Lavorwash S.p.A.

Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601

SKU: Lavor EAGLE 24 - 80300601
€9.39
VAT included

Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner EAGLE 24 230/50 -G-TS+AVVOLG.+REG.PRESS.-EU - 8.030.0601.

Fix Your Pressure Cleaner EAGLE 24. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

Cold Water High Pressure Cleaner EAGLE 24
Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601
  • Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601
  • Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601
  • Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601
Lavorwash S.p.A.

Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601

SKU: Lavor EAGLE 24 - 80300601 Condition: New
€9.39
VAT included

Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner EAGLE 24 230/50 -G-TS+AVVOLG.+REG.PRESS.-EU - 8.030.0601.

Fix Your Pressure Cleaner EAGLE 24. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

Cold Water High Pressure Cleaner EAGLE 24
settings 105 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
105 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
001
 photo_cameraImage coming soon 5.012.0052 SCREWS SET FOR EAGLE LANCE HOLDER HANDLE €9.49
002
 photo_cameraImage coming soon 4.008.0280 LANCE HOLDER FOR SPACE €5.05
003
 photo_cameraImage coming soon 4.008.0494 EAGLE BLOW HANDLE LMX €30.05
004
 photo_cameraImage coming soon 4.007.0114 NOZZLE CLEANING PIN €1.65
005
 photo_cameraImage coming soon 4.008.0281 ADJUSTING KNOB €1.72
006
 photo_cameraImage coming soon 4.006.0038 TOP 100 FAIRING BLOCKAGE RING NUT €3.14
008
 photo_cameraImage coming soon 4.012.0150 CABLE H05VV-F 3X1,5 MT.5,4 F/FSCHUKO PLUG €29.49
009
 photo_cameraImage coming soon 4.008.0506 BLACK LANCE HOLDER GLASS FOR EAGLE €1.72
010
 Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24 4.008.0278 Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24 €4.26
011
 photo_cameraImage coming soon 3.099.0122 TANK CAP LMX FOR EAGLE €14.80
012
 photo_cameraImage coming soon 4.013.0321 YELLOW UPPER COVER EAGLE (PANT.108C) €26.75
013
 photo_cameraImage coming soon 3.002.0138 SCREW TCEI M6X20 ZNT UNI 5931 €1.72
014
 photo_cameraImage coming soon 3.003.0011 HEXAGONAL NUT M6 MEDIUM UNI 5588 CL8ZNT €1.72
015
 photo_cameraImage coming soon 3.004.0007 FLAT WASHER D.6X18 Sp.2 UNI6593 ZNT €1.72
016
 photo_cameraImage coming soon 4.008.0535 TRANSPARENT HOSE D.6X9 L.430 CUT 45' €1.72
017
 photo_cameraImage coming soon 3.099.0127 BLACK WHEEL COVER D.250-200 FOR EAGLE/SPARK €14.80
018
 photo_cameraImage coming soon 3.006.0031 EAGLE WHEEL D.250 HOLE 20 €32.26
019
 photo_cameraImage coming soon 4.007.0224 EAGLE WHEEL AXLE D.20 €6.59
020
 photo_cameraImage coming soon 4.007.0287 FIXING CLAMP €7.98
021
