Metabo Spare Parts for Jig Saw STE 65 SP

SKU: Metabo STE 65 SP - 00362000
€1.92
VAT included

Metabo Spare Parts for Jig Saw STE 65 SP

METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 65 SP - 00362000.

Jig Saw STE 65 SP - 00362000
Metabo Spare Parts for Jig Saw STE 65 SP
  • Metabo Spare Parts for Jig Saw STE 65 SP
  • Metabo Spare Parts for Jig Saw STE 65 SP

Metabo Spare Parts for Jig Saw STE 65 SP

SKU: Metabo STE 65 SP - 00362000 Condition: New
€1.92
VAT included

Metabo Spare Parts for Jig Saw STE 65 SP

METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 65 SP - 00362000.

Jig Saw STE 65 SP - 00362000
settings 59 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:: METABO S/N START WITH ( 0 ) and have 8 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

53 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 34220057 Protective strap €3.10
2
Self Tapping Fill h Screw 4x18 for Power Tools Metabo 14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo €1.92
3
photo_cameraImage coming soon 31603045 Housing cpl. €35.49
6
photo_cameraImage coming soon 34340831 Electronic switch €31.87
7
photo_cameraImage coming soon 34151386 Cylindrical pin €1.65
9
photo_cameraImage coming soon 33912050 Sliding sheet €1.46
10
photo_cameraImage coming soon 34407004 Felt €1.46
11
photo_cameraImage coming soon 34202168 Pressure spring €1.65
12
photo_cameraImage coming soon 33912932 Guide plate €1.46
13
photo_cameraImage coming soon 34100261 Needle bearing €12.76
14
photo_cameraImage coming soon 33912549 Washer €1.65
15
photo_cameraImage coming soon 31603008 Spur gear cpl. €41.99
16
photo_cameraImage coming soon 14311143 Needle sleeve €5.07
17
photo_cameraImage coming soon 33912929 Balancing plate €8.92
18
photo_cameraImage coming soon 33912936 Pressure spring €9.86
19
photo_cameraImage coming soon 31603009 Bearing support cpl. €17.90
20
photo_cameraImage coming soon 34409758 Rubber plug €1.46
21
photo_cameraImage coming soon 34338006 Cover brush €1.52
22
photo_cameraImage coming soon 14311340 Ball bearing, 8x22x7 €11.17
23
photo_cameraImage coming soon 31000791 Armature cpl. 230 V €73.75
24
photo_cameraImage coming soon 14311566 Ball bearing, 6x19x6 €2.48
25
photo_cameraImage coming soon 34409255 Rubber stopper €1.45
28
Carbon Brushes for Jigsaw Metabo STE 65 SP 31603396 Carbon Brushes for Jigsaw Metabo STE 65 SP €17.98
29
photo_cameraImage coming soon 31603256 Oscillating guide €5.86
30
photo_cameraImage coming soon 34107031 Cover plate €2.40
31
photo_cameraImage coming soon 14319470 O-Ring €1.46
32
photo_cameraImage coming soon 33901052 Sealing washer €1.46
33
Metabo STE 65 SP Connecting Link 33912945 Metabo STE 65 SP Connecting Link €3.06
34
photo_cameraImage coming soon 14112055 Countersunk screw €1.46
36
photo_cameraImage coming soon 14116364 Cylindrical pin €1.65
37
photo_cameraImage coming soon 14116077 Spiral tightening pin €1.65
38
photo_cameraImage coming soon 34220052 Drift key €6.98
39
photo_cameraImage coming soon 14116081 Tightening pin €1.79
40
photo_cameraImage coming soon 34107026 Clamping piece €8.65
41
Blade Clamping Lever for Jigsaw Metabo STE 65 SP 34107028 Blade Clamping Lever for Jigsaw Metabo STE 65 SP €12.05
42
Clamping Lever Tension Spring for Jigsaw Metabo STE 65 SP 34202154 Clamping Lever Tension Spring for Jigsaw Metabo STE 65 SP €2.86
43
photo_cameraImage coming soon 31603257 Ram with guide €37.71
44
photo_cameraImage coming soon 14118181 Circlip €1.52
45
photo_cameraImage coming soon 34339548 Anti-splintering insert €1.52
46
photo_cameraImage coming soon 31602962 Base plate cpl. €13.50
47
photo_cameraImage coming soon 33912931 position plate €1.52
48
photo_cameraImage coming soon 14113137 Square nut €1.47
49
photo_cameraImage coming soon 34409142 Rubber plug €1.53
50
photo_cameraImage coming soon 34410114 Cable sleeve €2.55
51
Power Cord for Angle Grinder Metabo W 7-115 34448588 Power Cord for Angle Grinder Metabo W 7-115 €19.80
52
photo_cameraImage coming soon 34416153 Hexagonal key €1.79
53
photo_cameraImage coming soon 14112230 Cap screw €1.55
54
photo_cameraImage coming soon 33900562 Champing claw €2.22
55
photo_cameraImage coming soon 34105586 Shift axle €5.86
56
photo_cameraImage coming soon 31603014 Shift lever €5.28
57
photo_cameraImage coming soon 33812216 M-Label,08 52x22 €1.74
58
Metabo SBE 705 Nois Suppressor 34325378 Metabo SBE 705 Nois Suppressor €4.93
880
photo_cameraImage coming soon 34413093 Grease 50Gr 1,8oz €34.48

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Jig Saw STE 65 SP

METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 65 SP - 00362000.

In the following table, look for the model of the Jig Saw and the respective parts of the code.
Jig Saw STE 65 SP - 00362000

Jig Saw STE 65 SP/00362000
# Part Num. Description
1 34220057 Protective strap
2 14111602 Self-tap fill h screw
3 31603045 Housing cpl.
4 33804764 Rating plate
5 34337501 Dummy plug
6 34340831 Electronic switch
7 34151386 Cylindrical pin
8 31602988 Supporting lever
9 33912050 Sliding sheet
10 34407004 Felt
11 34202168 Pressure spring
12 33912932 Guide plate
13 34100261 Needle bearing
14 33912549 Washer
15 31603008 Spur gear cpl.
16 14311143 Needle sleeve
17 33912929 Balancing plate
18 33912936 Pressure spring
19 31603009 Bearing support cpl.
20 34409758 Rubber plug
21 34338006 Cover brush
22 14311340 Ball bearing, 8x22x7
23 31000791 Armature cpl. 230 V
24 14311566 Ball bearing, 6x19x6
25 34409255 Rubber stopper
26 31100994 Field coil 230V / 120 V
27 31604052 Brush holder module
28 31603396 Carbon brush cpl.
29 31603256 Oscillating guide
30 34107031 Cover plate
31 14319470 O-ring
32 33901052 Sealing washer
33 33912945 Connecting link
34 14112055 Countersunk screw
35 34105613 Ram
36 14116364 Cylindrical pin
37 14116077 Spiral tightening pin
38 34220052 Drift key
39 14116081 Tightening pin
40 34107026 Clamping piece
41 34107028 Clamping lever
42 34202154 Tension spring
43 31603257 Ram with guide
44 14118181 Circlip
45 34339548 Anti-splintering insert
46 31602962 Base plate cpl.
47 33912931 position plate
48 14113137 Square nut
49 34409142 Rubber plug
50 34410114 Cable sleeve
51 34448588 Cable with plug
52 34416153 Hexagonal key
53 14112230 Cap screw
54 33900562 Champing claw
55 34105586 Shift axle
56 31603014 Shift lever
57 33812216 M-Label,08 52x22
58 34325378 Interference suppr. cond.
880 34413093 Grease 50Gr 1,8oz
