Lavorwash S.p.A.

Lavor Original Parts for Pressure Cleaner Fury Plus 120

SKU: Lavor FURY PLUS 120 81090011C
€147.06
VAT included

Lavor Original Parts for Pressure Cleaner Fury Plus 120

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 81090011C - IDRO FURY PLUS 120 220-240~50/60 -G- TS EU 2L +SP.ROT. -LAVOR

Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Lavor Original Parts for Pressure Cleaner Fury Plus 120
  • Lavor Original Parts for Pressure Cleaner Fury Plus 120
  • Lavor Original Parts for Pressure Cleaner Fury Plus 120
  • Lavor Original Parts for Pressure Cleaner Fury Plus 120
  • Lavor Original Parts for Pressure Cleaner Fury Plus 120
  • Lavor Original Parts for Pressure Cleaner Fury Plus 120
  • Lavor Original Parts for Pressure Cleaner Fury Plus 120
Lavorwash S.p.A.

Lavor Original Parts for Pressure Cleaner Fury Plus 120

SKU: Lavor FURY PLUS 120 81090011C Condition: New
€147.06
VAT included

Lavor Original Parts for Pressure Cleaner Fury Plus 120

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 81090011C - IDRO FURY PLUS 120 220-240~50/60 -G- TS EU 2L +SP.ROT. -LAVOR

Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings 36 spare parts
description 5 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:: LAVOR S/N START WITH (8. ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
36 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
002
 photo_cameraImage coming soon 4.008.1186 AIR CONVEYOR FOR U76 (LIGHT) €134.59
007
 photo_cameraImage coming soon 5.001.0807C EXT MTP PT'03EVO 230/50 TSC-THERMAL 5'30 (7645PF-KC) SCHUKO PLUG €150.17
010
 photo_cameraImage coming soon 6.001.0106 Substituted by 6.001.0073 GUN S'16 WITH INTEGRAL QUICK JOINT €29.04
011
 H.P. Hose 4.018.0094 4 m for Quick Coupling Trigger Gun Lavor S’09 4.018.0094 H.P. Hose 4.018.0094 4 m for Quick Coupling Trigger Gun Lavor S’09 €26.58
014
 Head Nozzle Jet Adjustable Needle-Fan Ø 0.90 6.002.0636 6.002.0636 Head Nozzle Jet Adjustable Needle-Fan Ø 0.90 6.002.0636 €9.83
021
 photo_cameraImage coming soon 6.002.0259 Substituted by 6.002.0358 FOAM SPRAYER WITH TRANSPARENTTANK €13.09
022
 photo_cameraImage coming soon 3.100.0082C BLACK QUICK COUPLING INLET CONNECTOR (THREAD=9.5) €1.60
023
 photo_cameraImage coming soon 5.011.0270 ASSEMBLY BLACK WHEEL/YELLOW WHEEL COVER FAST/ONE (PANT.108C) €3.71
024
 photo_cameraImage coming soon 4.008.1862 GREY BACK BASE FOR TROLLEY ONE/SMART RAL.7016 (PANT.432C) €21.56
025
 photo_cameraImage coming soon 4.008.1863 GREY FRONT BASE FOR TROLLEY ONE/SMART RAL.7016 (PANT.432C) €21.56
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon R50090972C BODY GUIDE W/TSC-SCHUKO PLUG NO SUCTION +HEAD PT'03EVO €22.19
001
 Motor Assembly for Pressure Cleaner Lavor X-Ray Plus 140 5.009.0979 Motor Assembly for Pressure Cleaner Lavor X-Ray Plus 140 €87.31
002
 Kit 283 LW Needle Bearing for Pressure Washer Lavor ENDURO 145 6.005.0311 Kit 283 LW Needle Bearing for Pressure Washer Lavor ENDURO 145 €5.50
003
 Pin 10x70 for Pressure Washer Lavor Predator 160 WPS 4.007.0205 Pin 10x70 for Pressure Washer Lavor Predator 160 WPS €7.68
004
 Plate Assembly with Crown for Pressure Washer Lavor ENDURO 145 5.009.0726 Plate Assembly with Crown for Pressure Washer Lavor ENDURO 145 €6.90
005
 photo_cameraImage coming soon 4.007.0328 THRUST BEARING 35X55X12 PT'03 €15.13
006
 photo_cameraImage coming soon 5.009.0972C BODY GUIDE W/TSC-SCHUKO PLUG NO SUCTION +HEAD PT'03EVO €55.71
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon R50070264C BODY GUIDE PT'03EVO W/TSC-SCHUKO PLUG WITHOUT SUCTION €55.71
photo_cameraImage coming soon R50080261 PT'03EVO HEAD D.12 €25.22
001
 photo_cameraImage coming soon 5.007.0264C BODY GUIDE PT'03EVO W/TSC-SCHUKO PLUG WITHOUT SUCTION €33.89
002
 Head PT'03 EVO D.12 for Pressure Washer Lavor ENDURO 145 5.008.0261 Head PT'03 EVO D.12 for Pressure Washer Lavor ENDURO 145 €28.99
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
001
 photo_cameraImage coming soon 4.005.0299 PISTON BODY GUIDE PT'03EVO €22.92
002
 photo_cameraImage coming soon 5.009.X966 ASSIEME TS PT'03 Spring 13KG C/MICRO €21.50
002
 photo_cameraImage coming soon 6.005.0590 KIT COMPLETE TS PT'03 (AH) €24.00
003
 Kit 167 LW 3 Pistons + Springs for Pressurte Washer Lavor BEST 24 6.005.0181 Kit 167 LW 3 Pistons + Springs for Pressurte Washer Lavor BEST 24 €25.98
004
 Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 6.005.0226 Kit 209 O-Ring for PT'03 for Pressurte Washer Lavor BEST 24 €11.43
005
 Kit 256 Check Valve for Washer Lavor Predator 160 6.005.0281 Kit 256 Check Valve for Washer Lavor Predator 160 €15.93
007
 photo_cameraImage coming soon 4.012.0174C CABLE H05VV-F 2X1 MT.5,4 F/F SCHUKO PLUG W/FASTON COVER €21.99
008
 photo_cameraImage coming soon 4.008.1876 Substituted by 6.005.0590 MICRO SWITCH HOLDER COVER PT'03 (AH) €22.65
009
 photo_cameraImage coming soon 3.401.0232 Substituted by 6.005.0590 SWITCH + MICRO X TS (AH) €22.65
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
001
 photo_cameraImage coming soon 4.005.0298 PT''03EVO PARTNER HEAD €28.92
002
 Kit 124 Water Seal Partner for Pressurte Washer Lavor BEST 24 6.005.0133 Kit 124 Water Seal Partner for Pressurte Washer Lavor BEST 24 €14.54
003
 photo_cameraImage coming soon 6.005.0380 Sostituito da 6.005.0282 KIT 348 SPACER FOR WATER SEAL €13.17
003
 Kit LW Intake Delivery Valves for High Pressure Washer ARMY 110 6.005.0588 Kit LW Intake Delivery Valves for High Pressure Washer ARMY 110 €27.72
004
 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 6.005.0079 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 €14.50
005
 Kit 358 LW Intake Delivery Valves for High Pressure Washer ARMY 110 6.005.0392 Kit 358 LW Intake Delivery Valves for High Pressure Washer ARMY 110 €23.00

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Original Parts for Pressure Cleaner Fury Plus 120

Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 81090011C - IDRO FURY PLUS 120 220-240~50/60 -G- TS EU 2L +SP.ROT. -LAVOR

Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Lavor FURY PLUS 120 81090011C