 photo_cameraImage coming soon 4.008.0514 BLACK EAGLE FOOT FOR MOTOR- PUMP SUPPORT €3.37
022
 photo_cameraImage coming soon 5.611.0089 LOWER BLACK COVER EAGLE €113.30
023
 Hose Reel Handle + Screw for Pressure Washer Lavor EAGLE 24 5.012.0060 Hose Reel Handle + Screw for Pressure Washer Lavor EAGLE 24 €10.72
024
 photo_cameraImage coming soon 3.002.0112 CROSS HEAD -TORX SCREW 3,9x25HI-LO ZNT €1.72
025
 Winding Reel Handle Side for Pressure Washer Lavor EAGLE 24 4.008.0517 Winding Reel Handle Side for Pressure Washer Lavor EAGLE 24 €15.55
026
 photo_cameraImage coming soon 3.099.0158 3/8 BUSH €3.32
027
 Winding Reel Inlet Side for Pressure Washer Lavor EAGLE 24 4.008.0516 Winding Reel Inlet Side for Pressure Washer Lavor EAGLE 24 €14.34
028
 photo_cameraImage coming soon 4.606.0098 ROTATING BOLT €11.76
030
 Gasket O-Ring 9.92X2.62 for Pressure Washer Lavor FKX 1018 3.200.0018 Gasket O-Ring 9.92X2.62 for Pressure Washer Lavor FKX 1018 €1.66
031
 photo_cameraImage coming soon 4.606.0097 ROTATING COUPLUING BODY €12.31
032
 photo_cameraImage coming soon 3.099.0144 SEEGER RING FOR SHAFT €1.68
033
 photo_cameraImage coming soon 4.606.0096 COUPLING FOR HOSE WINDING €3.45
034
 photo_cameraImage coming soon 4.018.0046 1/4 145bar L=600 GIR.D.15 -M14 €25.72
036
 photo_cameraImage coming soon 5.609.0073 BOLT ASSY FOR HOSE WINDING €48.98
038
 photo_cameraImage coming soon 3.100.X005 QUICK COUPLING 3/4 BLACK WITH GASKET €1.50
039
 HP HOSE 1/4" 160 BAR 8Mts for Pressure Washer Lavor EAGLE 24 4.018.0052 HP HOSE 1/4" 160 BAR 8Mts for Pressure Washer Lavor EAGLE 24 €40.32
040
 photo_cameraImage coming soon 6.001.0038 Substituted by 6.001.0085 S'99 GUN METAL EXTENSION €56.95
041
 photo_cameraImage coming soon 6.002.0183 SY'99 LANCE 1,05 A/B (GREY) €38.58
044
 photo_cameraImage coming soon 4.008.0277 FIX PAD CABLE HOLDER €1.72
045
 photo_cameraImage coming soon 3.099.0019 BLOCK WHEEL D.250x55 D.20 €1.72
046
 photo_cameraImage coming soon 4.008.0622 UPPER BLACK COVER FOR EAGLE (2600W) €3.32
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
001
 photo_cameraImage coming soon 5.009.0213 EXT SWITCH WITH PROTECTION 12(10) €6.72
002
 photo_cameraImage coming soon 3.406.0004 CABLE TERMINAL PG.11 €1.72
003
 photo_cameraImage coming soon 3.406.0011 BUSHING FOR PG.11 CABLE TERMINA €1.72
004
 photo_cameraImage coming soon 3.002.0135 SELF-TAPPING CROSS HEAD SCREW2,9X13 UNI 6954 ZNT €1.68
005
 Capacitor 45mF 450V for Pressurte Washer Lavor BEST 24 3.404.0016 Capacitor 45mF 450V for Pressurte Washer Lavor BEST 24 €29.19
006
 photo_cameraImage coming soon 4.008.0618 LOWER RUBBER GASKET FOR ELECTICAL BOX €5.17
007
 photo_cameraImage coming soon 4.008.0583 MOTOR FAN COVER '96 WITHOUT GRILL €15.13
008
 photo_cameraImage coming soon 3.099.0049 LOCKING RING D.23 FAN FB80 €14.80
