R.A. FOR TUCSON
006	4.607.0246	AXLE L = 385 FOR ONTARIO-DANUBE
007	3.006.0164	WHEEL D.220x55 HOLE D.15 -GR- RAL.7046
008	3.099.0020	LOCK WHEEL D.150 D.15
009	3.099.1755	D.45 WHEEL COVER STUD X 30060155 -GR- RAL.7016
010	4.608.0454	ELECTRIC CASE X TUCSON
011	3.401.0042	ETA 3120-N554-P7T1-W02D-20A MICRO CIRCUIT BREAKER WITH PROTECTION
013	4.608.0477	ELECTRIC BOX COVER X INTERR. SINGLE PHASE TUCSON
014	4.012.0150	CORD H05VV-F 3X1,5 MT.5,4 SP.SCHUKO SPLASH F / F
56010684 - MTP. R.A. 220/60 4P HP3,5 SX X COLD (CL4) Pag.3
0	R56060125	MOTOR LW R.A. 220/60 1ph 152x125 LAVOR LINE
0	R57020072	PUMP LW CL4 150/11 1450 SX C / IN. C / TS W/ GAUGE (X DANUBIO MOT.R.A.)
001	5.606.0125	MOTOR LW R.A. 220/60 1ph 152x125 WORK LINE
003	4.605.0070	CORD ARMOR FOR MOT. R.A. M22
004	4.605.0071	FRONT FLANGE MOTOR D.152 FOR PUMP D.90 WORKED
005	5.702.0072	PUMP LW CL4 150/11 1450 SX W/ IN. W / TS W /GAUGE (X DANUBIO MOT.R.A.)
56060125 - MOTORE LW R.A. 220/60 1ph 152x125 LAVOR LINEA Pag.4
001	5.602.0051	HOUSING R.A. 220/60 4P 1ph D.152 H125
002	3.099.0805	COMPENSATION RING 61X51X 0,4 H.3,5 -62d-
003	3.001.0066	RADIAL BALL BEARING 6305 2RS (25X62X17) (KBC) X MOT.EL.
004	5.605.0061	ROTARY SHAFT 90X125 R.A. MONOF. LAV. LINE
57020072 - PUMP LW CL4 150/11 1450 SX W/IN. W/TS W/GAUGE (X DANUBIO MOT.R.A.) Pag.5
0	R50080281	HEAD LWS 1507 C / USC.3 / 8-IN.2,0 ENCLOSED C / TS (DANUBIO MOT.R.A.)
0	R56090311	PUMP ASSY KIT LAVOR CL4 D.15 1450rpm 11lt (1508) S / OIL
001	5.008.0281	HEAD OTT LWS 1507 C / USC.3 / 8-IN.2,0 ENCLOSED C / TS (DANUBIO MOT.R.A.)
002	5.609.0311	PUMP ASSY KIT LAVOR CL4 D.15 1450rpm 11lt (1508) S / OIL
003	3.107.0006	GAUGE D.40 0/300 BAR 1/8 GLYCERINE
50080281 - BRASS HEAD LWS 1507 C/USC.3/8-IN.2,0 W/TS (DANUBIO MOT.R.A.) Pag.6
001	4.606.0196	HEAD LAVOR LINE 1507
003	4.606.0161	CAP T.E. 3/8 GAS
004	4.606.0001	CAP T.E. 1/4 GAS
005	6.005.0117	Replaced by 6.005.0578 KIT 108LW 6 VALVES * AUTO SUCTION * (COMP.OR) TEST.OTT.'99
006	5.009.0101	CAP, SUCTION / DELIVERY VALVE WITH MOUNTED OR
007	5.609.Y154	HOSE ASSEMBLY D.1 C / OR-SPRING L = 7 wire D.0.4-BALL D.5.5
008	6.005.0120	KIT 111 LW PRESSURE REGULATOR BRASS HEAD OCT. '99
009	6.005.0290	KIT 265 LW REPAIR BY-PASS LW 18 TS
010	5.609.0106	ASSEMBLY BOX + MICRO + CABLE 2X1.5 PERFORATED CAP TEST.OTT.'99
012	5.609.0153	ASSEMBLY OUTLET 3 / 8G IN. D.2,0 C / OR WORK 18
013	6.605.0089	BUSH KIT D.15 FOR PUMP LP 1507
014	6.605.0088	SEALS KIT A.P. D.15 FOR LP 1507 PUMP
56090311 - KIT PUMP ASSY LAVOR CL4 D.15 1450rpm 11lt (1508) S/OLIO Pag.7
001	4.605.0096	PUMP BEARING COVER 1808
002	3.200.0219	GASKET OR 44,04X3,53 NBR SH.70
003	3.001.0084	RADIAL BALL BEARING 6305 (25X62X17)
004	4.606.0161	CAP T.E. 3/8 GAS
005	4.605.0154C	CL4-15 IN-LINE PUMP CASE -N- MACHINED
006	6.605.0180	ALUMINUM CONNECTING RODS KIT FOR LP CL4-15 PUMP
007	3.200.0249	GASKET OR 98.02X3.53 NBR SH.70
008	4.605.0174C	POSTER COVER. CRANKCASE CL4-15 BLACK X GUARN.OR
009	3.001.0085	RADIAL BALL BEARING 6304 (20X52X15) HIGH QUALITY
010	3.099.1480	OIL FILLING CAP C / HOSE AND BREATHER (ROD L = 58)
011	6.605.0090	KIT 3 PISTONS + PIN FOR PUMP LP 1507
012	4.607.0533	PUMP SHAFT IN LINE C = 14.4 MACHINED X 1808
013	6.605.0211	KIT 5 SEEGER D.28
014	6.605.0114	KIT 3 SEEGER D.62
015	3.201.0058	Replaced by 6.005.0306 RING SHAFT SEAL D.25X62X 10 DIN AS
018	6.605.0111	OIL SEALS KIT D.15 FOR PUMP LP 1507-1808

