FASA Pressure Cleaner KAIMAN-R Parts

SKU: 8.675.0010
€0.11
VAT included

FASA Original Parts for Pressure Cleaner KAIMAN-R

Fix Your Hot Water High Pressure Cleaner 8.675.0010 - Pressure Washer KAIMAN-R 1310 230/50 -BLU- SP.SCHUKO -FASA-. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

FASA Pressure Cleaner KAIMAN-R Parts
  • New
  • Out-of-Stock
  • FASA Pressure Cleaner KAIMAN-R Parts
  • FASA KAIMAN-R Drawing
  • FASA KAIMAN-R Drawing - 1
  • FASA KAIMAN-R Drawing - 2
  • FASA KAIMAN-R Drawing - 3
  • FASA KAIMAN-R Drawing - 4
  • FASA KAIMAN-R Drawing - 5
  • FASA KAIMAN-R Drawing - 6
  • FASA KAIMAN-R Drawing - 7
  • FASA KAIMAN-R Drawing - 8
  • FASA KAIMAN-R Drawing - 9
  • FASA KAIMAN-R Drawing - 10
  • FASA KAIMAN-R Drawing - 11
  • FASA KAIMAN-R Drawing - 12
  • FASA KAIMAN-R Drawing - 13
  • FASA KAIMAN-R Drawing - 14
Lavorwash S.p.A.

FASA Pressure Cleaner KAIMAN-R Parts

SKU: 8.675.0010 Condition: New
€0.11
VAT included

FASA Original Parts for Pressure Cleaner KAIMAN-R

Fix Your Hot Water High Pressure Cleaner 8.675.0010 - Pressure Washer KAIMAN-R 1310 230/50 -BLU- SP.SCHUKO -FASA-. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 117 Spare parts
description 15 exploded views
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

