Metabo Spare Parts for Combination Hammer KHE 2650

We have the original Spares METABO for Combination Hammer KHE 2650 - 00658000, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again

Metabo KHE 2650 - 00658000
Metabo Spare Parts for Combination Hammer KHE 2650
  • Metabo Spare Parts for Combination Hammer KHE 2650
  • Metabo Spare Parts for Combination Hammer KHE 2650 - Drawing
Metabo

Metabo Spare Parts for Combination Hammer KHE 2650

SKU: Metabo KHE 2650 - 00658000 Condition: New
€1.92
VAT included

Metabo Spare Parts for Combination Hammer KHE 2650

We have the original Spares METABO for Combination Hammer KHE 2650 - 00658000, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again

Metabo KHE 2650 - 00658000
settings 66 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
AVAILABLE

verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
66 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 31605100 Adaptor SDS -PLUS €73.14
2
 photo_cameraImage coming soon 14319516 Shaft sealing ring €10.05
3
 photo_cameraImage coming soon 14311509 Needle sleeve,30x37x16 €8.20
4
 photo_cameraImage coming soon 33900715 Washer €1.98
5
 photo_cameraImage coming soon 34200349 Pressure spring,34,7x38,3x1,8x27,7 €1.81
6
 photo_cameraImage coming soon 34339782 Retaining ring €1.81
7
 photo_cameraImage coming soon 31604784 Gear housing compl. €89.46
8
 photo_cameraImage coming soon 34000403 Sliding block €10.05
9
 photo_cameraImage coming soon 14115638 Circlip €1.81
10
 photo_cameraImage coming soon 34101306 Support ring €5.17
11
 photo_cameraImage coming soon 34207062 Cup spring €1.81
14
 photo_cameraImage coming soon 34343100 Support ring €1.81
15
 photo_cameraImage coming soon 14115636 Circlip €1.81
17
 photo_cameraImage coming soon 14319520 Shaft sealing ring €2.65
18
 photo_cameraImage coming soon 34100581 Bushing €11.12
19
 photo_cameraImage coming soon 34105903 Piston €9.70
20
 photo_cameraImage coming soon 34101298 Support ring €3.11
21
 photo_cameraImage coming soon 14319515 O-ring €1.98
22
 photo_cameraImage coming soon 33900719 Washer €1.81
23
 photo_cameraImage coming soon 14319521 O-ring €1.81
24
 photo_cameraImage coming soon 34105895 Catching sleeve €4.33
25
 photo_cameraImage coming soon 14118184 Circlip €1.81
26
 photo_cameraImage coming soon 34409314 Sealing ring €5.17
27
 photo_cameraImage coming soon 31604335 Striker compl. €26.19
28
 photo_cameraImage coming soon 34105868 exciter sleeve compl. €26.19
29
 photo_cameraImage coming soon 32005048 Ball holder €3.49
30
 photo_cameraImage coming soon 34409864 Seal €3.02
31
 photo_cameraImage coming soon 31604786 Gear flange cpl. €52.11
32
 photo_cameraImage coming soon 34407067 Felt seal €1.81
33
 photo_cameraImage coming soon 34409592 Rubber buffer €1.81
34
 photo_cameraImage coming soon 14112340 Filister head screw €1.81
35
 photo_cameraImage coming soon 14112361 Self-tap. fill. h. screw €1.81
36
 photo_cameraImage coming soon 31604447 Control knob compl. €6.69
37
 Control Knob Hole Cover for Rotary Hammer Metabo KHE 22 SP 34337675 Control Knob Hole Cover for Rotary Hammer Metabo KHE 22 SP €1.93
38
 photo_cameraImage coming soon 33912961 Washer €1.81
39
 Axial Needle Bearing for Rotary Hammer Metabo UHE 28 Plus 14311428 Axial Needle Bearing for Rotary Hammer Metabo UHE 28 Plus €6.71
40
 photo_cameraImage coming soon 14115255 Cup spring €1.98
41
 Pinion Shaft Cpl. for Rotary Hammer Metabo KHE 2650 31604788 Pinion Shaft Cpl. for Rotary Hammer Metabo KHE 2650 €111.77
42
 photo_cameraImage coming soon 33913435 guide sheet €1.81
43
 photo_cameraImage coming soon 31604446 Shift element compl. €19.64
45
 photo_cameraImage coming soon 31605227 Side support handle compl. €32.59
46
 photo_cameraImage coming soon 34337604 Sealing ring €1.98
47
 photo_cameraImage coming soon 33000182 Fan €2.07
48
 photo_cameraImage coming soon 31000926 Armature compl.,230 V €68.89
49
 O-Ring mm 1,98x15,08x19,06 for Percussion Drill Metabo SB 710 14319243 O-Ring mm 1,98x15,08x19,06 for Percussion Drill Metabo SB 710 €1.88
51
 photo_cameraImage coming soon 34308228 Electronic unit,230V 50/60Hz €46.36
52
 photo_cameraImage coming soon 14111699 Self-tap. fill. h. screw €1.98
53
 Self Tapping Fill h Screw 4x18 for Power Tools Metabo 14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo €1.92
54
 photo_cameraImage coming soon 34339853 Pistol grip 2-part, gummed €116.20
55
 photo_cameraImage coming soon 14311488 Ball bearing, 8x22x7 €7.22
56
 Ball Bearing 6x19x6 mm for Angle Grinders Metabo W 7-8-9-115 14311517 Ball Bearing 6x19x6 mm for Angle Grinders Metabo W 7-8-9-115 €7.95
57
 photo_cameraImage coming soon 34339977 Intermediate flange €2.65
58
 photo_cameraImage coming soon 34152023 Cylindrical pin €1.81
59
 photo_cameraImage coming soon 14111826 Self-tap. fill. h. screw €1.81
60
 230/240V Stator for Rotary Hammer Metabo UHE 28 Plus 31100981 230/240V Stator for Rotary Hammer Metabo UHE 28 Plus €27.59
61
 Motor Housing for Percussion Drill Metabo SB 710 31501325 Motor Housing for Percussion Drill Metabo SB 710 €15.50
63
 Carbon Brushe Set for Hammers Metabo KHE 2650-2851-UHE 2850 31604697 Carbon Brushe Set for Hammers Metabo KHE 2650-2851-UHE 2850 €19.80
64
 Carbon Brushes Holder for Percussion Drills Metabo BE 1100-1300 31605196 Carbon Brushes Holder for Percussion Drills Metabo BE 1100-1300 €24.79
65
 Switch for Percussion Drills Metabo BE 1100-1300 34340925 Switch for Percussion Drills Metabo BE 1100-1300 €24.79
66
 photo_cameraImage coming soon 14111706 Self-tap. fill. h. screw €1.98
67
 photo_cameraImage coming soon 34336249 Cable clip €2.02
68
 photo_cameraImage coming soon 34339430 Cable sleeve €2.52
69
 Cord CEE Plug for Rotary Hammer Metabo UHE 2250 Multi 34448673 Cord CEE Plug for Rotary Hammer Metabo UHE 2250 Multi €22.87
70
 photo_cameraImage coming soon 31604789 Maintenance kit €98.72
880
 Grease Tube GF 126 for All Metabo Power Tools 34413080 Grease Tube GF 126 for All Metabo Power Tools €22.39
890
 photo_cameraImage coming soon 34413121 Tube Grease,50g Klueber Microlube GL 261 €45.54

