Mountfield Spare Parts for Lawn Mower MC 380 Li
€0.12
VAT included
Mountfield Spare Parts for Lawn Mower MC 380 Li
We are Distributors of original MOUNTFIELD spare parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on purchasing the most suitable spare part to quickly resolve any maintenance and repair issue for the Lawn Mower MC 380 Li/293385064/MC.
Mountfield Spare Parts for Lawn Mower MC 380 Li
€0.12
VAT included
Mountfield Spare Parts for Lawn Mower MC 380 Li
We are Distributors of original MOUNTFIELD spare parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on purchasing the most suitable spare part to quickly resolve any maintenance and repair issue for the Lawn Mower MC 380 Li/293385064/MC.
settings
51 Spare parts
description
2 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
51 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 2
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1
|
photo_cameraImage coming soon | 273001200/20 Battery 40V - 2.5Ah Mountfield | €0.00 | Not available for order |
|
1
|
photo_cameraImage coming soon | 273001300/20 Battery 40V - 2.5Ah Mountfield | €0.00 | Not available for order |
|
2
|
photo_cameraImage coming soon | 273002000/20 Battery Charger 40V - BS plug Mountfield | €0.00 | Not available for order |
|
2
|
photo_cameraImage coming soon | 273002100/20 Battery Charger 40V - BS plug Mountfield | €0.00 | Not available for order |
Shipping and delivery information will be available shortly.
Mountfield Spare Parts for Lawn Mower MC 380 Li
We are Distributors of Original MOUNTFIELD Spare Parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and repair problem for the Lawn Mower MC 380 Li/293385064/MC.
| Lawn Mower MC 380 Li/293385064/MC | ||
|---|---|---|
| Lawn Mower Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118811001/0 | Safety Key |
| 2 | 118811002/0 | Electric Motor |
| 3 | 9959-0620-16 | Screw - Flanged Hex Head M6x20 |
| 4 | 118810989/0 | Blade Holder |
| 5 | 118811003/0 | Spacer |
| 6 | 118810999/0 | Blade Hub Cover |
| 7 | 118811004/0 | Motor Fan |
| 8 | 181004470/0 | Blade |
| 9 | 122671651/0 | Washer |
| 10 | 112793301/0 | Screw |
| 11 | 2312010 | Washer |
| 12 | 118802212/0 | Wheel |
| 13 | 118811005/0 | Rear Wheel Axle |
| 14 | 118811006/0 | Air Filter |
| 15 | 118811007/0 | Chassis |
| 16 | 118811008/0 | Flange |
| 17 | 118810987/0 | Front Handle |
| 18 | 118811009/0 | Front Wheel Axle |
| 19 | 118811010/0 | Front Wheel |
| 20 | 112604903/0 | Washer |
| 21 | 118811011/0 | Height Adjustment Control Rod |
| 22 | 118811012/0 | Spring |
| 23 | 118811013/0 | Spring |
| 24 | 118811014/0 | Conveyor |
| 25 | 118811015/0 | Spring |
| 26 | 118811022/0 | Handle Kit |
| 27 | 118811000/0 | Pin |
| 28 | 118810996/0 | Bag Handle |
| 29 | 118802664/0 | Hook |
| 30 | 118810994/0 | Yellow Knob |
| 31 | 112815255/0 | Bolt |
| 32 | 118811016/0 | Motor Protector Assy |
| 33 | 118811017/0 | Spring |
| 34 | 122671651/0 | Washer |
| 35 | 118811018/0 | Grey Stone Guard |
| 36 | 112154510/0 | Self-Locking Nut M6 |
| 37 | 118811052/0 | Safety Button and PCB Kit |
| 38 | 118811062/0 | Cable Assy |
| 39 | 118811063/0 | Battery Cover Kit |
| 40 | 118811059/0 | Handle |
| 41 | 118811044/0 | Rear Hubcap Kit (RH+LH) |
| 42 | 118811064/0 | Aesthetic Covers Kit |
| 43 | 118811065/0 | Battery Housing Kit |
| 44 | 118811045/0 | Front Hubcap Kit (RH+LH) |
| 45 | 118811046/0 | Height Adjustment Kit |
| 46 | 118811047/0 | Joint Kit (RH+LH) |
| 47 | 118811054/0 | Bag Kit |
| 48 | 118811698/0 | Height Adjustment Knob |
| Battery Pag.2 | ||
| # | Part Num. | Description |
| 1 | 273001200/20 | Battery 40V - 2Ah |
| 1 | 273001300/20 | Battery 40V - 2.5Ah |
| 2 | 273002000/20 | Battery Charger 40V - EU plug |
| 2 | 273002100/20 | Battery Charger 40V - BS plug |
All technical product information in this catalog is based on information taken from official sources, including Mountfield manufacturer websites, which we believe to be reliable. Unfortunately, even official documents may contain errors or misprints - we are unable to confirm that all of this data is accurate and truly represents the facts. Most manufacturers reserve the right to change product specifications or complete descriptions without prior notice. It is strongly recommended to use the published information as baseline information subject to Mountfield brand review. Please clarify important parameters with a sales assistant at the time of purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or reproduction (in whole or in part) without reference to the original page is prohibited.
293385064/MC-2021
Data sheet
- SHIPPING IN
- Usually Ships in 10/15 BUSINESS DAYS
- CHECK ITEM CODE OR S/N
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- Machine Type
- Lawn Mowers
Specific References