SHIPPING IN: Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR: LAVOR S/N START WITH (8. ) and have 8 DIGITS
Machine Type: Pressure Washer
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
117 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.613.0468 DARWIN UPPER FAIRING -BLUE-RAL 5015 W/LANCE UPPER HOOKS €77.78
2
 photo_cameraImage coming soon 5.611.0329 DARWIN HANDLE ASSEMBLY Lavorwash for pressure washer €28.16
3
 photo_cameraImage coming soon 7.700.0658 DARWIN/AUCKLAND LAVOR MANUAL 21L A5 183F Lavorwash for pressure washer €6.61
4
 Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor 3.700.0036 Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor €33.90
5
 photo_cameraImage coming soon 4.618.0049 HOSE 1/4 R1 210BAR L.8000 3/8"F €55.11
6
 photo_cameraImage coming soon 3.714.0190 LANCE L.700 COATED +NOZZLE.+QUICK COUPLING M22 Lavorwash for pressure washer €46.19
Page 2 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3.555.0904 D50 LOBED HANDWHEEL M8X35 MALE Lavorwash for pressure washer €5.34
2
 photo_cameraImage coming soon 3.103.0048 HIGH PRESSURE NOZZLE 15035 1/8M (C25035) €15.72
3
 Quick Coupling 3/4F for High Pressure Washers Lavor 3.100.0082 Quick Coupling 3/4F for High Pressure Washers Lavor €1.63
4
 photo_cameraImage coming soon 4.607.0046 STAINLESS STEEL FILTER DIAM.20 ASP. CONNECTOR €3.36
5
 photo_cameraImage coming soon 5.611.0316 EXTERNAL DETERGENT SUCTION KIT DARWIN Lavorwash for pressure washer €2.92
Page 3 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Capacitor 55mF 450V for Pressurte Washer Lavor GIANT 24 3.404.0095 Capacitor 55mF 450V for Pressurte Washer Lavor GIANT 24 €19.52
2
 photo_cameraImage coming soon 3.107.0030 PRESSURE GAUGE D.50 ATC G1/4' 0-250BAR+SUP 10(18160159) Lavorwash for pressure washer €36.03
3
 photo_cameraImage coming soon 4.607.1141 NEW SCOUT PRESSURE GAUGE SUPPORT Lavorwash for pressure washer €0.00 Not available for order
4
 photo_cameraImage coming soon 4.618.0264 PRESSURE GAUGE HOSE 2X400 630BAR 1/4 F W/SEAL-1/4 F CURVED Lavorwash for pressure washer €32.05
5
 photo_cameraImage coming soon 3.099.2057 THUMBSCREW G3/4X17 F PA6 BLACK Lavorwash for pressure washer €1.59
6
 photo_cameraImage coming soon 5.611.0314 ELECTRICAL CONTROL PANEL ASSEMBLY 230V DARWIN Lavorwash for pressure washer €173.81
7
 photo_cameraImage coming soon 4.012.0292 CABLE H05VV-F 3X1.5 MT.6.4 SP.SCHUKO ANTI-SPLASH F/F €32.38
8
 photo_cameraImage coming soon 3.499.0539 FERRITE ANTIDISTANCE FILTER 7427155 1 €15.85
9
 photo_cameraImage coming soon 5.611.0331 ULKA PUMP ASSEMBLY 230/50 FOR DARWIN Lavorwash for pressure washer €89.26
10
 photo_cameraImage coming soon 5.611.0328 NEW SCOUT DIESEL FILTER ASSEMBLY Lavorwash for pressure washer €8.65
11
 photo_cameraImage coming soon 5.611.0326 BOILER COVER ASSEMBLY W/NOZZLE 0.60 DARWIN Lavorwash for pressure washer €171.86
12
 photo_cameraImage coming soon 5.613.0426 DARWIN EXTERNAL BOILER BODY Lavorwash for pressure washer €102.22
13
 photo_cameraImage coming soon 5.613.0427 BOILER INNER CYLINDER Lavorwash for pressure washer €34.95
14
 photo_cameraImage coming soon 4.604.0038 COIL D.200 L-15,5M D.16X1,85 Lavorwash for pressure washer €242.28
15
 photo_cameraImage coming soon 4.607.1101 FUME SEAL RING D.123 H.43 Lavorwash for pressure washer €12.14
16
 photo_cameraImage coming soon 4.608.0569 CALORITE REFRACTORY D.203X30 Lavorwash for pressure washer €34.95
17
 photo_cameraImage coming soon 4.606.0318 FIXED COIL NUT G3/8X5-BRASS Lavorwash for pressure washer €4.86
