Lavorwash S.p.A.

Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP

SKU: ALASKA 1409XP - 86690001
€18.60
VAT included

Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP

Lavor original spare parts for to replace broken parts for to fix Cold Water Pressure Cleaner 86690001 - IDRO ALASKA 1409XP 230/50 -G- TS LAVOR PRO SP.SCHUKO.

Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP
  • Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP
  • Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP
  • Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP
  • Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP
  • Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP
Lavorwash S.p.A.

Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP

SKU: ALASKA 1409XP - 86690001 Condition: New
€18.60
VAT included

Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP

Lavor original spare parts for to replace broken parts for to fix Cold Water Pressure Cleaner 86690001 - IDRO ALASKA 1409XP 230/50 -G- TS LAVOR PRO SP.SCHUKO.

Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings 51 spare parts
description 4 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Shipped on: 10/15 Business Days Approx

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
51 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon R56010590 MOTORPUMP OMINA '15 230/50 2PD.125 H110 13° TS €16.06
1
 photo_cameraImage coming soon 4.008.1725 YELLOW FRONT COVER FOR GIANT/ALASKA €16.38
2
 photo_cameraImage coming soon 4.008.1728 TANK FOR GIANT/ALASKA (x motorD.125) €35.23
2
 photo_cameraImage coming soon 4.608.0457 GREY FRONT COVER FOR ALASKA €17.18
3
 photo_cameraImage coming soon 4.008.1728 TANK FOR GIANT/ALASKA (x motorD.125) €35.23
6
 photo_cameraImage coming soon 4.008.1432 BLACK SWITCH KNOB €3.23
7
 photo_cameraImage coming soon 4.008.1726 ELECTRICAL BOX COVER FOR GIANT/ALASKA €2.96
8
 photo_cameraImage coming soon 3.401.0225 ROTARY SWITCH TWO GEARS BIPOLAR 16A (0-1) W/PIN 15 €6.34
9
 photo_cameraImage coming soon 4.608.0458 GREY LANCE HOLDER FOR ALASKA RAL.7016 (PANT.432C) €3.55
10
 photo_cameraImage coming soon 5.601.0590 MOTORPUMP OMINA '15 230/50 2PD.125 H110 13° TS €466.67
11
 photo_cameraImage coming soon 4.613.0374 BLACK FRONT SIDE CABINET ALASKA €45.58
12
 photo_cameraImage coming soon 5.011.0277 ALASKA REAR HOUSING WITH WHEELS €80.06
13
 photo_cameraImage coming soon 4.008.1724 BLACK ACCESSORY HOLDER FOR GIANT/ALASKA €8.92
14
 photo_cameraImage coming soon 4.008.1021 MOTOR CONVEYOR €13.22
15
 photo_cameraImage coming soon 4.605.0173 EXTENSION M22F-M22M (ALASKA) €17.14
16
 Capacitor 55mF 450V for Pressurte Washer Lavor GIANT 24 3.404.0095 Capacitor 55mF 450V for Pressurte Washer Lavor GIANT 24 €20.13
17
 photo_cameraImage coming soon 4.012.0150 CABLE H05VV-F 3X1,5 MT.5,4 F/FSCHUKO PLUG €29.49
19
 photo_cameraImage coming soon 4.008.1521 BLACK PLUG FOR TANK -RAL.9011-(80007138) €3.25
20
 Trigger Gun BIT105 3000 PSI for Pressure Washer ALASKA 1409XP 6.001.0143 Trigger Gun BIT105 3000 PSI for Pressure Washer ALASKA 1409XP €40.39
21
 High Pression Hose for Pressure Washer ALASKA 1409XP 4.018.0003 High Pression Hose for Pressure Washer ALASKA 1409XP €67.49
22
 Lance for Pressure Washer ALASKA 1409XP 6.002.0322 Lance for Pressure Washer ALASKA 1409XP €39.34
26
