Michelin Spare Parts for Air Compressor MVX 300-678

Name: Michelin Spare Parts for Air Compressor MVX 300-678
Brand: FIAC spa
SKU: Michelin MVX 300-678
Availability: InStock

SKU: Michelin MVX 300-678

€0.11

VAT included

Michelin Spare Parts for Air Compressor MVX 300-678

Genuine spares Michelin for piston Air Compressors, Parts for to fix or replace broken components for Compressor MVX 300-678

Fix Your Piston Air Compressor MVX 300-678. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Michelin Spare Parts for Air Compressor MVX 300-678

New
Out-of-Stock

Michelin Spare Parts for Air Compressor MVX 300-678

SKU: Michelin MVX 300-678 Condition: New

€0.11

VAT included

Michelin Spare Parts for Air Compressor MVX 300-678

Genuine spares Michelin for piston Air Compressors, Parts for to fix or replace broken components for Compressor MVX 300-678

Fix Your Piston Air Compressor MVX 300-678. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

55 Spare parts

2 exploded views

Download Exploded PDF

Quantity

Out-of-Stock

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS

MORE INFO:: [email protected]

Machine Type: Air Compressor

Original Product Manufacturer warranty included

Technical Support Our team helps you choose

Secure and guaranteed payments

55 spare parts

Page 1 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
3	Image coming soon	4080910000 Screw kit	€17.75
3	Image coming soon	7090050000 Plug	€22.17
4	Image coming soon	7234260000 PIPE	€15.20
5	Image coming soon	7190330000 CHECK VALVE	€29.00
6	Image coming soon	7085020000 Fitting 1/2 "-3 / 8" MF	€7.05
7		7130460000 TAP	€15.30
9		7192090000 FIAC Safety Valve M3/8 10,4Bar	€6.65
10	Image coming soon	4056520000 PRESSURE SWITCH KIT	€111.29
10.1		7082690000 A fitting "T" 8.3 MFM	€10.05
10.2	Image coming soon	7090070000 Cap M1/4"	€4.52
10.3	Image coming soon	7250880000 PRESSURE SWITCH	€81.22
10.4	Image coming soon	7328690000 Cable Pressure Switch / Motor	€20.11
10.5	Image coming soon	7328700000 power cable	€33.25
11	Image coming soon	7085110000 Fitting 1 "-1/2" MF	€6.04
12		7110060000 FIAC Manometer for Air Compressor AB300	€17.87
13a	Image coming soon	7380850000 Three-phase motor	€807.26
13b	Image coming soon	7408040000 Pulley Øp140-DE144 1-3V F28 2901320501	€46.00
14	Image coming soon	1123020111 Pump Unit AB 858	€909.00
16		7070110000 O-Ring for Pumping Unit Fiac AB 335-410-858-998	€0.98
16	Image coming soon	7130150000 MF ball valve 1/2 "	€23.60
17		7230010000 Black Rilsan Tube Ø 6X4 for Compressors Fiac	€2.57
19	Image coming soon	7458990000 Belt guard Support	€23.64
20		7370230000 Belt for Air Compressors FIAC AB 300-480-550	€18.14
21	Image coming soon	7231110000 FEEDING TUBE	€38.67

Page 2 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1.1		4080090000 Piston Ring Set 105 mm for Pump Units FIAC AB 671-851	€32.85
1		4080870000 Conrod - Piston Kit LP for Pump Units FIAC AB 678-858	€64.77
1.3		7050150000 Piston Pin 18x94 for Pump Units FIAC AB 678-858	€5.03
1.7		7062170000 Connecting Rod Bearing for Air Pump Units Fiac AB 671 - AB 851	€14.13
1.5		7062170000 Connecting Rod Bearing for Air Pump Units Fiac AB 671 - AB 851	€14.13
1.2		7220140000 Piston LP for Pump Units FIAC AB 678-858	€61.19
2.1		4080080000 Piston Rings for Pumping Units FIAC AB 671-AB 851	€29.00
2		4080880000 Fiac AB678 Conrod Piston Kit HP	€79.26
2.4		7050130000 Piston Pin 18x42 for Pump Unit FIAC AB 550	€4.06
2.7		7062170000 Connecting Rod Bearing for Air Pump Units Fiac AB 671 - AB 851	€14.13
2.3		7062170000 Connecting Rod Bearing for Air Pump Units Fiac AB 671 - AB 851	€14.13
2.2		7220120000 FIAC AB858 HP Piston	€80.84
4	Image coming soon	4081900000 Gasket kit	€47.70
5		4231240000 Valves Plate Kit for Pumping Units FIAC AB 671-851-901	€110.20
6		5030620008 Fiac AB678 Head	€47.45
7		5041150008 Crank Shaft for Pump Unit FIAC AB 851	€208.18
8		5060720008 FIAC AB678 Cylinder	€229.24
9		5070270008 FIAC AB678 Crankcase	€199.89
10		5082050008 FIAC AB678 Crankshaft Holder	€28.04
11		5082090008 FIAC AB678 Holder Oil Cap	€14.92
12		5130010008 Fiac Pumping Unit AB 678 Aftercooler	€43.24
13		7051520000 Flywheel Woodruf Metric Key for Pumping Unit FIAC AB 598-678-858-998	€5.77
14	Image coming soon	7060150000 bearing 6206	€41.13
15		7060160000 Crank Shaft Ball Bearing for Pumping Units FIAC AB 671-678	€10.05
17		7090090000 Brass Cap M1/4" for Pump Units Fiac	€3.00
18		7153050000 Air Baffle for Pump Unit FIAC AB851	€9.90
19		7153050000 Air Baffle for Pump Unit FIAC AB851	€9.90
20		9700000408 FIAC Pump Unit AB268 Oil Sight Glass	€3.00
21		7192350000 Safety Valve M1/4-6 bar for Pumping Units Fiac	€5.78
22		7201050000 Flywheel for Pumping unit Fiac AB 450-550-800	€106.34
23	Image coming soon	7230040000 Rilsan hose	€5.99
24		7232700000 Intercooler	€57.02
25	Image coming soon	7458910000 band	€4.52
26.2		9103760330 Air Filter Element for Air Compressor Fiac AB678	€4.33
26		9700002979 Air Filter Kit for Air Compressor Fiac AB678	€16.70