009
 photo_cameraImage coming soon 4.008.0092 FAN FB80 WITH HOLE D.16,5 (PARTNER) €5.11
011
 Radial Ball Bearing 6203RS for Pressure Cleaner Lavor Missouri 3.001.0020 Radial Ball Bearing 6203RS for Pressure Cleaner Lavor Missouri €13.71
012
 photo_cameraImage coming soon 5.005.0029 ROTOR SHAFT 125'96 TAPERED H.110 230/50 €94.96
013
 photo_cameraImage coming soon 3.002.0115 SCREW TC M5X35 SWAGEFORM ZNT €1.72
014
 photo_cameraImage coming soon 4.005.0183 FRONT FLANGE MOTOR D.125 H.110FOR PARTNER €45.80
015
 Oil Seal 20-35-6-6.5 for Washer Lavor GIANT 24 3.201.0001 Oil Seal 20-35-6-6.5 for Washer Lavor GIANT 24 €2.76
016
 photo_cameraImage coming soon 3.001.0031 ANTERIOR RADIAL FOR CASING 20X52X15 - 6304 €6.01
017
 photo_cameraImage coming soon 4.005.0125 CONICAL PLATE INC. 9.16 CORS = 7,9-7,83 ROLLER BEARING €7.52
018
 Lavor Disk As for KARJET PROFI130 3.001.0003 Lavor Disk As for KARJET PROFI130 €3.33
019
 Lavor Needle Roller Cage for EQ18 3.001.0025 Lavor Needle Roller Cage for EQ18 €3.48
020
 Lavor Thrust Shoe for LP 20 EHR 4.007.0001 Lavor Thrust Shoe for LP 20 EHR €5.83
021
 Lavor Retaining Ring for EAGLE 24 5.009.0452 Lavor Retaining Ring for EAGLE 24 €8.85
022
 Gasket O-Ring 85x2.5 for Pressure Washer Lavor NPX 1500 3.200.0014 Gasket O-Ring 85x2.5 for Pressure Washer Lavor NPX 1500 €3.27
023
 photo_cameraImage coming soon 4.007.0283 NEW CODE 4.007.0025 RECALL PISTON SPRING D.14- 12 €1.57
024
 photo_cameraImage coming soon 5.009.0459 Substituted by 5.009.0516 ASSEMBLY MICRO+CABLE TOTAL STOP PARTNER USA/EU €25.50
025
 photo_cameraImage coming soon 4.006.0270 TS COUPLING €9.92
026
 photo_cameraImage coming soon 4.006.0269 BRASS SPACER FOR SPRING €14.70
027
 photo_cameraImage coming soon 4.007.0284 RECALL SPRING FOR ROD €9.37
028
 photo_cameraImage coming soon 3.200.0073 OR GASKET €1.57
029
 photo_cameraImage coming soon 4.008.0782 CONTROL ROD FOR MICRO €7.53
030
 photo_cameraImage coming soon 4.007.0305 SCREW M3M25 A2-70 €1.68
031
 photo_cameraImage coming soon 4.008.0779 SEAL SEAT WITH SPACER €2.83
032
 photo_cameraImage coming soon 3.200.0113 OR GASKET OR 15.08X2.62 €1.63
033
 photo_cameraImage coming soon 4.007.0285 SPRING €13.73
034
 photo_cameraImage coming soon 4.006.0268 BRASS PISTON D.11 €4.98
035
 photo_cameraImage coming soon 3.200.0059 O-RING 7.66 X1.78 €1.63
036
 photo_cameraImage coming soon 4.608.0153 ANTIEXTRUSION O-RING D.8X11X1.5 (FOR 2031 O-RING) €3.77
037
 photo_cameraImage coming soon 4.008.0780 PISTON SEAT AND UNLOADER VALVE FOR NEW COMPENSATED VALVE €5.27
038
 photo_cameraImage coming soon 3.200.0118 OR GASKET 14X1.78 NBR SH.90 €1.63
039
 photo_cameraImage coming soon 3.200.0029 O-RING 18,72X2,62 €1.63
042