 Set of 5 Nozzles for High Pressure Lance Lavor 5.012.0478 Set of 5 Nozzles for High Pressure Lance Lavor €39.62
28
 Quick Coupling 3/4 F with Filter for High Pressure Washers Lavor 3.100.0405 Quick Coupling 3/4 F with Filter for High Pressure Washers Lavor €7.83
30
 photo_cameraImage coming soon 4.008.1756 GREY SHORT HANDLE FOR GIANT/ALASKA (RAL.7016) €18.19
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon R50080331 TESTATA OMNIA'15 DIST.TENUTA ALTI C/TS-IN.2,0-USC.M22-INGR.3/4 €6.70
1
 photo_cameraImage coming soon 6.005.0251 168 LW RING+FAN €13.32
2
 photo_cameraImage coming soon 5.602.0074 CARCASSA LWM 230-240/50 2P D.125 H.110 €215.91
3
 Radial Ball Bearing 6203RS for Pressure Cleaner Lavor Missouri 3.001.0020 Radial Ball Bearing 6203RS for Pressure Cleaner Lavor Missouri €13.71
4
 photo_cameraImage coming soon 5.605.0075 ROTOR D.65 H110 FOR OMNIA14 €97.20
5
 photo_cameraImage coming soon 4.605.0161 D.125 H110 MOTOR FLANGE OMNIA'15 €15.91
6
 photo_cameraImage coming soon 3.201.0019 OIL SEAL RING D.25X40X7 DOUBLELIP €14.52
7
 photo_cameraImage coming soon 3.001.0084 RADIAL SPHERE BEARING 25X62X17 €28.65
8
 photo_cameraImage coming soon 4.605.0152 PLATE 13' €10.53
9
 photo_cameraImage coming soon 6.005.0340 KIT 312 LW THRUST SHOE + THRUST RING €13.32
10
 photo_cameraImage coming soon 6.005.0584 KIT PISTONS + SPRINGS €49.00
11
 photo_cameraImage coming soon 3.200.0130 GASKET OR 67x2,50 NBR SH.70 €1.62
12
 photo_cameraImage coming soon 4.605.0163 BODY GUIDE D.12 HIGH SPACER THERMIC 2015 €17.18
13
 Oil Seal Kit for Pressure Washer Lavor Independent 2800 6.605.0126 Oil Seal Kit for Pressure Washer Lavor Independent 2800 €29.42
14
 photo_cameraImage coming soon 4.008.1686 HIGH OIL SPACER D.12 €1.44
15
 photo_cameraImage coming soon 5.008.0331 TESTATA OMNIA'15 DIST.TENUTA ALTI C/TS-IN.2,0-USC.M22-INGR.3/4 €123.80
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon R50080293 OMNIA'15 BRASS HEAD HIGH SUCTION SEAL W/TS-M22 OUTLET-3/4"IN €140.52
1
 photo_cameraImage coming soon 5.008.0293 OMNIA'15 BRASS HEAD HIGH SUCTION SEAL W/TS-M22 OUTLET-3/4"IN €143.34
2
 photo_cameraImage coming soon 4.006.0109 TAPERED 1/8 CAP €7.67
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.606.0273 BRASS HEAD HORIZ. TH 6.5 (OMNIA 12) WAT. SEAL h5 FOR CAP VAL €104.64
2
 photo_cameraImage coming soon 4.605.0116 INLET CONNECTION 3/4M-3/8M WITH BRASS TREATMENT (TH.6.5) €6.79
3
 photo_cameraImage coming soon 6.005.0581 KIT LW INIETT.2 -VALV.RIT. TESTATA TPBH '10 €21.38
4
 photo_cameraImage coming soon 5.609.0154C HOSE HOLDER DETERGENT SUCTIONKIT WITH OR AND SPRING €9.55
5
 Kit 6 Intake Valves for Pressure Washer Lavor ALASKA 1409XP 6.005.0565 Kit 6 Intake Valves for Pressure Washer Lavor ALASKA 1409XP €12.26
6
 photo_cameraImage coming soon 6.005.0582 KIT BOCC.SEC.TEN.C/O-RING X DISTANZIALI TENUTA ALTI THERMIC 2015 €5.43
7
 photo_cameraImage coming soon 6.005.0597 KIT ANELLI TENUTA ACQUA PT'03 + ANTIESTR. €10.65
8
 Lavor ALASKA 1409XP Kit By Pass 6.005.0583 Lavor ALASKA 1409XP Kit By Pass €61.77
9
 photo_cameraImage coming soon 5.609.0281 ASSEMBLED BOX WITH MICRO+ 2X1,5 CABLE WITH PLUG HOLE FOR OMN €49.11

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Lavor Pro Parts for Pressure Cleaner Idro Alaska 1409XP

Lavor original spare parts for to replace broken parts for to fix Cold Water Pressure Cleaner 86690001 - IDRO ALASKA 1409XP 230/50 -G- TS LAVOR PRO SP.SCHUKO.