81090011C - IDRO FURY PLUS 120 220-240~50/60 -G- TS EU 2L +SP.ROT. Pag.1
# Part Num. Description
0 R50010807C MOTOP.SP.PT'03EVO 230/50 C/TERM.-TSC-SP.SCHUKO 5'30 (7645PF-KC)
001 5.011.0271 ASSIEME CAREN.-G- +COP.ANT.-GR- RAL.7016 ONE-R C/TAMP. -LAVOR- -B-
002 4.008.1186 AIR CONVEYOR FOR U76 (LIGHT)
003 4.008.1866 MANICO FAST -GR- RAL.7016 (PANT.432C)
004 4.008.1861 PORTACCESSORI ONE -GR- RAL.7016 (PANT.432C)
005 4.013.0778 CARENATURA POST. ONE -GR- RAL.7016 (PANT.432C)
006 7.100.2035 MANUAL ONE/SMART + CE LAVOR
007 5.001.0807C EXT MTP PT'03EVO 230/50 TSC-THERMAL 5'30 (7645PF-KC) SCHUKO PLUG
010 6.001.0106 Substituted by 6.001.0073 GUN S'16 WITH INTEGRAL QUICK JOINT
011 4.018.0094 EXT HOSE 1/4 180BAR L=4000 M22x1,5D.15-RAPID FIX W/SPIRAL SLEEV
014 6.002.0636 EXT NOZZLE HEAD LANCE S'12 D.0,95(ORANGE) ADJUST.FAN JET W/QUI
021 6.002.0259 Substituted by 6.002.0358 FOAM SPRAYER WITH TRANSPARENTTANK
022 3.100.0082C BLACK QUICK COUPLING INLET CONNECTOR (THREAD=9.5)
023 5.011.0270 ASSIEME RUOTA + BORCHIA -G- FAST/ONE (PANT.108C)
024 4.008.1862 BASE CARRELLO ONE/SMART POST. -GR- RAL.7016 (PANT.432C)
025 4.008.1863 BASE CARRELLO ONE/SMART ANT. -GR- RAL.7016 (PANT.432C)
50010807C - MOTOP. SP.PT'03EVO 230/50 C/TERM.-TSC-SP.SCHUKO 5'30 Pag.2
0 R50090972C GRUPPO CORPO GUIDA C/TSC-SP.SCHUKO M.13KG S/ASP. +TESTATA (PT'03EVO)
001 5.009.0979 7645PF-AL KC MOTOR 230/50 W/CAPACITOR-THERMAL
002 6.005.0311 THRUST RING KIT (PT'03 U76)
003 4.007.0205 PIN 10X70
004 5.009.0726 5'30 WOBBLE PLATE ASSEMBLY W/CROWN Z 62 (PT'03)
005 4.007.0328 THRUST BEARING 35X55X12 PT'03T
006 5.009.0972C BODY GUIDE W/TSC-SCHUKO PLUG NO SUCTION +HEAD PT'03EVO
50090972C - BODY GUIDE ASSY C_TSC-SP.SCHUKO M.13KG S_ASP. + HEAD Pag.3
0 R50070264C CORPO GUIDA PT'03EVO C/TSC S/ASP. MOLLA 13KG C/CAVO SP.SCHUKO
0 R50080261 TESTATA PT'03EVO D.12
001 5.007.0264C BODY GUIDE PT'03EVO W/TSC-SCHUKO PLUG WITHOUT SUCTION
002 5.008.0261 PT'03EVO HEAD D.12
50070264C - BODY GUIDE PT'03EVO C_TSC S_ASP. SPRING 13KG CABLE PLUG Pag.4
001 4.005.0299 PISTON BODY GUIDE PT'03EVO
002 5.009.1036 ASSIEME TS PT'03 MOLLA 13KG (AH)
002 5.009.X966 ASSIEME TS PT'03 MOLLA 13KG C/MICRO
002 6.005.0590 KIT ASSIEME TS PT'03 MOLLA 13KG C/MICRO (AH)
003 6.005.0181 KIT 167 LW PISTON
004 6.005.0226 KIT 209 O-RING
005 6.005.0281 KIT 256 VALVE GUIDE RID. W/OSUCTION PT'03C
007 4.012.0174C CABLE H05VV-F 2X1 MT.5,4 F/F SCHUKO PLUG W/FASTON COVER
008 4.008.1876 Substituted by 6.005.0590 COPERCHIO SCATOLA PORTA MICRO PT'03 (AH)
009 3.401.0232 Substituted by 6.005.0590 INTERRUTTORE + MICRO X TS (AH)
50080261 - HEAD PT'03EVO D.12 Pag.5
001 4.005.0298 PT''03EVO PARTNER HEAD
002 6.005.0133 KIT 124 O-RING WATER SEAL PARTNER D.12
003 6.005.0380 KIT 348 SPACER FOR WATER SEAL
003 6.005.0588 Substituted by 6.005.0282 KIT LW VALV.ASP./MAND.+TAPPI PT' 03EVO
004 6.005.0079 KIT 79 LW OIL SEALS
005 6.005.0392 KIT 358 LW HEAD VALVE KIT +CAPS PT'03EVO

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Lavor FURY PLUS 120 81090011C
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS

Specific References

New

Download

Drawing Lavor Fury Plus 120

Drawing Lavor Fury Plus 120

Download (798.96KB)