 photo_cameraImage coming soon 5.009.0503 RUBBER HOLDER WITH DET. SUCTION M10 WITH ORING €9.28
044
 photo_cameraImage coming soon 3.005.0001 BALL INOX 420 DIAM.5 (accuracy grade G 500) €1.72
045
 photo_cameraImage coming soon 4.007.0014 VALVE SPRING DETERGENT CHECK De4,5 / 6 L = 7 WIRE D.0,3 €2.50
048
 photo_cameraImage coming soon 5.009.0495 UNLOADER VALVE ASSEMBLY PLAST.+ OR €14.96
049
 photo_cameraImage coming soon 4.607.0105 VALVE SPRING CHECK D.4.8-6 L = 20 WIRE 0.6 STAINLESS STEEL €1.65
051
 photo_cameraImage coming soon 5.009.0523 D.1,8 INJECTORS ASSEMBLY WITH OR €6.62
052
 photo_cameraImage coming soon 3.200.0017 O-RING GASKET 9,13X2,62 REF.109 €1.66
053
 Gasket O-Ring 11,1x1,78 for Pressure Washer Lavor GIANT 24 3.200.0013 Gasket O-Ring 11,1x1,78 for Pressure Washer Lavor GIANT 24 €1.66
054
 photo_cameraImage coming soon 3.201.0014 OIL SEAL RING D.12X20X5/7 €5.38
055
 photo_cameraImage coming soon 3.002.0094 SCREW TCEI M6X30 ZNT €1.72
056
 photo_cameraImage coming soon 5.009.0101 CAP VALVE SUCTION DELIVERY-ORMOUNTED €6.91
057
 Delivery Suction Valve for Pressure Washer Lavor FKX 1018 5.009.0005 Delivery Suction Valve for Pressure Washer Lavor FKX 1018 €9.23
058
 Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018 3.200.0019 Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018 €1.70
059
 photo_cameraImage coming soon 4.006.0109 TAPERED 1/8 CAP €7.67
062
 Gasket O-Ring 9.92X2.62 for Pressure Washer Lavor FKX 1018 3.200.0018 Gasket O-Ring 9.92X2.62 for Pressure Washer Lavor FKX 1018 €1.66
064
 photo_cameraImage coming soon 4.008.0657 OIL SPACER D.12 €1.68
065
 photo_cameraImage coming soon 4.006.0251 PIECE FOR SUPPORT PARTNER D.12 €10.21
066
 photo_cameraImage coming soon 4.008.0695 ANTI-EXTRUSION RING 12x18x1 FOR PARTNER D.12 €1.68
067
 photo_cameraImage coming soon 3.201.0020 WATER SEAL 12X18X5 €3.39
068
 Complete Suction Valve for Pressure Washer Lavor FKX 1018 5.009.0015 Complete Suction Valve for Pressure Washer Lavor FKX 1018 €5.78
069
 photo_cameraImage coming soon 4.005.0187 PARTNER HEAD '01 FOR PISTONS DIAM. 12 €16.43
070
 photo_cameraImage coming soon 3.002.0130 HEXAGON SOCKET HEAD CAP SCREWM6X70 CL.12,9 UNI5931 DACROMET €1.68
071
 Inlet Water Filter Conical for Pressurte Washer Lavor BEST 24 4.008.0031 Inlet Water Filter Conical for Pressurte Washer Lavor BEST 24 €2.07
072
 photo_cameraImage coming soon 4.008.0376 COVER FOR ELECTRICAL BOX €7.53
074
 photo_cameraImage coming soon 4.008.0356 ELECTRICAL BOX €7.53
082
 photo_cameraImage coming soon 5.006.0157 MOTOR'99 D.125 H110 230/50 2P X PT. €288.36
083
 Body Guide Assembly for Pressure Washer Lavor EAGLE 24 5.007.0183 Body Guide Assembly for Pressure Washer Lavor EAGLE 24 €123.14 Not available for order
084
 photo_cameraImage coming soon 5.008.0160 PARTNER HEAD D.12 €40.03