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Metabo Spare Parts for Combination Hammer KHE 2650

Fix Your Combination Hammer KHE 2650 - 00658000. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.

In the following table, look for the model of the Drill and the respective parts of the code.
Metabo KHE 2650 - 00658000

Combination Hammer KHE 2650/00658000à
# Part Num. Description
1 31605100 Adaptor SDS -PLUS
2 14319516 Shaft sealing ring
3 14311509 Needle sleeve,30x37x16
4 33900715 Washer
5 34200349 Pressure spring,34,7x38,3x1,8x27,7
6 34339782 Retaining ring
7 31604784 Gear housing compl.
8 34000403 Sliding block
9 14115638 Circlip
10 34101306 Support ring
11 34207062 Cup spring
12 31606406 Ratched wheel set
14 34343100 Support ring
15 14115636 Circlip
16 31604785 Drill driving sleeve cpl.
17 14319520 Shaft sealing ring
18 34100581 Bushing
19 34105903 Piston
20 34101298 Support ring
21 14319515 O-ring
22 33900719 Washer
23 14319521 O-ring
24 34105895 Catching sleeve
25 14118184 Circlip
26 34409314 Sealing ring
27 31604335 Striker compl.
28 34105868 exciter sleeve compl.
29 32005048 Ball holder
30 34409864 Seal
31 31604786 Gear flange cpl.
32 34407067 Felt seal
33 34409592 Rubber buffer
34 14112340 Filister head screw
35 14112361 Self-tap. fill. h. screw
36 31604447 Control knob compl.
37 34337675 Seal
38 33912961 Washer
39 14311428 Axial needle bearing
40 14115255 Cup spring
41 31604788 Pinion shaft compl.
42 33913435 guide sheet
43 31604446 Shift element compl.
45 31605227 Side support handle compl.
46 34337604 Sealing ring
47 33000182 Fan
48 31000926 Armature compl.,230 V
49 14319243 O-ring
50 33805494 Rating plate
51 34308228 Electronic unit,230V 50/60Hz
52 14111699 Self-tap. fill. h. screw
53 14111602 Self-tap fill h screw
54 34339853 Pistol grip 2-part, gummed
55 14311488 Ball bearing, 8x22x7
56 14311517 Ball bearing,6x19x6
57 34339977 Intermediate flange
58 34152023 Cylindrical pin
59 14111826 Self-tap. fill. h. screw
60 31100981 Field coil 230V
61 31501325 Motor housing
63 31604697 Carbon brush set,230 V
64 31605196 Brush holder module,230V
65 34340925 Poti switch
66 14111706 Self-tap. fill. h. screw
67 34336249 Cable clip
68 34339430 Cable sleeve
69 34448673 Cable with plug
70 31604789 Maintenance kit
880 34413080 Grease FG 126
890 34413121 Tube Grease,50g Klueber Microlube GL 261
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo KHE 2650 - 00658000
6 Items

Specific References

New

Download

Metabo KHE 2650 Drawing

Metabo KHE 2650 Drawing

Download (311.4KB)