Shipping and delivery information will be available shortly.

Michelin Spare Parts for Air Compressor MVX 300-678

Genuine spares Michelin for piston Air Compressors, Parts for to fix or replace broken components for Compressor MVX 300-678

Fix Your Piston Air Compressor MVX 300-678. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the type of the Air Compressor and the respective parts of the code .

Michelin MVX 300-678
Air Compressor Pag.1
#	Part Num.	Description
1	5011390008	BASE PLATE
2	5154580008	TANK
3	7090050000	PLUG
4	7234260000	PIPE
5	7190330000	CHECK VALVE
6	7085020000	FITTING
7	7130460000	BALL COCK
8	7090020000	PLUG
9	7192090000	RELIEF VALVE
10	4056520000	PRESS. SWITCH KIT
10.1	7082690000	FITTING
10.2	7090070000	PLUG
10.3	7250880000	PRESSURE SWITCH
10.4	7328690000	CABLE
10.5	7328700000	POWER CABLE
11	7085110000	FITTING
12	7110060000	PRESSURE GAUGE
13a	7380850000	MOTOR 5.5HP V230/400/50-60/3
13b	7408040000	PULLEY
14	1123020111	PUMP UNIT
16	7130150000	DISCHARGE TAP
17	7230010000	RILSAN TUBE
18	4170340000	BELT GUARD KIT
19	7458990000	BELT GUARD SUPPORT
20	7370230000	BELT
21	7231110000	INFEED HOSE
Pump Group Pag.2
#	Part Num.	Description
1	4080870000	CON ROD-PISTON KIT
1.1	4080090000	PISTON RING KIT
1.2	7220140000	PISTON
1.3	7050150000	GUDGEON PIN
1.4	X	SEEGER RING
1.5	7062170000	CONNECTING ROD
1.6	X	NUT
1.7	7062170000	BEARING
2	4080880000	CON ROD-PISTON KIT
2.1	4080080000	PISTON RING KIT
2.2	7220120000	PISTON
2.3	7062170000	CONNECTING ROD
2.4	7050130000	GUDGEON PIN
2.5	X	SEEGER RING
2.6	X	NUT
2.7	7062170000	BEARING
3	4080910000	SCREWS KIT
3.1	X	SCREW
3.2	X	SCREW
3.3	X	SCREW
3.4	X	SCREW
3.5	X	SCREW
3.6	X	SCREW
3.7	X	SCREW
3.8	X	WASHER
3.9	X	WASHER
4	4081900000	GASKETS KIT
4.1	X	O RING
4.2	X	OIL SEAL
4.3	X	GASKET
4.4	X	GASKET
4.5	X	GASKET
4.6	X	GASKET
5	4231240000	VALVE PLATE KIT
5.1	X	VALVE PLATE
5.2	X	GASKET
6	5030620008	HEAD
7	5041150008	CRANKSHAFT
8	5060720008	CYLINDER
9	5070270008	CRANKCASE
10	5082050008	SUPPORT
11	5082090008	SUPPORT
12	5130010008	COOLER
13	7051520000	FEATHER
14	7060150000	BEARING
15	7060160000	BEARING
16	7070110000	GASKET
17	7090090000	PLUG
18	7153050000	PLUG
19	7153050000	CONVEYOR
20	9700000408	OIL LIGHT
21	7192350000	RELIEF VALVE
22	7201050000	FLYWHEEL
23	7230040000	PIPE
24	7232700000	COOLER
25	7458910000	BRACKET
26	9700002979	FILTER
26.1	X	BASE PLATE
26.2	9103760330	FILTER CARTRIDGE
26.3	X	FILTER COVER
26.4	X	SCREW

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Reference Michelin MVX 300-678

Data sheet

Machine Type: Air Compressor
SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]

Specific References

Condition New

Download

Michelin MVX 300-678 Drawing

Download (1.08MB)