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Original Parts for Pressure Cleaner EAGLE 24 - 8.030.0601

Fix Your Cold Water High Pressure Cleaner EAGLE 24 230/50 -G-TS+AVVOLG.+REG.PRESS.-EU - 8.030.0601. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Lavor EAGLE 24 - 80300601

80300601-2 - IDRO EAGLE 24 230/50 -G-TS+AVVOLG.+REG.PRESS.-EU Pag.1
# Part Num. Description
001 5.012.0052 SCREWS SET FOR EAGLE LANCE HOLDER HANDLE
002 4.008.0280 LANCE HOLDER FOR SPACE
003 4.008.0494 EAGLE BLOW HANDLE LMX
004 4.007.0114 NOZZLE CLEANING PIN
005 4.008.0281 ADJUSTING KNOB
006 4.006.0038 TOP 100 FAIRING BLOCKAGE RING NUT
008 4.012.0150 CABLE H05VV-F 3X1,5 MT.5,4 F/F SCHUKO PLUG
009 4.008.0506 BLACK LANCE HOLDER GLASS FOR EAGLE
010 4.008.0278 OUTLET CAP
011 3.099.0122 TANK CAP LMX FOR EAGLE
012 4.013.0321 YELLOW UPPER COVER EAGLE (PANT.108C)
013 3.002.0138 SCREW TCEI M6X20 ZNT UNI 5931
014 3.003.0011 NUT M6 UNI 5588
015 3.004.0007 PLAIN WASHER D.6X18X2 UNI6593
016 4.008.0535 TRANSPARENT HOSE D.6X9 L.430 CUT 45'
017 3.099.0127 BLACK WHEEL COVER D.250-200 FOR EAGLE/SPARK
018 3.006.0031 EAGLE WHEEL D.250 HOLE 20
019 4.007.0224 EAGLE WHEEL AXLE D.20
020 4.007.0287 FIXING CLAMP
021 4.008.0514 BLACK EAGLE FOOT FOR MOTOR- PUMP SUPPORT
022 5.611.0089 LOWER BLACK COVER EAGLE
023 5.012.0060 HANDLE + SCREW
024 3.002.0112 CROSS HEAD -TORX SCREW 3,9x25 HI-LO ZNT
025 4.008.0517 SUBSTITUITED BY 4.008.1216 WINDING WHEEL
026 3.099.0158 3/8 BUSH
027 4.008.0516 SUBSTITUITED BY 4.008.1215 WINDING WHEEL- INLET
028 4.606.0098 ROTATING BOLT
030 3.200.0018 OR-RING GASKET 9.92X2.62 SHORE 90
031 4.606.0097 ROTATING COUPLUING BODY
032 3.099.0144 SEEGER RING FOR SHAFT
033 4.606.0096 COUPLING FOR HOSE WINDING
034 4.018.0046 1/4 145bar L=600 GIR.D.15 -M14
036 5.609.0073 BOLT ASSY FOR HOSE WINDING
038 3.100.X005 QUICK COUPLING 3/4 BLACK WITH GASKET
039 4.018.0052 HOSE 1/4 160 BAR L=8000 1/4F.
040 6.001.0038 S'99 GUN METAL EXTENSION
041 6.002.0183 SY'99 LANCE 1,05 A/B (GREY)
044 4.008.0277 CABLE HOOK
045 3.099.0019 BLOCK WHEEL D.250x55 D.20
046 4.008.0622 UPPER BLACK COVER FOR EAGLE (2600W)
50010486-1 - MOTOPOMPA PT'02 230_50 9'16 125h110 REG.IN.1,8 TS (EAGLE) Pag.2
001 5.009.0213 SWITCH WITH PROTECTION 12(10)
002 3.406.0004 CABLE TERMINAL PG.11
003 3.406.0011 BUSHING FOR PG.11 CABLE TERMINAL
004 3.002.0135 SELF-TAPPING CROSS HEAD SCREW 2,9X13 UNI 6954 ZNT
005 3.404.0016 CAPACITOR 45mF 450V D.45X90 WITHOUT CABLE FASTON M
006 4.008.0618 LOWER RUBBER GASKET FOR ELECTICAL BOX
007 4.008.0583 MOTOR FAN COVER '96 WITHOUT GRILL
008 3.099.0049 LOCKING RING D.23 FAN FB80
009 4.008.0092 FAN FB80 WITH HOLE D.16,5 (PARTNER)
010 5.002.0121 Substituted by 5.006.0197 FRAME '96 D125 H110 230/50 2P 2800W
011 3.001.0020 RADIAL BEARING FOR MOTOR SHAFT 17X40X12 6203 2RS
012 5.005.0029 ROTOR SHAFT 125'96 TAPERED H.110
013 3.002.0115 SCREW TC M5X35 SWAGEFORM ZNT