18
 photo_cameraImage coming soon 3.555.1050 KM BOILER FIXING PLATE Lavorwash for pressure washer €3.79
19
 photo_cameraImage coming soon 5.611.0337 DARWIN BOILER CONVEYOR ASSEMBLY Lavorwash for pressure washer €37.87
20
 photo_cameraImage coming soon 5.611.0332 AUCKLAND MOTORPUMP ASSEMBLY Lavorwash for pressure washer €621.25
21
 Joint for Pump-Boiler for Pressure Washer Lavor Missouri 5.609.0328 Joint for Pump-Boiler for Pressure Washer Lavor Missouri €62.48
22
 photo_cameraImage coming soon 4.618.0253 HOSE 5/16 R1 250BAR 3/8 F 90GR-3/8 F 90GR L=320 Lavorwash for pressure washer €27.34
23
 photo_cameraImage coming soon 3.299.0008 OR FOR ADAPTOR sp.2.7 D.int15 D.ext.24.5 €1.63
24
 photo_cameraImage coming soon 4.618.0250 L.P. HOSE L=700 3/4 F 90GR-3/8 M Lavorwash for pressure washer €38.23
25
 photo_cameraImage coming soon 3.555.1309 M/F REDUCER G3/4-G3/8 L=45 Lavorwash for pressure washer €19.32
26
 photo_cameraImage coming soon 4.618.0262 HOSE R1 5/16 250BAR L 230 3/8 F 90GR OFFSET 90GR Lavorwash for pressure washer €27.34
27
 photo_cameraImage coming soon 4.606.0335 PROBE HOLDER M14-3/8F-3/8M Lavorwash for pressure washer €24.77
28
 photo_cameraImage coming soon 3.004.0036 COPPER WASHER 3/8 17X22 SP.1.5 €1.54
29
 photo_cameraImage coming soon 4.606.0322 DELIVERY FITTING L=45 M22-G3/8" M Lavorwash for pressure washer €15.15
30
 photo_cameraImage coming soon 3.555.0363 FLAT SWIVEL WHEEL D100 + "KM" BRAKE €25.08
31
 photo_cameraImage coming soon 6.605.0266 WHEEL KIT 30060155 +HUB CAP+RETAINER DARWIN-AUCKLAND Lavorwash for pressure washer €33.01
32
 photo_cameraImage coming soon 5.613.0429 COMPLETE PAINTED FRAME Lavorwash for pressure washer €149.54
33
 photo_cameraImage coming soon 3.406.0008 LOCKNUT PG.13,5 FOR TRUMPET CABLE GLAND Lavorwash for pressure washer €1.59
34
 photo_cameraImage coming soon 3.406.0020 TIGHT ANTI-TEARING CABLE HOLDER PG.13,5 €3.23
35
 photo_cameraImage coming soon 5.613.0430 PAINTED HANDLE FRAME Lavorwash for pressure washer €86.42
36
 photo_cameraImage coming soon 5.611.0315 DETERGENT TANK ASSEMBLY DARWIN Lavorwash for pressure washer €48.47
37
 photo_cameraImage coming soon 5.611.0327 DIESEL SUCTION DELIVERY ASSEMBLY DARWIN Lavorwash for pressure washer €33.01
38
 photo_cameraImage coming soon 6.005.0645 PATRIOT DIESEL TANK CAP KIT WITH GASKET €10.00
39
 photo_cameraImage coming soon 3.555.0972 CUP FILTER D.40,5X114,5 (FOR DIESEL) Lavorwash for pressure washer €4.38
40
 photo_cameraImage coming soon 4.608.0559 BLACK DIESEL TANK DARWIN Lavorwash for pressure washer €145.66
41
 photo_cameraImage coming soon 4.608.0576 LEFT SIDE ACCESSORY HOLDER-BLACK COLOR Lavorwash for pressure washer €16.03
42
 photo_cameraImage coming soon 4.613.0435 RIGHT LOWER FAIRING MISSISSIPPI-R2 BLACK Lavorwash for pressure washer €18.45
43
 photo_cameraImage coming soon 4.613.0434 LEFT LOWER FAIRING MISSISSIPPI-R2 BLACK Lavorwash for pressure washer €18.45
Page 4 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3.401.0004 THERMAL SWITCH €45.90
2
 Lavor Adjustment Knob for MEK 1108 4.608.0164 Lavor Adjustment Knob for MEK 1108 €5.83
3
 photo_cameraImage coming soon 3.555.0290 SEAL BUSH FOR THERMOSTAT PIN Lavorwash for pressure washer €2.64
4
 photo_cameraImage coming soon 7.701.4966 DARWIN ELECTRICAL CONTROL PANEL STICKER Lavorwash for pressure washer €11.65
5
 photo_cameraImage coming soon 4.608.0587 ELECTRICAL BOX COVER "SCOUT" Lavorwash for pressure washer €11.65
6
 photo_cameraImage coming soon 3.405.0011 TERMINAL BOARD PA 32/6 €12.60
7
