TTI Industries

Milwaukee AG22-230 DMS Parts

SKU: Milwaukee AG22-230 DMS
€2.45
VAT included

Milwaukee AG22-230 DMS Angle Grinder Spare Parts

Fix Your Milwaukee AG22-230 DMS 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Milwaukee Milwaukee M18FSAGSVO125X 125 mm M18 FUEL™
Milwaukee AG22-230 DMS Parts
  • Milwaukee AG22-230 DMS Parts
  • Milwaukee AG22-230 DMS Parts - Drawing
TTI Industries

Milwaukee AG22-230 DMS Parts

SKU: Milwaukee AG22-230 DMS Condition: New
€2.45
VAT included

Milwaukee AG22-230 DMS Angle Grinder Spare Parts

Fix Your Milwaukee AG22-230 DMS 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Milwaukee Milwaukee M18FSAGSVO125X 125 mm M18 FUEL™
settings 30 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK AEG S/N:: AEG S/N START WITH (4) or (5) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
30 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
5
 photo_cameraImage coming soon 4931441045 NUT €2.38
8
 photo_cameraImage coming soon 4931441046 BEARING €12.98
13
 photo_cameraImage coming soon 4931441047 BEARING €14.50
21
 Milwaukee AG22-230DMS Flange Nut 4931441048 Milwaukee AG22-230DMS Flange Nut €5.57
22
 Milwaukee AG22-230DMS Lower Flange 4931441049 Milwaukee AG22-230DMS Lower Flange €4.78
30
 photo_cameraImage coming soon 4931441050 HANDLE €5.41
34
 photo_cameraImage coming soon 4931441052 GEAR BOX €2.38
39
 photo_cameraImage coming soon 4931441053 BEARING €17.53
47
 photo_cameraImage coming soon 4931441054 AIR DEFLECTOR RING €2.38
49
 photo_cameraImage coming soon 4931441055 ELECTRIC FIELD €62.97
50
 photo_cameraImage coming soon 4931441057 HOUSING SET ASSY €22.07
59
 Milwaukee AG22-230DMS Switch 4931441061 Milwaukee AG22-230DMS Switch €20.20
62
 photo_cameraImage coming soon 4931441064 PROTECTING COVER €3.50
63
 photo_cameraImage coming soon 4931441066 CABLE €27.52
66
 photo_cameraImage coming soon 4931441074 BRUSH COVER €2.38
68
 photo_cameraImage coming soon 4931441075 WRENCH €5.41
70
 photo_cameraImage coming soon 4931441090 GEAR KIT €55.40
71
 Milwaukee AG22-230DMS Interlock Element 4931441091 Milwaukee AG22-230DMS Interlock Element €7.12
72
 photo_cameraImage coming soon 4931441093 SPINDLE €56.91
73
 Milwaukee AG22-230DMS Bevel Gear Pair 4931441097 Milwaukee AG22-230DMS Bevel Gear Pair €41.70
74
 photo_cameraImage coming soon 4931441098 BEARING KIT €16.01
75
 Milwaukee AG22-230DMS Armature 4931441099 Milwaukee AG22-230DMS Armature €72.16
76
 photo_cameraImage coming soon 4931441101 BALL BEARING €12.98
77
 Milwaukee AG22-230DMS Carbon Brush Holder 4931441102 Milwaukee AG22-230DMS Carbon Brush Holder €10.26
78
 photo_cameraImage coming soon 4931441103 HOUSING €12.98
79
 Milwaukee AG22-230DMS Carbon Brush Set 4931441104 Milwaukee AG22-230DMS Carbon Brush Set €21.64
80
 photo_cameraImage coming soon 4931441079 RATING PLATE €2.38
93
 photo_cameraImage coming soon 4931441110 GUARD CAP €25.10
95
 photo_cameraImage coming soon 4931441089 WRENCH €6.93
1000
 photo_cameraImage coming soon 4931441114 BOLT SET €11.47

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Milwaukee AG22-230 DMS Angle Grinder Spare Parts

Fix Your Milwaukee AG22-230 DMS 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Drill Driver and their spare part.
Milwaukee AG 22-230 DMS ANGLE GRINDER

AG 22-230 DMS ANGLE GRINDER Spare Parts
AG22-230 DMS ANGLE GRINDER IN2 4933433630 - AG22230DMS - 4000431841
# Part Num. Description
5 4931441045 NUT
8 4931441046 BEARING
13 4931441047 BEARING
21 4931441048 FLANGE NUT
22 4931441049 FLANGE
30 4931441050 HANDLE
34 4931441052 GEAR BOX
39 4931441053 BEARING
47 4931441054 AIR DEFLECTOR RING
49 4931441055 ELECTRIC FIELD
50 4931441057 HOUSING SET ASSY
52 4931441058 BRUSH COVER Discontinued
59 4931441061 SWITCH
62 4931441064 PROTECTING COVER
63 4931441066 CABLE
65 1000000003 Not available for this version
66 4931441074 BRUSH COVER
68 4931441075 WRENCH
70 4931441090 GEAR KIT
71 4931441091 INTERLOCK ELEMENT
72 4931441093 SPINDLE
73 4931441097 BEVEL GEAR PAIR
74 4931441098 BEARING KIT
75 4931441099 ARMATURE
76 4931441101 BALL BEARING
77 4931441102 BRUSH HOLDER COMPL.
78 4931441103 HOUSING
79 4931441104 CARBON BRUSH SET
80 4931441079 RATING PLATE
93 4931441110 GUARD CAP
94 4931441112 GUARD CAP Discontinued
95 4931441089 WRENCH
700 5131000000 CARRYING CASE Discontinued
1000 4931441114 BOLT SET
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Milwaukee websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Milwaukee brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Milwaukee AG22-230 DMS
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK AEG S/N:
AEG S/N START WITH (4) or (5) AND HAVE 10 DIGITS

Specific References

New

Download

Milwaukee AG22-230 DMS Drawing

Milwaukee AG22-230 DMS Drawing

Download (373.01KB)