014 4.005.0183 Substituted by 5.009.0395 FRONT FLANGE MOTOR D.125 H.110 FOR PARTNER
015 3.201.0001 OIL SEAL 20/35/6/6,5 BABSL
016 3.001.0031 ANTERIOR RADIAL FOR CASING 20X 52X15 - 6304
017 4.005.0125 CONIC PLATE
018 3.001.0003 DISK AS 4565
019 3.001.0025 NEEDLE-ROLLER CAGE Axk4565 -STTEL-
020 4.007.0001 BEARING WASHER D.65X30X6 (C10Pb) FINISHED
021 5.009.0452 ASSEMBLY RETAINING RING D.29/PISTON D.12
022 3.200.0014 O-RING GASKET 85X2,5 NITRILIC
023 4.007.0283 Substituted by 4.007.0025 RECALL PISTON SPRING D.14- 12
024 5.009.0459 Substituted by 5.009.0516 ASSEMBLY MICRO+CABLE TOTAL STOP PARTNER USA/EU
025 4.006.0270 TS COUPLING
026 4.006.0269 BRASS SPACER FOR SPRING
027 4.007.0284 RECALL SPRING FOR ROD
028 3.200.0073 Substituted by 3.200.0021 OR GASKET
029 4.008.0782 CONTROL ROD FOR MICRO
030 4.007.0305 Substituted by 3.002.0267 SCREW M3M25 A2-70
031 4.008.0779 SEAL SEAT WITH SPACER
032 3.200.0113 OR GASKET OR 15.08X2.62
033 4.007.0285 SPRING Di6.6 De10.2 L=23.8 wire D.1.8
034 4.006.0268 BRASS PISTON D.11
035 3.200.0059 O-RING 7.66 X1.78
036 4.608.0153 Substituted by 4.608.0326 ANTIEXTRUSION O-RING D.8X11X1.5 (FOR 2031 O-RING)
037 4.008.0780 PISTON SEAT AND UNLOADER VALVE FOR NEW COMPENSATED VALVE
038 3.200.0118 OR GASKET 14X1.78 NBR SH.90
039 3.200.0029 O-RING 18,72X2,62
040 5.009.0278 PRESSURE REGULATOR
042 5.009.0503 RUBBER HOLDER WITH DET. SUCTION M10 WITH ORING
044 3.005.0001 BALL INOX 420 DIAM.5 DEGREE OF ACCURACY G 500
045 4.007.0014 DETERG.STOP VALVE SPRING 4X8 ESP.3
046 4.005.0209 BODY GUIDE D.12
048 5.009.0495 UNLOADER VALVE ASSEMBLY PLAST. + OR
049 4.607.0105 Substituted by 4.007.0324 STOP VALVE SPRING D.6X20
051 5.009.0523 Substituted by 5.009.0560 D.1,8 INJECTORS ASSEMBLY WITH OR
052 3.200.0017 O-RING GASKET 9,13X2,62 REF.109
053 3.200.0013 O-RING 11,1X1,78
054 3.201.0014 OIL SEAL RING D.12X20X5/7
055 3.002.0094 SCREW TCEI M6X30 ZNT
056 5.009.0101 CAP VALVE SUCTION DELIVERY-OR MOUNTED
057 5.009.0005 DELIVERY SUCTION VALVE LAVOR
058 3.200.0019 O-RING 12.4X1.78 SH.90
059 4.006.0109 TAPERED 1/8 CAP
062 3.200.0018 OR-RING GASKET 9.92X2.62 SHORE 90
064 4.008.0657 OIL SPACER D.12
065 4.006.0251 PIECE FOR SUPPORT PARTNER D.12
066 4.008.0695 ANTI-EXTRUSION RING 12x18x1 FOR PARTNER D.12
067 3.201.0020 WATER SEAL 12X18X5
068 5.009.0015 COMPLETE SUCTION VALVE
069 4.005.0187 PARTNER HEAD '01 FOR PISTONS DIAM. 12
070 3.002.0130 HEXAGON SOCKET HEAD CAP SCREW M6X70 CL.12,9 UNI5931 DACROMET
071 4.008.0031 INLET WATER FILTER H2O D.16 CONICAL
072 4.008.0376 COVER FOR ELECTRICAL BOX
074 4.008.0356 ELECTRICAL BOX
082 5.006.0157 MOTOR'99 D.125 H110 230/50 2P X PT.
083 5.007.0183 Substituted by 5.007.0149 BODY GUIDE
084 5.008.0160 PARTNER HEAD D.12
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor EAGLE 24 - 80300601
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