 photo_cameraImage coming soon 5.611.0399 DELAYER KIT W/FASTON-FASTON COVER Lavorwash for pressure washer €35.93
8
 photo_cameraImage coming soon 3.403.0401 THERMOSTAT 30/90 BULB D. 6.5 PARANA' PIN L=23MM 1 €0.11
9
 Pressure Switch for Pressure Washer Lavor Missouri 3.704.0006 Pressure Switch for Pressure Washer Lavor Missouri €30.90
10
 photo_cameraImage coming soon 3.200.0262 OR GASKET 2,62X215,57 NBR 70SH Lavorwash for pressure washer €2.14
11
 photo_cameraImage coming soon 4.608.0588 ELECTRICAL BOX "SCOUT" Lavorwash for pressure washer €15.53
Page 5 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.609.0409 DARWIN DETERGENT REGULATOR CAP ASSEMBLY Lavorwash for pressure washer €13.02
2
 photo_cameraImage coming soon 4.608.0570 DETERGENT TANK Lavorwash for pressure washer €32.04
Page 6 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.608.0572 FAN HOUSING(0404003300) Lavorwash for pressure washer €20.79
2
 photo_cameraImage coming soon 4.608.0579 FAN D.145X50 PLASTIC MAT. Lavorwash for pressure washer €15.25
3
 photo_cameraImage coming soon 3.555.1070 BUTTERFLY CONVEYOR Lavorwash €2.81
4
 photo_cameraImage coming soon 4.608.0575 AIR CONVEYOR Lavorwash for pressure washer €20.89
5
 photo_cameraImage coming soon 4.607.1098 MOTORPUMP FASTENING BAND Lavorwash for pressure washer €5.15
6
 photo_cameraImage coming soon 3.555.1414 CABLE GLAND M20X1.5 CH.24 (6-12) IP68 Lavorwash for pressure washer €1.94
7
 photo_cameraImage coming soon 4.608.0571 OMNIA MOTORPUMP BOX COVER Lavorwash for pressure washer €3.79
8
 photo_cameraImage coming soon 5.001.0993 MOTORPUMP PT'03 125H110ALL 230-240/50 12' TS IN.1,7 DOUBLE SEAL €581.66
9
 photo_cameraImage coming soon 4.008.0514 BLACK EAGLE FOOT FOR MOTOR- PUMP SUPPORT €3.37
Page 7 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.608.0578 DARWIN BOILER-CONVEYOR SLEEVE Lavorwash for pressure washer €12.14
2
 photo_cameraImage coming soon 6.605.0269 DARWIN BOILER CONVEYOR KIT Lavorwash for pressure washer €27.68
Page 8 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 8
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.609.0260 MAX PRESSURE VALVE 250BAR 1/8 €24.79
2
 Lavor FKX 1018 Kit 291 LW 6.005.0319 Lavor FKX 1018 Kit 291 LW €28.92
Page 9 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 9
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.009.1209 ULKA PUMP PRESSURE REGULATION VALVE ASSY 90GR FITTING €21.36
2
 Pump ULKA EK2/M for Pressure Washer Lavor Missouri 3.551.0055 Pump ULKA EK2/M for Pressure Washer Lavor Missouri €68.85
3
 photo_cameraImage coming soon 3.401.0233 THERMAL UL*(F13A11005L300U198)W/FASTON+FASTON COVER €11.38
Page 10 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 10
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 6.605.0268 TRANSFORMER KIT 34000047+ CABLE 46120143 Lavorwash for pressure washer €108.75
2
 photo_cameraImage coming soon 4.608.0558 GASKET FOR H.T. TRANSFORMER COFI LWS COMET Lavorwash for pressure washer €1.37
3
 photo_cameraImage coming soon 3.100.0075 CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- €14.98
4
 photo_cameraImage coming soon 3.555.1099 CAP D21,75X2 (3200007400) €4.50
5
 photo_cameraImage coming soon 3.555.1098 EXTERNAL SEEGER ZJ D.22 (3019003500) €1.63
6
 photo_cameraImage coming soon 4.006.0408 NOZZLE HOLDER PIN FOR MISSISSIPI R2 BOILER Lavorwash for pressure washer €0.00 Not available for order
7
 photo_cameraImage coming soon 4.605.0210 DARWIN BURNER FLANGE Lavorwash for pressure washer €20.39
8
