TTI Industries

Milwaukee AG21-230E Parts

SKU: Milwaukee AG21-230E
€23.12
VAT included

Milwaukee AG21-230E Angle Grinder Spare Parts

Fix Your Milwaukee AG21-230E 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Milwaukee AG21-230E
Milwaukee AG21-230E Parts
  • Milwaukee AG21-230E Parts
  • Milwaukee AG21-230E Parts - Drawing
TTI Industries

Milwaukee AG21-230E Parts

SKU: Milwaukee AG21-230E Condition: New
€23.12
VAT included

Milwaukee AG21-230E Angle Grinder Spare Parts

Fix Your Milwaukee AG21-230E 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Milwaukee AG21-230E
settings 59 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK AEG S/N:: AEG S/N START WITH (4) or (5) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
59 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
4
 photo_cameraImage coming soon 4931455392 CONNECTION CABLE €24.58
5
 photo_cameraImage coming soon 4931387206 PROTECTING COVER €4.18
6
 photo_cameraImage coming soon 4931622765 SCREW N874101-1 SHR C-K5X45/20 KOMBITORX €3.51
100
 photo_cameraImage coming soon 4931402172 MOTOR HOUSING €30.02
103
 photo_cameraImage coming soon 4931455338 SWITCH HANDLE €27.30
105
 photo_cameraImage coming soon 4931426289 ELECTRIC FIELD €56.53
106
 photo_cameraImage coming soon 4931442690 ARMATURE €106.85
107
 photo_cameraImage coming soon 4931334394 FAN €4.86
108
 Milwaukee K500S Ball Bearing 609LBT 4931341741 Milwaukee K500S Ball Bearing 609LBT €8.28
109
 photo_cameraImage coming soon 4931329086 RUBBER SLEEVE €3.51
110
 photo_cameraImage coming soon 4931329084 SEAL RING €4.18
114
 photo_cameraImage coming soon 4931402271 AIR DEFLECTOR RING €5.55
116
 Milwaukee K500S Brush Holder 4931381694 Milwaukee K500S Brush Holder €6.34
117
 photo_cameraImage coming soon 4931402169 COVER €4.18
118
 photo_cameraImage coming soon 4931624538 SCREW €2.27
119
 photo_cameraImage coming soon 4931331734 SCREW €3.51
121
 photo_cameraImage coming soon 4931619992 SPRING WASHER D 137 B 4 €3.51
126
 photo_cameraImage coming soon 4931624537 SCREW €3.51
131
 Milwaukee AG21-230E DMS Carbon Brush Set 4931369479 Milwaukee AG21-230E DMS Carbon Brush Set €18.56
135
 photo_cameraImage coming soon 4931476614 SWITCH €46.46
141
 photo_cameraImage coming soon 4931329273 CABLE COLLAR €4.18
144
 photo_cameraImage coming soon 4931618253 SCREW €3.51
147
 photo_cameraImage coming soon 4931402013 DUST SEAL €4.86
156
 photo_cameraImage coming soon 4931402286 DUST SEAL €4.86
200
 photo_cameraImage coming soon 4931402161 GEAR BOX €85.76
201
 photo_cameraImage coming soon 4931621981 SLEEVE €6.90
202
 photo_cameraImage coming soon 4931621629 DISC N874237 22,5X35X0,3 €4.18
204
 photo_cameraImage coming soon 4931624305 BALL BEARING €8.94
205
 photo_cameraImage coming soon 4931622897 DISC €4.18
206
 photo_cameraImage coming soon 4931334400 LOCKING RING €4.18
209
 photo_cameraImage coming soon 4931402166 LOCKING BOLT €4.86
210
 photo_cameraImage coming soon 4931329173 PRESSURE SPRING €4.18
212
 photo_cameraImage coming soon 4931622764 O-RING €3.51
216
 photo_cameraImage coming soon 4931402546 DRIVE GEAR €102.08
218
 photo_cameraImage coming soon 4931407540 GEAR ENDPLATE €43.61
219
 photo_cameraImage coming soon 4931624672 SEAL RING €4.86
220
 photo_cameraImage coming soon 9170316990 BEARING €6.90
223
 photo_cameraImage coming soon 4931402150 BEARING COVER €4.18
224
 photo_cameraImage coming soon 4931624147 SCREW D 7500 M 3X12 €3.51
225
 photo_cameraImage coming soon 4931279734 RUBBER SLEEVE €4.86
226
 photo_cameraImage coming soon 4931329178 GREASE RETAIN.DISC €4.18
227
 photo_cameraImage coming soon 4931329494 NUT €4.86
228
 photo_cameraImage coming soon 4931409592 BEVEL GEAR PAIR €47.01
232
 photo_cameraImage coming soon 4931409816 SPINDLE €11.66
235
 photo_cameraImage coming soon 4931623312 WASHER N874237 €3.51
236
 photo_cameraImage coming soon 4931624701 DISC €4.18
237
 photo_cameraImage coming soon 4931622747 COMPENSATING WASHER €3.51
238
 photo_cameraImage coming soon 4931624591 WASHER €3.51
239
 photo_cameraImage coming soon 4931941094 DISC N874237 18X27,9X0,5 €4.18
242
 photo_cameraImage coming soon 4931329150 GASKET €4.86
600
 photo_cameraImage coming soon 4931426625 GUARD CAP €25.94
601
 photo_cameraImage coming soon 201256002 CATCH LEVER €17.10
602
 photo_cameraImage coming soon 4931402063 FLANGE €5.55
603
 photo_cameraImage coming soon 4931402089 PRESSURE SPRING €4.18
604
 photo_cameraImage coming soon 4931624491 SCREW €3.51
702
 photo_cameraImage coming soon 4932367712 PIN SPANNER 115-230/WP/WSAP1 A/M €8.27
703
 photo_cameraImage coming soon 4931433531 HANDLE 180-230/WP/WSA P1A/M €8.27
710
 Milwaukee AG8-115QX Clamping Flange 4932449324 Milwaukee AG8-115QX Clamping Flange €11.99
711
 photo_cameraImage coming soon 4932345628 FLANGE NUT M14 3MM P1 A/M €12.21
Page 2 local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Pos. Item Price Buy
702
 photo_cameraImage coming soon 4932367712 PIN SPANNER 115-230/WP/WSAP1 A/M €8.27
703
 photo_cameraImage coming soon 4931433531 HANDLE 180-230/WP/WSA P1A/M €8.27
710
 Milwaukee AG8-115QX Clamping Flange 4932449324 Milwaukee AG8-115QX Clamping Flange €11.99
711
 photo_cameraImage coming soon 4932345628 FLANGE NUT M14 3MM P1 A/M €12.21

