Milwaukee M18FHACO745-122C Spare Parts
Fix Your Milwaukee M18FHACO745-122C SDS-MAX Combination Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill Driver and their spare part.
| M18FHACO745-122C 7KG SDS-MAX COMBINATION HAMMER-IN2 | ||
| 4933493446 - M18FHACO745-122C - 4000509515 | ||
| # | Part Num. | Description |
| 1 | 4931511027 | COVER |
| 2 | 4931435133 | CAP |
| 3 | 4931511028 | SNAP RING |
| 4 | 4931511029 | WASHER |
| 5 | 4931511030 | RING |
| 6 | 4931435137 | WASHER |
| 7 | 4931511031 | SLIDING CHUCK COLLAR |
| 8 | 4931506091 | SLEEVE |
| 9 | 4931511032 | RETAINING PLATE |
| 10 | 4931511033 | LATCH |
| 11 | 4931511034 | RETAINING PLATE |
| 12 | 4931506095 | SPRING |
| 13 | 4931511035 | SPRING |
| 14 | 4931511036 | SNAP RING |
| 15 | 4931511037 | CAP |
| 16 | 4931511038 | SNAP RING |
| 17 | 4931511039 | SEAL |
| 23 | 4931511040 | WASHER |
| 24 | 4931511041 | RING |
| 47 | 4931511042 | CRANK ASSEMBLY |
| 59 | 4931511043 | LOCKING PLATE |
| 60 | 4931511044 | SET COLLAR |
| 61 | 4931511045 | BEVEL GEAR |
| 62 | 4931511046 | PLATE |
| 63 | 4931435150 | SCREW |
| 64 | 4931511047 | GASKET |
| 80 | 4931496229 | SCREW |
| 88 | 4931436408 | NEEDLE BEARING |
| 89 | 4931506112 | WASHER |
| 90 | 4931511048 | GASKET |
| 91 | 4931511049 | SEAL |
| 103 | 4931466678 | SCREW |
| 115 | 4931480330 | SCREW |
| 122 | 4931435162 | SCREW |
| 123 | 4931511050 | WASHER |
| 124 | 4931480707 | O-RING |
| 125 | 4931453797 | SCREW |
| 138 | 4931466659 | SCREW |
| 139 | 4931511051 | CAP |
| 141 | 4931511052 | ELECTRONIC |
| 142 | 4931511053 | BRACKET |
| 151 | 4931511054 | WASHER |
| 160 | 4931511055 | BUSHING |
| 161 | 4931511056 | SPINDLE |
| 162 | 4931511057 | SNAP DIE |
| 163 | 4931511058 | STRIKER |
| 164 | 4931511059 | HANDLE |
| 165 | 4931511060 | GEAR BOX COVER |
| 166 | 4931511061 | CROSS BRACKET |
| 167 | 4931511062 | KNOB |
| 168 | 4931511063 | PISTON |
| 169 | 4931511064 | GEAR CASE |
| 170 | 4931511065 | GEAR CASE |
| 171 | 4931511066 | CLUTCH |
| 172 | 4931511067 | ROTOR |
| 173 | 4931511068 | ELECTRONIC |
| 174 | 4931511069 | HOLDING BRACKET |
| 175 | 4931511070 | BRACKET |
| 176 | 4931511071 | LOCK |
| 177 | 4931511072 | HOUSING |
| 178 | 4931511073 | COVER |
| 179 | 4931509522 | RATING PLATE |
| 700 | 4931511074 | CARRYING CASE |
| 1000 | 4931455865 | GREASE |
| 1200 | 4931511075 | MAINTENANCE SET |