 photo_cameraImage coming soon 4.607.1082 UPPER BOILER COVER Lavorwash for pressure washer €12.72
9
 photo_cameraImage coming soon 4.607.1096 HEXAGONAL SPACER CH.8 H.24 Lavorwash for pressure washer €2.14
10
 photo_cameraImage coming soon 6.605.0267 DARWIN-AUCKLAND ELECTRODE DEFLECTOR KIT Lavorwash for pressure washer €34.87
11
 Diesel Nozzle for Pressure Washer Lavor FKX 1018 3.104.0008 Diesel Nozzle for Pressure Washer Lavor FKX 1018 €29.49
12
 photo_cameraImage coming soon 5.613.0431 LOWER BOILER COVER D.235 H.90 Lavorwash for pressure washer €46.23
Page 11 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 11
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.009.1175 MOTOR ASSY D.125H110ALL 230-240/50 2P+PLATE 12'(CLOCKWISE ROT.) €610.88
2
 photo_cameraImage coming soon 4.007.0416 THRUST BEARING 35X58X12 PT'03(180BAR) €7.42
3
 photo_cameraImage coming soon 5.009.1188C GUIDE BODY ASSY W/TS 17KG-SUCT. €110.69
4
 photo_cameraImage coming soon 3.100.0551 FITTING AT 1/8G F/M/F Lavorwash for pressure washer €6.50
5
 photo_cameraImage coming soon 3.100.0093 NIPPLE 1/8M-1/4M ZINC PLATED HEX 17 Lavorwash for pressure washer €3.09
Page 12 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 12
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.007.0314 PT03EVO GUIDE BODY MACH.DOUBLE SEAL TS 17KG-MACH.SEATS-SUCT. €105.84
2
 photo_cameraImage coming soon 6.005.0649 PT' 03 DOUBLE SEAL SPACER KIT €14.12
3
 photo_cameraImage coming soon 6.005.0585 PT03 WATER SEAL RING KIT €5.71
4
 photo_cameraImage coming soon 5.008.0395 PT'03 HEAD D.12 BRASS W/FILLED CAPS DOUBLE SEAL W/MANOMETER €271.15
Page 13 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 13
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5.002.0158 FRAME'96 D125H110ALL 230-240/50 2P W/TERM.CLOCKWISE ROT. Lavorwash for pressure washer €362.00
2
 photo_cameraImage coming soon 5.005.0081 ROTOR SHAFT D.65 H.110 FOR MOT.125ALL 230/50 CLOCKWISE ROT. Lavorwash for pressure washer €139.82
3
 photo_cameraImage coming soon 5.Y09.0587 FLANGE FOR PT'03 D.125H110 W/THREADS €37.08 Not available for order
4
 Oblique Ball Bearing for Pressure Washers Lavor GIANT 24 - 28 3.001.0002 Oblique Ball Bearing for Pressure Washers Lavor GIANT 24 - 28 €14.41
5
 INCLINATED PLATE 12 DEGREE X PT'03 4.005.0225 INCLINATED PLATE 12 DEGREE X PT'03 €3.71
Page 14 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 14
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 6.005.0648 KIT VALVE INLET/OUTLET W/ BRASS SEAT-PLUGS BRASS FILTER PT'03 €9.44
2
 photo_cameraImage coming soon 4.006.0409 HEAD PT'03 BRASS MACHINED DOUBLE SEAL FOR PRESSURE GAUGE €0.11 Not available for order
3
 photo_cameraImage coming soon 6.005.0585 PT03 WATER SEAL RING KIT €5.71
Page 15 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 15
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4.005.0300 PISTON BODY GUIDE PT'03EVO WITH SUCTION €27.54
2
 Kit Total Stop Pystop Automatic Stop for Washer Lavor GIANT 24 5.009.0596 Kit Total Stop Pystop Automatic Stop for Washer Lavor GIANT 24 €15.97
3
 photo_cameraImage coming soon 6.005.0646 3 PISTONS +SPRINGS PT'03 DOUBLE SEAL KIT Lavorwash for pressure washer €19.42
4
 photo_cameraImage coming soon 6.005.0647 KIT 'O-RING FOR PT'03 DOUBLE SEAL' €7.58
5
 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 6.005.0277 Kit 252 LW for High Pressure Washers ARMY 110 - MARINE 125 - NAVY 140 €4.79
6
 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 6.005.0079 Kit 79 LW Oil Seal for Pressurte Washer Lavor BEST 24 €14.50