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Milwaukee AG21-230E Angle Grinder Spare Parts

Fix Your Milwaukee AG21-230E 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Drill Driver and their spare part.
Milwaukee AG21-230E
Milwaukee ANGLE GRINDER AG21-230E Spare Parts
IN2 4933402515 - AG21-230E - 4000402516 Pag.1
# Part Num. Description
4 4931455392 CONNECTION CABLE
5 4931387206 PROTECTING COVER
6 4931622765 SCREW N874101-1 SHR C-K5X45/20 KOMBITORX
10 4931402518 RATING PLATE
100 4931402172 MOTOR HOUSING
103 4931455338 SWITCH HANDLE
105 4931426289 ELECTRIC FIELD
106 4931442690 ARMATURE
107 4931334394 FAN
108 4931341741 BALL BEARING
109 4931329086 RUBBER SLEEVE
110 4931329084 SEAL RING
114 4931402271 AIR DEFLECTOR RING
116 4931381694 BRUSH HOLDER
117 4931402169 COVER
118 4931624538 SCREW
119 4931331734 SCREW
121 4931619992 SPRING WASHER D 137 B 4
126 4931624537 SCREW
131 4931369479 CARBON BRUSH SET
135 4931476614 SWITCH
141 4931329273 CABLE COLLAR
144 4931618253 SCREW
147 4931402013 DUST SEAL
156 4931402286 DUST SEAL
200 4931402161 GEAR BOX
201 4931621981 SLEEVE
202 4931621629 DISC N874237 22,5X35X0,3
204 4931624305 BALL BEARING
205 4931622897 DISC
206 4931334400 LOCKING RING
209 4931402166 LOCKING BOLT
210 4931329173 PRESSURE SPRING
212 4931622764 O-RING
216 4931402546 DRIVE GEAR
218 4931407540 GEAR ENDPLATE
219 4931624672 SEAL RING
220 9170316990 BEARING
223 4931402150 BEARING COVER
224 4931624147 SCREW D 7500 M 3X12
225 4931279734 RUBBER SLEEVE
226 4931329178 GREASE RETAIN.DISC
227 4931329494 NUT
228 4931409592 BEVEL GEAR PAIR
232 4931409816 SPINDLE
235 4931623312 WASHER N874237
236 4931624701 DISC
237 4931622747 COMPENSATING WASHER
238 4931624591 WASHER
239 4931941094 DISC N874237 18X27,9X0,5
242 4931329150 GASKET
600 4931426625 GUARD CAP
601 201256002 CATCH LEVER
602 4931402063 FLANGE
603 4931402089 PRESSURE SPRING
604 4931624491 SCREW
Accessori Pag.2
702 4932367712 PIN SPANNER 115-230/WP/WSAP1 A/M
703 4931433531 HANDLE 180-230/WP/WSA P1A/M
710 4932449324 CLAMPING FLANGE WS115-230 P1 A/M
711 4932345628 FLANGE NUT M14 3MM P1 A/M
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Milwaukee websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Milwaukee brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