New

Download

Drawing EAGLE 24 - 8.030.0601

Drawing EAGLE 24 - 8.030.0601

Download (619.8KB)

You might also like

Oil Seal 20-35-6-6.5 for Washer Lavor GIANT 24
Lavorwash S.p.A. SKU: 3.201.0001
Oil Seal 20-35-6-6.5 for Washer Lavor GIANT 24
Oil Seal 20-35-6-6.5 for Washer Lavor GIANT 24 Original replacement part Lavor, Oil Seal 20/35/6/6,5 BABS L for Pressure Washers GIANT 24 - GIANT 28 - TEMPESTA 24 - TORMENTA 28 - VERTIGO 28 PLUS. Part for the following products: -...
AVAILABLE €2.76
Details
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.107.0004
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500
Pressure Gauge for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Pressure Gauge D.50 0/315 BAR - 1/4 Rear thread + Bracket (ref 129 939 81) for Pressure Washers NPX 1400 - NPX...
on 7/10 Business Days Approx. €33.35
Details
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 4.608.0083
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500
PVC Fan for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, PVC Fan D.180 Lowered Hub for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - ...
Last items in stock €30.42
Details
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 5.009.0340
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500
Quick Coupling for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Quick Coupling Assy + O-Ring + Ring Nut for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor...
Last items in stock €15.06
Details
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 4.608.0019
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500
Thermostate Knob for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, Black Thermostate Knob 3079/1t for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor NPX 1400...
on 10 Business Days Approx €10.03
Details
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.100.0043
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500
Rotating Quick Coupling for Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, 3/8 M Rotating Quick Coupling for Pressure Washers NPX 1400 - NPX 1500. Part for the following products: - Pressure Washer Lavor NPX 1400 -...
AVAILABLE €17.59
Details
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500
Lavorwash S.p.A. SKU: 5.009.0136
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500
Hose Coupling Omnia for Pressure Washers Lavor NPX 1500 Genuine replacement part  Lavor , Hose Coupling Omnia Complete with O-Rings for  Pressure Washer NPX 1500  - 8.605.0049. Part for the following products: -  Pressure Washer Lavor...
on 10 Business Days Approx €3.27
Details
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018
Lavorwash S.p.A. SKU: 3.200.0019
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018
Gasket O-Ring 12.4X1.78 for Pressure Washer Lavor FKX 1018 Genuine replacement part Lavor, Gasket O-Ring 12.4X1.78 SHORE 90 for Pressure Washer Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 8052001. Part for the following...
AVAILABLE €1.70
Details
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500
Lavorwash S.p.A. SKU: 3.200.0003
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500
O-Ring 25.12x1.78 for Pressure Washers Lavor NPX 1400 - NPX 1500 Genuine replacement part Lavor, O-Ring Gasket 25.12x1.78 REF.2100 for Pressure Washers  NPX 1400  8.605.0048 - NPX 1500 8.605.0049. Part for the following products: -...
AVAILABLE €1.70
Details
Diesel Filter Unit for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.611.0043
Diesel Filter Unit for Pressure Washer Lavor Missouri
Diesel Filter Unit for Pressure Washer Lavor Missouri Genuine part Lavor, Diesel Filter Unit JOLLY 4 '93 / MISSOURI / MEK for Pressure Washers Missouri - NPX 1400 - NPX 1500. Part for the following...
Usually Ships in: 10 Business Days Approx. €15.19
Details
Winding Reel Inlet Side for Pressure Washer Lavor EAGLE 24
Lavorwash S.p.A. SKU: 4.008.0516
Winding Reel Inlet Side for Pressure Washer Lavor EAGLE 24
Winding Reel Inlet Side for Pressure Washer Lavor EAGLE 24 Genuine replacement part Lavor, Winding Reel Inlet Side (VERSION 2010) for Pressure Washer EAGLE 24 - 8.030.0807  - 8.030.0901 - YUKON 1310 - 8.618.0001 Part for the following...