In the following tables, look for the spare part and its respective code.
ALASKA 1409XP - 86690001

86690001 - IDRO ALASKA 1409XP 230/50 -G- TS LAVOR PRO SP.SCHUKO pag.1
# Part Num. Description
0 R56010590 MOTOPOMPA OMNIA '15 D.12 230/50 2P 125 h110 13gr. TS
1 4.008.1725 YELLOW FRONT COVER FOR GIANT/ALASKA
2 4.008.1728 TANK FOR GIANT/ALASKA (x motorD.125)
2 4.608.0457 GREY FRONT COVER FOR ALASKA
3 4.008.1728 TANK FOR GIANT/ALASKA (x motorD.125)
6 4.008.1432 BLACK SWITCH KNOB
7 4.008.1726 ELECTRICAL BOX COVER FOR GIANT/ALASKA
8 3.401.0225 ROTARY SWITCH TWO GEARS BIPOLAR 16A (0-1) W/PIN 15
9 4.6080.458. LANCE HOLDER FOR ALASKA
10 5.601.0590 MOTORPUMP OMINA '15 230/50 2PD.125 H110 13° TS
11 4.613.0374 BLACK FRONT SIDE CABINET ALASKA
12 5.011.0277 CARENATURA POSTERIORE ALASKA -NERO- C/RUOTE D.200 -GR- RAL.7046
13 4.008.1724 BLACK ACCESSORY HOLDER FOR GIANT/ALASKA
14 4.008.1021 MOTOR CONVEYOR
15 4.605.0173 EXTENSION M22F-M22M (ALASKA)
16 3.404.0095 CAPACITOR 55mF 450V D.50X94 W/FASTON M
17 4.012.0150 CABLE H05VV-F 3X1,5 MT.5,4 F/FSCHUKO PLUG
18 7.700.0463 MANUAL ALASKA/HYPER K/HURON LAVOR
19 4.008.1521 BLACK PLUG FOR TANK -RAL.9011-(80007138)
20 6.001.0143 PISTOLA BIT105 3000PSI C/RACC. G1/4M - M22X1,5F
21 4.018.0003 HOSE 1/4 R1 210BAR L.8000 1/4F.G+ D.15 RUBBER
22 6.002.0322 METAL LANCE NOZZLE HOLDER QUICK COUPLING-M22
26 5.012.0478 5 NOZZLES KIT OF D.1,15 FOR QUICK JOINT GR.0-15-25-40FOAM
28 3.100.0405 TRANSPARENT QUICK COUPLING INLET CONNECTOR WITH INSPECTIONAB
30 4.008.1756 GREY SHORT HANDLE FOR GIANT/ALASKA (RAL.7016)
86690001 - IDRO ALASKA 1409XP 230/50 -G- TS LAVOR PRO SP.SCHUKO PAG.2
0 R50080331 TESTATA OMNIA'15 DIST.TENUTA ALTI C/TS-IN.2,0-USC.M22-INGR.3/4
1 6.005.0251 KIT 168 LW RING+FAN
2 5.602.0074 CARCASSA LWM 230-240/50 2P D.125 H.110
3 3.001.0020 RADIAL BEARING FOR POSTERIOR FLANGE 17X40X12 6203 2RS
4 5.605.0075 ROTOR D.65 H110 FOR OMNIA14
5 4.605.0161 D.125 H110 MOTOR FLANGE OMNIA'15
6 3.201.0019 OIL SEAL RING D.25X40X7 DOUBLELIP
7 3.001.0084 RADIAL SPHERE BEARING 25X62X17
8 4.605.0152 PLATE 13'
9 6.005.0340 KIT 312 LW THRUST SHOE + THRUST RING
10 6.005.0584 KIT 3 PISTONI +MOLLE OMNIA'15
11 3.200.0130 12 GASKET OR 67x2,50 NBR SH.70
12 4.605.0163 BODY GUIDE D.12 HIGH SPACER THERMIC 2015
13 6.605.0126 OIL SEAL RING D.12X20X6 16 VSOKC4
14 4.008.1686 HIGH OIL SPACER D.12
15 5.008.0331 TESTATA OMNIA'15 DIST.TENUTA ALTI C/TS-IN.2,0-USC.M22-INGR.3/4
86690001 - IDRO ALASKA 1409XP 230/50 -G- TS LAVOR PRO SP.SCHUKO PAG.3
0 R50080293 TESTATA OMNIA'15 OTT. C/IN.2,0-TS - USC. M22-INGR.3/4 DIST.TENUTA ALTI
1 5.008.0293 OMNIA'15 BRASS HEAD HIGH SUCTION SEAL W/TS-M22 OUTLET-3/4"IN
2 4.006.0109 TAPERED 1/8 CAP
86690001 - IDRO ALASKA 1409XP 230/50 -G- TS LAVOR PRO SP.SCHUKO PAG.4
1 4.606.0.273 BRASS HEAD HORIZ. TH 6.5 (OMNIA 12) WAT. SEAL h5 FOR CAP VAL
2 4.605.0116 INLET CONNECTION 3/4M-3/8M WITH BRASS TREATMENT (TH.6.5)
3 6.005.0581 KIT LW INIETT.2 -VALV.RIT. TESTATA TPBH '10
4 5.609.0154C HOSE HOLDER DETERGENT SUCTIONKIT WITH OR AND SPRING
5 6.005.0565 KIT 6 SUCTION VALVE WITH BRASS VALVE SEATS+THREAD CAPS PT'03
6 6.005.0582 KIT BOCC.SEC.TEN.C/O-RING X DISTANZIALI TENUTA ALTI THERMIC 2015
7 6.005.0597 KIT ANELLI TENUTA ACQUA PT'03 + ANTIESTR.
8 6.005.0583 KIT BY PASS (OMNIA'15) C/TS
9 5.609.0281 ASSEMBLED BOX WITH MICRO+ 2X1,5 CABLE WITH PLUG HOLE FOR OMN
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
ALASKA 1409XP - 86690001
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Drawing Lavor Alaska 1409XP