Shipping and delivery information will be available shortly.

FASA Original Parts for Pressure Cleaner KAIMAN-R

Fix Your Hot Water High Pressure Cleaner 8.675.0010 - Pressure Washer KAIMAN-R 1310 230/50 -BLU- SP.SCHUKO -FASA-. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
KAIMAN-R 1310 230/50 -BLU- SP.SCHUKO -FASA-

Kaiman-R  Pag.1
# Part Num. Description
1 4.613.0468 DARWIN UPPER FAIRING -BLUE-RAL 5015 W/LANCE UPPER HOOKS
2 5.611.0329 DARWIN HANDLE ASSEMBLY
3 7.700.0658 DARWIN/AUCKLAND LAVOR MANUAL 21L A5 183F
4 3.700.0036 AL15 GUN 26MPA-100GR-30LT/MIN G3/8M-M22.
5 4.618.0049 R1 HOSE 1/4 21MPA 8M 3/8F SWIVEL-M22X1.5 W/HOSE SLEEVE
6 3.714.0190 LANCE L.700 COATED +NOZZLE.+QUICK COUPLING M22
DARWIN Pag.2
# Part Num. Description
1 3.555.0904 D50 LOBED HANDWHEEL M8X35 MALE
2 3.103.0048 H.P. NOZZLE 15035 1/8M 1/8MC4-035/15
3 3.100.0082 QUICK COUPLING 3/4 BLACK WITH GASKET (THREAD L=11.5)
4 4.607.0046 STAINLESS STEEL FILTER DIAM.20 SUCTION FITTING
5 5.611.0316 EXTERNAL DETERGENT SUCTION KIT DARWIN
Pag.3
# Part Num. Description
1 3.404.0095 CAPACITOR 55MF 450V D.50X94 F/M
2 3.107.0030 PRESSURE GAUGE D.50 ATC G1/4' 0-250BAR+SUP 10(18160159)
3 4.607.1141 NEW SCOUT PRESSURE GAUGE SUPPORT
4 4.618.0264 PRESSURE GAUGE HOSE 2X400 630BAR 1/4 F W/SEAL-1/4 F CURVED
5 3.099.2057 THUMBSCREW G3/4X17 F PA6 BLACK
6 5.611.0314 ELECTRICAL CONTROL PANEL ASSEMBLY 230V DARWIN
7 4.012.0292 CABLE H05VV-F 3X1,5 MT.6.4 SCHUKO PLUG ANTISPLASH F/F
8 3.499.0539 FERRITE RFI FILTER 7427155
9 5.611.0331 ULKA PUMP ASSEMBLY 230/50 FOR DARWIN
10 5.611.0328 NEW SCOUT DIESEL FILTER ASSEMBLY
11 5.611.0326 BOILER COVER ASSEMBLY W/NOZZLE 0.60 DARWIN
12 5.613.0426 DARWIN EXTERNAL BOILER BODY
13 5.613.0427 BOILER INNER CYLINDER
14 4.604.0038 COIL D.200 L-15,5M D.16X1,85
15 4.607.1101 FUME SEAL RING D.123 H.43
16 4.608.0569 CALORITE REFRACTORY D.203X30
17 4.606.0318 FIXED COIL NUT G3/8X5-BRASS
18 3.555.1050 KM BOILER FIXING PLATE
19 5.611.0337 DARWIN BOILER CONVEYOR ASSEMBLY
20 5.611.0332 AUCKLAND MOTORPUMP ASSEMBLY
21 5.609.0328 PUMP-COIL JUNCTION FITTING ASSEMBLY
22 4.618.0253 HOSE 5/16 R1 250BAR 3/8 F 90GR-3/8 F 90GR L=320
23 3.299.0008 GASKET FOR ADAPTER TH.2.7 INT.D.15 EXT.D.24.5
24 4.618.0250 L.P. HOSE L=700 3/4 F 90GR-3/8 M
25 3.555.1309 M/F REDUCER G3/4-G3/8 L=45
26 4.618.0262 HOSE R1 5/16 250BAR L 230 3/8 F 90GR OFFSET 90GR
27 4.606.0335 PROBE HOLDER M14-3/8F-3/8M
28 3.004.0036 COPPER WASHER 3/8 17X22 TH.1,5
29 4.606.0322 DELIVERY FITTING L=45 M22-G3/8" M
30 3.555.0363 PIVOT WHEEL D100 + BRAKE "KM"
31 6.605.0266 WHEEL KIT 30060155 +HUB CAP+RETAINER DARWIN-AUCKLAND
32 5.613.0429 COMPLETE PAINTED FRAME
33 3.406.0008 LOCKNUT PG.13,5 FOR TRUMPET CABLE GLAND
34 3.406.0020 CABLE GLAND PG.13,5 WATERTIGHT ANTITENSION
35 5.613.0430 PAINTED HANDLE FRAME
36 5.611.0315 DETERGENT TANK ASSEMBLY DARWIN
37 5.611.0327 DIESEL SUCTION DELIVERY ASSEMBLY DARWIN
38 6.005.0645 PATRIOT DIESEL TANK CAP KIT WITH GASKET
39 3.555.0972 CUP FILTER D.40,5X114,5 (FOR DIESEL)
40 4.608.0559 BLACK DIESEL TANK DARWIN
41 4.608.0576 LEFT SIDE ACCESSORY HOLDER-BLACK COLOR
42 4.613.0435 RIGHT LOWER FAIRING MISSISSIPPI-R2 BLACK
43 4.613.0434 LEFT LOWER FAIRING MISSISSIPPI-R2 BLACK
Electric Scheme Pag.4
# Part Num. Description
1 3.401.0004 MICRO CIRCUIT BREAKER ETA 3120-N554-P7T1-W02D-16A W/PROT.
2 4.608.0164 THERMOSTAT ADJUSTMENT KNOB-N-
3 3.555.0290 SEAL BUSH FOR THERMOSTAT PIN
4 7.701.4966 DARWIN ELECTRICAL CONTROL PANEL STICKER
5 4.608.0587 ELECTRICAL BOX COVER "SCOUT"
6 3.405.0011 TERMINAL BLOCK PA 32/6