AVAILABLE €14.34
Details
Winding Reel Handle Side for Pressure Washer Lavor EAGLE 24
Lavorwash S.p.A. SKU: 4.008.0517
Winding Reel Handle Side for Pressure Washer Lavor EAGLE 24
Winding Reel Handle Side for Pressure Washer Lavor EAGLE 24 Genuine replacement part Lavor, Winding Reel Handle Side (VERSION 2010) for Pressure Washer EAGLE 24 - 8.030.0807  - 8.030.0901 - YUKON 1310 - 8.618.0001 Part for the...
AVAILABLE €15.55
Details
Micro Assy + Cable Total Stop for Lavor YUKON 1310 - MACH 20 - EAGLE 24
Lavorwash S.p.A. SKU: 5.009.0516
Micro Assy + Cable Total Stop for Lavor YUKON 1310
Micro Assy + Cable Total Stop PARTNER USA/EU for Lavor YUKON 1310 Genuine part Lavor, Micro Assy + Cable Total Stop PARTNER USA/EU for Pressure Washers YUKON 1310 - MISSOURI - 86190001 - HOT130 Part for the following products: -...
on 7/10 Business Days Approx €28.02
Details
HP HOSE 1/4" 160 BAR 8Mts for Pressure Washer Lavor EAGLE 24
Lavorwash S.p.A. SKU: 4.018.0052
HP HOSE 1/4" 160 BAR 8Mts for Pressure Washer Lavor EAGLE 24
HP HOSE 1/4" 160 BAR 8Mts for Pressure Washer Lavor EAGLE 24 Genuine replacement part Lavor, HP HOSE 1/4" 160 BAR L. 8Mts 1/4F. for Pressure Washers EAGLE 24. Part for the following products: -  Pressure...
Usually Ships in: 10 Business Days Approx. €40.32
Details
Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24
Lavorwash S.p.A. SKU: 4.008.0278
Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24
Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24 Genuine replacement part Lavor, Inlet/Outlet Cover for Spark Version PARTNER for Pressure Washers EAGLE 24. Part for the following products: -  Pressure Washer EAGLE 24 -...
on 7/10 Business Days Approx €4.26
Details
Lavor Retaining Ring for EAGLE 24
Lavorwash S.p.A. SKU: 5.009.0452
Lavor Retaining Ring for EAGLE 24
Lavor Retaining Ring for Pressure Cleaner EAGLE 24 Original replacement part Lavorwash, Assembly Retaining Ring D.29/Piston D.12 for Pressure Cleaners EAGLE 24 - MACH 20. Part for the following products: -  Pressure Cleaner...
Usually Ships in: 10 Business Days Approx. €8.85
Details
Lavor Disk As for KARJET PROFI130
Lavorwash S.p.A. SKU: 3.001.0003
Lavor Disk As for KARJET PROFI130
Lavor Disk As for Pressure Cleaner KARJET PROFI130 Original replacement part Lavorwash, Disk As for Pressure Cleaners KARJET PROFI130 - FKX 1018. Part for the following products: -  Pressure Cleaner Lavor KARJET PROFI130 -...
Usually Ships in: 10 Business Days Approx. €3.33
Details
Lavor Bearing Washer for LP 20 EHR
Lavorwash S.p.A. SKU: 4.007.0001
Lavor Thrust Shoe for LP 20 EHR
Lavor Thrust Shoe for Pressure Cleaner LP 20 EHR Original replacement part Lavorwash, Thrust Shoe D.65x30x6 (C10pb) Finished for Pressure Cleaners LP 20 EHR - FKX 1018. Part for the following products: - ...
Usually Ships in: 10 Business Days Approx. €5.83
Details
Lavor Piston Recall Spring for FKX 1018
Lavorwash S.p.A. SKU: 4.007.0025
Lavor Piston Recall Spring for FKX 1018
Lavor Piston Recall Spring for Pressure Cleaner FKX 1018 Original replacement part Lavorwash, Piston Recall Spring D.14- 12 for Pressure Cleaners FKX 1018 - MACH 20. Part for the following products: - ...
Usually Ships in: 10 Business Days Approx. €2.12
Details
Lavor Needle Roller Cage for EQ18
Lavorwash S.p.A. SKU: 3.001.0025
Lavor Needle Roller Cage for EQ18
Lavor Needle Roller Cage for Pressure Cleaner EQ18 Original replacement part Lavorwash, Needle Roller Cage Type Axk4565 -STEEL- for Pressure Cleaners EQ18 - MISSOURI. Part for the following products: - ...
Usually Ships in: 10 Business Days Approx. €3.48
Details
Lavor Recall Spring for Pressure Cleaner FKX 1018
Lavorwash S.p.A. SKU: 00030-00517 ex 4.007.0014
Lavor Recall Spring for Pressure Cleaner FKX 1018
Lavor Recall Spring for Pressure Cleaner FKX 1018 Original replacement part Lavorwash, Detergent Stop Valve Spring De4, 5/6 L=7 FILO D.0,3 INOX for Pressure Cleaners FKX 1018 - NPX1400. Part for the following products:...
Usually Ships in: 10 Business Days Approx. €2.57
Details
Comments (0)
