Metabo Spare Parts for Drill BE 6/BE 10
€1.92
VAT included
Metabo Spare Parts for Drill BE 6/BE 10
Metabo genuine spare parts for replacing or repairing Drill BE 6/00132000 - BE 10/00133000.
Metabo Spare Parts for Drill BE 6/BE 10
€1.92
VAT included
Metabo Spare Parts for Drill BE 6/BE 10
Metabo genuine spare parts for replacing or repairing Drill BE 6/00132000 - BE 10/00133000.
settings
23 Spare parts
description
1 exploded view
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
23 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in 10 BUSYNESS DAYS
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1
|
|
34170194 Cheese-head screw | €1.71 | |
|
2
|
|
34160419 Spindle | €5.00 | |
|
3
|
|
34409222 Rubber plug | €1.60 | |
|
4
|
|
14311564 Ball bearing, 12x28x8 | €2.00 | |
|
5
|
|
34003314 Spur gear | €6.18 | |
|
5
|
|
34003315 Spur gear | €8.16 | |
|
6
|
|
14311146 Needle sleeve | €3.80 | |
|
7
|
|
34170194 Cheese-head screw | €1.71 | |
|
9
|
|
14311340 Ball bearing, 8x22x7 | €11.17 | |
|
10
|
|
31001003 Armature compl. | €36.88 | |
|
10
|
|
31001004 Armature compl. | €40.84 | |
|
12
|
|
14311566 Ball bearing, 6x19x6 | €2.48 | |
|
13
|
|
14111602 Self Tapping Fill h Screw 4x18 for Power Tools Metabo | €1.92 | |
|
14
|
|
34325467 Choke | €1.57 | |
|
15
|
|
34339952 Housing (2K) | €16.46 | |
|
16
|
|
34410059 Cable sleeve | €2.25 | |
|
17
|
|
34325466 Condenser | €2.10 | |
|
18
|
|
34340953 Switch | €12.38 | |
|
19
|
|
33805533 Rating plate | €0.00 | Not available for order |
|
19
|
|
33805534 Rating plate | €0.00 | Not available for order |
|
20
|
|
31101139 Field coil | €20.41 | |
|
21
|
|
34336249 Cable clip | €1.74 | |
|
22
|
|
31605748 Carbon brush set | €16.46 | |
|
23
|
|
34449842 Cable with plug | €7.34 |
Shipping and delivery information will be available shortly.
Metabo Spare Parts for Drill BE 6/BE 10
Metabo genuine spare parts for replacing or repairing Drill BE 6/00132000 - BE 10/00133000.
In the following table, look for the model of the Drill and the respective parts of the code.
| Drill BE 6/00132000 | ||
| # | Part Num. | Description |
| 1 | 34170194 | Cheese-head screw |
| 2 | 34160419 | Spindle |
| 3 | 34409222 | Rubber plug |
| 4 | 14311564 | Ball bearing, 12x28x8 |
| 5 | 34003315 | Spur gear |
| 6 | 14311146 | Needle sleeve |
| 9 | 14311340 | Ball bearing, 8x22x7 |
| 10 | 31001004 | Armature compl. |
| 12 | 14311566 | Ball bearing, 6x19x6 |
| 13 | 14111602 | Self-tap fill h screw |
| 14 | 34325467 | Choke |
| 15 | 34339952 | Housing (2K) |
| 16 | 34410059 | Cable sleeve |
| 17 | 34325466 | Condenser |
| 18 | 34340953 | Switch |
| 19 | 33805533 | Rating plate |
| 20 | 31101139 | Field coil |
| 21 | 34336249 | Cable clip |
| 22 | 31605748 | Carbon brush set |
| 23 | 34449842 | Cable with plug |
| Drill BE 10/00133000 | ||
| 2 | 34160419 | Spindle |
| 3 | 34409222 | Rubber plug |
| 4 | 14311564 | Ball bearing, 12x28x8 |
| 5 | 34003314 | Spur gear |
| 6 | 14311146 | Needle sleeve |
| 7 | 34170194 | Cheese-head screw |
| 9 | 14311340 | Ball bearing, 8x22x7 |
| 10 | 31001003 | Armature compl. |
| 12 | 14311566 | Ball bearing, 6x19x6 |
| 13 | 14111602 | Self-tap fill h screw |
| 14 | 34325467 | Choke |
| 15 | 34339952 | Housing (2K) |
| 16 | 34410059 | Cable sleeve |
| 17 | 34325466 | Condenser |
| 18 | 34340953 | Switch |
| 19 | 33805534 | Rating plate |
| 20 | 31101139 | Field coil |
| 21 | 34336249 | Cable clip |
| 22 | 31605748 | Carbon brush set |
| 23 | 34449842 | Cable with plug |