7 5.611.0399 DELAYER KIT W/FASTON-FASTON COVER
8 3.403.0401 THERMOSTAT 30/90 BULB D. 6,5 PARANA' PIN L=23MM
9 3.704.0006 PRESSURE SWITCH PS2 1/8M 25BAR RED
10 3.200.0262 OR GASKET 2,62X215,57 NBR 70SH
11 4.608.0588 ELECTRICAL BOX "SCOUT"
Tank Pag.5
# Part Num. Description
1 5.609.0409 DARWIN DETERGENT REGULATOR CAP ASSEMBLY
2 4.608.0570 DETERGENT TANK
Pump Pag.6
# Part Num. Description
1 4.608.0572 FAN HOUSING(0404003300)
2 4.608.0579 FAN D.145X50 PLASTIC MAT.
3 3.555.1070 BUTTERFLY CONVEYOR
4 4.608.0575 AIR CONVEYOR
5 4.607.1098 MOTORPUMP FASTENING BAND
6 3.555.1414 CABLE GLAND M20X1.5 CH.24 (6-12) IP68
7 4.608.0571 OMNIA MOTORPUMP BOX COVER
8 5.001.0993 MOTORPUMP PT'03 125H110ALL 230-240/50 12' TS IN.1,7 DOUBLE SEAL
9 4.008.0514 EAGLE MOTORPUMP SUPPORT FOOT BLACK
Boiler Pag.7
# Part Num. Description
1 4.608.0578 DARWIN BOILER-CONVEYOR SLEEVE
2 6.605.0269 DARWIN BOILER CONVEYOR KIT
Pump Pag.8
# Part Num. Description
1 5.609.0260 SAFETY VALVE MAX 250BAR 1/8 W/HOSETAIL
2 6.005.0319 KIT 291 LW HOBBY PUMP/BOILER JUNCTION FITTING
Pump Pag.9
# Part Num. Description
1 5.009.1209 ULKA PUMP PRESSURE REGULATION VALVE ASSY (SPRING L=20) 90GR FITTING
2 3.551.0055 ULKA PUMP EK2/M 56W 230/50 W/OR R4 VITON
3 3.401.0233 THERMAL UL*(F13A11005L300U198)W/FASTON+FASTON COVER
Tap Boiler Pag.10
# Part Num. Description
1 6.605.0268 TRANSFORMER KIT 34000047+ CABLE 46120143
2 4.608.0558 GASKET FOR H.T. TRANSFORMER COFI LWS COMET
3 3.100.0075 FITTING M 1/8 TAPERED F D.4 CURVED
4 3.555.1099 FLAME CONTROL PEEP HOLE D. 21,75X2 (GLASS)
5 3.555.1098 SEEGER TYPE ZJ D22
6 4.006.0408 NOZZLE HOLDER PIN FOR MISSISSIPI R2 BOILER
7 4.605.0210 DARWIN BURNER FLANGE
8 4.607.1082 UPPER BOILER COVER
9 4.607.1096 HEXAGONAL SPACER CH.8 H.24
10 6.605.0267 DARWIN-AUCKLAND ELECTRODE DEFLECTOR KIT
11 3.104.0008 DIESEL NOZZLE 0.60 60 H MONEL FILTER(HAGO)
12 5.613.0431 LOWER BOILER COVER D.235 H.90
Pump Pag.11
# Part Num. Description
1 5.009.1175 MOTOR ASSY D.125H110ALL 230-240/50 2P+PLATE 12'(CLOCKWISE ROT.)
2 4.007.0416 BALL THRUST BEARING 35X58X12 FOR PT03(180BAR)
3 5.009.1188C GUIDE BODY ASSY W/TS 17KG-SUCT.+HEAD BRASS FILTER DOUBLE SEAL W/MAN.PRED.
4 3.100.0551 FITTING AT 1/8G F/M/F
5 3.100.0093 NIPPLE 1/8M-1/4M ZINC PLATED HEX 17
Guide Pag.12
# Part Num. Description
1 5.007.0314 PT03EVO GUIDE BODY MACH.DOUBLE SEAL TS 17KG-MACH.SEATS-SUCT.
2 6.005.0649 PT 03 DOUBLE SEAL SPACERS KIT
3 6.005.0585 PT03 WATER SEAL RINGS KIT
4 5.008.0395 PT'03 HEAD D.12 BRASS W/FILTER PLUGS DOUBLE SEAL W/PRESSURE GAUGE
Pag.13
# Part Num. Description
1 5.002.0158 FRAME'96 D125H110ALL 230-240/50 2P W/TERM.CLOCKWISE ROT.
2 5.005.0081 ROTOR SHAFT D.65 H.110 FOR MOT.125ALL 230/50 CLOCKWISE ROT.
3 5.Y09.0587 FRONT FLANGE FOR PT03 D.125H110 W/THREADS
4 3.001.0002 OBLIQUE BALL BEARING 20X52X15 7304 B
5 4.005.0225 PLATE 12GR FOR PT03 SPHERES THRUST BEAR.
Pag.14
# Part Num. Description
1 6.005.0648 SUCT./DELIV.VALVE KIT W/BRASS SEAT-BRASS THREAD PLUGS PT'03
2 4.006.0409 PT'03 BRASS HEAD MACHINED DOUBLE SEAL W/PRESSURE GAUGE
3 6.005.0585 PT03 WATER SEAL RINGS KIT
Pag.15
# Part Num. Description
1 4.005.0300 PT03EVO PISTON GUIDE BODY W/THRET.DET.SUCT.HOLE
2 5.009.0596 COMP.VALVE ASSY W/TS PT03 CABLE L=530 SPRING 17KG(GREEN COVER)
3 6.005.0646 3 PISTONS +SPRINGS PT'03 DOUBLE SEAL KIT
4 6.005.0647 O-RING KIT FOR PT'03 DOUBLE SEAL
5 6.005.0277 INJECTOR KIT 1.7 HOSETAIL FIL.+CHECK VALVE PT 03
6 6.005.0079 79 LW OIL SEAL RINGS KIT FOR PARTNER D. 12/FIBRE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
8.675.0010