Drawing Lavor Alaska 1409XP

Download (780.44KB)

You might also like

High Pression Hose for Pressure Washer ALASKA 1409XP
Lavorwash S.p.A. SKU: 4.018.0003
High Pression Hose for Pressure Washer ALASKA 1409XP
High Pression Hose for Pressure Washer ALASKA 1409XP Genuine Part Lavor, High Pression Hose R1 1/4 210BAR L = 8m 1/4F F - M22x1,5 for Washers ALASKA 1409XP - ADVANCED 1108. Part suitable...
AVAILABLE €67.49
Details
Lance for Pressure Washer ALASKA 1409XP
Lavorwash S.p.A. SKU: 6.002.0322
Lance for Pressure Washer ALASKA 1409XP
Lance for Pressure Washer ALASKA 1409XP Genuine Part Lavor, Lance L=430 S/Nozzle Holder with Quick Coupling for Nozzles - M22 for Pressure Washer ALASKA 1409XP 230/50 -G- TS LAVOR PRO. Part suitable for the following high pressure...
AVAILABLE €39.34
Details
Capacitor 55mF 450V for Pressurte Washer Lavor GIANT 24
Lavorwash S.p.A. SKU: 3.404.0095
Capacitor 55mF 450V for Pressurte Washer Lavor GIANT 24
Capacitor 55mF 450V for Pressurte Washer Lavor GIANT 24 Original replacement part Lavor, Capacitor 55mF 450V D.50x94 F/M per Pressure Washers GIANT 24 - GIANT 28 - TEMPESTA 24 - TEMPESTA 28. Part for the following products: - 81050002...
AVAILABLE €20.13
Details
Radial Ball Bearing 6203RS for Pressure Cleaner Lavor Missouri
Lavorwash S.p.A. SKU: 3.001.0020
Radial Ball Bearing 6203RS for Pressure Cleaner Lavor Missouri
Radial Ball Bearing 6203RS for Pressure Cleaner Lavor Missouri Genuine part Lavor, Radial Ball Bearing 6203RS for Pressure Cleaners MISSOURI - Giant 24 - Giant 28 - Tempesta 24 - Tormenta 28. Part for the following products: -...
on 7/10 Business Days Approx €13.71
Details
Oil Seal Kitfor Pressure Washer Lavor Independent 2800
Lavorwash S.p.A. SKU: 6.605.0126
Oil Seal Kit for Pressure Washer Lavor Independent 2800
Oil Seal Kit for Pressure Washer Lavor Independent 2800 Genuine replacement part Lavor, Oil Seal Kit for Petrol Pressure Washer Independent 2800. Part for the following products: -  Petrol Pressure...
on 10 Business Days Approx. €29.42
Details
Lavor ALASKA 1409XP Kit By Pass
Lavorwash S.p.A. SKU: 6.005.0583
Lavor ALASKA 1409XP Kit By Pass
Lavor ALASKA 1409XP Kit By Pass (OMNIA'15) with Total Stop Genuine Part Lavor, Kit By Pass (OMNIA'15) with Total Stop for Washers ALASKA 1409XP - ADVANCED 1108. Part suitable for the following high pressure washers: -...
Usually Ships in: 10 Business Days Approx. €61.77
Details
Comments (0)
