Michelin Air Compressor MCX6U Parts

SKU: Michelin MCX6U 9109460000
€151.16
VAT included

Michelin Air Compressor MCX6U Spare Parts

Genuine Parts Michelin for piston Air Compressors and spare parts for the repair or replacement for Air Compressor MCX6U 9109460000.
Michelin Air Compressor MCX6U Parts
  • Michelin Air Compressor MCX6U Parts
  • Michelin Pump Unit MCX6U Parts Diagram
  • Michelin Air Compressor MCX6U Parts
FIAC spa

Michelin Air Compressor MCX6U Parts

SKU: Michelin MCX6U 9109460000 Condition: New
€151.16
VAT included

Michelin Air Compressor MCX6U Spare Parts

Genuine Parts Michelin for piston Air Compressors and spare parts for the repair or replacement for Air Compressor MCX6U 9109460000.
settings 42 Spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN: Usually Ships in 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
Machine Type: Air Compressor
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
42 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 9700002201 Pump unit F3001(230V) €139.70
2
 photo_cameraImage coming soon 9700001816 COVER €4.36
3
 photo_cameraImage coming soon 9700002605 FITTING €14.58
4
 photo_cameraImage coming soon 9700001707 Rilsan Hose €7.95
5
 photo_cameraImage coming soon 7310670000 Capacitor MF0,22 €24.78
6
 photo_cameraImage coming soon 9700002259 support €0.11 Not available for order
7A
 photo_cameraImage coming soon 7011460000 Screw M6X16 TAP-TITE €20.94
7
 photo_cameraImage coming soon 9700001693 Screw €0.11 Not available for order
8
 photo_cameraImage coming soon 9700002590 Pressure reducer €0.11 Not available for order
9
 photo_cameraImage coming soon 9700002591 RELIEF VALVE €3.67
10
 photo_cameraImage coming soon 9700002612 FITTING €5.60
11
 photo_cameraImage coming soon 9700001519 Pressure gauge €10.77
12
 photo_cameraImage coming soon 9700000276 universal tap €7.09
13
 photo_cameraImage coming soon 9700002517 Housing €0.11 Not available for order
14
 photo_cameraImage coming soon 9700002614 Screw €0.11 Not available for order
15
 photo_cameraImage coming soon 7300370000 Switch €14.39
16
 photo_cameraImage coming soon 7021010000 Nut M6-7473 UNI €1.52
17
 photo_cameraImage coming soon 9700002497 Tank €0.11 Not available for order
18
 FIAC F205 Drain Tap 1/4" 7130090000 FIAC F205 Drain Tap 1/4" €10.00
19
 Fiac AIRBOX2 Pressure Switch 9700002262 Fiac AIRBOX2 Pressure Switch €28.12
20
 photo_cameraImage coming soon 9700001528 CHECK VALVE €30.05
21
 photo_cameraImage coming soon 9700000633 wishbone Ø10 €1.48
22
 photo_cameraImage coming soon 9700000634 Nut €1.38
23
 photo_cameraImage coming soon 9700002592 Infeed hose €0.11 Not available for order
24
 photo_cameraImage coming soon 9700000631 NUT €1.10
25
 photo_cameraImage coming soon 9700002649 Cable €0.11 Not available for order
26
 Black Rilsan Tube Ø 6X4 for Compressors Fiac 7230010000 Black Rilsan Tube Ø 6X4 for Compressors Fiac €2.57
27
 photo_cameraImage coming soon 7013060000 Screw M4X8 UNI-8112 €1.48
28
 photo_cameraImage coming soon 9700010183 washer OD 4 €0.18
29
 photo_cameraImage coming soon 9700002518 Housing black €0.11 Not available for order
30
 photo_cameraImage coming soon 9700002593 Power Cord €0.11 Not available for order
31
 photo_cameraImage coming soon 7012110000 Screw 0 4,2X16 UNI-6954 €0.00 Not available for order
32
 photo_cameraImage coming soon 9700002524 Rubber Feet €0.11 Not available for order
33
 photo_cameraImage coming soon 9701192003 WASHER D5 €0.00 Not available for order
34
 photo_cameraImage coming soon 9700002607 Screw €0.11 Not available for order
35
 photo_cameraImage coming soon 9700002623 Knob €3.66
Page 2 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 9101500230 Convoyer F3001 - DISCONTINUED €0.11 Not available for order
2
 Valve Plate Kit for Air Compressors B&D CP 6 - Michelin MCX 6-MCX 20 7422250010 Valve Plate Kit for Air Compressors B&D CP 6 - Michelin MCX 6-MCX 20 €36.17
3
 Cylinder for Air Compressor Black & Decker CP6 7422250020 Cylinder for Air Compressor Black & Decker CP6 €15.97
4
 Belt for Air Compressor Yamato Oil-Less 6-1,5 7422250030 Belt for Air Compressor Yamato Oil-Less 6-1,5 €24.80
5
 photo_cameraImage coming soon 7013070000 Screw M5X20 UNI-5931 €0.00 Not available for order
6
 Conrod + Piston Kit for Air Compressor Black & Decker CP6 7422250040 Conrod + Piston Kit for Air Compressor Black & Decker CP6 €44.33

Shipping and delivery information will be available shortly.

Michelin Air Compressor MCX6U Spare Parts

Genuine Parts Michelin for piston Air Compressors and spare parts for the repair or replacement for Air Compressor MCX6U 9109460000.

In the following table, look for the type of the air compressor and the respective parts of the code .
Air Compressor MCX6U

MICHELIN Air Compressor MCX6U - 9109460000 Parts Pag.1
# Part Num. Description
1 9700002201 Pump unit F3001(230V)
2 9700001816 Conveyor
3 9700002605 Joint
4 9700001707 Rilsan tube
5 7310670000 Pressure Switch cable Cavo Pressostato
6 9700002259 support
7 9700001693 Screw
7A 7011460000 Screw
8 9700002590 Pressure reducer
9 9700002591 Safety valve
10 9700002612 L joint
11 9700001519 Pressure gauge
12 9700000276 Quick coupler
13 9700002517 Housing
14 9700002614 Screw
15 7300370000 Main switch
16 7021010000 Locking nut
17 9700002497 Tank
18 7130090000 Discharge tap
19 9700002262 Pressure switch
20 9700001528 Non return valve
21 9700000633 Ogive
22 9700000634 Nut
23 9700002592 Infeed hose
24 9700000631 Nut
25 9700002649 Cable
26 7230010000 Rilsan hose
27 7013060000 Screw
28 9700010183 Washer
29 9700002518 Housing black
30 9700002593 Power Cord
31 7012110000 Screw
32 9700002524 Rubber Feet
33 9701192003 Washer
34 9700002607 Screw
35 9700002623 Knob
Pump Unit F3001 Pag.2
1 9101500230 Convoyer F3001 - DISCONTINUED
2 7422250010 Kit plate valve
3 7422250020 Cylinder
4 7422250030 Belt
5 7013070000 Screw M5X20 UNI-5931
6 7422250040 Kit Conrod/piston