Data sheet

SHIPPING IN
Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR
LAVOR S/N START WITH (8. ) and have 8 DIGITS
Machine Type
Pressure Washer

Specific References

New

Download

FASA KAIMAN-R Drawing

FASA KAIMAN-R Drawing

Download (3.27MB)

You might also like

Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor
Lavorwash S.p.A. SKU: 3.700.0036
Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor
Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Lavor Genuine Replacement part Lavor, Gun AL 15 3/8 "- M22 for Hot Water Pressure Washers Advanced 1108 - XTR 1007 - Rio 1108 - Mek 1108 -  Missouri 1310.  Part suitable for the...
AVAILABLE €33.90
Details
Kit 125 LW Rings Holding Brass Seal for Pressurte Washer Lavor BEST 24
Lavorwash S.p.A. SKU: 6.005.0134
Kit 125 LW Rings Holding Brass Seal for Pressurte Washer Lavor BEST 24
Kit 125 LW Rings Holding Brass Seal for Pressurte Washer Lavor BEST 24 Original spare part Lavor, Kit 125 LW Rings Holding Brass Seal + Spacers PT D.12 per Pressure Washers GIANT 24 - TEMPESTA 24 - BEST 24. Part for the following...
Usually Ships in: 7/10 Business Days Approx. €14.50
Details
Piston Guide Body With Complete Valve Head for Lavor Missouri
Lavorwash S.p.A. SKU: 5.007.0231
Piston Guide Body With Complete Valve Head for Lavor Missouri
Piston Guide Body With Complete Valve Head for Lavor Missouri Genuine part Lavor, Piston Guide Body PT'03 - Ceramic Pistons Diameter 12 mm + Total-Stop, Turned With Complete Valve Head With Intake Springs 17K. Part for the following...
Usually Ships in: 7/10 Business Days Approx. €72.11
Details
Diesel Filter Unit for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.611.0043
Diesel Filter Unit for Pressure Washer Lavor Missouri
Diesel Filter Unit for Pressure Washer Lavor Missouri Genuine part Lavor, Diesel Filter Unit JOLLY 4 '93 / MISSOURI / MEK for Pressure Washers Missouri - NPX 1400 - NPX 1500. Part for the following products: -  86190601 - IDRO...
Usually Ships in: 10 Business Days Approx. €15.19
Details
Joint for Pump-Boiler for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.609.0328
Joint for Pump-Boiler for Pressure Washer Lavor Missouri
Joint for Pump-Boiler for Pressure Washer Lavor Missouri Genuine part Lavor, Joint for Pump-Boiler W/Safety Valve for Pressure Washers MISSOURI Part for the following products: -  Pressure washer MISSOURI 230/50...
on 10 Business Days Approx €62.48
Details
Brass Head PT'03 D.12 for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.008.0238
Brass Head PT'03 D.12 for Pressure Washer Lavor Missouri
Brass Head PT'03 D.12 for Pressure Washer Lavor Missouri Genuine part Lavor, Brass Head PT'03 D.12 with Capsi Pressure Gouge (Brown Seal TEL.) for Pressure Washers  MISSOURI. Part for the following products: -  Pressure Washer...
on 10 Business Days Approx €118.95
Details
Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24
Lavorwash S.p.A. SKU: 4.008.0278
Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24
Inlet/Outlet Cover for Pressure Washer Lavor EAGLE 24 Genuine replacement part Lavor, Inlet/Outlet Cover for Spark Version PARTNER for Pressure Washers EAGLE 24. Part for the following products: -  Pressure Washer EAGLE 24 -...
on 7/10 Business Days Approx €4.26
Details
Motorpump PT'03 for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 5.001.0817
Motorpump PT'03 for Pressure Washer Lavor Missouri
Motorpump PT'03 for Pressure Washer Lavor Missouri Genuine part Lavor, Motorpump PT'03 125h110AL 230-240/50 12' TS IN.1,7 BRASS HEAD for Pressure Washers  MISSOURI - YUKON 1310 - NPX 1500...
Last items in stock €514.57
Details
Pump ULKA EK2/M for Pressure Washer Lavor Missouri
Lavorwash S.p.A. SKU: 3.551.0055
Pump ULKA EK2/M for Pressure Washer Lavor Missouri
Pump ULKA EK2/M for Pressure Washer Lavor Missouri Genuine part Lavor, Pump ULKA EK2/M 59W 230/50 C/OR R4 VITON for Pressure Washers  MISSOURI. Part for the following products: -  Pressure...
on 10 Business Days Approx €68.85
Details
Lavor FKX 1018 Kit 291 LW
Lavorwash S.p.A. SKU: 6.005.0319
Lavor FKX 1018 Kit 291 LW
Lavor FKX 1018 Kit 291 LW Genuine replacement part Lavor, Kit 291 LW Boiler Pump Junction Fitting for Pressure Washer FKX 1018 230/50 TS -R- (VAPORNOVA)- 80520001. Part for the following products: - ...
on 10 Business Days Approx €28.92
Details
Lavor Missouri Thermostat Body Bulb + Quick Joint
Lavorwash S.p.A. SKU: 5.609.0327
Lavor Missouri Thermostat Body Bulb + Quick Joint
Lavor Missouri Thermostat Body Bulb + Quick Joint Genuine part Lavor, Thermostat Body Bulb + Quick Joint 3/8" M for Pressure Washers  MEK/MISSOURI/MISSISSIPPI/ PARANA'. Part for the following products: - Pressure Washer MISSOURI...
Usually Ships in: 10/15 Business Days Approx. €69.87
Details
Lavor Disk As for KARJET PROFI130
Lavorwash S.p.A. SKU: 3.001.0003
Lavor Disk As for KARJET PROFI130
Lavor Disk As for Pressure Cleaner KARJET PROFI130 Original replacement part Lavorwash, Disk As for Pressure Cleaners KARJET PROFI130 - FKX 1018. Part for the following products: -  Pressure Cleaner Lavor KARJET PROFI130 -...
Usually Ships in: 10 Business Days Approx. €3.33
Details
Lavor Bearing Washer for LP 20 EHR
Lavorwash S.p.A. SKU: 4.007.0001
Lavor Thrust Shoe for LP 20 EHR
Lavor Thrust Shoe for Pressure Cleaner LP 20 EHR Original replacement part Lavorwash, Thrust Shoe D.65x30x6 (C10pb) Finished for Pressure Cleaners LP 20 EHR - FKX 1018. Part for the following products: - ...
Usually Ships in: 10 Business Days Approx. €5.83
Details
Lavor Piston Recall Spring for FKX 1018
Lavorwash S.p.A. SKU: 4.007.0025
Lavor Piston Recall Spring for FKX 1018
Lavor Piston Recall Spring for Pressure Cleaner FKX 1018 Original replacement part Lavorwash, Piston Recall Spring D.14- 12 for Pressure Cleaners FKX 1018 - MACH 20. Part for the following products: -  Pressure Cleaner Lavor KARJET...
Usually Ships in: 10 Business Days Approx. €2.12
Details
Lavor Needle Roller Cage for EQ18
Lavorwash S.p.A. SKU: 3.001.0025
Lavor Needle Roller Cage for EQ18
Lavor Needle Roller Cage for Pressure Cleaner EQ18 Original replacement part Lavorwash, Needle Roller Cage Type Axk4565 -STEEL- for Pressure Cleaners EQ18 - MISSOURI. Part for the following products: - ...
Usually Ships in: 10 Business Days Approx. €3.48
Details
Comments (0)
No customer reviews for the moment.