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Reference Lavor TUCSON 1013LP 8.671.0016

Available 12 Items

Data sheet

Machine Type: Pressure Washer
SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

Condition New

Download

Diagram TUCSON 1013LP

Download (1.28MB)

Lavorwash S.p.A. SKU: 3.700.0036

Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor

Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor Genuine Replacement part Lavor, Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Advanced 1108 - XTR 1007 - Rio 1108 - Mek 1108 - Missouri 1310. Part suitable for the...

AVAILABLE €30.90

Details

Lavorwash S.p.A. SKU: 3.701.0015

700 mm Lance 1/8 "F High/Low Pressure for Pressure Washers Lavor

700 mm Lance 1/8 "F High/Low Pressure for Pressure Washers Lavor Genuine Replacement part Lavor, 700 mm Lance 1/8 "F High/Low Pressure for Pressure washers XTR 1007 - Rio 1108 - Mek 1108...

Usually Ships in: 7/10 Business Days Approx. €37.13

Details

Lavorwash S.p.A. SKU: 6.005.0120

Lavor MCHPV 1515LP Kit 111 LW

Lavor MCHPV 1515LP Kit 111 LW Genuine replacement part Lavor, Kit 111 LW Pressure Regulator For Brass Head Test.Oct.'99 for Pressure Cleaner MCHPV 1515LP 400-415/SC1 - 8.626.0002. Part for the following products:...

on 10 Business Days Approx. €28.38

Details

Lavorwash S.p.A. SKU: 3.107.0006

Lavor Ontario 1211LP Pressure Gauge D.40

Lavor Ontario 1211LP Pressure Gauge D.40 Genuine replacement part Lavor, Pressure Gauge D.40 0/300 BAR 1/8" Glycerine for Pressure Cleaner Ontario 1211LP - 86590033. Part for the following products: - ONTARIO 1211LP 220/60 -G- LWS...

on 10 Business Days Approx. €26.50

Details

Einhell Italia s.r.l. SKU: 4.008.0095

Einhell Tank Cap for RT-HP 1855 TR

Einhell Tank Cap for Pressure Cleaner RT-HP 1855 TR Original replacement part Lavorwash, Black Detergent Tank Cap With Hole D.9 for Pressure Cleaners EINHELL RT-HP 1855 TR - Lawor TUCSON 1013LP. Part for the following products:...

Usually Ships in: 10 Business Days Approx. €7.41

Details

Lavorwash S.p.A. SKU: 3.401.0042

ETA 3120-N554-P7T1-W02D-20A MICRO CIRCUIT BREAKER WITH PROTECTION

Original Lavorwash S.p.A. spare part - ETA 3120-N554-P7T1-W02D-20A MICRO CIRCUIT BREAKER WITH PROTECTION. Part number: 3.401.0042 Product Overview The ETA Micro Circuit Breaker (Part Number: 3.401.0042) is an original Lavorwash...

AVAILABLE €45.91

Details

Comments (0)

No customer reviews for the moment.

Cart (0)

Subcategories

Subcategories

Subcategories

Power Tools Spare Parts

Garden Spare Parts

Air Compressor Spare Parts

Protezione & Edilizia

Impianti & Utensili

Casa & Giardino

Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Lavor Original Parts for Pressure Cleaner TUCSON 1013LP

Data sheet

Specific References

Download

Diagram TUCSON 1013LP

You might also like

Products

News

Notes

Our company
